Smart Key System (For Entry Function) (Diagnostics - Introduction) (Plug-In): Other Toyota Prius Plug-in

PRECAUTION

Note. When disconnecting the cable from the negative (-) auxiliary battery terminal, initialize the following systems after the cable is reconnected. System Name See Procedure Power Door Lock Control System Refer to INITIALIZATION

1. PRECAUTIONS WHEN USING TECHSTREAM When using the Techstream to troubleshoot the smart key system: Connect the Techstream to the DLC3 while the power switch is off, and turn a door courtesy light switch on and off at intervals of 1.5 seconds until communication between the Techstream and vehicle begins. After all DTCs are cleared, check if the malfunction occurs again 6 seconds after the power switch is turned on (IG).
2. PRECAUTION FOR DISCONNECTING AND CONNECTING CABLE OF NEGATIVE AUXILIARY BATTERY TERMINAL Immediately after disconnecting or connecting the cable of the negative (-) auxiliary battery terminal, the doors may not be unlocked by the smart key system. In this situation, lock and unlock the doors using the wireless function. Then, it will be possible to unlock doors using the smart key system.
3. PRECAUTIONS FOR KEY BATTERY AND VEHICLE AUXILIARY BATTERY When the doors are locked, the vehicle auxiliary battery is used to transmit radio waves. The auxiliary battery may discharge if the vehicle remains stopped for a long time. If the vehicle is not to be used for a long time, remove the auxiliary battery from the vehicle or cancel the smart key system. When the doors are locked and the key is in the detection area of a door electrical key oscillator, the key battery will be depleted due to regular communication between the key and vehicle. If the vehicle is not to be used, keep the key away from the vehicle (more than 2 m (6.56 ft.) ).
4. PRECAUTION FOR KEY The key is a precision instrument. Be sure to observe the following: Do not drop the key, subject it to strong shocks or bend it. Do not keep the key in a high temperature area for a long time. Do not get the key wet or wash it in an ultrasonic washer etc. Keep the key away from magnets or magnetized items during use. Do not disassemble the key except when replacing the key battery. Do not place the key near objects that produce magnetic fields such as TVs, audio systems and electric ranges, or electrical medical equipment such as low-frequency therapy instruments.
5. PRECAUTIONS FOR SMART KEY SYSTEM (for Entry Function) INSPECTION Overall smart key system (for entry function): Make sure to carry the key. All registered keys for the vehicle should be available when repairing or diagnosing the smart key system (for entry function). The smart key system, wireless door lock control system and engine immobiliser system may not operate normally, or the size of the operation area may decrease in the following situations: HINT: This is because faint radio waves are used for key detection. When the key battery is depleted. When any facilities that generate strong radio waves or electrical noise such as a TV tower, power plant, gas station, broadcast station, video billboard or airport are located near the inspection site. When the key is located near a wireless device such as a radio, cellular phone or cordless telephone. When the key is in contact with or covered with a metal object similar to the following: Metal or aluminum plated card Aluminum film from a cigarette box Metallic wallet or bag Coins Heating pad Media such as CDs or DVDs When a wireless remote is operated near the vehicle. When the key is carried with following items: Electrical key or wireless remote from another vehicle PC or similar handheld device (PDA etc.) Digital audio player Portable game device When a metallic film is applied to the back window glass. Precautions for key detection When using the key outside the vehicle, do not keep it too close to the vehicle. Depending on the way the key is held, the key may not be detected properly and the system will not operate normally. HINT: In this situation, a warning buzzer may sound accidentally or the key confinement prevention function may not operate. Even if the key is in a detection area, it may not function normally in the following situations: When the doors are locked or unlocked with the key too close to a window or door outside handle, near the ground or in a high place When the key is on the instrument panel, floor, rear package tray, in a door pocket or the glove box Precautions specific to the smart key system If the key is within the vehicle exterior detection area, the doors can be locked or unlocked even when a person other than the person carrying the key holds the door outside handle. However, doors other than the door that detects the key cannot be unlocked. If a large amount of water is applied to the door outside handle due to a car wash or heavy rain, and the key is within the vehicle exterior detection area, the doors may be locked or unlocked. However, even when the doors are unlocked, the doors will be locked again after approximately 30 seconds if a door is not opened. If the doors are locked using the wireless remote transmitter when the key is in the cabin or near the vehicle, it may not be possible to unlock the doors using the smart key system. In this situation, use the wireless function of the key to unlock the doors. HINT: If the doors are locked from inside the vehicle using the wireless transmitter, it would not be desirable for it to be possible to unlock the vehicle via the touch sensors on the front outside door handles. Thus, unlocking via the touch sensors is disabled because radio waves from the door electrical key oscillator might otherwise leak into the cabin, detect the key, and enable the front door outside handle touch sensors.
6. PRECAUTIONS FOR SMART DOOR UNLOCK FUNCTION When unlocking the doors, make sure to grasp the door outside handle, ensuring contact with the sensor on the inner part of the handle. Pull the handle after confirming that the door has unlocked. When attempting to open a door suddenly or immediately after entering the vehicle exterior antenna detection area, the doors may not be unlocked. If the doors are not unlocked, return the door outside handle to its original position. Pull the handle after confirming that the door has unlocked. HINT: Due to mechanical reasons the door cannot be unlocked when the handle is being pulled. If the door outside handle is grasped with gloved hands, unlocking may be delayed or may not occur. If another key is in the detection area, the unlocking time may be delayed. The doors cannot be unlocked within 3 seconds after the door lock operation.
7. PRECAUTIONS FOR SMART DOOR LOCK FUNCTION Be sure to touch the lock sensor on the door outside handle (depressed portion on the handle) to lock the doors. If the doors are not locked even when the lock sensor on the door outside handle is touched, touch both the upper and lower lock sensors simultaneously. If the lock sensor is touched with gloved hands, locking may be delayed or may not occur. If water is applied to the door outside handle when washing the vehicle and carrying a key, lock and unlock operations may repeat. In this situation, keep the key more than 2 m (6.56 ft.) away from the vehicle while washing the vehicle (be aware of the potential for key theft). If water is applied to the door outside handle due to a car wash or heavy rain with a key inside the cabin, the warning message "Key Detected in Vehicle" may be displayed and a buzzer may sound outside the vehicle. In this situation, the warning message will disappear and buzzer will stop when all the doors are locked. If ice, snow or dirt adheres to a lock sensor surface, the sensor may not react. In this situation, remove the ice, snow or dirt and touch the sensor again or touch the lock sensor on the lower part of the handle.

