Contents Section: Antenna Systems All sections

Audio System & Visual System: Removal & Installation Toyota Prius II рестайлинг

Antenna Systems 30 illustrations ~2055 words

INSTALLATION

  1. INSTALL NO. 2 RADIO BRACKET Install the No. 2 radio bracket to the radio receiver with the 6 screws.
  2. INSTALL NO. 1 RADIO BRACKET Install the No. 1 radio bracket to the radio receiver with the 6 screws.
  3. INSTALL RADIO RECEIVER WITH BRACKET Connect all the connectors and install the radio receiver. Install the 4 screws.
  4. INSTALL MULTI-DISPLAY ASSEMBLY (See «INSTALLATION»(ref-289889-S02749256222008070800000) )
  5. INSTALL INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY CENTER (See «INSTALLATION»(ref-289871-S30577160482008070800000) )
  6. INSTALL NO. 4 INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(ref-289871-S39684456092008070800000) )
  7. INSTALL NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(ref-289871-S39684456092008070800000) )
  8. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  9. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-289861-S01642846932008070800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 265

Scheme 265: COMPONENTS
Scheme 265: COMPONENTS

Scheme 266

Scheme 266: REMOVAL
Scheme 266: REMOVAL

Scheme 267

Scheme 267
Scheme 267
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
  2. REMOVE FRONT SEAT ASSEMBLY RH (See «REMOVAL»(ref-289872-S02165685892008070800000) )
  3. REMOVE AUDIO AMPLIFIER COVER Detach the 2 clips and amplifier cover.
  4. REMOVE STEREO COMPONENT AMPLIFIER ASSEMBLY Disconnect the connector. Remove the 3 bolts and stereo component amplifier.

Scheme 268

Scheme 268
Scheme 268
  1. INSTALL STEREO COMPONENT AMPLIFIER ASSEMBLY Connect the connector. Install the stereo component amplifier with the 3 bolts.
  2. INSTALL AUDIO AMPLIFIER COVER Attach the 2 clips to install the amplifier cover.
  3. INSTALL FRONT SEAT ASSEMBLY RH (See «INSTALLATION»(ref-289872-S22918062022008070800000) )
  4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  5. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-289861-S01642846932008070800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 269

Scheme 269: COMPONENTS
Scheme 269: COMPONENTS

Scheme 270

Scheme 270: REMOVAL
Scheme 270: REMOVAL

Scheme 271

Scheme 271
Scheme 271
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
  2. REMOVE ROOF HEADLINING ASSEMBLY Remove the roof headlining (See «REMOVAL»(ref-289865-S03770848912008070800000) ) .
  3. REMOVE ANTENNA CORD SUB-ASSEMBLY Disconnect the connector. Remove the 10 clamps, ground bolt and antenna cord.
  4. REMOVE INSTRUMENT PANEL SUB- ASSEMBLY Remove the instrument panel (See «REMOVAL»(ref-289871-S38188274822008070800000) ) .
  5. REMOVE NO. 2 ANTENNA CORD SUB-ASSEMBLY Disconnect the connector. Detach the 3 clamps and 2 claws, and then remove the antenna cord.
  1. INSTALL NO. 2 ANTENNA CORD SUB-ASSEMBLY Attach the 3 clamps and 2 claws to install the antenna cord. Connect the connector.
  2. INSTALL INSTRUMENT PANEL SUB-ASSEMBLY Install the instrument panel (See «INSTALLATION»(ref-289871-S39684456092008070800000) ) .
  3. INSTALL ANTENNA CORD SUB-ASSEMBLY Attach the 10 clamps. Install the antenna cord with the bolt. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf) Connect the connector.
  4. INSTALL ROOF HEADLINING ASSEMBLY Install the roof headlining (See «INSTALLATION»(ref-289865-S19689597482008070800000) ) .
  5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  6. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-289861-S01642846932008070800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 272

Scheme 272: COMPONENTS
Scheme 272: COMPONENTS

Scheme 273

Scheme 273: REMOVAL
Scheme 273: REMOVAL

Scheme 274

Scheme 274
Scheme 274
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
  2. REMOVE ROOF HEADLINING ASSEMBLY Remove the roof headlining (See «REMOVAL»(ref-289865-S03770848912008070800000) ) .
  3. REMOVE ANTENNA (CORD / POLE SEPARATE TYPE) HOLDER ASSEMBLY Disconnect the connector. Remove the antenna nut. Remove the clamp and detach the 2 claws to remove the antenna holder.

