Introduction (Base): Other Toyota Prius Plug-in

CUSTOMIZE PARAMETERS

Note. When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting.

HINT

The following items can be customized.

1. POWER DOOR LOCK CONTROL SYSTEM Customizing with the Techstream DOOR LOCK Display Default Content Setting Unlock Key Twice ON Function that unlocks only the driver door when the driver door key cylinder is turned to unlock once, and unlock all doors when it is turned to unlock twice. For the OFF setting, turning it once unlocks all doors. ON or OFF Auto Lock ON*1 OFF*2 Function that locks all doors when the vehicle speed reaches a certain level. ON or OFF Auto Lock/Shift ON*2 OFF*1 Function that locks all doors when the shift lever is moved to select another shift state with park (P) selected, the power switch on (READY) and all doors closed. ON or OFF Auto Unlock/Shift ON Function that unlocks all doors when the P position switch (transmission shift main switch) is pushed with a shift state other than park (P) selected and the power switch on (READY). ON or OFF All Unlock/Open-Close OFF Function that unlocks the other doors when the driver door is opened within 10 seconds after the power switch is turned off. ON or OFF *1: for Korea *2: except Korea ILLUMINATED ENTRY Display Default Content Setting Lighting Time 15 s Function that changes the lighting time after closing all doors. (It will quickly fade out in case of turning the power switch from off to on (ACC) or (IG)) 7.5 s, 15 s or 30 s Customizing with the Multi-display (w/ Navigation System (for Navigation Receiver Type) or w/ Audio and Visual System (w/o Daytime Running Light)) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle / Vehicle Settings / Door Lock Settings. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Unlock on Second Key Turn On Function that unlocks only the driver door when the driver door key cylinder is turned to unlock once, and unlocks all doors when it is turned to unlock twice. For the OFF setting, turning it once unlocks all doors. On or Off Main body ECU (Multiplex network body ECU) Auto Lock by Speed On*1 Off*2 Function that locks all doors when the vehicle speed reaches a certain level. On or Off Main body ECU (Multiplex network body ECU) Auto Lock by Shift from P On*2 Off*1 Function that locks all doors when the shift lever is moved to select another shift state with park (P) selected, the power switch on (READY) and all doors closed. On or Off Main body ECU (Multiplex network body ECU) Auto Unlock by Shift to P On Function that unlocks all doors when the P position switch (transmission shift main switch) is pushed with a shift state other than park (P) selected and the power switch on (READY). On or Off Main body ECU (Multiplex network body ECU) Auto Unlock by Driver Door Off Function that unlocks the other doors when the driver door is opened within 10 seconds after the power switch is turned off. On or Off Main body ECU (Multiplex network body ECU) *1: for Korea *2: except Korea Customizing with the Multi-display (w/ Navigation System (for Radio and Display Type) or w/ Audio and Visual System (w/ Daytime Running Light)) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle / Vehicle Customization / Door Lock Settings. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Speed Sensitive Auto Lock Off Function that locks all doors when the vehicle speed reaches a certain level. On or Off Main body ECU (Multiplex network body ECU) Shift-Linked Auto Lock On Function that locks all doors when the shift lever is moved to select another shift state with park (P) selected, the power switch on (READY) and all doors closed. On or Off Main body ECU (Multiplex network body ECU) Shift-Linked Auto Unlock On Function that unlocks all doors when the P position switch (transmission shift main switch) is pushed with a shift state other than park (P) selected and the power switch on (READY). On or Off Main body ECU (Multiplex network body ECU)
2. WIRELESS DOOR LOCK CONTROL SYSTEM Customizing with the Techstream WIRELESS DOOR LOCK CONTROL SYSTEM Display (item) Default Function Setting Wireless Control ON Function that turns wireless door lock function on or off ON or OFF Hazard Answer Back ON When the doors are locked by wireless operation, the hazard warning lights flash once. When the doors are unlocked by wireless operation, the hazard warning lights flash twice. ON or OFF Open Door Warning ON The buzzer sounds when lock is pressed when any of the doors are ajar. ON or OFF Unlock 2 Operation ON Function that unlocks driver door when unlock switch on transmitter is pressed once, and unlocks all doors when pressed twice. If setting is OFF, pressing unlock switch once makes all doors unlock. ON or OFF Panic Function ON Function to operate theft deterrent system by continuously pressing panic switch on transmitter for 0.8 seconds ON or OFF Auto Lock Time 60 s*1 or 30 s*2 Function that regulates the interval between unlocking and automatic relocking of doors 30 s, 60 s or 120 s Wireless Auto Lock ON This function turns the wireless auto lock function on or off. ON or OFF Wireless Buzzer Resp ON Wireless door lock buzzer response ON or OFF Wireless Buzzer Vol Level7 Wireless door lock buzzer volume Level7, Level6, Level5, Level4, Level3, Level2, Level1 or Level0 *1: except for Korea *2: for Korea ILLUMINATED ENTRY Display Default Content Setting Lighting Time 15 s Changes the lighting time after closing all doors. (It will quickly fade out in case of turning the power switch from off to on (ACC or IG).) 