Engine Cooling System [service Information] Toyota Prius V I

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. DRAIN COOLANT (for Engine) NOTE: Do not remove the reserve tank cap and radiator drain cock plug while the engine and radiator are still hot. Pressurized, hot engine coolant and steam may be released and cause serious burns. Loosen the radiator drain cock plug. Remove the reserve tank cap and drain the coolant. TEXT IN ILLUSTRATION *1 Reserve Tank Cap *2 Radiator Drain Cock Plug HINT: Collect the coolant in a container and dispose of it according to the local regulations.
2. ADD COOLANT (for Engine) Tighten the radiator drain cock plug. Remove the reserve tank cap. Add coolant up to the B line of the reserve tank. TEXT IN ILLUSTRATION *1 B Line Standard Capacity Item Capacity Engine coolant 6.9 liters (7.3 US qts, 6.1 lmp. qts) HINT: TOYOTA vehicles are filled with TOYOTA SLLC at the factory. In order to avoid damage to the engine cooling system and other technical problems, only use TOYOTA SLLC or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, non-borate coolant with long-life hybrid organic acid technology (coolant with long-life hybrid organic acid technology is a combination of low phosphates and organic acids). NOTE: Never use water as a substitute for engine coolant. Squeeze the inlet and outlet radiator hoses several times by hand, and then check the level of the coolant. If the coolant level is low, add coolant. Install the reserve tank cap. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-v/i-2011-2014/remont/hoistjack/#introduction) . Bleed air from the cooling system. NOTE: Before starting the engine, turn the A/C switch off. Adjust the heater control to the maximum hot setting. Adjust the blower speed to low setting. Warm up the engine until the thermostat opens. While the thermostat is open, allow the coolant to circulate for several minutes. HINT: The thermostat opening timing can be confirmed by squeezing the inlet radiator hose by hand, and sensing vibrations when the engine coolant starts to flow inside the hose. WARNING: When squeezing the radiator hose: Wear protective gloves. Be careful as the radiator hoses are hot. Keep your hands away from the radiator fan. Squeeze the inlet and outlet radiator hoses several times by hand to bleed air from the system. WARNING: When squeezing the radiator hose: Wear protective gloves. Be careful as the radiator hoses are hot. Keep your hands away from the radiator fan. After the engine has cooled down, check that the coolant level is between the full and low lines. TEXT IN ILLUSTRATION *1 Full Line *2 Low Line If the coolant level is low, add coolant up to the full line on the reserve tank.
3. INSPECT FOR COOLANT LEAK (for Engine) . Refer to «ON-VEHICLE INSPECTION - Step 1»(/toyota/prius-v/i-2011-2014/remont/cooling-system-mechanical/#engine-cooling-system-inspection)

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. REMOVE INLET AIR CLEANER ASSEMBLY . Refer to «REMOVAL - Step 25»(/toyota/prius-v/i-2011-2014/remont/mechanical/#engine-mechanical-service-information)
2. DRAIN COOLANT (for Engine) See step 1
3. REMOVE ENGINE WATER PUMP ASSEMBLY Disconnect the connector from the engine water pump assembly. Remove the 5 bolts and engine water pump assembly. Remove the gasket from the engine water pump assembly.

Scheme 9

1. INSTALL ENGINE WATER PUMP ASSEMBLY Install a new gasket. HINT: Be sure to clean the contact surfaces. Install the engine water pump assembly with the 5 bolts. Bolt A Torque: 26 N*m (260 kgf*cm, 19 ft.*lbf) Bolt B Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Bolt Length Item Length Bolt A 35 mm (1.38 in.) Bolt B 18 mm (0.709 in.) Connect the connector to the engine water pump assembly.
2. INSTALL INLET AIR CLEANER ASSEMBLY . Refer to «INSTALLATION - Step 67»(/toyota/prius-v/i-2011-2014/remont/mechanical/#engine-mechanical-service-information)
3. ADD COOLANT (for Engine) See step 2
4. INSPECT FOR COOLANT LEAK (for Engine) . Refer to «ON-VEHICLE INSPECTION - Step 1»(/toyota/prius-v/i-2011-2014/remont/cooling-system-mechanical/#engine-cooling-system-inspection)

Scheme 10

Scheme 11

Scheme 12

1. DRAIN COOLANT (for Engine) See step 1
2. REMOVE ENGINE COOLANT TEMPERATURE SENSOR Disconnect the connector. Using a union nut wrench (19 mm), remove the engine coolant temperature sensor. NOTE: Do not apply any excessive force to the heater pipe when removing the engine coolant temperature sensor.

