SERVICE PRECAUTIONS (PRIUS)

WARNINGWhen performing any inspection or service procedure on this vehicle, ensure following service precautions are followed to prevent personal injury or death due to the extremely high voltage.

The following service precautions must be followed

Scheme 1

Scheme 1
Scheme 1
  1. Ensure ignition is off and ignition key is removed from ignition before performing any inspection or service procedure in engine compartment, as engine may automatically start and shut off when ignition is on and READY light is illuminated. READY light is displayed just above the shift lever position indicator on instrument cluster at center of instrument panel.
  2. Read all service and warning labels in engine compartment before performing any procedures in engine compartment.
  3. All high-voltage wiring harness connectors contain Orange connectors. DO NOT touch any wiring harness that contains Orange connectors.
  4. High-voltage battery and other high-voltage components may be identified by HIGH VOLTAGE caution labels on them. DO NOT touch these components.
  5. If necessary to inspect or service high-voltage system, ensure ignition is off. Remove service plug and wait at least 5 minutes to ensure high voltage is fully discharged before touching any high-voltage wiring harness, connectors or components. Service plug is located on service plug assembly at driver's side front corner of trunk compartment, near high-voltage battery. (Scheme 1) Ensure service plug is stored in a location in which no one may install service plug while technician is working on the vehicle.
  6. If necessary to touch any high-voltage wiring harness, connectors or components, ensure service plug is removed and battery voltage or less exists at electrical connector. Use Toyota insulated gloves when touching any high-voltage wiring harness, connectors or components. Ensure insulated gloves are dry and in good condition and that no holes exist in insulated gloves by applying air to insulated glove before touching any high-voltage wiring harness, connectors or components.
  7. DO NOT wear any metal objects while working on vehicle which may accidently drop and cause a short circuit.
  8. If any high-voltage wiring harness connector is disconnected, ensure terminal on wiring harness connector is wrapped with tape to prevent wiring harness connector from contacting any surface.
  9. If servicing high-voltage system, place sign on roof of vehicle to indicate to other technicians that high-voltage system is being serviced.

LEFT OR RIGHT POWER MIRROR INOPERATIVE

Check power mirror switch. See POWER MIRROR SWITCH under COMPONENT TESTS. Check power mirror motor(s). See POWER MIRROR MOTOR under COMPONENT TESTS. Check ground circuit and wiring harness for poor connections and damaged wiring. See WIRING DIAGRAMS .

UP/DOWN OR LEFT/RIGHT FUNCTION INOPERATIVE

Check power mirror switch. See POWER MIRROR SWITCH under COMPONENT TESTS. Check power mirror motor(s). See POWER MIRROR MOTOR under COMPONENT TESTS. Check ground circuit and wiring harness for poor connections and damaged wiring. See WIRING DIAGRAMS .

COMPONENT TESTS

WARNINGOn Prius, when performing any inspection or service procedure on this vehicle, ensure service precautions are followed to prevent personal injury or death due to the extremely high voltage. See SERVICE PRECAUTIONS (PRIUS) .

POWER MIRROR SWITCH

Remove power mirror switch. Using an ohmmeter, check continuity between appropriate mirror switch terminals. See appropriate POWER MIRROR SWITCH CONTINUITY TEST table. Continuity or resistance should or should not exist between specified terminals, depending on vehicle model. Check table foot note. If switch fails any test, replace switch. If switch passes continuity or resistance test, inspect switch circuit for defects or damage. See WIRING DIAGRAMS .

Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up3 & 4; 7 & 8
Down3 & 8; 4 & 7
Left4 & 9; 7 & 8
Right4 & 7; 8 & 9
Right Side For Left/Right Adjustment Switch
Up2 & 4; 7 & 8
Down2 & 8; 4 & 7
Left4 & 10; 7 & 8
Right4 & 7; 8 & 10
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 2)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 2)

POWER MIRROR SWITCH CONTINUITY TEST (AVALON - WITHOUT DRIVING POSITION MEMORY)

Scheme 2

Scheme 2
Scheme 2
Switch Position(1) Terminals No.Resistance (Ohms)
Left8 & 9100
Right8 & 90
Illumination5 & 6Continuity
(1) If continuity or resistance is as specified between specified terminals, replace switch. (Scheme 2)
(1)If continuity or resistance is as specified between specified terminals, replace switch. (Scheme 2)

LEFT/RIGHT ADJUSTMENT SWITCH CONTINUITY TEST (AVALON - WITH DRIVING POSITION MEMORY)

Mirror Switch Position(2) Resistance (Ohms)
Up100
Right250
Down470
Left800
(1) Measure resistance between terminals 7 & 9 with Left/Right Adjustment switch in both positions. (2) If resistance is as specified between terminals 7 & 9, replace switch. (Scheme 2)
(1)Measure resistance between terminals 7 & 9 with Left/Right Adjustment switch in both positions.
(2)If resistance is as specified between terminals 7 & 9, replace switch. (Scheme 2)

POWER MIRROR SWITCH RESISTANCE TEST (AVALON - WITH DRIVING POSITION MEMORY) (1)

Check circuits of power mirror switch at harness side of connector. See MIRROR SWITCH CIRCUITS TEST (AVALON & LAND CRUISER) table. If circuits are not as specified, inspect circuits connected to other components.

Check Between Ground & Terminal No. (1)ConditionSpecified Condition
8At All TimesContinuity
4Ignition Switch In LOCK PositionNo Voltage
4Ignition Switch In ACC or ON PositionBattery Voltage
(1) (Scheme 3)

MIRROR SWITCH HARNESS CIRCUITS TEST (AVALON & LAND CRUISER)

Scheme 3

Scheme 3
Scheme 3
Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up1 & 9; 6 & 10
Down1 & 10; 6 & 9
Left5 & 9; 6 & 10
Right5 & 10; 6 & 9
Right Side For Left/Right Adjustment Switch
Up6 & 10; 7 & 9
Down6 & 9; 7 & 10
Left6 & 10; 8 & 9
Right6 & 9; 8 & 10
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 4)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 4)

POWER MIRROR SWITCH CONTINUITY TEST (CAMRY & CAMRY SOLARA)

Scheme 4

Scheme 4
Scheme 4
Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up4 & 8; 6 & 7
Down4 & 7; 6 & 8
Left5 & 8; 6 & 7
Right5 & 7; 6 & 8
Right Side For Left/Right Adjustment Switch
Up3 & 8; 6 & 7
Down3 & 7; 6 & 8
Left2 & 8; 6 & 7
Right2 & 7; 6 & 8
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 5)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 5)

POWER MIRROR SWITCH CONTINUITY TEST (CELICA)

Scheme 5

Scheme 5
Scheme 5
Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up1 & 9; 6 & 10
Down1 & 10; 6 & 9
Left5 & 9; 6 & 10
Right5 & 10; 6 & 9
Right Side For Left/Right Adjustment Switch
Up6 & 10; 7 & 9
Down6 & 9; 7 & 10
Left6 & 10; 8 & 9
Right6 & 9; 8 & 10
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 6)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 6)

POWER MIRROR SWITCH CONTINUITY TEST (COROLLA)

Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up4 & 8; 6 & 7
Down4 & 7; 6 & 8
Left5 & 8; 6 & 7
Right5 & 7; 6 & 8
Right Side For Left/Right Adjustment Switch
Up3 & 8; 6 & 7
Down3 & 7; 6 & 8
Left2 & 8; 6 & 7
Right2 & 7; 6 & 8
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 8)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 8)

POWER MIRROR SWITCH CONTINUITY TEST (HIGHLANDER)

Scheme 6

Scheme 6
Scheme 6
Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up3 & 4; 7 & 8
Down3 & 8; 4 & 7
Left4 & 9; 7 & 8
Right4 & 7; 8 & 9
Right Side For Left/Right Adjustment Switch
Up2 & 4; 1 & 7; 1 & 8
Down4 & 7; 1 & 2; 1 & 8
Left4 & 10; 1 & 7; 1 & 8
Right4 & 7; 1 & 8; 1 & 10
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 7)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 7)

POWER MIRROR SWITCH CONTINUITY TEST (LAND CRUISER)

Scheme 7

Scheme 7
Scheme 7

Check circuits of power mirror switch at harness side of connector. See MIRROR SWITCH CIRCUITS TEST (AVALON & LAND CRUISER) table. If circuits are not as specified, inspect circuits connected to other components.

Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up4 & 8; 6 & 7
Down4 & 7; 6 & 8
Left5 & 8; 6 & 7
Right5 & 7; 6 & 8
Right Side For Left/Right Adjustment Switch
Up3 & 8; 6 & 7
Down3 & 7; 6 & 8
Left2 & 8; 6 & 7
Right2 & 7; 6 & 8
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 8)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 8)

POWER MIRROR SWITCH CONTINUITY TEST (MR2)

Scheme 8

Scheme 8
Scheme 8
Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up4 & 8; 6 & 7
Down4 & 7; 6 & 8
Left5 & 8; 6 & 7
Right5 & 7; 6 & 8
Right Side For Left/Right Adjustment Switch
Up3 & 8; 6 & 7
Down3 & 7; 6 & 8
Left5 & 8; 6 & 7
Right2 & 7; 6 & 8
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 9)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 9)

POWER MIRROR SWITCH CONTINUITY TEST (PRIUS)

Scheme 9

Scheme 9
Scheme 9

Check circuits of power mirror switch at harness side of connector. See MIRROR SWITCH HARNESS CIRCUITS TEST (PRIUS) table. If circuits are not as specified, inspect circuits connected to other components.

Check Between Ground & Terminal No. (1)ConditionSpecified Result
7At All TimesContinuity
8Ignition Switch In LOCK PositionNo Voltage
8Ignition Switch In ACC or ON PositionBattery Voltage
(1) (Scheme 3)

MIRROR SWITCH HARNESS CIRCUITS TEST (PRIUS)

Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up4 & 8; 6 & 7
Down4 & 7; 6 & 8
Left5 & 8; 6 & 7
Right5 & 7; 6 & 8
Right Side For Left/Right Adjustment Switch
Up3 & 8; 6 & 7
Down3 & 7; 6 & 8
Left2 & 8; 6 & 7
Right2 & 7; 6 & 8
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 8)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 8)

POWER MIRROR SWITCH CONTINUITY TEST (RAV4)

Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up1 & 9; 6 & 10
Down1 & 10; 6 & 9
Left5 & 9; 6 & 10
Right5 & 10; 6 & 9
Right Side For Left/Right Adjustment Switch
Up6 & 10; 7 & 9
Down6 & 9; 7 & 10
Left6 & 10; 8 & 9
Right6 & 9; 8 & 10
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 9)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 9)

POWER MIRROR SWITCH CONTINUITY TEST (SIENNA)

Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up4 & 8; 6 & 7
Down4 & 7; 6 & 8
Left5 & 8; 6 & 7
Right5 & 7; 6 & 8
Right Side For Left/Right Adjustment Switch
Up3 & 8; 6 & 7
Down3 & 7; 6 & 8
Left2 & 8; 6 & 7
Right2 & 7; 6 & 8
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 10)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 10)

POWER MIRROR SWITCH CONTINUITY TEST (SEQUOIA WITHOUT RETRACTABLE MIRROR)

Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up4 & 8; 6 & 7
Down4 & 7; 6 & 8
Left5 & 8; 6 & 7
Right5 & 7; 6 & 8
Right Side For Left/Right Adjustment Switch
Up3 & 8; 6 & 7
Down3 & 7; 6 & 8
Left5 & 8; 6 & 7
Right5 & 7; 6 & 8
Retract Switch
Drive7 & 9; 8 & 10
Retract7 & 10; 8 & 9
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 10)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 10)