7.5 s, 15 s or 30 s Customizing with the Multi-display (w/ Navigation System (for Navigation Receiver Type) or w/ Audio and Visual System (w/o Daytime Running Light)) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle / Vehicle Customization / Door Lock Settings. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Remote 2-Press Unlock On Function that unlocks driver door when unlock switch on electrical key transmitter sub-assembly is pressed once, and unlocks all doors when pressed twice. If setting is Off, pressing unlock switch once makes all doors unlock. On or Off Main body ECU (Multiplex network body ECU) Auto Relock Timer 60 s*1 30 s*2 Function that regulates the interval between unlocking and automatic relocking of doors 30 s, 60 s or 120 s Main body ECU (Multiplex network body ECU) Lock/Unlock Feedback-Lights On When the doors are locked by wireless operation, the hazard warning lights flash once. When the doors are unlocked by wireless operation, the hazard warning lights flash twice. On or Off Main body ECU (Multiplex network body ECU) Lock/Unlock Feedback-Tone 7 Wireless door lock buzzer volume Off, 1, 2, 3, 4, 5, 6 or 7 Main body ECU (Multiplex network body ECU) *1: except Korea *2: for Korea Customizing with the Multi-display (w/ Navigation System (for Radio and Display Type) or w/ Audio and Visual System (w/ Daytime Running Light)) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle / Vehicle Settings. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Remote 2-Press Unlock On Function that unlocks driver door when unlock switch on electrical key transmitter sub-assembly is pressed once, and unlocks all doors when pressed twice. If setting is Off, pressing unlock switch once makes all doors unlock. On or Off Main body ECU (Multiplex network body ECU) Lock Feedback Volume 7 Wireless door lock buzzer volume Off, 1, 2, 3, 4, 5, 6 or 7 Main body ECU (Multiplex network body ECU)
3. SMART KEY SYSTEM (for Entry Function) Customizing with the Techstream SMART KEY / ACCESS Tester Display Default Content Setting Park Wait Time 2.5 s Function that sets waiting time to permit opening door after door is locked with entry lock function 0.5 s, 1.5 s, 2.5 s or 5 s Ignition Available Area All Function that switches the entry hybrid vehicle control system start detection area Front or All*1 Back Door Opening Operation*2 Long Function that opens the back door when the driver has the key and presses back door opener switch assembly (opener switch) Long, Twice or OFF Door Unlock Mode*2, *3 Driver Function that chooses the doors to be operated by entry unlock operation All or Driver Touch Activation Over Threshold Active The function that limits the consecutive entry lock operation to only 2 times can be changed between Active and Not Active. When in Not Active mode, there is no limit for the number of times that the consecutive entry lock operation can be performed. Active or Not Active *1: Weak radio waves will still be emitted from oscillators other than the front oscillator even when the "Front" customize setting is selected. *2: w/ Entry System Back Door Open Function *3: except for Korea and Mexico WARNING Tester Display Default Content Setting Key Low Battery Warning ON Function that warns driver that the key battery is weak ON or OFF Customizing with the multi-display (w/ Navigation System (for Navigation Receiver Type) or w/ Audio and Visual System (w/o Daytime Running Light)) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle / Vehicle Customization / Door Lock Setting. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Select Doors to Unlock Driver's Door Function that sets which doors are unlocked by the entry unlock function. All Doors or Driver's Door Certification ECU (smart key ECU assembly) Key System with Elec. Key*1 Entry and Start System*2 On Function that enables or disables the smart key system. On or Off Certification ECU (smart key ECU assembly) *1: except Korea *2: for Korea Customizing with the multi-display (w/ Navigation System (for Radio and Display Type) or w/ Audio and Visual System (w/ Daytime Running Light)) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Key System with Elec. Key*1 Entry and Start System*2 On Function that enables or disables the smart key system. On or Off Certification ECU (smart key ECU assembly) *1: except Korea *2: for Korea