Scheme 13

1. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Condition Specified Condition Approximately 20°C (68°F) 2.32 to 2.59 kohms Approximately 80°C (176°F) 0.310 to 0.326 kohms NOTE: When checking the engine coolant temperature sensor in water, keep the terminals dry. After the check, dry the engine coolant temperature sensor. If the resistance is not as specified, replace the engine coolant temperature sensor.

INSTALLATION

1. INSTALL ENGINE COOLANT TEMPERATURE SENSOR Using a union nut wrench (19 mm), install the engine coolant temperature sensor. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) NOTE: Do not apply any excessive force to the heater pipe when installing the engine coolant temperature sensor. Connect the connector.
2. ADD COOLANT (for Engine) See step 2
3. INSPECT FOR COOLANT LEAK (for Engine) . Refer to «ON-VEHICLE INSPECTION - Step 1»(/toyota/prius-v/i-2011-2014/remont/cooling-system-mechanical/#engine-cooling-system-inspection)

Scheme 14

Scheme 15

Scheme 16

Scheme 17

1. REMOVE INLET AIR CLEANER ASSEMBLY . Refer to «REMOVAL - Step 25»(/toyota/prius-v/i-2011-2014/remont/mechanical/#engine-mechanical-service-information)
2. REMOVE ENGINE OIL LEVEL DIPSTICK GUIDE SUB-ASSEMBLY . Refer to «REMOVAL - Step 4»(/toyota/prius-v/i-2011-2014/remont/mechanical/#engine-mechanical-service-information)
3. DRAIN COOLANT (for Engine) See step 1
4. REMOVE WATER INLET WITH THERMOSTAT SUB-ASSEMBLY Disconnect the No. 2 radiator hose and No. 3 water by-pass hose. TEXT IN ILLUSTRATION *1 No. 2 Radiator Hose *2 No. 3 Water By-pass Hose NOTE: Do not apply force to the water inlet with thermostat sub-assembly when disconnecting the No. 3 water by-pass hose. Do not damage the water inlet with thermostat sub-assembly. HINT: When disconnecting the No. 3 water by-pass hose, pinch the hose clamp, rotate the hose and pull it straight off the pipe. Remove the 2 nuts, bolt and water inlet with thermostat sub-assembly. Remove the gasket from the water inlet with thermostat sub-assembly.

Scheme 18

Scheme 19

1. INSPECT WATER INLET WITH THERMOSTAT SUB-ASSEMBLY Immerse the water inlet with thermostat sub-assembly in water and then gradually heat the water. Check the valve opening temperature of the water inlet with thermostat sub-assembly. Valve opening temperature 80 to 84°C (176 to 183°F) HINT: If the valve opening temperature is not as specified, replace the water inlet with thermostat sub-assembly. Check the valve lift. TEXT IN ILLUSTRATION *1 Valve Lift Valve lift 10 to 14 mm (0.394 to 0.551 in.) at 95°C (203°F) HINT: If the valve lift is not as specified, replace the water inlet with thermostat sub-assembly. Check that the valve is fully closed when the water inlet with thermostat sub-assembly is at low temperatures (below 77°C (171°F)). HINT: If it is not fully closed, replace the water inlet with thermostat sub-assembly.

