Advanced Parking Guidance System (Diagnostics - Introduction) (Except Phv): Other Toyota Prius III

PRECAUTION

1. PRECAUTION FOR DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following system after the terminal is reconnected. System Name See Procedure Advanced Parking Guidance System Refer to «INITIALIZATION»(ref-393052-S29548740432011040700000)
2. POINTS TO NOTE WHEN SERVICING Pay attention to the following points when servicing. When disconnecting the cable from the negative (-) battery terminal, "System initializing" may appear on the navigation receiver assembly. In this case, restore the steering angle neutral point. Refer to «INITIALIZATION»(ref-393052-S29548740432011040700000) . Depending on the parts that are replaced or operations that are performed during vehicle inspection or maintenance, calibration of other systems as well as the advanced parking guidance system may be needed. Refer to «CALIBRATION»(ref-393052-S10915828912011040700000) . HINT: Each adjusted value for the calibration of the advanced parking guidance system will be stored in the parking assist ECU. When the lens of the rear television camera assembly is dirty, wash the lens with water and wipe it off with a soft cloth to obtain clear images. For heavy dirt, use neutral detergent to clean the lens.
3. NOTES FOR REAR TELEVISION CAMERA Notes for the rear television camera assembly The advanced parking guidance system may not function properly if subjected to a severe blow by any hard object. Do not scrub the cover part of the camera (resin made). Scrubbing may scratch the cover and affect the image. Prevent organic solvents, waxes, bond removing solvents or glass coating from adhering to the cover. If such material adheres to the cover, clean it off immediately and wash with water. Exposing the camera to a sudden temperature change may affect proper functioning of the camera. A clear image may not appear if the camera is dirty with snow, mud, etc. In that case, wash it with water and wipe off the lens. Use a detergent to remove dirt if necessary. Images are difficult to discern even in normal conditions if: Noise may occur in the image depending on electrical devices used in the cabin. Noise may occur in the image if the outer mirror switch assembly is operated. Noise may occur in the image if accessories that generate radio waves have been installed. The camera screen is frosted over (the image immediately after turning the power switch on (IG) may be blurred or darker than normal). The camera lens is dirty with snow, mud, etc. A strong beam of light, such as a sunbeam or headlight, hits the camera. It is too dark around the camera (at night etc.). The ambient temperature around the camera is either too high or too low. The vehicle is tilted at a steep angle. The ambience of the camera is too bright. (When a strong light, such as a sunbeam reflected off the vehicle body, hits the camera, the image may be blurred. This is called the "SMEAR" phenomenon, peculiar to the CCD camera.)
4. NOTES FOR ULTRASONIC SENSOR Under the following conditions, the detection function may not function properly: A sensor or the front bumper is not installed in the correct position. A sensor is improperly located due to damage to the front bumper. A sensor is covered with foreign matter, such as mud or snow (detection function returns to normal when the sensor is cleaned). A sensor is frozen (detection function returns to normal when the temperature of the sensor rises). A hand is blocking a sensor. HINT: In very cold weather where a malfunction display appears, the sensor may not be able to detect obstacles. If the sensor has malfunction, the advanced parking guidance system DTC will be output. Refer to «DTC CHECK / CLEAR»(ref-393052-S28442832582011040700000) . If the malfunction display appears, visually check the sensor first. If the sensor is free of foreign matter but the malfunction display remains, the sensor may have a malfunction. The detection range may be affected by the following conditions: HINT: Depending on a shape of a parked vehicle or an obstacle such as a wall or post near the parking space, the detection range may change even though the sensors are operating normally. A sensor or the front bumper is not installed in the correct position. A sensor is improperly located due to damage to the front bumper. A sensor is covered with foreign matter, such as mud or snow. The vehicle is in an excessively hot or excessively cold area. Under the following conditions, a detection error may occur: HINT: Depending on a shape of a parked vehicle or an obstacle such as a wall or post near the parking space, the detection range may change even though the sensors are operating normally. A sensor or the front bumper is not installed in the correct position. A sensor is improperly located due to damage to the front bumper. Driving on a bumpy road, an unpaved road or in tall grass. Ultrasonic waves are received from the horn or parking sonar system of another vehicle, a motorcycle engine, or the air brakes of a large vehicle. It is raining heavily or the sensor is splashed with water. The vehicle is tilted at a steep angle. The vehicle is equipped with a fender pole or a wireless antenna mechanism. A sensor is covered with foreign matter, such as mud or snow. The vehicle is moving forward or backward towards high curbs or objects that are perpendicular to the ground. A sensor is sprayed with high pressure water or steam. The sensors cannot detect the following objects: Thin objects, such as wires and ropes. Materials that absorb ultrasonic waves, such as cotton, snow, etc. Objects with sharp edges. Short objects. Objects that are tall and protrude toward the vehicle above the detection range of the sensors. Other notices: The sensors cannot detect objects directly under the bumper. (A sensor may detect low objects and thin poles, and then lose track of them.) Beware that the detection range of the ultrasonic sensor is limited. In certain conditions, some objects may not be detected. As a result, always make sure to check all around the vehicle when driving or parking. The sensors may not be able to detect obstacles that are too close to the sensor. The sensors may not be able to detect obstacles if the sensors have been dropped or subjected to a strong impact.