4. ENTRY UNLOCK MODE SWITCHING* (SMART KEY SYSTEM (for Entry Function)) *: except for Korea and Mexico Check that the power source mode is OFF and the LED on the key is not blinking. Press the LOCK button and one of the other buttons on the key at the same time for approximately 5 seconds while the key is in the actuation area. Driver door unlock default setting: When the switches are pressed and held for 5 seconds, the entry door unlock mode changes to the mode that is not currently selected. NOTE: After pressing and holding the switches for 5 seconds, wait 5 seconds before performing the same procedure again. Driver door unlock mode: When the driver door touch sensor is touched, only the driver door unlocks. When another touch sensor is touched, all doors unlock.* *: w/ Entry System Back Door Open Function All door unlock mode: When any touch sensor is touched, all doors unlock. The certification ECU (smart key ECU assembly) receives this signal from the door control receiver assembly and changes the smart key system to entry unlock mode. The certification ECU (smart key ECU assembly) sounds the buzzers of the wireless door lock buzzer assembly. Mode Wireless Door Lock Buzzer Assembly Driver Door (Default) Sounds 3 times All Doors (Customized) Sounds 2 times HINT: The procedure only changes entry unlock mode of the smart key system. It does not switch the unlocking of the wireless door lock control.
5. ELECTRICAL KEY CANCEL (SMART KEY SYSTEM (for Entry Function)) The electrical key cancel operation disables the following functions: Entry Unlock/Lock Entry Hybrid Vehicle Control System Start Entry System Back Door Open Function* *: w/ Entry System Back Door Open Function Electrical Key Lock-in Prevention Warning The operation procedure is as follows: Precondition: Power switch off, driver door closed and unlocked. Push the unlock switch of the key once. Open the driver door within 5 seconds. Push the unlock switch of the key twice within 5 seconds. Close and open the driver door twice within 30 seconds. (Driver door: Close --> Open --> Close --> Open) Push the unlock switch of the key twice within 5 seconds. Close and open the driver door within 30 seconds. (Driver door: Close --> Open) Close the driver door within 5 seconds. When electrical key cancel is activated, the wireless door lock buzzer sounds twice. To return to the original condition, perform the procedure again. When the original condition is returned, the wireless door lock buzzer sounds once.
6. SMART KEY SYSTEM (for Start Function) Customizing with the Techstream SMART KEY / ACCESS Tester Display Default Content Setting Ignition Available Area (Entry ignition available area) All Function to choose the available area for electrical key to start the hybrid control system. Front or All* *: Weak radio waves will still be emitted from oscillators other than the front oscillator even when the "Front" customize setting is selected. Customizing with the multi-display (w/ Navigation System (for Navigation Receiver Type) or w/ Audio and Visual System (w/o Daytime Running Light)) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle / Vehicle Customization / Door Lock Setting. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Key System with Elec. Key*1 Entry and Start System*2 On Function that enables or disables the smart key system. On or Off Certification ECU (smart key ECU assembly) *1: except Korea *2: for Korea Customizing with the multi-display (w/ Navigation System (for Radio and Display Type) or w/ Audio and Visual System (w/ Daytime Running Light)) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Key System with Elec. Key*1 Entry and Start System*2 On Function that enables or disables the smart key system. On or Off Certification ECU (smart key ECU assembly) *1: except Korea *2: for Korea
7. CUSTOMIZING FUNCTION WITHOUT TECHSTREAM (SMART KEY SYSTEM (for Start Function)) Performing the following procedure disables the smart key system. HINT: To start the hybrid control system while the smart key system is disabled, follow the procedure for when the key battery is low. Refer to «SYSTEM DESCRIPTION»(ref-551394-S22945162632013051500000) . The operation procedure is as follows: Precondition: Power switch off, driver door closed and unlocked. Push the unlock switch of the key once. Open the driver door within 5 seconds. Push the unlock switch of the key twice within 5 seconds. Close and open the driver door twice within 30 seconds. (Driver door: Close --> Open --> Close --> Open) Push the unlock switch of the key twice within 5 seconds. Close and open the driver door within 30 seconds. (Driver door: Close --> Open) Close the driver door within 5 seconds. When electrical key cancel is activated, the wireless door lock buzzer sounds twice. To return to the original condition, perform the procedure again. When the original condition is returned, the wireless door lock buzzer sounds once.