1. INSTALL WATER INLET WITH THERMOSTAT SUB-ASSEMBLY Install a new gasket on the water inlet with thermostat sub-assembly. Install the water inlet with thermostat sub-assembly with the 2 nuts and bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the No. 2 radiator hose and No. 3 water by-pass hose.
2. ADD COOLANT (for Engine) See step 2
3. INSPECT FOR COOLANT LEAK (for Engine) . Refer to «ON-VEHICLE INSPECTION - Step 1»(/toyota/prius-v/i-2011-2014/remont/cooling-system-mechanical/#engine-cooling-system-inspection)
4. INSTALL ENGINE OIL LEVEL DIPSTICK GUIDE SUB-ASSEMBLY . Refer to «INSTALLATION - Step 13»(/toyota/prius-v/i-2011-2014/remont/mechanical/#engine-mechanical-service-information)
5. INSTALL INLET AIR CLEANER ASSEMBLY . Refer to «INSTALLATION - Step 67»(/toyota/prius-v/i-2011-2014/remont/mechanical/#engine-mechanical-service-information)

Scheme 20

Scheme 21

1. REMOVE FRONT EXHAUST PIPE ASSEMBLY Refer to «REMOVAL»(/toyota/prius-v/i-2011-2014/remont/exhaust/#exhaust-system-service-information)
2. DRAIN COOLANT (for Engine) See step 1
3. REMOVE EXHAUST PIPE GAS CONTROL ACTUATOR SUB-ASSEMBLY Remove the 5 bolts and exhaust pipe gas control actuator sub-assembly with the exhaust by-pass pipe installed. NOTE: When removing the exhaust pipe gas control actuator sub-assembly, use caution because coolant may spill out from the exhaust heat recirculation system. Do not apply any excessive force to the exhaust by-pass pipe when removing the exhaust pipe gas control actuator sub-assembly. Remove the exhaust by-pass pipe from the exhaust pipe gas control actuator sub-assembly.

Scheme 22

Scheme 23

1. INSTALL EXHAUST PIPE GAS CONTROL ACTUATOR SUB-ASSEMBLY Install the exhaust by-pass pipe to the exhaust pipe gas control actuator sub-assembly. NOTE: When reusing the exhaust by-pass pipe, inspect the O-ring. If the O-ring has scratches or cuts, replace the exhaust by-pass pipe. Install the exhaust pipe gas control actuator sub-assembly and exhaust by-pass pipe with the 5 bolts. Bolt A Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) Bolt B Torque: 8.5 N*m (87 kgf*cm, 75 in.*lbf) NOTE: Do not apply any excessive force to the exhaust by-pass pipe when installing the exhaust pipe gas control actuator sub-assembly. When replacing the exhaust pipe gas control actuator sub-assembly with a new one: Remove the spacer from the new exhaust pipe gas control actuator sub-assembly. TEXT IN ILLUSTRATION *1 Spacer HINT: The spacer is provided with a new exhaust pipe gas control actuator sub-assembly.
2. INSTALL FRONT EXHAUST PIPE ASSEMBLY Refer to «INSTALLATION»(/toyota/prius-v/i-2011-2014/remont/exhaust/#exhaust-system-service-information)
3. ADD COOLANT (for Engine) See step 2
4. INSPECT FOR COOLANT LEAK (for Engine) . Refer to «ON-VEHICLE INSPECTION - Step 1»(/toyota/prius-v/i-2011-2014/remont/cooling-system-mechanical/#engine-cooling-system-inspection)

Scheme 24

Scheme 25

Scheme 26

1. INSPECT COOLING FAN MOTOR Check that the motor operates smoothly when the auxiliary battery is connected to the cooling fan motor connector. TEXT IN ILLUSTRATION *1 Component without harness connected (to Cooling Fan Motor) Clamp the 400 A probe of an ammeter over the M+ wire of the cooling fan motor. Measure the current while the motor is operating. Standard Current Item Condition Specified Condition Cooling fan motor 20°C (68°F) at 12 V 7.4 to 11.4 A If the result is not as specified, replace the cooling fan motor.
2. INSPECT NO. 2 COOLING FAN MOTOR Check that the motor operates smoothly when the auxiliary battery is connected to the No. 2 cooling fan motor connector. TEXT IN ILLUSTRATION *1 Component without harness connected (to No. 2 Cooling Fan Motor) Clamp the 400 A probe of an ammeter over the M+ wire of the No. 2 cooling fan motor. Measure the current while the motor is operating. Standard Current Item Condition Specified Condition No. 2 cooling fan motor 20°C (68°F) at 12 V 4.7 to 8.7 A If the result is not as specified, replace the No. 2 cooling fan motor.