Scheme 14

Scheme 15

Scheme 16

COMMUNICATION TABLE

Scheme 17

Scheme 18

Scheme 19

1. GENERAL The parking assist ECU uses vehicle condition signals from the spiral with sensor cable sub-assembly, power steering ECU, skid control ECU, power management control ECU, etc. to make calculations and estimates. These results are used to make various guidelines, which are combined together with video from the rear television camera, and output to the navigation receiver assembly. Also, control signals are output to each ECU and the advanced parking guidance system various controls are performed. This system has a rear television camera assembly mounted on the back door to display an image of the area behind the vehicle on the navigation receiver assembly display. The display panel also shows a composite view consisting of the area behind the vehicle and parking guidelines to assist the driver in parking the vehicle by monitoring the area behind the vehicle. This system is equipped with a self-diagnosis system, which is operated on a designated window that appears on the display panel, just as in the navigation system.
2. FUNCTION OF COMPONENTS The parking assist ECU controls the system by using information from the following components. Component Function Rear Television Camera Assembly Mounted on the back door to the transmit an image of the area behind the vehicle to the parking assist ECU. Has a color video camera that uses a Charge Coupled Device (CCD) and a wide-angle lens. Parking Assist ECU Receives vehicle condition signals from various ECUs, makes frame based on calculations, combines the frame with video from the rear television camera, and outputs the video with frame to the navigation receiver assembly. Also, control signals are output to each ECU and the advanced parking guidance system various controls are performed. Navigation Receiver Assembly Receives video signals containing a composite of an image of the area behind the vehicle and the frame signals from the parking assist ECU, and displays them on the display panel. Uses the yaw rate detected by the gyro sensor that is built into the navigation receiver assembly to transmit the movement of the vehicle to the parking assist ECU. Spiral with Sensor Cable Sub-assembly Detects the angle of the steering wheel and sends the resulting signals to the parking assist ECU through CAN communication. ECM Sends the shift position signal to the parking assist ECU through CAN communication. Skid Control ECU Sends stop switch, vehicle speed, driving distance, and other vehicle condition signals to the parking assist ECU. Power Steering ECU Assembly Sends EPS failure, intervention steering, and other related vehicle condition signals to the parking assist ECU. Also, based on advanced parking guidance control signals and steering-related signals, performs steering control. Parking Assist Pre Support Switch Sends the switch operation signal to the parking assist ECU. No. 1 Ultrasonic Sensor Controlled by the parking assist ECU and detects an available parking space. Air Conditioner Amplifier Assembly Sends the outside temperature signal to the parking assist ECU through CAN communication. Rear Height Control Sensor Sub-assembly RH Sends the vehicle height signal to the parking assist ECU.
3. OPERATION EXPLANATION The parking assist ECU receives the camera activation information from the navigation receiver assembly. Then, the parking assist ECU switches the display signal for the navigation receiver assembly from the navigation system to the advanced parking guidance system.
4. PRE SUPPORT FUNCTION Function Description A pre support function is provided to assist the driver with initial positioning of the vehicle when backing-in mode or parallel parking mode operation is used. Pre Support Function Operation Condition For the pre support function, when the advanced parking guidance system is operating normally (no DTCs are stored) and the following conditions are met, pressing the parking assist pre support switch changes the image displayed on the screen and pre support operation starts. Screen Displayed on Navigation Receiver Assembly Shift Position Vehicle Speed Screen Displayed (Display switches in the following sequence when parking assist pre support switch is pressed) Navigation screen or information setting screen Other than P or R 15 km/h (9.3 mph) or less Pre support off (Navigation screen or information setting screen) --> Pre support on (Parallel parking mode) --> Pre support on (Backing-in mode) --> Pre support off (Navigation screen or information setting screen)*1 *1: A tone sounds when the screen transfers. Backing-in Mode Operation Press the parking assist pre support switch before the target parking space to turn on the pre support function (backing-in mode). Drive the vehicle slowly while keeping a distance of approximately 1 m (3.3 ft.) from and perpendicular to the target parking space or vehicles around the target parking space. When the ultrasonic sensor (No. 1 ultrasonic sensor) detects an available parking space, start to turn the steering wheel from the straight ahead position when the tone sounds. HINT: An available parking space may not be detected by the ultrasonic sensor (No. 1 ultrasonic sensor) depending on the distance between the vehicle being parked and the target parking space or vehicles around the target parking space, vehicle orientation and vehicle speed. A target parking space may not be detected by the ultrasonic sensor (No. 1 ultrasonic sensor) depending on the conditions around the target parking space. For details, refer to Precautions for the parking space detection sensor. Refer to «PRECAUTION»(ref-393052-S06744151392011040700000) . When the ultrasonic sensor (No. 1 ultrasonic sensor) cannot detect a target parking space, a tone will not sound. Drive the vehicle while turning the steering wheel and when the vehicle reaches the support start position (the tone will sound twice), stop the vehicle, return the steering wheel