8. LIGHTING SYSTEM (LIGHTING INT) Customizing with the Techstream ILLUMINATED ENTRY Tester Display Default Content Setting Relevant ECU Lighting Time 15 s Changes the lighting time after closing all of the doors. (It will fade out immediately in case of turning the power switch from off to on (ACC or IG).) 7.5 s, 15 s or 30 s Main body ECU (Multiplex network body ECU) I/L when ACC OFF ON Lights up power switch illumination, front interior lights, rear interior light and footwell lights when the power switch is turned from on (ACC or IG) to off. ON or OFF I/L ON W/Door Key Unlock ON Lights up power switch illumination, front interior lights, rear interior light and footwell lights when doors are unlocked using a mechanical key or door control transmitter. ON or OFF Light Control ON Dims (ON setting) or turns off (OFF setting) the footwell lights under the following conditions: Power switch on (IG), shift lever not in P, and all doors closed. ON or OFF Room Light when Aprchd ON Lights up the power switch illumination, front interior lights, rear interior light and footwell lights when a key enters any actuation area around the doors. ON or OFF Inside Foot Light ON ON/OFF of footwell light control function. ON or OFF Customizing with the multi-display (w/ Navigation System (for Navigation Receiver Type) or w/ Audio and Visual System (w/o Daytime Running Light)) Turn the power switch on (IG). Enter the following menus: Setup / Vehicle / Vehicle Customization / Light Settings. Select the setting by referring to the table below. LIGHT SETTINGS Display Default Content Setting Relevant ECU Interior Lights Off Timer 15 sec. Changes the lighting time after closing all of the doors. (It will fade out immediately in case of turning the power switch from off to on (ACC or IG).) Off, 7.5 sec., 15 sec., or 30 sec. Main body ECU (Multiplex network body ECU)
9. METER / GAUGE SYSTEM WARNING Tester Display Default Content Setting Key Remind Sound Slow Function to change the cycle of the key reminder buzzer Normal, Fast or Slow Driver Side Seatbelt Warning Buzzer*1 ON Function to turn on/off the seat belt warning buzzer ON or OFF Front Passenger Side Seatbelt Warning Buzzer*1 ON Function to turn on/off the seat belt warning buzzer ON or OFF Rear Seatbelt Warning Buzzer*2 ON Function to turn on/off the rear seat belt warning buzzer ON or OFF Reverse Buzzer Continual Function to change the type of the reverse warning buzzer Single or Continual *1: This setting is only valid for the buzzer which sounds at 20 km/h (12 mph) or more. *2: w/ Rear Seat Belt Warning
10. SEAT BELT WARNING SYSTEM COMBINATION METER Tester Display Default Content Setting Driver Side Seatbelt Warning Buzzer ON Function to sound the seat belt warning buzzer ON / OFF Front Passenger Side Seatbelt Warning Buzzer ON Function to sound the seat belt warning buzzer ON / OFF HINT: This setting is only valid when the vehicle is driven at 20 km/h (12 mph) or more.