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

1. w/ Entry System Back Door Open Function: COMMUNICATION TABLE Transmitting ECU (Transmitter) Receiving ECU Signal Communication Method Main body ECU (multiplex network body ECU) Certification ECU (smart key ECU assembly) Courtesy light switch signal CAN Door lock output signal Door lock position switch signal Driver door key operated switch signal IG signal ACC switch signal Certification ECU (smart key ECU assembly) Main body ECU (multiplex network body ECU) Illumination light request signal CAN Light answer back signal Door lock/unlock request signal Back door output request signal Wireless door lock buzzer request signal Certification ECU (smart key ECU assembly) Combination meter assembly Meter buzzer single tone request signal CAN Meter buzzer intermittent tone request signal Meter buzzer continuous tone request signal Key loss warning signal Auto power off operation request signal Key not detected warning signal Low key battery warning signal Shift position warning signal Immobiliser system certification completion signal Emergency operation support display request signal Hybrid vehicle control system start method display request signal Combination meter assembly Certification ECU (smart key ECU assembly) Main body ECU (multiplex network body ECU) Vehicle speed signal CAN
2. w/o Entry System Back Door Open Function: COMMUNICATION TABLE Transmitting ECU (Transmitter) Receiving ECU Signal Communication Method Main body ECU (multiplex network body ECU) Certification ECU (smart key ECU assembly) Courtesy light switch signal CAN Door lock output signal Door lock position switch signal Driver door key operated switch signal IG signal ACC switch signal Certification ECU (smart key ECU assembly) Main body ECU (multiplex network body ECU) Illumination light request signal CAN Light answer back signal Door lock/unlock request signal Back door output request signal Wireless door lock buzzer request signal Certification ECU (smart key ECU assembly) Combination meter assembly Meter buzzer single tone request signal CAN Meter buzzer intermittent tone request signal Meter buzzer continuous tone request signal Key loss warning signal Auto power off operation request signal Key not detected warning signal Low key battery warning signal Shift position warning signal Immobiliser system certification completion signal Emergency operation support display request signal Hybrid vehicle control system start method display request signal Combination meter assembly Certification ECU (smart key ECU assembly) Main body ECU (multiplex network body ECU) Vehicle speed signal CAN

