HOW TO PROCEED WITH TROUBLESHOOTING
Carry out troubleshooting in accordance with the procedure. Details are provided in Diagnostics section, showing the most effective methods for each circuit. Confirm the troubleshooting procedures first for the relevant circuit before beginning troubleshooting of that circuit.
Troubleshooting Flow Chart. Scheme 34
Scheme 35
Scheme 36
Scheme 37
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
Scheme 43
Scheme 44
Scheme 45
- Customer Problem Analysis In troubleshooting, the problem symptoms must be confirmed accurately and all preconceptions must be cleared away in order to give an accurate judgment. To ascertain just what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time it occurred. Important Point in the Problem Analysis: The following 5 items are important points in the problem analysis. Past problems which are thought to be unrelated and the repair history, etc. may also help in some cases, so as much information as possible should be gathered and its relationship with the problem symptoms should be correctly ascertained for reference in troubleshooting. A customer problem analysis table is provided in Diagnostics section for each system for your use. (Scheme 35): Customer Problem Analysis Check Sheet
- Symptom Confirmation And Diagnostic Trouble Code Check The diagnostic system in the PRIUS fulfills various functions. The first function is the Diagnostic Trouble Code Check in which a malfunction in the signal circuits to the ECU is stored in code in the ECU memory at the time of occurrence, to be output by the technician during troubleshooting. Another function is the Input Signal Check which checks if the signals from various switches are sent to the ECU correctly. By using these check functions, the problem areas can be narrowed down quickly and troubleshooting can be performed effectively. Diagnostic functions are incorporated in the following systems in the PRIUS. (Scheme 36): Symptom Confirmation And Diagnostic Trouble Code Check Chart In diagnostic trouble code check, it is very important to determine whether the problem indicated by the diagnostic trouble code is still occurring or occurred in the past but returned to normal at present. In addition, it must be checked in the problem symptom check whether the malfunction indicated by the diagnostic trouble code is directly related to the problem symptom or not. For this reason, the diagnostic trouble codes should be checked before and after the symptom confirmation to determine the current conditions. If this is not done, it may, depending on the case, result in unnecessary troubleshooting for normally operating systems, thus making it more difficult to locate the problem, or in repairs not pertinent to the problem. Therefore, always follow the procedure in correct order and perform the diagnostic trouble code check. (Scheme 37): Diagnostic Trouble Code Check Procedure A flow chart showing how to proceed with troubleshooting using the diagnostic trouble code check. This flow chart shows how to utilize the diagnostic trouble code check effectively, then by carefully checking the results, indicates how to proceed either to diagnostic trouble code troubleshooting or to troubleshooting of problem symptoms table. (Scheme 38): Diagnostic Trouble Code Troubleshooting Flow Chart
- Symptom Simulation The most difficult case in troubleshooting is when there are no problem symptoms occurring. In such cases, a thorough customer problem analysis must be carried out, then simulate the same or similar conditions and environment in which the problem occurred in the customer's vehicle. No matter how much experience a technician has, or how skilled he may be, if he proceeds to troubleshoot without confirming the problem symptoms he will tend to overlook something important in the repair operation and make a wrong guess somewhere, which will only lead to a standstill. For example, for a problem which only occurs when the engine is cold, or for a problem which occurs due to vibration caused by the road during driving, etc., the problem can never be determined so long as the symptoms are confirmed with the engine hot condition or the vehicle at a standstill. Since vibration, heat or water penetration (moisture) is likely cause for problem which is difficult to reproduce, the symptom simulation tests introduced here are effective measures in that the external causes are applied to the vehicle in a stopped condition. Important Points in the Symptom Simulation Test: In the symptom simulation test, the problem symptoms should of course be confirmed, but the problem area or parts must also be found out. To do this, narrow down the possible problem circuits according to the symptoms before starting this test and connect a tester beforehand. After that, carry out the symptom simulation test, judging whether the circuit being tested is defective or normal and also confirming the problem symptoms at the same time. Refer to the problem symptoms table for each system to narrow down the possible causes of the symptom. (Scheme 39): Symptoms Simulation Tests Chart
- Diagnostic Trouble Code Chart The inspection procedure is (Scheme 40) This table permits efficient and accurate troubleshooting using the diagnostic trouble codes displayed in the diagnostic trouble code check. Proceed with troubleshooting in accordance with the inspection procedure given in the diagnostic chart corresponding to the diagnostic trouble codes displayed. The engine diagnostic trouble code chart (Scheme 40), is an example. (Scheme 40): Diagnostic Trouble Code Chart
- Problem Symptoms Table The suspected circuits or parts for each problem symptom are (Scheme 41) Use this table to troubleshoot the problem when a "Normal" code is displayed in the diagnostic trouble code check but the problem is still occurring. Numbers in the table indicate the inspection order in which the circuits or parts should be checked.