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. REMOVE RADIATOR ASSEMBLY HINT: Refer to «REMOVAL»(/toyota/prius-v/i-2011-2014/remont/cooling-fan/#engine-cooling-system-service-information)
2. REMOVE NO. 2 FAN Remove the nut and No. 2 fan.
3. REMOVE FAN Remove the nut and fan.
4. REMOVE NO. 2 COOLING FAN MOTOR Remove the 3 screws and No. 2 cooling fan motor.
5. REMOVE COOLING FAN MOTOR Disconnect the 5 clamps. NOTE: Be careful not to damage the connector. Remove the 3 screws and cooling fan motor.

1. INSTALL COOLING FAN MOTOR Install the cooling fan motor with the 3 screws. Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf) Connect the 5 clamps. NOTE: Be careful not to damage the connector.
2. INSTALL NO. 2 COOLING FAN MOTOR Install the No. 2 cooling fan motor with the 3 screws. Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)
3. INSTALL FAN Install the fan with the nut. Torque: 6.3 N*m (64 kgf*cm, 56 in.*lbf)
4. INSTALL NO. 2 FAN Install the No. 2 fan with the nut. Torque: 6.3 N*m (64 kgf*cm, 56 in.*lbf)
5. INSTALL RADIATOR ASSEMBLY HINT: Refer to «INSTALLATION»(/toyota/prius-v/i-2011-2014/remont/cooling-fan/#engine-cooling-system-service-information)

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

1. CHECK RESERVE TANK CAP (for Engine) Measure the valve opening pressure. If there are water stains or foreign matter on O-ring 1, clean it with water and finger scouring. Check that O-ring 1 is not deformed, cracked or swollen. Apply engine coolant to O-ring 1 and rubber packing 2 before using a radiator cap tester. When using the cap tester, tilt it upwards 30 degrees or more. Pump the cap tester several times, and check the maximum pressure*1. TEXT IN ILLUSTRATION *1 Radiator Cap Tester *2 Reserve tank Cap *a 30° or more Pumping speed 1 pump per second HINT: *1: Even if the cap cannot maintain the maximum pressure, it is not a defect. Judgment Criterion Item Specified Condition Standard value (for brand-new cap) 94 to 122 kPa (1.0 to 1.2 kgf/cm 2 , 13.5 to 17 psi) Minimum standard value (after using cap) 79 kPa (0.8 kgf/cm 2 , 11.4 psi) If the maximum pressure is less than the minimum standard value, replace the reserve tank cap.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