to the straight ahead position, and move the shift lever to R. When the advanced parking guidance screen is displayed, the target parking frame will also displayed for the target parking space that is detected by the ultrasonic sensor (No. 1 ultrasonic sensor) during the pre support function operation. Parallel Parking Mode Operation Press the parking assist pre support switch before the target parking space to turn on the pre support function (parallel parking mode). Drive the vehicle slowly while keeping a distance of approximately 1 m (3.3 ft.) from and parallel to the target parking space or vehicles around the target parking space to allow the ultrasonic sensor (No. 1 ultrasonic sensor) to start detection. HINT: For parallel parking mode, a tone will not sound when the ultrasonic sensor (No. 1 ultrasonic sensor) detects the available parking space. An available parking space may not be detected by the ultrasonic sensor (No. 1 ultrasonic sensor) depending on a distance between the vehicle being parked and the target parking space or vehicles around the target parking space, vehicle orientation and vehicle speed. A target parking space may not be detected by the ultrasonic sensor (No. 1 ultrasonic sensor) depending on the conditions around the target parking space. For details, refer to Precautions for the parking space detection sensor. Refer to «PRECAUTION»(ref-393052-S06744151392011040700000) . Drive as is and stop the vehicle when the vehicle reaches the support start position (the tone will sound twice), and move the shift lever to R. HINT: When the ultrasonic sensor (No. 1 ultrasonic sensor) cannot detect a target parking space, the tone will not sound. When the advanced parking guidance screen is displayed, the target parking frame will also be displayed for the target parking space that is detected by the ultrasonic sensor (No. 1 ultrasonic sensor) during the pre support function operation.
5. COMMUNICATION SYSTEM OUTLINE The components of the advanced parking guidance system communicate with each other through the AVC-LAN. The parking assist ECU judges the vehicle angle data transmitted via the AVC-LAN from the navigation receiver assembly (the data is calculated by the navigation receiver assembly by integrating the yaw rate of the gyro sensor built into the navigation receiver assembly). If a short circuit or open circuit occurs in the AVC-LAN, communication is interrupted and this system will stop functioning.
6. DIAGNOSTIC FUNCTION OUTLINE This advanced parking guidance system has a diagnostic function displayed in the navigation receiver assembly. This function enables the calibration (adjustment and verify) of the advanced parking guidance system. Refer to «CALIBRATION»(ref-393052-S10915828912011040700000) . The advanced parking guidance system can check the following items by using the Techstream. Item Proceed to DTC Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-393052-S00889970472011040700000) Data List / Active Test Refer to «DATA LIST / ACTIVE TEST»(ref-393052-S37923776382011040700000)

INITIALIZATION

1. INITIALIZE ADVANCED PARKING GUIDANCE SYSTEM When "System initializing" message is displayed on the navigation receiver assembly, correct the steering angle neutral point using the following method. Fully turn the steering wheel to the right and left on the flat ground. NOTE: Memorizing the steering angle neutral point must be carried out with the hybrid system started. Apply the parking brake, depress the brake pedal, push the P position switch, and ensure that the vehicle is not moving. HINT: "?" button is displayed at the same time as "System initializing" message. If the "?" button is selected, this method is displayed.

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. ADJUST ADVANCED PARKING GUIDANCE SYSTEM This advanced parking guidance system can be set from the diagnostic screen of the navigation receiver assembly. If the following operations are performed, it is necessary to perform adjustments and checks on the diagnostic screen. Part Name Operation Adjustment Item Proceed to Spiral with sensor cable sub-assembly Removal and installation of the spiral with sensor cable sub-assembly Removal and installation of the connector of the spiral with sensor cable sub-assembly Steering angle neutral point Refer to «INITIALIZATION»(ref-393052-S29548740432011040700000) Steering angle setting Refer to «DIAGNOSIS SYSTEM»(ref-393052-S08611273262011040700000) Spiral with sensor cable sub-assembly Replacement Steering angle neutral point Refer to «INITIALIZATION»(ref-393052-S29548740432011040700000) Steering angle setting Refer to «DIAGNOSIS SYSTEM»(ref-393052-S08611273262011040700000) Parking assist ECU Replacement Parking assist ECU initialization Step 2 Suspension, tires, etc. The vehicle height changes because of suspension or tire replacement Height control sensor vehicle height difference (Height set) Step 3 Rear television camera optical axis (Camera position setting) Step 4 Rear television camera assembly Replacement Installation angle of the rear television camera changes because of the removal and installation of the rear television camera, etc. Rear television camera optical axis (Camera position setting) Step 4 Rear height control sensor sub-assembly RH Replacement Installation position of the rear height control sensor sub-assembly RH changes because of the removal and installation of the rear height control sensor sub-assembly RH Height control sensor vehicle height difference (Height set) Step 3 Rear television camera optical axis (Camera position setting) Step 4 Lighting system initialization Refer to «INITIALIZATION»(ref-393059-S11552308032011040700000) Rear bumper cover Replacement Installation position of the rear bumper cover changes because of the removal and installation of the rear bumper cover Rear bumper position (BUMPER) Step 5 HINT: The adjustment values stored while performing advanced parking guidance system calibration are stored in the parking assist ECU.