- Circuit Inspection (Scheme 42): Circuit Inspection Chart (1 Of 2) (Scheme 43): Circuit Inspection Chart (2 Of 2) (Scheme 44): Checking Connector Connection (Scheme 45): Checking Wire Harness (Scheme 46): Identifying ECU
Scheme 46
Scheme 47
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
Scheme 59
- Connector Connection And Terminal Inspection For troubleshooting, diagnostic trouble code charts or problem symptom table are provided for each circuit with detailed inspection procedures. When all the component parts, wire harnesses and connectors of each circuit except the ECU are found to be normal in troubleshooting, then it is determined that the problem is in the ECU. Accordingly, if diagnosis is performed without the problem symptoms occurring, refer to Step 5 to replace the ECU. So always confirm that the problem symptoms are occurring, or proceed with inspection while using the symptom simulation method. The instructions "Check wire harness and connector" and "Check and replace ECU" which appear in the inspection procedure, are common and applicable to all diagnostic trouble codes. Follow the procedure outlined below whenever these instructions appear. Open Circuit: This could be due to a disconnected wire harness, faulty contact in the connector, and a connector terminal pulled out, etc. NOTE: It is rarely the case that a wire is broken in the middle of it. Most cases occur at the connector. In particular, carefully check the connectors of sensors and actuators Faulty contact could be due to rusting of the connector terminals, to foreign materials entering terminals or a deformation of connector terminals. Simply disconnecting and reconnecting the connectors once changes the condition of the connection and may result in a return to normal operation. Therefore, in troubleshooting, if no abnormality is found in the wire harness and connector check, but the problem disappears after the check, then the cause is considered to be in the wire harness or connectors. Short Circuit: This could be due to a contact between wire harness and the body ground or to a short circuit occurred inside the switch, etc. NOTE: When there is a short circuit between the wire harness and body ground, check thoroughly whether the wire harness is caught in the body or is clamped properly. (Scheme 47): Inserting Tester Probe To Connector
- Connector Handling When inserting tester probes into a connector, insert them from the rear of the connector. When necessary, use mini test leads. For water resistant connectors which cannot be accessed from behind, take good care not to deform the connector terminals. (Scheme 48): Disconnecting Connectors At Both ECU And Sensor Sides
- Continuity Check (Open Circuit Check) Disconnect the connectors at both ECU and sensor sides. (Scheme 49): Measuring Resistance Between Applicable Terminals Of Connectors (Open Circuit Check) NOTE: Measure the resistance while lightly shaking the wire harness vertically and horizontally. Measure the resistance between the applicable terminals of the connectors. Resistance: 1 ohm or less (Scheme 50): Measuring Resistance Between Applicable Terminals Of Connectors And Ground (Short Circuit Check)
- Resistance Check (Short Circuit Check) Disconnect the connectors on both ends. NOTE: Measure the resistance while lightly shaking the wire harness vertically and horizontally. Measure the resistance between the applicable terminals of the connectors and body ground. Be sure to carry out this check on the connectors on both ends. Resistance: 1 Mohm or higher (Scheme 51): Checking Crimped Portions For Looseness
- Visual Check And Contact Pressure Check Disconnect the connectors at both ends. Check for rust or foreign material, etc. in the terminals of the connectors. NOTE: The terminals should not come out when pulled lightly from the back. Check crimped portions for looseness or damage and check that the terminals are secured in lock portion. NOTE: When testing a gold-plated female terminal, always use a gold-plated male terminal. When the test terminal is pulled out more easily than others, there may be poor contact in that section. Prepare a test male terminal and insert it in the female terminal, then pull it out. (Scheme 52): Checking Open Circuit