Scheme 275

Scheme 275: INSTALLATION
Scheme 275: INSTALLATION
  1. INSTALL ANTENNA (CORD / POLE SEPARATE TYPE) HOLDER ASSEMBLY Install the antenna holder assembly on the roof and align the antenna cord with the antenna nut cutout. Tighten the antenna holder assembly with the antenna nut. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) Attach the clamp. Connect the connector.
  2. INSTALL ROOF HEADLINING ASSEMBLY Install the roof headlining (See «INSTALLATION»(ref-289865-S19689597482008070800000) ) .
  3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  4. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-289861-S01642846932008070800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 276

Scheme 276: COMPONENTS
Scheme 276: COMPONENTS

REMOVAL

  1. REMOVE ANTENNA POLE SUB-ASSEMBLY Remove the antenna pole by turning it counterclockwise.

Scheme 277

Scheme 277: INSTALLATION
Scheme 277: INSTALLATION
  1. INSTALL ANTENNA POLE SUB-ASSEMBLY Install the antenna pole by turning it clockwise.

Scheme 278

Scheme 278: COMPONENTS
Scheme 278: COMPONENTS

Scheme 279

Scheme 279: REMOVAL
Scheme 279: REMOVAL
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
  2. REMOVE INSTRUMENT PANEL SUB-ASSEMBLY Remove the instrument panel (See «REMOVAL»(ref-289871-S38188274822008070800000) ) .
  3. REMOVE NETWORK GATEWAY ECU Disconnect the connector. Remove the bolt and network gateway ECU.
  1. INSTALL NETWORK GATEWAY ECU Install the network gateway ECU with the bolt. Connect the connector.
  2. INSTALL INSTRUMENT PANEL SUB-ASSEMBLY Install the instrument panel (See «INSTALLATION»(ref-289871-S39684456092008070800000) ) .
  3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  4. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-289861-S01642846932008070800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
  1. INSTALL STEERING PAD SWITCH LH Connect the connector. Attach the 2 claws to install the steering pad switch.
  2. INSTALL STEERING PAD SWITCH RH Connect the connector. Attach the 2 claws to install the steering pad switch.
  3. INSTALL STEERING PAD ASSEMBLY (See «INSTALLATION»(ref-307039-S36311307362008123100000) )
  4. INSTALL NO. 2 STEERING WHEEL COVER LOWER
  5. INSTALL NO. 3 STEERING WHEEL COVER LOWER
  6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-289861-S01642846932008070800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
  8. INSPECT STEERING PAD ASSEMBLY (See «ON-VEHICLE INSPECTION»(ref-307039-S29860749112008123100000) )
  9. CHECK SRS WARNING LIGHT (See «CHECK MODE PROCEDURE»(ref-307039-S00067083582008123100000) )

Scheme 280

Scheme 280: COMPONENTS
Scheme 280: COMPONENTS

Scheme 281

Scheme 281: REMOVAL
Scheme 281: REMOVAL

Scheme 282

Scheme 282
Scheme 282
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
  2. REMOVE MAP LIGHT ASSEMBLY (See «REMOVAL»(ref-289880-S00224700092008070800000) )
  3. REMOVE MICROPHONE AMPLIFIER ASSEMBLY Remove the 3 screws and print board. Detach the 4 claws and remove the amplifier cover. Disconnect the connector. Remove the microphone amplifier.