2. PARKING ASSIST ECU INITIALIZATION HINT: Be sure to check for DTCs before performing this procedure. Refer to «DTC CHECK / CLEAR»(ref-393052-S28442832582011040700000) . Preparation for adjustment Park the vehicle on the flat place with the steering wheel centered. HINT: Before parking the vehicle, be sure to move the vehicle forward and in reverse to check that the tires are facing straight ahead with the steering wheel centered. Adjust the tire pressure to the specification. Measure the distance A between the ground and the edge of a rear wheel arch. Calculate the difference between the distance A and the standard height below. Standard 697 mm (2.29 ft.) HINT: Subtract the standard value from the measured value to get the standard height. When the measured value is 707 mm: 707 - 697 = +10 (standard height is +10 mm). Set a target bar for optical axis adjustment of the rear television camera. HINT: Only when adjusting the optical axis of the camera, create a target bar for adjustment. Dimension A B C D E F 1100 mm (3.61 ft.) 1600 mm (5.25 ft.) 30 mm (1.18 in.) 100 mm (3.94 in.) 500 mm (1.64 ft.) 30 mm (1.18 in.) TEXT IN ILLUSTRATION *1 Target Bar for Camera Adjustment *2 Vehicle Center *3 Bumper Edge *4 Front Side HINT: Check the tape color on the navigation receiver assembly and choose a tape color which can be easily seen. Start diagnostic mode. Refer to «DTC CHECK / CLEAR»(ref-393256-S34206371832011040700000) . NOTE: Mode setting must be carried out with the hybrid system started. Apply the parking brake, depress the brake pedal, push the P position switch, and ensure that the vehicle is not moving. HINT: The displayed items may differ depending on vehicle specifications. Select "Function Check/Setting" on the Service Menu screen. Select "Camera Setting" on the Function Check/Setting screen. Check that "CHK" (red) is not displayed on the SIGNAL CHECK screen. NOTE: When "CHK" (red) is displayed for any items except "EPS TYPE" on the SIGNAL CHECK screen, selecting "NEXT" will not change the screen to the INDIVIDUAL SETTING screen. When "CHK" (red) is displayed for any items except "EPS TYPE" and "HT INIT" on the SIGNAL CHECK screen, perform inspections using the SIGNAL CHECK screen. Refer to «DIAGNOSIS SYSTEM»(ref-393052-S08611273262011040700000) . HINT: When the screen is not change to the HEIGHT SET screen, check for DTCs and perform troubleshooting based on the output DTCs. Refer to «DTC CHECK / CLEAR»(ref-393052-S28442832582011040700000) . HEIGHT SET NOTE: The height control sensor vehicle height difference setting must be performed on the flat place. Before performing the television camera optical axis adjustment, the height control sensor vehicle height difference must be performed in the "HEIGHT SET" screen. Select the indicator "A" for "HT INIT" on the SIGNAL CHECK screen. Press "UP" and "DOWN" to input the calculated difference. HINT: A positive value is indicated in green and a negative value is indicated in red. When a value is "10 MM" in green, it means +10 mm. Available setting range: -102 mm to +102 mm (can be adjusted in 1 mm increments) After inputting the calculated difference, select "OK". The height control sensor vehicle height difference setting will be recorded. HINT: When "OK" is selected, a beep will sound to confirm that the height difference set values have been stored. The setting value will not be stored unless "OK" is selected. Until a beep finishes sounding, the adjustment values are not stored. When "BACK" is selected, the screen changes to SIGNAL CHECK screen without storing the set values. Press "OK" with the vehicle in the same condition as when the vehicle height was measured. If a person was in the driver seat when the vehicle height was measured, press "OK" with the same person in the driver seat. On the "SIGNAL CHECK" screen, check that the indicator "A" for "HT INIT" is "OK" (blue). Select "NEXT" on the SIGNAL CHECK screen. INDIVIDUAL SETTING Confirm the vehicle specification and select the EPS brush specification. Vehicle Specification EPS Brush Specification for 15 inch tire models EPS BRS (Brush type) for 17 inch tire models EPS LES (Brushless type) HINT: Selected EPS brush specification is indicated in blue. EPS brush refers to the type of motor used for the EPS system (with brushes or brushless). Select "NEXT" on the INDIVIDUAL SETTING screen. CAMERA POSITION SETTING (ROLL ANGLE ADJUSTMENT) NOTE: Before performing the television camera optical axis adjustment, the height control sensor vehicle height difference setting must be performed in the "HEIGHT SET" screen. HINT: When the back door is open, the "Back door is open. Do not use the rear view monitor when the back door is not completely closed." message will be displayed and television camera optical axis adjustment will not be possible. If the "Back door is open. Do not use the rear view monitor when the back door is not completely closed." message is displayed even when the back door is closed, perform inspections according to Problem Symptoms Table (A back door open warning message is displayed even after back door is closed). Refer to «PROBLEM SYMPTOMS TABLE»(ref-393052-S30211429652011040700000) . Select switches A and B to rotate C so that it is parallel to the target adjustment