11. AIR CONDITIONING SYSTEM Customizing with the Techstream AIR CONDITIONER Display (Item) Default Content Setting Set Temperature Shift Normal Function to control with the shifted temperature against the displayed temperature. -2C, -1C, Normal, +1C, +2C Compressor Mode*3 Automatic Function to automatically turn the A/C on by pressing the AUTO button when blower is on and the A/C is off. Manual or Automatic Air inlet Mode*2 Automatic In case of turning the A/C ON to cool the cabin down quickly, this is the function to change the mode automatically to RECIRCULATION mode Manual or Automatic Foot/DEF Auto Mode ON Function to automatically turn the airflow from FOOT/DEF on when AUTO mode is on. ON or OFF Foot/DEF Automatic Blow Up Function ON Function to automatically increase the blower level when the defroster is on. ON or OFF Ambient Temperature Shift Normal Function to control the shifted ambient temperature in relation to the displayed ambient temperature. -3C, -2C, -1C, Normal, +1C, +2C, +3C ECO MODE Cancel OFF Function to cancel the ECO mode drive when item is on. OFF or ON Noise and Vibration Reduction OFF Function to change speed of the compressor when item is on. OFF or ON Start Pre A/C*1 Long1 Function to set the activation operation method for the remote air conditioning system using the key (electrical transmitter). 1 tim ON, 2 tim ON, Long1 or Long2 Stop Pre A/C*1 2 tim ON Function to set the stop operation method for the remote air conditioning system using the key (electrical transmitter). 1 tim ON, 2 tim ON, Long1 or Long2 *1: w/ Remote Air Conditioning System *2: for Korea and Mexico *3: except Korea and Mexico Customizing with the multi-display (w/ Navigation System (for Navigation Receiver Type) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle / Vehicle Settings / Climate Settings. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Auto A/C Mode*2 On Function to automatically turn the A/C on by pressing the AUTO button when blower is on and the A/C is off On or Off Air conditioning amplifier assembly Efficient Ventilation Mode*1 On In case of turning the A/C ON to cool the cabin down quickly, this is the function to change the mode automatically to RECIRCULATION mode On or Off Air conditioning amplifier assembly *1: for Korea *2: except Korea
12. POWER WINDOW CONTROL SYSTEM POWER WINDOW Tester Display Default Content Setting Relevant ECU P Window Auto Up Avail This function is used to enable or disable the auto up function for the front passenger door window using the power window regulator switch assembly (for front passenger door). Not Avl/Avail Power window ECU (Power window regulator motor assembly) P Window Auto Up From Driver Avail This function is used to enable or disable the remote auto up function for the front passenger door window using the multiplex network master switch assembly. Not Avl/Avail Power window ECU (Power window regulator motor assembly) RR Window Auto Up Avail This function is used to enable or disable the auto up function using the power window regulator switch assembly (for rear RH door). Not Avl/Avail Power window ECU (Power window regulator motor assembly) RR Window Auto Up From Driver Avail This function is used to enable or disable the remote auto up function for the rear RH door window using the multiplex network master switch assembly. Not Avl/Avail Power window ECU (Power window regulator motor assembly) RL Window Auto Up Avail This function is used to enable or disable the auto up function using the power window regulator switch assembly (for rear LH door). Not Avl/Avail Power window ECU (Power window regulator motor assembly) RL Window Auto Up From Driver Avail This function is used to enable or disable the remote auto up function for the rear LH door window using the multiplex network master switch assembly. Not Avl/Avail Power window ECU (Power window regulator motor assembly)
13. LIGHTING SYSTEM (LIGHTING EXT) Customizing with the Techstream LIGHT CONTROL Display Default Content Setting Relevant ECU Disp Ex ON Sen Normal Changes the ambient brightness level required to dim the lights such as the indicator lights of the combination meter, A/C indicator light and clock.*A Light2, Light1, Normal, Dark1 or Dark2 Main Body ECU (Multiplex Network Body ECU) Disp Ex OFF Sen Normal Changes the ambient brightness level required to cancel the dimming of the lights such as the indicator lights of the combination meter, A/C indicator light and clock.*B Light2, Light1, Normal, Dark1 or Dark2 Light Auto OFF Delay 30 s Keeps the headlights on for a certain period of time after turning the power switch off and closing all the doors with the low beam headlights on. Off, 30 s, 60 s or 90 s Response Time*1 0.1 s Changes the delay timing of lighting the taillights when going into a tunnel when the light control switch is in the AUTO position 0.1 s or 1.0 s Sensitivity Normal Adjusts the sensitivity of the automatic light control system.