POWER MIRROR SWITCH CONTINUITY TEST (SEQUOIA WITH RETRACTABLE MIRROR)

Scheme 10

Scheme 10
Scheme 10
Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up4 & 8; 6 & 7
Down4 & 7; 6 & 8
Left5 & 8; 6 & 7
Right5 & 7; 6 & 8
Right Side For Left/Right Adjustment Switch
Up3 & 8; 6 & 7
Down3 & 7; 6 & 8
Left2 & 8; 6 & 7
Right2 & 7; 6 & 8
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 9)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 9)

POWER MIRROR SWITCH CONTINUITY TEST (TACOMA)

Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up4 & 8; 6 & 7
Down4 & 7; 6 & 8
Left5 & 8; 6 & 7
Right5 & 7; 6 & 8
Right Side For Left/Right Adjustment Switch
Up3 & 8; 6 & 7
Down3 & 7; 6 & 8
Left5 & 8; 6 & 7
Right5 & 7; 6 & 8
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 9)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 9)

POWER MIRROR SWITCH CONTINUITY TEST (TUNDRA)

Mirror Switch Position(1) Terminals No.
Left Side For Left/Right Adjustment Switch
Up1 & 9; 6 & 10
Down1 & 10; 6 & 9
Left5 & 9; 6 & 10
Right5 & 10; 6 & 9
Right Side For Left/Right Adjustment Switch
Up6 & 10; 7 & 9
Down6 & 9; 7 & 10
Left6 & 10; 8 & 9
Right6 & 9; 8 & 10
(1) If continuity does not exist between specified terminals, replace switch. (Scheme 4)
(1)If continuity does not exist between specified terminals, replace switch. (Scheme 4)

POWER MIRROR SWITCH CONTINUITY TEST (4RUNNER)

Scheme 11

Scheme 11: Avalon
Scheme 11: Avalon

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. Disconnect drivers side power mirror switch harness connector. Strip off the vinyl tape of connector and remove wire terminals No. 2, 3, 6, 7 and 9 from connector housing. Connect three 1.5-volt dry cell batteries in series. (Scheme 11)
  2. Connect dry cell batteries positive lead to terminal No. 7 and negative lead to terminal No. 6. Connect DVOM positive lead to terminal No. 9 and negative lead to terminal No. 6. (Scheme 12)
  3. Apply vehicle battery voltage to terminals No. 2 and 3, while checking the gradual voltage change from mirror uppermost position of 0-1.8 volts to mirror lowermost position of 2.8-5.0 volts. Reverse vehicle battery voltage leads on terminals No. 2 and 3, while checking the gradual voltage change from mirror lowermost to uppermost position. If voltage is not as specified, replace motor assembly.
  4. Disconnect vehicle battery leads. Leave dry cell battery leads connected to terminals No. 6 and 7. Disconnect DVOM positive lead from terminal No. 9 and connect to terminal No. 8.
  5. Apply vehicle battery voltage to terminals No. 1 and 2, while checking the gradual voltage change from mirror left-most to right-most position. Reverse vehicle battery voltage leads on terminals No. 1 and 2 while checking the gradual voltage change from mirror right-most to left-most position.
  6. With mirror voltage in left position, voltage should gradually change from right-most 0-1.8 volts to 2.8-5.0 volts in left-most position. With mirror voltage in right position, voltage should gradually change from left-most 0-1.8 volts to 2.8-5.0 volts in right-most position. If voltage is not as specified, replace motor assembly.
  7. Using an ohmmeter, check driving position memory and return switch continuity. See «DRIVING POSITION MEMORY & RETURN SWITCH CONTINUITY TEST (AVALON)»(ref-129667-S08914733782001111600000) table. DRIVING POSITION MEMORY & RETURN SWITCH CONTINUITY TEST (AVALON) Switch Position (1) Terminal No. SET On 3 & 4 SW1 On 2 & 3 SW2 On 1 & 3 (1) If continuity does not exist between specified terminals, replace switch. (Scheme 13)

POWER MIRROR MOTOR

Disconnect power mirror motor harness connector. Using a 12-volt power source, connect positive and negative leads to specified terminals. See appropriate POWER MIRROR MOTOR TEST table. If power mirror motor fails any test, replace power mirror assembly.

Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
32Up
23Down
12Left
21Right
(1) (Scheme 14)

POWER MIRROR MOTOR TEST (AVALON - WITHOUT DRIVING POSITION MEMORY - WITHOUT MIRROR HEATER)

Scheme 14

Scheme 14
Scheme 14
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
42Up
24Down
12Left
21Right
(1) (Scheme 15)

POWER MIRROR MOTOR TEST (AVALON - WITH MIRROR HEATER)

Scheme 15

Scheme 15
Scheme 15
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
32Up
23Down
12Left
21Right
(1) (Scheme 12)

POWER MIRROR MOTOR TEST (AVALON - WITH DRIVING POSITION MEMORY)

Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
12Up
21Down
32Left
23Right
(1) (Scheme 16)

POWER MIRROR MOTOR TEST (CAMRY - JAPAN BUILT - WITHOUT MIRROR HEATER)

Scheme 16

Scheme 16
Scheme 16
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
32Up
23Down
12Left
21Right
(1) (Scheme 17)

POWER MIRROR MOTOR TEST (CAMRY - USA BUILT - WITHOUT MIRROR HEATER)

Scheme 17

Scheme 17
Scheme 17
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
12Up
21Down
32Left
23Right
(1) (Scheme 18)

POWER MIRROR MOTOR TEST (CAMRY - USA BUILT - WITH MIRROR HEATER)

Scheme 18

Scheme 18
Scheme 18
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
34Up
43Down
24Left
42Right
(1) (Scheme 19)

POWER MIRROR MOTOR TEST (CAMRY SOLARA)

Scheme 19

Scheme 19
Scheme 19
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
53Up
35Down
13Left
31Right
(1) (Scheme 20)

POWER MIRROR MOTOR TEST (CELICA)

Scheme 20

Scheme 20
Scheme 20
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
32Up
23Down
12Left
21Right
(1) see scheme 21
(1)See scheme 21

POWER MIRROR MOTOR TEST (COROLLA)

Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
65Up
56Down
45Left
54Right
(1) (Scheme 21)

POWER MIRROR MOTOR TEST (HIGHLANDER)

Scheme 21

Scheme 21
Scheme 21
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
87Left
78Right
67Up
76Down
(1) (Scheme 22)

POWER MIRROR MOTOR TEST (LAND CRUISER)

Scheme 22

Scheme 22
Scheme 22
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
21Right
12Left
23Down
32Up
(1) (Scheme 23)

POWER MIRROR MOTOR TEST (MR2)

Scheme 23

Scheme 23
Scheme 23
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
13Left
31Right
53Up
35Down
(1) (Scheme 20)

POWER MIRROR MOTOR TEST (PRIUS)

Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
31Left
13Right
53Up
35Down
(1) (Scheme 20)

POWER MIRROR MOTOR TEST (RAV4)

Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
45Left
54Right
21Up
12Down
(1) (Scheme 24)

POWER MIRROR MOTOR TEST (SEQUOIA)

Scheme 24

Scheme 24
Scheme 24
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
23Left
32Right
21Up
12Down
(1) see scheme 26or (Scheme 25).
(1)See scheme 26or (Scheme 25).

POWER MIRROR MOTOR TEST (SIENNA)

Scheme 25

Scheme 25
Scheme 25
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
21Up
12Down
31Left
13Right
(1) (Scheme 26)

POWER MIRROR MOTOR TEST (TACOMA & TUNDRA)

Scheme 26

Scheme 26
Scheme 26
Apply 12 Volts To Pin No.(1) Ground Pin No.Mirror Operation
54Up
45Down
14Left
41Right
(1) see scheme 29
(1)See scheme 29

POWER MIRROR MOTOR TEST (4RUNNER)

Note. Power mirror switch removal and installation procedures are not available from manufacturer.