CUSTOMIZE PARAMETERS

1. CUSTOMIZE SMART KEY SYSTEM (for Entry Function) HINT: The items in the table below can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current setting before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. Customizing with the Techstream Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Customize Setting. Select the setting by referring to the table below. SMART KEY / ACCESS Tester Display Default Content Setting Relevant ECU Park Wait Time 2.5 s Function that sets waiting time to permit opening door after door is locked with entry lock function 0.5 s, 1.5 s, 2.5 s or 5 s Certification ECU (smart key ECU assembly) Ignition Available Area All Function that switches the entry hybrid control system start detection area Front or All*1 Certification ECU (smart key ECU assembly) Back Door Opening Operation*2 Long Function that opens the back door when the driver has the key and presses back door opener switch assembly (opener switch) Long, Twice or OFF Certification ECU (smart key ECU assembly) Door Unlock Mode Driver Function that chooses the doors to be operated by entry unlock operation All or Driver Certification ECU (smart key ECU assembly) Touch Activation Over Threshold Active The function that limits the consecutive entry lock operation to only 2 times can be changed between Active and Not Active. When in Not Active mode, there is no limit for the number of times that the consecutive entry lock operation can be performed. Active or Not Active Certification ECU (smart key ECU assembly) HINT: *1: Weak radio waves will still be emitted from antennas other than the front antenna even when the "Front" customize setting is selected. *2: w/ Entry Back Door Open Function WARNING Tester Display Default Content Setting Relevant ECU Key Low Battery Warning ON Function that warns driver that the key battery is weak ON or OFF Certification ECU (smart key ECU assembly) Customizing with the multi-display (for Navigation Receiver Type) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle / Vehicle Customization / Door Lock Setting. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Select Doors to Unlock Driver's Door Function that sets which doors are unlocked by the entry unlock function. All Doors or Driver's Door Certification ECU (smart key ECU assembly) Key System with Elec. Key On Function that enables or disables the smart key system. On or Off Certification ECU (smart key ECU assembly) Customizing with the multi-display (for Radio and Display Type) Turn the power switch on (IG). Enter the following menus: SETUP / Vehicle. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Key System with Elec. Key On Function that enables or disables the smart key system. On or Off Certification ECU (smart key ECU assembly) Entry unlock mode switching function (manual operation). Check that the power source mode is OFF and the LED on the key is not blinking. Press the LOCK switch and one of the other switches on the key at the same time for approximately 5 seconds while the key is in the detection area. Driver door unlock default setting: When the switches are pressed and held for 5 seconds, the entry door unlock mode changes to the mode that is not currently selected. NOTE: After pressing and holding the switches for 5 seconds, wait 5 seconds before performing the same procedure again. Driver door unlock mode: When the driver door touch sensor is touched, only the driver door unlocks. When another touch sensor is touched, all doors unlock. All door unlock mode: When any touch sensor is touched, all doors unlock. The certification ECU (smart key ECU assembly) receives this signal from the door control receiver and changes the smart key system to entry unlock mode. The certification ECU (smart key ECU assembly) sounds the buzzers of the wireless door lock buzzer. Mode Wireless Door Lock Buzzer Driver Door (Default) Sounds 3 times All Doors (Customized) Sounds 2 times HINT: The procedure only changes entry unlock mode of the smart key system. It does not switch the unlocking of the wireless door lock control. Entry cancel function (manual operation). The electrical key cancel operation disables the following functions: Entry Unlock/Lock Entry Hybrid Control System Start Entry System Back Door Open Function Key Lock-in Prevention Warning The operation procedure is as follows: Precondition: Power switch off, driver door closed and unlocked. Push the unlock switch of the key once. Open the driver door within 5 seconds. Push the unlock switch of the key twice within 5 seconds. Close and open the driver door twice within 30 seconds. (Driver door: Close --> Open --> Close --> Open) Push the unlock switch of the key twice within 5 seconds. Close and open the driver door within 30 seconds. (Driver door: Close --> Open) Close the driver door within 5 seconds. When electrical key cancel is activated, the wireless door lock buzzer sounds twice. To return to the original condition, perform the procedure again. When the original condition is returned, the wireless door lock buzzer sounds once.
