INSTALL RELIEF VALVE

Insert the relief valve and spring into the pump body hole, and install the plug.

Torque: 25 N.m (255 kgf.cm, 18 ft.lbf)

Scheme 15

Scheme 16

1. INSTALL OIL PUMP Place the drive and driven rotors into timing chain cover with the marks facing the oil pump cover side. (Scheme 15): Identifying Drive And Driven Rotor Installation Marks Install the oil pump cover to the timing chain cover with the 2 bolts and 3 screws. (Scheme 16): Installing Oil Pump Cover Torque: Bolt 8.8 N.m (90 kgf.cm, 78 in..lbf) Screw 10.3 N.m (105 kgf.cm, 8 ft.lbf)
2. INSTALL TIMING CHAIN COVER (See «INSTALLATION»(ref-182296-S19210172432005080800000) )
3. FILL WITH ENGINE OIL
4. CHECK FOR LEAKS
