Starting System: Specifications Toyota RAV4 II

Starter 17 illustrations

STARTER SPECIFICATIONS

ApplicationSpecification
Camry, Camry Solara, Corolla, MR2
Minimum Brush Length.394" (10.0 mm)
Brush Spring Load
1.2 kW3.0-4.4 Lbs. (1.4-2.0 kg)
1.4 kW4.0-5.3 Lbs. (1.8-2.4 kg)
Commutator
Minimum Diameter1.14" (29.0 mm)
Minimum Undercut Depth.008" (.2 mm)
Runout.002" (.05 mm)
Armature Core Runout.002" (.05 mm)
Celica & RAV4
Minimum Brush Length.394" (10.0 mm)
Brush Spring Load
1.2 kW3.1-4.4 Lbs. (1.4-2.0 kg)
1.4 kW4.0-5.3 Lbs. (1.8.2.4 kg)
Commutator
Minimum Diameter1.14" (29.0 mm)
Minimum Undercut Depth.008" (.2 mm)
Runout.002" (.05 mm)
Armature Core Runout.002" (.05 mm)
ECHO
Minimum Brush Length.354" (9.0 mm)
Brush Spring Load
0.8 kW3.1-4.0 Lbs. (1.4-1.8 kg)
Commutator
Minimum Diameter1.06" (27.0 mm)
Minimum Undercut Depth.008" (.2 mm)
Runout.002" (.05 mm)
Armature Core Runout.002" (.05 mm)
Highlander
Minimum Brush Length.335" (8.5 mm)
Brush Spring Load(1)
Commutator
Minimum Diameter1.14" (29 mm)
Minimum Undercut Depth.008" (.2 mm)
Runout.002" (.5 mm)
Armature Core Runout.002" (.5 mm)
Tacoma & 4Runner
Minimum Brush Length
1.4 kW.394" (10.0 mm)
2.0 kW.354" (9.0 mm)
Brush Spring Load
1.4 kW4.0-5.3 Lbs. (1.8-2.4 kg)
2.0 kW5.0-6.2 Lbs. (2.2-2.8 kg)
Commutator
Minimum Diameter
1.4 kW1.14" (29.0 mm)
2.0 kW1.34" (34 mm)
Minimum Undercut Depth.008" (.2 mm)
Runout.002" (.05 mm)
Armature Core Runout.002" (.05 mm)
(1) Information not available from manufacturer.
(1)Information not available from manufacturer.

STARTER SPECIFICATIONS (4-CYLINDER)

ApplicationSpecification
Avalon, Camry, Camry Solara & Sienna
Minimum Brush Length.394" (10.0 mm)
Brush Spring Load4.0-5.3 Lbs. (1.8-2.4 kg)
Commutator
Minimum Diameter1.14" (29.0 mm)
Minimum Undercut Depth.008" (.2 mm)
Runout.002" (.05 mm)
Armature Core Runout.002" (.05 mm)
Highlander
Minimum Brush Length.335" (8.5 mm)
Brush Spring Load(1)
Commutator
Minimum Diameter1.14" (29.0 mm)
Minimum Undercut Depth.008" (.2 mm)
Runout.002" (.5 mm)
Armature Core Runout.002" (.5 mm)
Tacoma, Tundra & 4Runner
Minimum Brush Length
1.2 & 1.4 kW.394" (10.0 mm)
1.8 kW.354" (9.0 mm)
Brush Spring Load
1.2 kW3.1-4.4 Lbs. (1.4-2.0 kg)
1.4 kW4.0-5.3 Lbs. (1.8-2.4 kg)
1.8 kW5.0-6.2 Lbs. (2.2-2.8 kg)
Commutator
Minimum Diameter
1.2 & 1.4 kW1.14" (29.0 mm)
1.8 kW1.34" (34 mm)
Minimum Undercut Depth.008" (.2 mm)
Runout.002" (.05 mm)
Armature Core Runout.002" (.05 mm)
(1) Information not available from manufacturer.
(1)Information not available from manufacturer.