Scheme 283

Scheme 283: INSTALLATION
Scheme 283: INSTALLATION

Scheme 284

Scheme 284
Scheme 284

Scheme 285

Scheme 285
Scheme 285
  1. INSTALL MICROPHONE AMPLIFIER ASSEMBLY Install the microphone amplifier. Connect the connector. Attach the 4 claws to install the amplifier cover. Install the print board with the 3 screws.
  2. INSTALL MAP LIGHT ASSEMBLY (See «INSTALLATION»(ref-289880-S00594755102008070800000) )
  3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  4. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-289861-S01642846932008070800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

HINT

  1. Use the same procedures for the RH side and LH sides.
  2. The procedures listed below are for the LH side.

Scheme 286

Scheme 286
Scheme 286
  1. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See «DISASSEMBLY»(ref-289862-S15975408392008070800000) )
  2. REMOVE FRONT DOOR INSIDE HANDLE BEZEL LH (See «DISASSEMBLY»(ref-289862-S15975408392008070800000) )
  3. REMOVE DOOR PULL HANDLE (See «DISASSEMBLY»(ref-289862-S15975408392008070800000) )
  4. REMOVE FRONT ARMREST BASE PANEL UPPER LH (See «DISASSEMBLY»(ref-289862-S15975408392008070800000) )
  5. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH (See «DISASSEMBLY»(ref-289862-S15975408392008070800000) )
  6. REMOVE FRONT NO. 1 SPEAKER ASSEMBLY Disconnect the connector. Using a drill bit with a diameter of less than 4 mm (0,16 in.), drill out the 3 rivet heads and remove the speaker. NOTE: Do not drill the rivet at an angle as this will cause damage to the drill and drill hole. Line up the drill and rivet, and carefully drill out the rivet head. Be careful. The cut rivet is very hot. Continue drilling and push out the remaining rivet fragments. Using a vacuum cleaner, remove the rivet fragments and shavings from the inside of the door.

HINT

  1. Use the same procedures for the RH and LH sides.
  2. The procedures listed below are for the LH side.

Scheme 287

Scheme 287
Scheme 287

Scheme 288

Scheme 288
Scheme 288

Scheme 289

Scheme 289
Scheme 289

Scheme 290

Scheme 290
Scheme 290
  1. INSTALL FRONT NO. 1 SPEAKER ASSEMBLY Using an air riveter or hand riveter, install the speaker with 3 new rivets. HINT: Install the new strike rivets in the order shown in the illustration. NOTE: Do not pry the rivet with the riveter, as this will cause damage to the riveter and mandrel. Confirm that the rivets are seated properly against the speaker. Do not tilt the riveter when installing the rivet to the speaker. Do not leave any space between the rivet head and speaker. Do not leave any space between the speaker and door. Firmly hold together the 2 items while installing the rivet. Connect the connector.
  2. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH (See «REASSEMBLY»(ref-289862-S06099659132008070800000) )
  3. INSTALL FRONT ARMREST BASE PANEL UPPER LH (See «REASSEMBLY»(ref-289862-S06099659132008070800000) )
  4. INSTALL DOOR PULL HANDLE (See «REASSEMBLY»(ref-289862-S06099659132008070800000) )
  5. INSTALL FRONT DOOR INSIDE HANDLE BEZEL LH (See «REASSEMBLY»(ref-289862-S06099659132008070800000) )
  6. INSTALL FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See «REASSEMBLY»(ref-289862-S06099659132008070800000) )
  7. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  8. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-289861-S01642846932008070800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

HINT

  1. Use the same procedures for the RH and LH sides.
  2. The procedures listed below are for the LH side.
  1. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See «DISASSEMBLY»(ref-289862-S15975408392008070800000) )
  2. REMOVE FRONT NO. 2 SPEAKER ASSEMBLY Detach the 3 claws and remove the speaker.

HINT

Scheme 291

Scheme 291: INSTALLATION
Scheme 291: INSTALLATION
  1. Use the same procedures for the RH and LH sides.
  2. The procedures listed below are for the LH side.
  1. INSTALL FRONT NO. 2 SPEAKER ASSEMBLY Attach the 3 claws to install the speaker.
  2. INSTALL FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See «REASSEMBLY»(ref-289862-S06099659132008070800000) )
  3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  4. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-289861-S01642846932008070800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 292

Scheme 292: COMPONENTS
Scheme 292: COMPONENTS
  1. INSTALL INSTRUMENT PANAL SPEAKER ASSEMBLY Install the speaker with the 2 screws and clamp. Connect the connector. Attach the 4 claws to install the speaker panel.