bar. Select "NEXT" on the CAMERA POSITION SETTING (ROLL ANGLE ADJUSTMENT) screen. CAMERA POSITION SETTING (VERTICAL AND HORIZONTAL POSITION ADJUSTMENT) By pressing the left and right, and up and down switches, move the parallelograms (A) vertically and horizontally so that the corners of the target bars (C) and the corners of the parallelograms (A) match. NOTE: If the left and right parallelograms (A) and target bars do not match completely, just match the corners of the target bars (C) with the corners of the parallelograms (A). If the left and right parallelograms (A) and the corners of the target bars (C) do not match, make the gaps between each parallelogram (A) and the target bars equal on the left and right sides. Select "NEXT" on the CAMERA POSITION SETTING (VERTICAL AND HORIZONTAL POSITION ADJUSTMENT) screen. BUMPER (SIMULTANEOUS ADJUSTMENT) By pressing the left and right, up and down and A and B switches, move the bumper reference lines vertically and horizontally or rotate them so that the bumper reference lines overlap or contact the bumper edge line. HINT: If the bumper reference lines do not overlap or contact the bumper edge line, select "L/R" to perform bumper reference line position adjustment (individual adjustment). When the bumper reference lines and bumper edge line overlap or contact each other, select "NEXT". LEFT BUMPER By pressing the left and right, up and down and A and B switches, move the left bumper reference line vertically and horizontally or rotate it so that the bumper reference lines overlap or contact the bumper edge line. HINT: When the left bumper reference line overlaps or contacts the bumper edge line in the bumper reference line position adjustment (individual adjustment) step, select "NEXT". Select "NEXT" on the LEFT BUMPER screen. RIGHT BUMPER By pressing the left and right, up and down and A and B switches, move the right bumper reference line vertically and horizontally or rotate it so that the bumper reference lines overlap or contact the bumper edge line. HINT: When the right bumper reference line overlaps or contacts the bumper edge line in the bumper reference line position adjustment (individual adjustment) step, select "NEXT". Select "NEXT" on the RIGHT BUMPER screen. VERIFY MODE Check that line A (indicating 1100 mm forward from the bumper edge) and the target bars are nearly overlapping and that the bumper reference lines and bumper edge line are nearly overlapping. With the steering wheel centered, check that the predicted path line is straight (overlapping the vehicle width extension lines). Selecting "NEXT" on the VERIFY MODE screen will be completed the camera aiming adjustment. HINT: When "NEXT" is selected, a beep will sound to confirm that the camera aiming adjustment values have been stored. The adjustment value will not be stored unless "NEXT" is selected. Until a beep finishes sounding, the adjustment values are not stored. STEERING ANGLE SETTING Perform the STEERING CENTER MEMORIZE operation. Check that the steering wheel is centered, and then select "STEERING CENTER MEMORIZE". HINT: When performing removal and installation, or replacement of the television camera, steering angle adjustment is not required. Perform the MAX STEERING ANGLE MEMORIZE operation. After adjusting the steering angle neutral point, turn the steering wheel to the left and right lock positions and select "MAX STEERING ANGLE MEMORIZE". The maximum steering angle is then stored and the screen changes to the Function Check/Setting screen. HINT: It is also possible to start by initially turning the steering to the right side. When "MAX STEERING ANGLE MEMORIZE" is selected, a beep will sound to confirm that the steering adjustment values have been stored. Until a beep finishes sounding, the adjustment values are not stored. The adjustment value will not be stored unless "MAX STEERING ANGLE MEMORIZE" is selected after turning the steering wheel side to side. When "BACK" is selected, the screen changes to VERIFY MODE without storing the set values. The "OK" button does not respond until the system stores the steering angle neutral point and maximum steering angle. Even if no DTCs are detected, selecting "MAX STEERING ANGLE MEMORIZE" may not cause the adjustment value to be stored if the steering sensor is malfunctioning. If selecting "MAX STEERING ANGLE MEMORIZE" does not cause the adjustment value to be stored after adjusting the steering angle, replace the spiral with sensor cable sub-assembly. Refer to «REMOVAL»(ref-393047-S42331158282011040700000) . Finish diagnostic mode. Refer to «DTC CHECK / CLEAR»(ref-393256-S34206371832011040700000) . Confirm steering angle adjustment. HINT: If the steering angle has been adjusted, confirm the steering angle adjustment on the advanced parking guidance screen after finishing diagnosis mode. Check on the advanced parking guidance screen that the predicted path line moves until the steering wheel is fully turned to either the left or right. HINT: If the predicted path line stops moving before the steering wheel is fully turned to either the left or right, the steering angle adjustment values have not been stored correctly. In this case, perform "STEERING CENTER MEMORIZE" and "MAX STEERING ANGLE MEMORIZE" again.