*C Light2, Light1, Normal, Dark1 or Dark2 DRL Function*2 ON ON/OFF of the DRL function ON or OFF *1: w/o DRL *2: Headlight dimmer switch with DRL OFF HINT: The sensitivity adjustment may be difficult to confirm. Check by driving the customer's vehicle. *A Brightness level required to dim the lights Setting DARK2 DARK1 NORMAL LIGHT1 LIGHT2 *B Brightness level required to cancel the dimming of the lights Setting DARK2 DARK1 NORMAL LIGHT1 LIGHT2 *C Sensitivity of the automatic light control system Setting Dark2 Dark1 Normal Light1 Light2 Customizing with the multi-display (w/ Navigation System (for Navigation Receiver Type) or w/ Audio and Visual System (w/o Daytime Running Light)) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle / Vehicle Customization / Light Settings. Select the setting by referring to the table below. LIGHT SETTINGS Display Default Content Setting Relevant ECU Headlamps-On Sensitivity 0 Adjusts the sensitivity of the automatic light control system.*A -2, -1, 0, +1 or +2 Main Body ECU (Multiplex Network Body ECU) Headlamps Auto-Off Timer 30 sec. Keeps the headlights on for a certain period of time after turning the power switch off and closing all doors with the low beam headlights on. Off, 30 sec., 60 sec. or 90 sec. Daytime Running Lights*1 On ON/OFF of the DRL function On or Off *1: Headlight dimmer switch with DRL OFF function. HINT: The sensitivity adjustment may be difficult to confirm. Check by driving the customer's vehicle. *A Sensitivity of the automatic light control system Setting -2 -1 0 +1 +2 Customizing with the multi-display (w/ Navigation System (for Radio and Display Type) or w/ Audio and Visual System (w/ Daytime Running Light)) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle. Select the setting by referring to the table below. VEHICLE SETTINGS Display Default Content Setting Relevant ECU Light Sensor Sensitivity 0 Adjusts the sensitivity of the automatic light control system.*A -2, -1, 0, +1 or +2 Main Body ECU (Multiplex Network Body ECU) Headlight Off Time Adjust 30 sec. Keeps the headlights on for a certain period of time after turning the power switch off and closing all doors with the low beam headlights on. Off, 30 sec., 60 sec. or 90 sec. Daytime Running Lights*1 On ON/OFF of the DRL function On or Off *1: Headlight dimmer switch with DRL OFF function. HINT: The sensitivity adjustment may be difficult to confirm. Check by driving the customer's vehicle. *A Sensitivity of the automatic light control system Setting -2 -1 0 +1 +2

INITIALIZATION

1. PROCEDURES NECESSARY WHEN BATTERY TERMINAL IS DISCONNECTED/RECONNECTED NOTE: After the power switch is turned off, the navigation receiver assembly (for Navigation Receiver Type) or radio and display receiver assembly (w/o Daytime Running Light) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal. When the auxiliary battery is replaced or the cable is disconnected from its negative (-) battery terminal, the ISC learning value will be initialized and symptoms as a loud rattle from the hybrid vehicle transaxle assembly may occur until ISC learning is performed. Therefore, perform ISC learning when the auxiliary battery is replaced or the cable is disconnected from the negative (-) terminal of the auxiliary battery. Refer to «Loud Rattle from Hybrid Vehicle Transmission»(ref-551392-S34866440412013051500000) .
2. PROCEDURES NECESSARY WHEN ECU OR OTHER PARTS ARE REPLACED Replacement Part Necessary Procedure Effect / Inoperative Function when Necessary Procedures are not Performed See ECM Vehicle Identification Number (VIN) registration MIL comes on Refer to «REGISTRATION»(ref-551395-S23436995082013051500000) Millimeter wave radar sensor assembly Adjust millimeter wave radar sensor assembly (Dynamic radar cruise control system) Dynamic radar cruise control system Pre-collision system Refer to «ADJUSTMENT»(ref-551396-S27436209962013051500000) Lane recognition camera sensor assembly Adjust lane recognition camera sensor assembly (Lane keeping assist system) Lane keeping assist system Pre-collision system Refer to «ADJUSTMENT»(ref-551396-S02622148052013051500000) Tire pressure warning ECU Tire pressure warning valve and transmitter Code registration (Tire pressure warning system) Initialization When DTC detection conditions of "transmitter ID not received" DTC are met, TPWS indicator blinks for 1 minute, and then illuminates. Tire pressure warning function Refer to «INITIALIZATION»(ref-551397-S32489022462013051500000) for initialization Refer to «REGISTRATION»(ref-551397-S27772702662013051500000) for registration Brake booster with master cylinder (Skid control ECU, brake actuator or pressure sensor) Initialization and calibration of the linear solenoid valve Yaw rate and acceleration sensor zero point calibration ABS warning