HINT

  1. Use the same procedures for the RH side and LH sides.
  2. The procedures listed below are for the LH side.
  1. REMOVE REAR DOOR INSIDE HANDLE BEZEL LH (See «DISASSEMBLY»(ref-289862-S13927783902008070800000) )
  2. REMOVE DOOR PULL HANDLE (See «DISASSEMBLY»(ref-289862-S13927783902008070800000) )
  3. REMOVE REAR DOOR ARMREST BASE PANEL UPPER LH (See «DISASSEMBLY»(ref-289862-S13927783902008070800000) )
  4. REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (See «DISASSEMBLY»(ref-289862-S13927783902008070800000) )
  5. REMOVE REAR SPEAKER ASSEMBLY Disconnect the connector. Using a drill bit with a diameter of less than 4 mm (0,16 in.), drill out the 3 rivet heads and remove the speaker. NOTE: Do not drill the rivet at an angle as this will cause damage to the drill and drill hole. Line up the drill and rivet, and carefully drill out the rivet head. Be careful as the cut rivet will be very hot. Continue drilling and push out the remaining rivet fragments. Using a vacuum cleaner, remove the rivet fragments and shavings from the inside of the door.

HINT

  1. Use the same procedures for the RH and LH sides.
  2. The procedures listed below are for the LH side.
  1. INSTALL REAR SPEAKER ASSEMBLY Using an air riveter or hand riveter, install the speaker with 3 new rivets. HINT: Install the new strike rivets in the order shown in the illustration. NOTE: Do not pry the rivet with the riveter, as this will cause damage to the riveter and mandrel. Confirm that the rivets are seated properly against the speaker. Do not tilt the riveter when installing the rivet to the speaker. Do not leave any space between the rivet head and speaker. Do not leave any space between the speaker and door. Firmly hold together the 2 items while installing the rivet. Connect the connector.
  2. INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (See «REASSEMBLY»(ref-289862-S30383042162008070800000) )
  3. INSTALL REAR DOOR ARMREST BASE PANEL UPPER LH (See «REASSEMBLY»(ref-289862-S30383042162008070800000) )
  4. INSTALL DOOR PULL HANDLE (See «REASSEMBLY»(ref-289862-S30383042162008070800000) )
  5. INSTALL REAR DOOR INSIDE HANDLE BEZEL LH (See «REASSEMBLY»(ref-289862-S30383042162008070800000) )

HINT

  1. Use the same procedures for the RH side and LH sides.
  2. The procedures listed below are for the LH side.
  1. REMOVE REAR DOOR INSIDE HANDLE BEZEL LH (See «DISASSEMBLY»(ref-289862-S13927783902008070800000) )
  2. REMOVE DOOR PULL HANDLE (See «DISASSEMBLY»(ref-289862-S13927783902008070800000) )
  3. REMOVE REAR DOOR ARMREST BASE PANEL UPPER LH (See «DISASSEMBLY»(ref-289862-S13927783902008070800000) )
  4. REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (See «DISASSEMBLY»(ref-289862-S13927783902008070800000) )
  5. REMOVE REAR NO. 2 SPEAKER ASSEMBLY Detach the 3 claws and remove the speaker.

HINT

Scheme 293

Scheme 293: INSTALLATION
Scheme 293: INSTALLATION
  1. Use the same procedures for the RH and LH sides.
  2. The procedures listed below are for the LH side.

Scheme 294

Scheme 294
Scheme 294
  1. INSTALL REAR NO, 2 SPEAKER ASSEMBLY Attach the 3 claws to install the speaker.
  2. INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (See «REASSEMBLY»(ref-289862-S30383042162008070800000) )
  3. INSTALL REAR DOOR ARMREST BASE PANEL UPPER LH (See «REASSEMBLY»(ref-289862-S30383042162008070800000) )
  4. INSTALL DOOR PULL HANDLE (See «REASSEMBLY»(ref-289862-S30383042162008070800000) )
  5. INSTALL REAR DOOR INSIDE HANDLE BEZEL LH (See «REASSEMBLY»(ref-289862-S30383042162008070800000) )
