SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | SCS06 Scroll |
| Compressor Belt Deflection (1) |
| New Belt | 99-121 lbs. (44.9-54.9) |
| Used Belt | 57-77 lbs. (25.9-34.9) |
| System Oil Capacity | (2) |
| Refrigerant (R-134a) Capacity | 15.9-19.4 ozs. |
| System Operating Pressures (3) |
| High Side | 199-228 psi (14-16 kg/cm 2 ) |
| Low Side | 21-36 psi (1.5-2.5 kg/cm 2 ) |
| (1) Using a tension gauge, measure at mid-point of bottom belt run. A new belt is one that has been run less than 5 minutes. (2) Check underhood A/C specification label. Use ND-OIL 8. (3) Specification is with ambient temperature at 86-95°F (30-35°C) and 1500 RPM engine speed. |
| (1) | Using a tension gauge, measure at mid-point of bottom belt run. A new belt is one that has been run less than 5 minutes. |
| (2) | Check underhood A/C specification label. Use ND-OIL 8. |
| (3) | Specification is with ambient temperature at 86-95°F (30-35°C) and 1500 RPM engine speed. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor-To-Bracket Bolts | 18 (25) |
| Passenger's Side Air Bag Bolts | 15 (20) |
| INCH Lbs. (N.m) |
| Compressor Hoses | 89 (10) |
| Condenser Lines | 48 (5.4) |
| Expansion Valve Lines | 30 (3.5) |
| Driver's Side Air Bag Bolts | 78 (8.8) |
| Water Pump Bolts | 48 (5.4) |
Automatic A/C-Heater System Wiring Diagram (2001 Prius - 1 Of 2). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (2001 Prius - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 Prius - 2 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (2001 Prius - 2 Of 2)
