Pre-Collision System (Service Information) (Except Phv): Overview Toyota Prius III

Restraints Control Systems 3 illustrations ~104 words

Scheme 29

Scheme 29: ILLUSTRATION
Scheme 29: ILLUSTRATION

Scheme 30

Scheme 30: REMOVAL
Scheme 30: REMOVAL
  1. REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 21»(/toyota/prius/iii-2009-2011/remont/exteriorinterior-trim/#interior-panels-trim-service-information-except-phv)
  2. REMOVE PRE-COLLISION SYSTEM CANCEL SWITCH ASSEMBLY Disengage the 2 claws and remove the pre-collision system cancel switch assembly.

Scheme 31

Scheme 31: INSPECTION
Scheme 31: INSPECTION
  1. INSPECT PRE-COLLISION BRAKE CANCEL SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *1 Component without harness connected (Pre-collision Brake Cancel Switch Assembly) Standard Resistance Tester Connection Switch Condition Specified Condition 1 - 2 Pressed Below 1 ohms Not pressed 10 kohms or higher