light illumination Slip indicator light illumination Brake warning light / yellow (minor malfunction) illumination VSC disabled or malfunctioning Refer to «INITIALIZATION»(ref-551398-S37327440802013051500000) for initialization Refer to «CALIBRATION»(ref-551398-S18642875902013051500000) for calibration Brake pedal stroke sensor Brake pedal Clearing stored linear solenoid valve calibration data Initialization and calibration of the linear solenoid valve ABS warning light illumination Slip indicator light illumination Brake warning light / yellow (minor malfunction) illumination VSC disabled or malfunctioning Yaw rate and acceleration sensor Clearing zero point calibration data Yaw rate and acceleration sensor zero point calibration ABS warning light illumination Slip indicator light illumination Brake warning light / yellow (minor malfunction) illumination VSC disabled or malfunctioning Power steering ECU assembly*1 Torque sensor zero point calibration Assist map writing P/S warning light comes on EPS control Refer to «CALIBRATION»(ref-551399-S40879837932013051500000) Electric power steering column sub-assembly (containing the torque sensor)*1 Torque sensor zero point calibration Steering effort is different between turning steering wheel to left and right Power steering ECU assembly*2 Rotation angle sensor initialization and torque sensor zero point calibration P/S warning light comes on EPS control Refer to «CALIBRATION»(ref-551400-S02033606252013051500000) Electric power steering column sub-assembly (containing the torque sensor)*2 Power steering motor assembly*2 Rotation angle sensor initialization and torque sensor zero point calibration Steering effort is different between turning steering wheel to left and right Rear height control sensor sub-assembly RH Perform headlight leveling ECU initialization Automatic leveling function Refer to «INITIALIZATION»(ref-551401-S35601319502013051500000) Inner rear view mirror assembly*3 Re-registration of codes in the garage door opener system Register transmitter code Rolling code systems Garage door opener system Refer to «REGISTRATION»(ref-551402-S00197618612013051500000) DCM (Telematics Transceiver) DCM activation Safety connect system Refer to «PRECAUTION»(ref-551403-S21788048362013051500000) Certification ECU (smart key ECU assembly) ID code box (immobiliser code ECU)*4 Transmission control ECU assembly Key Code registration (Engine immobiliser system) Wireless door lock control system Smart key system Hybrid start Refer to «REGISTRATION»(ref-551404-S42324304552013051500000) Occupant classification ECU Front passenger seat Zero point calibration (Occupant classification system) Sensitivity check (Occupant classification system) Occupant classification system Passenger airbag ON/OFF indicator Airbag system (Front passenger side) Seat belt warning system (Front passenger side) Refer to «INITIALIZATION»(ref-551405-S33174946942013051500000) Power window regulator motor Door window regulator Initialize power window control system Automatic door glass open/ close function Jam protection function Operation function after power switch is turned off Refer to «INITIALIZATION»(ref-551406-S32487670822013051500000) Sliding roof ECU (sliding roof drive gear sub-assembly) Sliding roof glass Sliding roof housing Initialize sliding roof ECU (pulse sensor initial position setting) Automatic open function of sliding roof Jam protection function Operation function after power switch is turned off Refer to «INITIALIZATION»(ref-551407-S18929273182013051500000) Headlight leveling ECU Suspension, tires, etc. Perform headlight leveling ECU initialization Automatic leveling function Refer to «INITIALIZATION»(ref-551401-S35601319502013051500000) *1: for Brush Type Motor *2: for Brushless Type Motor *3: w/ Garage Door Opener System *4: for Canada

Scheme 64

Scheme 65

1. INSPECTION MODE NOTE: When the vehicle is run in inspection mode for an operation such as a speedometer test, a DTC may be set. Therefore, if the warning light comes on, after canceling inspection mode, check for DTCs using the Techstream and clear the DTCs. HINT: If the engine is warmed up and the battery is charged, the engine of the vehicle will stop after the vehicle stops. For example, if the engine is required to run continuously even after the vehicle stops, such as for an ignition timing check, switch to maintenance mode. The following table shows the types of inspection modes that are available, their purpose and the control that occurs in each mode. Mode (Display) Purpose Control MAINTENANCE MODE (2WD for measuring Exhaust Gas) Inspection of ignition timing etc. when performing engine maintenance, idle speed exhaust emissions testing (CO, HC), etc. Tests using a speedometer tester, two-wheel chassis dynamometer, etc. Keeps the engine idling when park (P) is selected Cancels traction control