- Check Open Circuit For the open circuit in the wire harness in (Scheme 52), perform "(a) Continuity Check" or "(b) Voltage Check" to locate the section. (Scheme 53): Measuring Resistance Between Connector A And C (Scheme 54): Measuring Resistance Between Connector A And B
- Check the continuity. Disconnect connectors "A" and "C" and measure the resistance between them. In the case of (Scheme 53): Between terminal 1 of connector "A" and terminal 1 of connector "C" --> No continuity (open) Between terminal 2 of connector "A" and terminal 2 of connector "C" --> Continuity Therefore, it is found out that there is an open circuit between terminal 1 of connector "A" and terminal 1 of connector "C". Disconnect connector "B" and measure the resistance between the connectors. In the case of (Scheme 54): Between terminal 1 of connector "A" and terminal 1 of connector "B1" --> Continuity Between terminal 1 of connector "B2" and terminal 1 of connector "C" --> No continuity (open) Therefore, it is found out that there is an open circuit between terminal 1 of connector "B2" and terminal 1 of connector "C". (Scheme 55): Checking Voltage (Open Circuit) Check The Voltage. In a circuit in which voltage is applied (to the ECU connector terminal), an open circuit can be checked for by conducting a voltage check. (Scheme 55), with each connector still connected, measure the voltage between body ground and terminal 1 of connector "A" at the ECU 5V output terminal, terminal 1 of connector "B", and terminal 1 of connector "C", in that order. If the results are: 5V: Between Terminal 1 of connector "A" and Body Ground 5V: Between Terminal 1 of connector "B" and Body Ground 0V: Between Terminal 1 of connector "C" and Body Ground Then it is found out that there is an open circuit in the wire harness between terminal 1 of "B" and terminal 1 of "C". (Scheme 56): Checking Short Circuit Check Short Circuit If the wire harness is ground shorted as in (Scheme 56), locate the section by conducting a "continuity check with ground". (Scheme 57): Measuring Resistance Between Terminal 1 And 2 Of Connector A And Body Ground Check the continuity with ground. Disconnect connectors "A" and "C" and measure the resistance between terminal 1 and 2 of connector "A" and body ground. In the case of (Scheme 57): Between terminal 1 of connector "A" and body ground --> Continuity (short) Between terminal 2 of connector "A" and body ground --> No continuity Therefore, it is found out that there is a short circuit between terminal 1 of connector "A" and terminal 1 of connector "C". (Scheme 58): Measuring Resistance Between Terminal 1 Of Connector A And Body Ground, And Terminal 1 Of Connector And Body Ground Disconnect connector "B" and measure the resistance between terminal 1 of connector "A" and body ground, and terminal 1 of connector "B2" and body ground. In the case of (Scheme 58): Between terminal 1 of connector "A" and body ground --> No continuity Between terminal 1 of connector "B2" and body ground --> Continuity (short) Therefore, it is found out that there is a short circuit between terminal 1 of connector "B2" and terminal 1 of connector "C". Check And Replace ECU First check the ECU ground circuit. If it is faulty, repair it. If it is normal, the ECU could be faulty, so replace the ECU with a normal functioning one and check that the symptoms appear. (Scheme 59): Measuring Resistance Between ECU Ground Terminal And Body Ground Measure the resistance between the ECU ground terminal and the body ground. Resistance: 1 ohm or less see scheme 60: Disconnecting ECU Connector Disconnect the ECU connector, check the ground terminals on the ECU side and the wire harness side for bend and check the contact pressure.
