Engine Control System (diagnostic Codes (p1604-u0293) & Circuit Tests) Toyota Prius C I

DESCRIPTION

If the engine does not start or it takes a long time for the engine to start although the ECM is receiving the engine start request signal from the power management control ECU via CAN communication, this DTC will be stored.

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was running or stopped, whether the engine was warmed up or not, whether the air fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction.

It is necessary to check if the vehicle has run out of fuel before starting diagnosis because this DTC is also stored due to running out of fuel.

Scheme 42

INSPECTION PROCEDURE

HINT

1. In contrast to normal malfunction diagnosis for components, circuits and systems, DTC P1604 is used to determine the malfunctioning area from the problem symptoms and freeze frame data when the user mentions problems such as starting difficulty. As these DTCs can be stored as a result of certain user actions, even if these DTCs are output, if the customer makes no mention of problems, clear these DTCs without performing any troubleshooting and return the vehicle to the customer.
2. If any DTCs other than P1604 are output, troubleshoot those DTCs first.
3. Since DTC P1604 is different from other DTCs, the following procedure is shown as a reference.
4. Read freeze frame data using the Techstream. Freeze frame data records engine conditions when a malfunction occurs. This information can be useful when troubleshooting.
5. When confirming the freeze frame data, be sure to check all 5 sets of freeze frame data. Refer to «FREEZE FRAME DATA»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) .
6. When confirming freeze frame data, if there are multiple items related to the cause of the malfunction, perform troubleshooting for all related items.
7. Try to start the vehicle under the conditions recorded in the freeze frame data which were present when the malfunction occurred. Confirm the data at this time and compare it with the freeze frame data.
8. If the malfunction does not reoccur, carefully check the vehicle conditions from when the malfunction occurred using freeze frame data.
9. When performing inspections, jiggle the relevant wire harnesses and connectors in an attempt to reproduce malfunctions that do not always occur.
10. If the same inspection or replacement procedure appears 2 times when performing an inspection procedure, it is not necessary to repeat the procedure the second time.

PROCEDURE

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P1604) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P1604 is output A DTC P1604 and other DTCs are output B HINT: If any DTCs other than P1604 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
2. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Check the following freeze frame data to see the state of the auxiliary battery when the freeze frame data was recorded. CONFIRMATION ITEM Battery Voltage Check the following freeze frame data to see if the engine was cranking when the freeze frame data was recorded. CONFIRMATION ITEM Engine Speed Engine Speed (Starter Off) Check the following freeze frame data to check temperature data recorded when the engine did not start normally. CONFIRMATION ITEM Coolant Temp Intake Air Engine Oil Temperature Ambient Temp for A/C Check the following freeze frame data to see the engine operating conditions recorded when the engine started. CONFIRMATION ITEM MAF Throttle Position ISC Flow ISC Position MAP EGR Step Position Check the following freeze frame data to see before the engine did not start normally. CONFIRMATION ITEM Run Dist of Previous Trip Previous Trip Intake Temp Previous Trip Eng Oil Temp Previous Trip Ambient Temp Use this information to perform a simulation test. Compare the "Normal Condition" information in the Data List table (reference values) with the freeze frame data listed above and with the simulation test results to determine the problem cause. RESULT Result Proceed to The problem cause can be determined A The problem cause cannot be determined B B --> See step 4 A --> REPAIR OR REPLACE MALFUNCTIONING PARTS
3. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__diagnostic-trouble-code-chart)
4. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__check-for-intermittent-problems)

When the engine is idling stably under a low load, if the idle speed drops or becomes unstable, this DTC will be stored.

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was running or stopped, whether the engine was warmed up or not, whether the air fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction.

HINT

1. In contrast to normal malfunction diagnosis for components, circuit and systems, DTC P1605 is used to determine the malfunctioning area from the problem symptoms and freeze frame data when the user mentions problems such as rough idling. As these DTCs can be stored as a result of certain user actions, even if these DTCs are output, if the customer makes no mention of problems, clear these DTCs without performing any troubleshooting and return the vehicle to the customer.
2. If any DTCs other than P1605 are output, troubleshoot those DTCs first.
3. Since DTC P1605 is different from other DTCs, the following procedure is shown as a reference.
4. Read freeze frame data using the Techstream. Freeze frame data records engine conditions when a malfunction occurs. This information can be useful when troubleshooting.
5. When confirming the freeze frame data, be sure to check all 5 sets of freeze frame data. Refer to «FREEZE FRAME DATA»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) .
6. When confirming freeze frame data, if there are multiple items related to the cause of the malfunction, perform troubleshooting for all related items.
7. Try to operate the vehicle under the conditions recorded in the freeze frame data which were present when the malfunction occurred. Confirm the data at this time and the data when the engine is idling (engine warmed up and no load) and compare these data with the freeze frame data.
8. Inspections take into account the fact that the malfunction may not have reoccurred and place emphasis on checking the vehicle conditions present at the time when the malfunction occurred.
9. When performing inspections, jiggle the relevant wire harnesses and connectors in an attempt to reproduce malfunctions that do not always occur.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P1605) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P1605 is output A DTC P1605 and other DTCs are output B HINT: If any DTCs other than P1605 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
2. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Check the following freeze frame data to see if the engine was cold or warm when the freeze frame data was recorded. CONFIRMATION ITEM Coolant Temp Initial Engine Coolant Temp Check the following freeze frame data to see if the vehicle was idling. CONFIRMATION ITEM Engine Speed Check the following freeze frame data to see purge VSV operation when the freeze frame data was recorded. CONFIRMATION ITEM EVAP (Purge) VSV Evap Purge Flow Purge Density Learn Value EVAP Purge VSV Check the following freeze frame data to see engine idle operating conditions recorded. CONFIRMATION ITEM Throttle Position ISC Flow ISC Position Idle Spark Advn Ctrl #1 Idle Spark Advn Ctrl #2 Idle Spark Advn Ctrl #3 Idle Spark Advn Ctrl #4 ISC Feedback Value ISC Learning Value Electric Load Feedback Value Air Conditioner FB Val Low Revolution Control MAP EGR Step Position Check the following freeze frame data to see the engine load and electric load. CONFIRMATION ITEM Calculate Load Electric Fan Motor Use this information to perform a simulation test. Compare the "Normal Condition" in the Data List table (reference values) with the freeze frame data listed above and with the simulation test results to determine the problem cause. RESULT Result Proceed to The problem cause can be determined A The problem cause cannot be determined B B --> See step 4 A --> REPAIR OR REPLACE MALFUNCTIONING PARTS
3. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__diagnostic-trouble-code-chart)
4. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__check-for-intermittent-problems)

