POWER WINDOW SWITCH CONTINUITY TEST (DRIVER'S SIDE SWITCH)
Using an ohmmeter, check continuity between specified terminals with driver's side power window switch in specified position. See DRIVER'S SIDE POWER WINDOW SWITCH CONTINUITY TEST table. (Scheme 1)or (Scheme 2). If continuity does not exist at specified terminals, replace power window switch.
| Application & Position | (1) Terminals No. | |||
|---|---|---|---|---|
| 3-Door | ||||
| Driver's Side Switch | ||||
| Locked & Unlocked | ||||
| UP | 3 & 9; 4 & 6 | |||
| OFF | 3, 4 & 6 | |||
| DOWN | 3 & 6; 4 & 9 | |||
| Passenger's Side Switch | ||||
| Locked | ||||
| UP | 9 & 10 | |||
| OFF | 7 & 10 | |||
| DOWN | 7 & 9 | |||
| Unlocked | ||||
| UP | 6 & 7; 9 & 10 | |||
| OFF | 6, 7 & 10 | |||
| DOWN | 6 & 10; 7 & 9 | |||
| 5-Door | ||||
| Driver's Side Switch | ||||
| Locked & Unlocked | ||||
| UP | 1 & 13; 6, 7 & 8 | |||
| OFF | 1, 2, 6 & 13 | |||
| DOWN | 1, 2 & 6; 7, 8 & 13 | |||
| Passenger's Side Switch | ||||
| Locked | ||||
| UP | 7, 8 & 12 | |||
| OFF | 5 & 12 | |||
| DOWN | 5, 7 & 8 | |||
| Unlocked | ||||
| UP | 1, 2 & 5; 7, 8 & 12 | |||
| OFF | 1, 2, 5 & 12 | |||
| DOWN | 1, 2 & 12; 5, 7 & 8 | |||
| Left Rear Switch | ||||
| Locked | ||||
| UP | 7, 8 & 10 | |||
| OFF | 9 & 10 | |||
| DOWN | 7, 8 & 9 | |||
| Unlocked | ||||
| UP | 1, 2 & 9; 7, 8 & 10 | |||
| OFF | 1, 2, 9 & 10 | |||
| DOWN | 1, 2 & 10; 7, 8 & 9 | |||
| Right Rear Switch | ||||
| Locked | ||||
| UP | 7, 8 & 11 | |||
| OFF | 11 & 14 | |||
| DOWN | 7, 8 & 14 | |||
| Unlocked | ||||
| UP | 1, 2 & 14; 7, 8 & 11 | |||
| OFF | 1, 2, 11 & 14 | |||
| DOWN | 1, 2 & 11; 7, 8 & 14 | |||
| (1) (Scheme 1)or (Scheme 2). | ||||
| (1) | (Scheme 1)or (Scheme 2). |
DRIVER'S SIDE POWER WINDOW SWITCH CONTINUITY TEST
Scheme 1
Scheme 2
POWER WINDOW SWITCH CONTINUITY TEST (PASSENGER'S SIDE & REAR SWITCHES)
Using an ohmmeter, check continuity between specified terminals with power window switch in specified position. See the POWER WINDOW SWITCH CONTINUITY TEST TABLE (PASSENGER'S SIDE & REAR) table. (Scheme 3) If continuity does not exist at specified terminals, replace appropriate power window switch.
| Application & Position | (1) Terminals No. | |
|---|---|---|
| Front Switch | ||
| UP | 1 & 2; 3 & 4 | |
| OFF | 1 & 2; 3 & 5 | |
| DOWN | 1 & 4; 3 & 5 | |
| Rear Switch | ||
| UP | 1 & 2; 3 & 4 | |
| OFF | 1 & 2; 4 & 5 | |
| DOWN | 2 & 3; 4 & 5 | |
| (1) (Scheme 3) | ||
| (1) | (Scheme 3) |
POWER WINDOW SWITCH CONTINUITY TEST (PASSENGER'S SIDE & REAR)
Scheme 3
POWER WINDOW SYSTEM CURRENT TEST
Note. System circuit breaker opens 4-40 seconds after window operation stops. Ensure circuit test is performed before circuit breaker operates.