3. HEIGHT CONTROL SENSOR VEHICLE HEIGHT DIFFERENCE SETTING (HEIGHT SET) Preparation for adjustment HINT: The height control sensor vehicle height difference setting must be performed on the flat place. Before performing the television camera optical axis adjustment, the height control sensor vehicle height difference setting must be performed in the "HEIGHT SET" screen. Adjust the tire pressure to the specification. Measure the distance A between the ground and the edge of a rear wheel arch. Calculate the difference between the distance A and the standard height below. Standard 697 mm (2.29 ft.) HINT: Subtract the standard value from the measured value to get the standard height. When the measured value is 707 mm: 707 - 697 = +10 (standard height is +10 mm). Start diagnostic mode. NOTE: Mode setting must be carried out with the hybrid system started. Apply the parking brake, depress the brake pedal, push the P position switch, and ensure that the vehicle is not moving. HINT: The displayed items may differ depending on vehicle specifications. Select "Function Check/Setting" on the Service Menu screen. Select "Camera Setting" on the Function Check/Setting screen. Select "BACK CAMERA SETTING" on the MODE SETTING screen. HINT: To select a grayed out item, select and hold the item for 2 seconds or more. Select the indicator "A" for "HT INIT" on the SIGNAL CHECK screen. HINT: When "CHK" (red) is displayed for any items except "EPS TYPE" and "HT INIT" on the SIGNAL CHECK screen, perform inspections using the SIGNAL CHECK screen. When the screen is not change to the HEIGHT SET screen, check for DTCs and perform troubleshooting based on the output DTCs. HEIGHT SET Press "UP" and "DOWN" to input the calculated difference. HINT: A positive value is indicated in green and a negative value is indicated in red. When a value is "10 MM" in green, it means +10 mm. Available setting range: -102 mm to +102 mm (can be adjusted in 1 mm increments) After inputting the calculated difference, select "OK". The height control sensor vehicle height difference setting will be recorded. HINT: When "OK" is selected, a beep will sound to confirm that the height difference set values have been stored. The setting value will not be stored unless "OK" is selected. Until a beep finishes sounding, the adjustment values are not stored. When "BACK" is selected, the screen changes to SIGNAL CHECK screen without storing the set values. Press "OK" with the vehicle in the same condition as when the vehicle height was measured. If a person was in the driver seat when the vehicle height was measured, press "OK" with the same person in the driver seat. On the "SIGNAL CHECK" screen, check that the indicator "A" for "HT INIT" is "OK" (blue). Finish diagnostic mode.
4. REAR TELEVISION CAMERA OPTICAL AXIS ADJUSTMENT (CAMERA POSITION SETTING) HINT: Be sure to check for DTCs before performing this procedure. Preparation for adjustment NOTE: Before performing the television camera optical axis adjustment, the height control sensor vehicle height difference setting must be performed in the "HEIGHT SET" screen. Park the vehicle with the steering wheel centered. HINT: Before parking the vehicle, be sure to move the vehicle forward and in reverse to check that the tires are facing straight ahead with the steering wheel centered. Adjust the tire pressure to the specification. Set a target bar for optical axis adjustment of the rear television camera. HINT: Only when adjusting the optical axis of the camera, create a target bar for adjustment. Dimension A B C D E F 1100 mm (3.61 ft.) 1600 mm (5.25 ft.) 30 mm (1.18 in.) 100 mm (3.94 in.) 500 mm (1.64 ft.) 30 mm (1.18 in.) TEXT IN ILLUSTRATION *1 Target Bar for Camera Adjustment *2 Vehicle Center *3 Bumper Edge *4 Front Side HINT: Check the tape color on the navigation receiver assembly and choose a tape color which can be easily seen. Start diagnostic mode. NOTE: Mode setting must be carried out with the hybrid system started. Apply the parking brake, depress the brake pedal, push the P position switch, and ensure that the vehicle is not moving. HINT: The displayed items may differ depending on vehicle specifications. Select "Function Check/Setting" on the "Service Menu" screen. Select "Camera Setting" on the Function Check/Setting screen. Select "BACK CAMERA SETTING" on the MODE SETTING screen. HINT: To select a grayed out item, select and hold the item for 2 seconds or more. Select "NEXT" on the SIGNAL CHECK screen. NOTE: When "CHK" (red) is displayed for any items except "EPS TYPE" on the SIGNAL CHECK screen, selecting "NEXT" will not change the screen to the INDIVIDUAL SETTING screen. When "CHK" (red) is displayed for any items except "EPS TYPE" and "HT INIT" on the SIGNAL CHECK screen, perform inspections using the SIGNAL CHECK