STARTER SPECIFICATIONS (V6)

ApplicationSpecification
Land Cruiser & LX 470
Minimum Brush Length.354" (9.0 mm)
Brush Spring Load4.8-6.2 Lbs. (2.2-2.8 kg)
Commutator
Minimum Diameter1.34" (34 mm)
Minimum Undercut Depth.008" (.2 mm)
Runout.002" (.05 mm)
Armature Core Runout.002" (.05 mm)
Sequoia
Minimum Brush Length
1.4 kW.335" (8.5 mm)
2.0 kW.354" (9.0 mm)
Brush Spring Load
1.4 kW4.0-5.3 Lbs. (1.8-2.4 kg)
2.0 kW4.8-6.2 Lbs. (2.2-2.8 kg)
Commutator
Minimum Diameter1.34" (34 mm)
Minimum Undercut Depth.008" (.2 mm)
Runout.002" (.05 mm)
Armature Core Runout.002" (.05 mm)
Tundra
Minimum Brush Length
1.4 kW.394" (10.0 mm)
2.0 kW.354" (9.0 mm)
Brush Spring Load
1.4 kW4.0-5.3 Lbs. (1.8-2.4 kg)
2.0 kW5.0-6.2 Lbs. (2.2-2.8 kg)
Commutator
Minimum Diameter1.34" (34 mm)
1.4 kW1.14" (29.0 mm)
2.0 kW1.34" (34 mm)
Minimum Undercut Depth.008" (.2 mm)
Runout.002" (.05 mm)
Armature Core Runout.002" (.05 mm)

STARTER SPECIFICATIONS (V8)

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Starter Mounting Bolts
Avalon, Corolla, ECHO, Highlander, Land Cruiser, LX 470, RAV4, Sequoia, Tundra & 4Runner29 (39)
Camry, Camry Solara, Sienna & Tacoma27 (37)
Celica28 (38)
MR228 (37)
INCH Lbs. (N.m)
Park Neutral Position Switch
Land Cruiser, LX 470, Tacoma, Tundra & 4Runner116 (13)
All Others48 (5.4)

TORQUE SPECIFICATIONS

Fig. 19: Starting System Wiring Diagram (Avalon)
Scheme 19: Starting System Wiring Diagram (Avalon)
Fig. 20: Starting System Wiring Diagram (Camry - 2.2L & 3.0L)
Scheme 20: Starting System Wiring Diagram (Camry - 2.2L & 3.0L)
Fig. 21: Starting System Wiring Diagram (Camry - 2.2L CNG)
Scheme 21: Starting System Wiring Diagram (Camry - 2.2L CNG)
Fig. 22: Starting System Wiring Diagram (Camry Solara)
Scheme 22: Starting System Wiring Diagram (Camry Solara)
Fig. 23: Starting System Wiring Diagram (Celica)
Scheme 23: Starting System Wiring Diagram (Celica)
Fig. 24: Starting System Wiring Diagram (Corolla)
Scheme 24: Starting System Wiring Diagram (Corolla)
Fig. 25: Starting System Wiring Diagram (ECHO)
Scheme 25: Starting System Wiring Diagram (ECHO)
Fig. 26: Starting System Wiring Diagram (Highlander)
Scheme 26: Starting System Wiring Diagram (Highlander)
Fig. 27: Starting System Wiring Diagram (Land Cruiser)
Scheme 27: Starting System Wiring Diagram (Land Cruiser)
Fig. 28: Starting System Wiring Diagram (Lexus LX470)
Scheme 28: Starting System Wiring Diagram (Lexus LX470)
Fig. 29: Starting System Wiring Diagram (MR2)
Scheme 29: Starting System Wiring Diagram (MR2)
Fig. 30: Starting System Wiring Diagram (RAV4)
Scheme 30: Starting System Wiring Diagram (RAV4)
Fig. 31: Starting System Wiring Diagram (Sequoia)
Scheme 31: Starting System Wiring Diagram (Sequoia)
Fig. 32: Starting System Wiring Diagram (Sienna)
Scheme 32: Starting System Wiring Diagram (Sienna)
Fig. 33: Starting System Wiring Diagram (Tacoma)
Scheme 33: Starting System Wiring Diagram (Tacoma)
Fig. 34: Starting System Wiring Diagram (Tundra)
Scheme 34: Starting System Wiring Diagram (Tundra)
Fig. 35: Starting System Wiring Diagram (4Runner)
Scheme 35: Starting System Wiring Diagram (4Runner)