1. PRECAUTION NOTE: After turning the power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notice before proceeding with work. Refer to «PRECAUTION»(/toyota/prius-v/i-2011-2014/remont/hoistjack/#introduction) .
2. REMOVE RADIATOR SUPPORT OPENING COVER . Refer to «REMOVAL - Step 1»(/toyota/prius-v/i-2011-2014/remont/exterior-body-panels/#exterior-panels-trim-service-information)
3. REMOVE DECK BOARD ASSEMBLY . Refer to «REMOVAL - Step 1»(/toyota/prius-v/i-2011-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
4. REMOVE NO. 1 DECK BOARD . Refer to «REMOVAL - Step 2»(/toyota/prius-v/i-2011-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
5. REMOVE NO. 2 DECK BOARD . Refer to «REMOVAL - Step 3»(/toyota/prius-v/i-2011-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
6. REMOVE REAR DECK FLOOR BOX . Refer to «REMOVAL - Step 4»(/toyota/prius-v/i-2011-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
7. REMOVE DECK FLOOR BOX RH . Refer to «REMOVAL - Step 5»(/toyota/prius-v/i-2011-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
8. DISCONNECT CABLE FROM NEGATIVE AUXILIARY BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(/toyota/prius-v/i-2011-2014/remont/hoistjack/#introduction__initialization) .
9. REMOVE NO. 1 ENGINE UNDER COVER
10. DRAIN COOLANT (for Engine) See step 1
11. DISCONNECT NO. 1 RADIATOR HOSE Disconnect the No. 1 radiator hose from the radiator assembly.
12. DISCONNECT NO. 2 RADIATOR HOSE Disconnect the No. 2 radiator hose from the radiator assembly.
13. REMOVE FRONT BUMPER ASSEMBLY Refer to «REMOVAL»(/toyota/prius-v/i-2011-2014/remont/exterior-body-panels/#exterior-panels-trim-service-information)
14. REMOVE MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) . Refer to «REMOVAL - Step 2»(/toyota/prius-v/i-2011-2014/remont/cruise-control-systems/#cruise-control-system-service-information)
15. REMOVE NO. 1 MILLIMETER WAVE RADAR SENSOR BRACKET (w/ Dynamic Radar Cruise Control System) . Refer to «REMOVAL - Step 11»(/toyota/prius-v/i-2011-2014/remont/ac-compressor/#air-conditioning-system-service-information)
16. REMOVE NO. 1 INVERTER BRACKET . Refer to «REMOVAL - Step 5»(/toyota/prius-v/i-2011-2014/remont/engine-control-systems/#hybrid-battery-control-system-service-information)
17. REMOVE HOOD LOCK SUPPORT SUB-ASSEMBLY Disconnect the water by-pass hose clamp from the radiator support RH. Disconnect the clamp and hood lock control cable wire. Disconnect the 2 clamps and 2 connectors. Disconnect the 2 connectors. Remove the 2 bolts, radiator support RH and radiator support LH. Remove the 2 radiator support cushions from the radiator support RH and radiator support LH. Remove the 4 bolts and hood lock support sub-assembly.
18. REMOVE AIR CLEANER CAP SUB-ASSEMBLY . Refer to «REMOVAL - Step 24»(/toyota/prius-v/i-2011-2014/remont/mechanical/#engine-mechanical-service-information)
19. REMOVE INLET AIR CLEANER ASSEMBLY . Refer to «REMOVAL - Step 25»(/toyota/prius-v/i-2011-2014/remont/mechanical/#engine-mechanical-service-information)
20. REMOVE AIR CLEANER CASE . Refer to «REMOVAL - Step 26»(/toyota/prius-v/i-2011-2014/remont/mechanical/#engine-mechanical-service-information)
21. REMOVE NO. 2 FAN SHROUD Disconnect the No. 1 water by-pass hose from the radiator assembly. Disconnect the No. 3 water by-pass hose from the radiator assembly. Disconnect the 4 clamps and No. 3 water by-pass hose from the No. 2 fan shroud. Disconnect the 4 clamps and No. 5 inverter cooling hose from the fan shroud. Remove the 2 bolts, 2 claws and No. 2 fan shroud from the radiator assembly.
22. REMOVE RADIATOR ASSEMBLY Remove the radiator assembly with the fan shroud. NOTE: Do not apply any excessive force to the radiator assembly (for inverter coolant), cooler condenser assembly or pipe when removing the radiator assembly. Remove the 2 lower radiator supports. Remove the 2 bolts and radiator assembly.