screen. INDIVIDUAL SETTING Confirm the vehicle specification and select the EPS brush specification. Vehicle Specification EPS Brush Specification for 15 inch tire models EPS BRS (Brush type) for 17 inch tire models EPS LES (Brushless type) HINT: Selected EPS brush specification is indicated in blue. EPS brush refers to the type of motor used for the EPS system (with brushes or brushless). NOTE: If the selected EPS brush specification does not match the vehicle specification, select the one that matches the vehicle specification. When the EPS brush specification is modified, steering angle setting is required. Refer to «INITIALIZATION»(ref-393052-S29548740432011040700000) . Select "NEXT" on the INDIVIDUAL SETTING screen. HINT: The INDIVIDUAL SETTING screen will not be displayed when "BACK" is selected after switching to the CAMERA POSITION SETTING (ROLL ANGLE ADJUSTMENT) screen. To display the INDIVIDUAL SETTING screen again, go back to the Function Check/Setting screen, select "Camera Setting" and repeat the steps. CAMERA POSITION SETTING (ROLL ANGLE ADJUSTMENT) NOTE: Before performing the television camera optical axis adjustment, the height control sensor vehicle height difference setting must be performed in the "HEIGHT SET" screen. HINT: When the back door is open, the "Back door is open. Do not use the rear view monitor when the back door is not completely closed." message will be displayed and television camera optical axis adjustment will not be possible. If the "Back door is open. Do not use the rear view monitor when the back door is not completely closed." message is displayed even when the back door is closed, perform inspections according to Problem Symptoms Table (A back door open warning message is displayed even after back door is closed). Select switches A and B to rotate C so that it is parallel to the target adjustment bar. Select "NEXT" on the CAMERA POSITION SETTING (ROLL ANGLE ADJUSTMENT) screen. CAMERA POSITION SETTING (VERTICAL AND HORIZONTAL POSITION ADJUSTMENT) By pressing the left and right, and up and down switches, move the parallelograms (A) vertically and horizontally so that the corners of the target bars (C) and the corners of the parallelograms (A) match. NOTE: If the left and right parallelograms (A) and target bars do not match completely, just match the corners of the target bars (C) with the corners of the parallelograms (A). If the left and right parallelograms (A) and the corners of the target bars (C) do not match, make the gaps between each parallelogram (A) and the target bars equal on the left and right sides. Select "NEXT" on the CAMERA POSITION SETTING (VERTICAL AND HORIZONTAL POSITION ADJUSTMENT) screen. BUMPER (SIMULTANEOUS ADJUSTMENT) By pressing the left and right, up and down and A and B switches, move the bumper reference lines vertically and horizontally or rotate them so that the bumper reference lines overlap or contact the bumper edge line. HINT: If the bumper reference lines do not overlap or contact the bumper edge line, select "L/R" to perform bumper reference line position adjustment (individual adjustment). When the bumper reference lines and bumper edge line overlap or contact each other, select "NEXT". LEFT BUMPER By pressing the left and right, up and down and A and B switches, move the left bumper reference line vertically and horizontally or rotate it so that the bumper reference lines overlap or contact the bumper edge line. HINT: When the left bumper reference line overlaps or contacts the bumper edge line in the bumper reference line position adjustment (individual adjustment) step, select "NEXT". Select "NEXT" on the LEFT BUMPER screen. RIGHT BUMPER By pressing the left and right, up and down and A and B switches, move the right bumper reference line vertically and horizontally or rotate it so that the bumper reference lines overlap or contact the bumper edge line. HINT: When the right bumper reference line overlaps or contacts the bumper edge line in the bumper reference line position adjustment (individual adjustment) step, select "NEXT". Select "NEXT" on the RIGHT BUMPER screen. VERIFY MODE Check that line A (indicating 1100 mm forward from the bumper edge) and the target bars are nearly overlapping and that the bumper reference lines and bumper edge line are nearly overlapping. With the steering wheel centered, check that the predicted path line is straight (overlapping the vehicle width extension lines). Selecting "NEXT" on the VERIFY MODE screen will be completed the camera aiming adjustment. HINT: When "NEXT" is selected, a beep will sound to confirm that the camera aiming adjustment values have been stored. The adjustment value will not be stored unless "NEXT" is selected. Until a beep finishes sounding, the adjustment values are not stored. Finish diagnostic mode.