Power Mirror System Wiring Diagram (Avalon). Scheme 27

Scheme 27: Power Mirror System Wiring Diagram (Avalon)
Scheme 27: Power Mirror System Wiring Diagram (Avalon)

Power Mirror System Wiring Diagram (Camry 2.2L CNG). Scheme 28

Scheme 28: Power Mirror System Wiring Diagram (Camry 2.2L CNG)
Scheme 28: Power Mirror System Wiring Diagram (Camry 2.2L CNG)

Power Mirror System Wiring Diagram (Camry 2.2L & 3.0L). Scheme 29

Scheme 29: Power Mirror System Wiring Diagram (Camry 2.2L & 3.0L)
Scheme 29: Power Mirror System Wiring Diagram (Camry 2.2L & 3.0L)

Power Mirror System Wiring Diagram (Camry Solara). Scheme 30

Scheme 30: Power Mirror System Wiring Diagram (Camry Solara)
Scheme 30: Power Mirror System Wiring Diagram (Camry Solara)

Power Mirror System Wiring Diagram (Celica). Scheme 31

Scheme 31: Power Mirror System Wiring Diagram (Celica)
Scheme 31: Power Mirror System Wiring Diagram (Celica)

Power Mirror System Wiring Diagram (Corolla). Scheme 32

Scheme 32: Power Mirror System Wiring Diagram (Corolla)
Scheme 32: Power Mirror System Wiring Diagram (Corolla)

Power Mirror System Wiring Diagram (Highlander). Scheme 33

Scheme 33: Power Mirror System Wiring Diagram (Highlander)
Scheme 33: Power Mirror System Wiring Diagram (Highlander)

Power Mirror System Wiring Diagram (Land Cruiser). Scheme 34

Scheme 34: Power Mirror System Wiring Diagram (Land Cruiser)
Scheme 34: Power Mirror System Wiring Diagram (Land Cruiser)

Power Mirror System Wiring Diagram (MR2). Scheme 35

Scheme 35: Power Mirror System Wiring Diagram (MR2)
Scheme 35: Power Mirror System Wiring Diagram (MR2)

Power Mirror System Wiring Diagram (Prius). Scheme 36

Scheme 36: Power Mirror System Wiring Diagram (Prius)
Scheme 36: Power Mirror System Wiring Diagram (Prius)

Power Mirror System Wiring Diagram (RAV4). Scheme 37

Scheme 37: Power Mirror System Wiring Diagram (RAV4)
Scheme 37: Power Mirror System Wiring Diagram (RAV4)

Power Mirror System Wiring Diagram (Sequoia). Scheme 38

Scheme 38: Power Mirror System Wiring Diagram (Sequoia)
Scheme 38: Power Mirror System Wiring Diagram (Sequoia)

Power Mirror System Wiring Diagram (Sienna). Scheme 39

Scheme 39: Power Mirror System Wiring Diagram (Sienna)
Scheme 39: Power Mirror System Wiring Diagram (Sienna)

Power Mirror System Wiring Diagram (Tacoma). Scheme 40

Scheme 40: Power Mirror System Wiring Diagram (Tacoma)
Scheme 40: Power Mirror System Wiring Diagram (Tacoma)

Power Mirror System Wiring Diagram (Tundra). Scheme 41

Scheme 41: Power Mirror System Wiring Diagram (Tundra)
Scheme 41: Power Mirror System Wiring Diagram (Tundra)

Power Mirror System Wiring Diagram (4Runner With Power Windows). Scheme 42

Scheme 42: Power Mirror System Wiring Diagram (4Runner With Power Windows)
Scheme 42: Power Mirror System Wiring Diagram (4Runner With Power Windows)

Power Mirror System Wiring Diagram (4Runner Without Power Windows). Scheme 43

Scheme 43: Power Mirror System Wiring Diagram (4Runner Without Power Windows)
Scheme 43: Power Mirror System Wiring Diagram (4Runner Without Power Windows)

More articles — Power Mirrors
