Torque Converter Lock-Up Will Not Release
Check shift solenoid valve SL circuit, TP sensor circuit, brakelight circuit, ECM circuit, lock-up relay valve and torque converter clutch.
SHIFT SPEED SPECIFICATIONS
| Application | MPH |
|---|
| "D" Position |
| 1st-2nd (1) | 35-39 |
| 2nd-3rd (1) | 65-70 |
| 3rd-4th (1) | 104-112 |
| 4th-3rd (1) | 99-108 |
| 3rd-2nd (1) | 61-66 |
| 2nd-1st (1) | 29-33 |
| 3rd-4th (2) | 26-30 |
| 4th-3rd (2) | 11-14 |
| "2" Position |
| 1st-2nd (1) | 35-39 |
| 3rd-2nd (1) | 65-70 |
| 2nd-1st (1) | 29-33 |
| "L" Position |
| 3rd-2nd (1) | 70-76 |
| 2nd-1st (1) | 32-36 |
| (1) Wide open throttle. (2) Fully closed throttle. |
| (2) | Fully closed throttle. |
SHIFT SPEED SPECIFICATIONS (HIGHLANDER)
| Application | MPH |
|---|
| "D" Position |
| 1st-2nd (1) | 35-40 |
| 2nd-3rd (1) | 65-71 |
| 3rd-4th (1) | 99-109 |
| 4th-3rd (1) | 94-104 |
| 3rd-2nd (1) | 60-66 |
| 2nd-1st (1) | 28-32 |
| 3rd-4th (2) | 25-28 |
| 4th-3rd (2) | 9-12 |
| "2" Position |
| 1st-2nd (1) | 35-40 |
| 3rd-2nd (1) | 65-71 |
| 2nd-1st (1) | 28-32 |
| "L" Position |
| 3rd-2nd (1) | 65-71 |
| 2nd-1st (1) | 30-35 |
| (1) Wide open throttle. (2) Fully closed throttle. |
| (2) | Fully closed throttle. |
SHIFT SPEED SPECIFICATIONS (RAV4)
LOCK-UP SPEED SPECIFICATIONS
| Application | MPH |
|---|
| "D" Position (1) |
| Lock-Up On In 3rd (2) | 60-65 |
| Lock-Up Off In 3rd (2) | 59-63 |
| Lock-Up On In OD (2) | 39-43 |
| Lock-Up Off In OD (2) | 32-42 |
| (1) There is no lock-up in "L" or "2" position. (2) Throttle valve opening 5 percent. |
| (1) | There is no lock-up in "L" or "2" position. |
| (2) | Throttle valve opening 5 percent. |
LOCK-UP SPEEDS (HIGHLANDER)
| Application | MPH |
|---|
| "D" Position (1) |
| Lock-Up On In 3rd (2) | 99-110 |
| Lock-Up Off In 3rd (2) | 94-104 |
| Lock-Up On In OD (2) | 34-39 |
| Lock-Up Off In OD (2) | 32-37 |
| (1) There is no lock-up in "L" or "2" position. (2) Throttle valve opening 5 percent. |
| (1) | There is no lock-up in "L" or "2" position. |
| (2) | Throttle valve opening 5 percent. |
LOCK-UP SPEEDS (RAV4) (1)
LINE PRESSURE SPECIFICATIONS
| Engine RPM | "D" Range - psi (kg/cm 2 ) | "R" Range - psi (kg/cm 2 ) |
|---|
| Idle Speed | 54-60 (3.8-4.2) | 135-149 (9.5-10.5) |
| Stall Speed (Throttle Fully Open) | 135-150 (9.5-10.5) | 256-285 (18.0-20.0) |
LINE PRESSURE SPECIFICATIONS (HIGHLANDER)
| Engine RPM | "D" Range - psi (kg/cm 2 ) | "R" Range - psi (kg/cm 2 ) |
|---|
| Idle Speed | 54-65 (3.8-4.6) | 93-116 (6.5-8.2) |
| Stall Speed (Throttle Fully Open) | 131-160 (9.2-11.2) | 251-294 (17.6-20.7) |
LINE PRESSURE SPECIFICATIONS (RAV4)
ELECTRICAL SPECIFICATIONS
| Application | Ohms |
|---|
| Counter Gear & Input Turbine Speed Sensor | 560-680 |
| Shift Solenoids DSL | 11-13 |
| Shift Solenoid SLT | 5.0-5.6 |
| Shift Solenoid SL1 | 5.0-5.6 |
| Shift Solenoid SL2 | 5.1-5.5 |
| Shift Solenoid S4 | 11-15 |
COMPONENT RESISTANCE SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | INCH Lbs. (N.m) |
|---|
| Manual Lever Nut | 61 (6.9) |
| Park/Neutral Position Switch |
| Nut | 61 (6.9) |
| Bolt | 48 (5.4) |
| Shift Control Cable Nut | 133 (15) |
| Speed Sensor Bolt | 100 (11.3) |
| Temperature Sensor Clamp Bolt | 58 (6.6) |
Scheme 36
Scheme 36: CONNECTOR IDENTIFICATION
Scheme 37
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
Scheme 43
Scheme 44
Scheme 45
Scheme 46
Scheme 47
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