5. BUMPER POSITION SETTING Start diagnostic mode. NOTE: Mode setting must be carried out with the hybrid system started. Apply the parking brake, depress the brake pedal, push the P position switch, and ensure that the vehicle is not moving. HINT: The displayed items may differ depending on vehicle specifications. Select "Function Check/Setting" on the "Service Menu" screen. Select "Camera Setting" on the Function Check/Setting screen. Select "BACK CAMERA SETTING" on the MODE SETTING screen. HINT: To select a grayed out item, select and hold the item for 2 seconds or more. Select "NEXT" on the SIGNAL CHECK screen. NOTE: When "CHK" (red) is displayed for any items except "EPS TYPE" on the SIGNAL CHECK screen, selecting "NEXT" will not change the screen to the INDIVIDUAL SETTING screen. When "CHK" (red) is displayed for any items except "EPS TYPE" and "HT INIT" on the SIGNAL CHECK screen, perform inspections using the SIGNAL CHECK screen. INDIVIDUAL SETTING Confirm the vehicle specification and select the EPS brush specification. Vehicle Specification EPS Brush Specification for 15 inch tire models EPS BRS (Brush type) for 17 inch tire models EPS LES (Brushless type) HINT: Selected EPS brush specification is indicated in blue. EPS brush refers to the type of motor used for the EPS system (with brushes or brushless). NOTE: If the selected EPS brush specification does not match the vehicle specification, select the one that matches the vehicle specification. When the EPS brush specification is modified, steering angle setting is required. Select "NEXT" on the INDIVIDUAL SETTING screen. HINT: The INDIVIDUAL SETTING screen will not be displayed when "BACK" is selected after switching to the CAMERA POSITION SETTING (ROLL ANGLE ADJUSTMENT) screen. To display the INDIVIDUAL SETTING screen again, go back to the Function Check/Setting screen, select "Camera Setting" and repeat the steps. CAMERA POSITION SETTING (ROLL ANGLE ADJUSTMENT) HINT: When only bumper reference line position adjustment is required after servicing the vehicle, CAMERA POSITION SETTING (ROLL ANGLE ADJUSTMENT) is unnecessary. Select "NEXT". When the back door is open, the "Back door is open. Do not use the rear view monitor when the back door is not completely closed." message will be displayed and television camera optical axis adjustment will not be possible. If the "Back door is open. Do not use the rear view monitor when the back door is not completely closed." message is displayed even when the back door is closed, perform inspections according to Problem Symptoms Table (A back door open warning message is displayed even after back door is closed). Select switches A and B to rotate C so that it is parallel to the target adjustment bar. Select "NEXT" on the CAMERA POSITION SETTING (ROLL ANGLE ADJUSTMENT) screen. CAMERA POSITION SETTING (VERTICAL AND HORIZONTAL POSITION ADJUSTMENT) By pressing the left and right, and up and down switches, move the parallelograms (A) vertically and horizontally so that the corners of the target bars (C) and the corners of the parallelograms (A) match. HINT: When only bumper reference line position adjustment is required after servicing the vehicle, CAMERA POSITION SETTING (ROLL ANGLE ADJUSTMENT) is unnecessary. Select "NEXT". Select "NEXT" on the CAMERA POSITION SETTING (VERTICAL AND HORIZONTAL POSITION ADJUSTMENT) screen. BUMPER (SIMULTANEOUS ADJUSTMENT) By pressing the left and right, up and down and A and B switches, move the bumper reference lines vertically and horizontally or rotate them so that the bumper reference lines overlap or contact the bumper edge line. HINT: If the bumper reference lines do not overlap or contact the bumper edge line, select "L/R" to perform bumper reference line position adjustment (individual adjustment). When the bumper reference lines and bumper edge line overlap or contact each other, select "NEXT". LEFT BUMPER By pressing the left and right, up and down and A and B switches, move the left bumper reference line vertically and horizontally or rotate it so that the bumper reference lines overlap or contact the bumper edge line. HINT: When the left bumper reference line overlaps or contacts the bumper edge line in the bumper reference line position adjustment (individual adjustment) step, select "NEXT". Select "NEXT" on the LEFT BUMPER screen. RIGHT BUMPER By pressing the left and right, up and down and A and B switches, move the right bumper reference line vertically and horizontally or rotate it so that the bumper reference lines overlap or contact the bumper edge line. HINT: When the right bumper reference line overlaps or contacts the bumper edge line in the bumper reference line position adjustment (individual adjustment) step, select "NEXT". Select "NEXT" on the RIGHT BUMPER screen. VERIFY MODE Check that the bumper reference lines and bumper edge line are nearly overlapping. Selecting "NEXT" on the VERIFY MODE screen will be completed the camera aiming adjustment. HINT: When "NEXT" is selected, a beep will sound to confirm that the bumper position adjustment values have been stored. The adjustment value will not be stored unless "NEXT" is selected. Until a beep finishes sounding, the adjustment values are not stored. Finish diagnostic mode.