CERTIFICATION MODE (2WD for cutting TRC) Tests using a speedometer tester, two-wheel chassis dynamometer, etc. Cancels traction control Vehicle conditions Before activating inspection mode, turn the air conditioning off, start the hybrid system with park (P) selected, and check that the engine stops within several seconds after starting (engine warm up check). Activate the appropriate inspection mode and inspect the vehicle. The shift state for each test is as follows: Test Item Mode Shift State 1. Vehicle straight travelling test (side slip inspection) Maintenance mode or normal mode D 2. Braking force test Maintenance mode N 3. Speedometer test Maintenance mode D 4. Exhaust gas test (idling) Maintenance mode P 5. Headlight test Maintenance mode or normal mode P Cancel inspection mode immediately after completion of inspection. NOTE: Driving the vehicle without canceling inspection mode may damage the transaxle. Special notes for speedometer test WARNING: Be sure to perform the test in maintenance mode. NOTE: Do not perform rapid starting or quick acceleration on a speedometer tester. If rapid starting or quick acceleration is performed on a speedometer tester, damage may occur to the transaxle. Depress the accelerator pedal slowly and gradually accelerate the vehicle. Make a measurement. After the measurement, use the brakes to gradually decelerate the vehicle. Special notes for using a chassis dynamometer Always set an appropriate load before starting the test. NOTE: Sudden acceleration or deceleration of the vehicle on a chassis dynamometer under minimal load may damage the transaxle. Activating maintenance mode (Not using the Techstream) Perform the following steps from (A) through (D) in 60 seconds. Turn the power switch on (IG). (Step A) Fully depress the accelerator pedal twice with park (P) selected. (Step B) Fully depress the accelerator pedal twice with neutral (N) selected. (Step C) Fully depress the accelerator pedal twice with park (P) selected. (Step D) Check that "MAINTENANCE MODE" is displayed on the multi-information display. Start the engine by turning the power switch on (READY) while depressing the brake pedal. HINT: The idle speed in maintenance mode is approximately 1000 rpm with park (P) selected. The engine speed increases to 1500 rpm when the accelerator pedal is depressed midway with park (P) selected. When the accelerator pedal is depressed more than midway, or when the accelerator pedal is fully depressed, the engine speed increases to approximately 2500 rpm. Activating maintenance mode (Using the Techstream) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter following menus: Powertrain / Hybrid Control / Utility / Inspection Mode - 2WD for measuring Exhaust Gas. Check that "MAINTENANCE MODE" is displayed on the multi-information display. Start the engine by turning the power switch on (READY) while depressing the brake pedal. HINT: The idle speed in maintenance mode is approximately 1000 rpm with park (P) selected. The engine speed increases to 1500 rpm when the accelerator pedal is depressed midway with park (P) selected. When the accelerator pedal is depressed more than midway, or when the accelerator pedal is fully depressed, the engine speed increases to approximately 2500 rpm. Activating certification mode (Not using the Techstream) Perform the following steps from (A) through (D) in 60 seconds. Turn the power switch on (IG). (Step A) Fully depress the accelerator pedal three times with park (P) selected. (Step B) Fully depress the accelerator pedal three times with neutral (N) selected. (Step C) Fully depress the accelerator pedal three times with park (P) selected. (Step D) Check that "CERTIFICATION MODE" is displayed on the multi-information display. Start the engine by turning the power switch on (READY) while depressing the brake pedal. Activating certification mode (Using the Techstream) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter following menus: Powertrain / Hybrid Control / Utility / Inspection Mode - 2WD for cutting TRC. Check that "CERTIFICATION MODE" is displayed on the multi-information display. Start the engine by turning the power switch on (READY) while depressing the brake pedal. Deactivating inspection mode Turn the power switch off. The HV system turns off simultaneously. NOTE: If a DTC is set during inspection mode, the master warning light will illuminate and a warning message will appear on the multi-information display. When the master warning light and the warning message illuminate during inspection mode, cancel inspection mode, and check for DTC(s). Driving the vehicle without canceling inspection mode may damage the transaxle.

GLOSSARY OF SAE AND TOYOTA TERMS

This glossary lists all SAE-J1930 terms and abbreviations used in this service information in compliance with SAE recommendations, as well as their TOYOTA equivalents.
