Cellular Communication System (Service Information) (Base): Overview Toyota Prius Plug-in

Scheme 306

Scheme 307

Scheme 308

Scheme 309

1. REMOVE UPPER INSTRUMENT PANEL ASSEMBLY HINT: Refer to the procedure up to Remove Upper Instrument Panel Assembly. Refer to «REMOVAL»(/toyota/prius-plug-in/2012-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information-base) .
2. REMOVE BACK-UP BATTERY WITH BRACKET See step 7
3. REMOVE DCM (TELEMATICS TRANSCEIVER) WITH BRACKET Disconnect the 3 connectors. Remove the 3 bolts and DCM (telematics transceiver) with bracket.
4. REMOVE NO. 2 TELEPHONE BRACKET Remove the 2 screws and No. 2 telephone bracket.
5. REMOVE NO. 3 TELEPHONE BRACKET Remove the 2 screws and No. 3 telephone bracket.
6. REMOVE DCM (TELEMATICS TRANSCEIVER)