1. INSTALL RADIATOR ASSEMBLY Install the radiator assembly with the 2 bolts. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf) Install the 2 lower radiator supports. Install the radiator assembly with the fan shroud. NOTE: Do not apply any excessive force to the radiator assembly (for inverter coolant), cooler condenser assembly or pipe when installing the radiator assembly.
2. INSTALL NO. 2 FAN SHROUD Install the No. 2 fan shroud with the 2 bolts and 2 claws. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf) Connect the No. 5 inverter cooling hose and 4 clamps to the fan shroud. Connect the No. 3 water by-pass hose and 4 clamps to the No. 2 fan shroud. Connect the No. 3 water by-pass hose to the radiator assembly. Connect the No. 1 water by-pass hose to the radiator assembly.
3. INSTALL AIR CLEANER CASE . Refer to «INSTALLATION - Step 66»(/toyota/prius-v/i-2011-2014/remont/mechanical/#engine-mechanical-service-information)
4. INSTALL INLET AIR CLEANER ASSEMBLY . Refer to «INSTALLATION - Step 67»(/toyota/prius-v/i-2011-2014/remont/mechanical/#engine-mechanical-service-information)
5. INSTALL AIR CLEANER CAP SUB-ASSEMBLY . Refer to «INSTALLATION - Step 68»(/toyota/prius-v/i-2011-2014/remont/mechanical/#engine-mechanical-service-information)
6. INSTALL HOOD LOCK SUPPORT SUB-ASSEMBLY Install the hood lock support sub-assembly with the 4 bolts. Torque: 13 N*m (133 kgf*cm, 10 ft.*lbf) Install the 2 radiator support cushions to the radiator support RH and radiator support LH. Install the radiator support RH and radiator support LH with the 2 bolts. Torque: 19 N*m (194 kgf*cm, 14 ft.*lbf) Connect the 2 connectors. Connect the 2 clamps and 2 connectors. Connect the hood lock control cable wire and clamp. Connect the clamp to the radiator support RH.
7. INSTALL NO. 1 INVERTER BRACKET . Refer to «INSTALLATION - Step 14»(/toyota/prius-v/i-2011-2014/remont/engine-control-systems/#hybrid-battery-control-system-service-information)
8. INSTALL NO. 1 MILLIMETER WAVE RADAR SENSOR BRACKET (w/ Dynamic Radar Cruise Control System) . Refer to «INSTALLATION - Step 9»(/toyota/prius-v/i-2011-2014/remont/ac-compressor/#air-conditioning-system-service-information)
9. INSTALL MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) . Refer to «INSTALLATION - Step 1»(/toyota/prius-v/i-2011-2014/remont/cruise-control-systems/#cruise-control-system-service-information)
10. INSTALL FRONT BUMPER ASSEMBLY Refer to «INSTALLATION»(/toyota/prius-v/i-2011-2014/remont/exterior-body-panels/#exterior-panels-trim-service-information)
11. CONNECT NO. 2 RADIATOR HOSE Connect the No. 2 radiator hose to the radiator assembly.
12. CONNECT NO. 1 RADIATOR HOSE Connect the No. 1 radiator hose to the radiator assembly.
13. CONNECT CABLE TO NEGATIVE AUXILIARY BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(/toyota/prius-v/i-2011-2014/remont/hoistjack/#introduction__initialization) .
14. ADD COOLANT (for Engine) See step 2
15. INSPECT FOR COOLANT LEAK (for Engine) . Refer to «ON-VEHICLE INSPECTION - Step 1»(/toyota/prius-v/i-2011-2014/remont/cooling-system-mechanical/#engine-cooling-system-inspection)
16. INSTALL NO. 1 ENGINE UNDER COVER
17. INSTALL DECK FLOOR BOX RH . Refer to «INSTALLATION - Step 55»(/toyota/prius-v/i-2011-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
18. INSTALL REAR DECK FLOOR BOX . Refer to «INSTALLATION - Step 56»(/toyota/prius-v/i-2011-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
19. INSTALL NO. 1 DECK BOARD . Refer to «INSTALLATION - Step 57»(/toyota/prius-v/i-2011-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
20. INSTALL NO. 2 DECK BOARD . Refer to «INSTALLATION - Step 58»(/toyota/prius-v/i-2011-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
21. INSTALL DECK BOARD ASSEMBLY . Refer to «INSTALLATION - Step 59»(/toyota/prius-v/i-2011-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
22. INSTALL RADIATOR SUPPORT OPENING COVER . Refer to «INSTALLATION - Step 2»(/toyota/prius-v/i-2011-2014/remont/exterior-body-panels/#exterior-panels-trim-service-information)

Scheme 54

Scheme 55

1. INSPECT FAN NO. 1 RELAY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Auxiliary battery voltage is not applied between terminals 1 and 2 10 kohms or higher 3 - 5 Auxiliary battery voltage is applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the fan No. 1 relay.
2. INSPECT FAN NO. 2 RELAY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 4 Auxiliary battery voltage is not applied between terminals 1 and 2 Below 1 ohms 3 - 4 Auxiliary battery voltage is applied between terminals 1 and 2 10 kohms or higher 3 - 5 Auxiliary battery voltage is not applied between terminals 1 and 2 10 kohms or higher 3 - 5 Auxiliary battery voltage is applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the fan No. 2 relay.
3. INSPECT FAN NO. 3 RELAY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Auxiliary battery voltage is not applied between terminals 1 and 2 10 kohms or higher 3 - 5 Auxiliary battery voltage is applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the fan No. 3 relay.