The throttle actuator is operated by the ECM and opens and closes the throttle valve using gears.

The opening angle of the throttle valve is detected by the throttle position sensor, which is mounted on the throttle body with motor assembly. The throttle position sensor provides feedback to the ECM. This feedback allows the ECM to appropriately control the throttle actuator and monitor the throttle opening angle as the ECM responds to driver inputs.

HINT

This Electronic Throttle Control System (ETCS) does not use a throttle cable.

MONITOR DESCRIPTION

The ECM monitors the electrical current through the electronic actuator, and detects malfunctions and open circuits in the throttle actuator based on this value. If the current is outside the standard range, the ECM determines that there is a malfunction in the throttle actuator. In addition, if the throttle valve does not function properly (for example, stuck on), the ECM determines that there is a malfunction. The ECM then illuminates the MIL and stores a DTC.

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

ALL

P2102

P2103

TYPICAL MALFUNCTION THRESHOLDS

P2102

P2103 (CASE 1)

P2103 (CASE 2)

Scheme 43

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) .
7. Start the engine.
8. With the vehicle stationary, fully depress the accelerator pedal and quickly release it [B].
9. Check that 16 seconds or more have elapsed from the instant when the accelerator pedal is first depressed.
10. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
11. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
13. Input the DTC: P2102 or P2103.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
15. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

FAIL-SAFE

When either of these DTCs or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 5.5° throttle angle by the return spring. The ECM stops the engine and the vehicle can be driver using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

Scheme 44

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

1. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
2. The throttle actuator current (Throttle Motor Current) and the throttle actuator duty ratio (Throttle Motor Duty (Open) / Throttle Motor Duty (Close)) can be read using the Techstream. However, the ECM shuts off the throttle actuator current when the electronic throttle control system malfunctions.

1. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY (RESISTANCE OF THROTTLE ACTUATOR) Inspect the throttle body with motor assembly. Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the throttle body with motor assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 5 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (THROTTLE BODY WITH MOTOR ASSEMBLY - ECM) Disconnect the throttle body with motor assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C12-2 (M+) - C10-60 (M+) Always Below 1 ohms C12-1 (M-) - C10-30 (M-) Always Below 1 ohms C12-2 (M+) or C10-60 (M+) - Body ground Always 10 kohms or higher C12-1 (M-) or C10-30 (M-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for foreign objects between the throttle valve and the housing. OK No foreign objects between the throttle valve and housing. HINT: Perform "Inspection After Repair" after cleaning the throttle body with motor assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> REMOVE FOREIGN OBJECT AND CLEAN THROTTLE BODY WITH MOTOR ASSEMBLY OK: Go to next step
4. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY (THROTTLE VALVE) Check if the throttle valve opens and closes smoothly. OK Throttle valve opens and closes smoothly. HINT: Perform "Inspection After Repair" after replacing the throttle body with motor assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 6 OK --> See step 7
5. REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
6. REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
7. REPLACE ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)

The idle speed is controlled by the Electronic Throttle Control System (ETCS). The ETCS is comprised of a throttle actuator, which operates the throttle valve, and a throttle position sensor, which detects the opening amount of the throttle valve. The ECM controls the throttle actuator to adjust the throttle valve opening amount so that the idle speed is maintained at the target idle speed.

HINT

1. The ISC learned value is the calculated intake air amount corresponding to the throttle opening amount necessary to maintain the idle speed.
2. This malfunction is only detected once per trip. After it has been detected once, the system will not monitor for the malfunction for the rest of the trip.
3. The system uses the throttle body with motor assembly and mass air flow meter sub-assembly to detect this malfunction.

If there are deposits in the throttle valve, a decrease in the ISC flow rate may cause engine stall or unstable idling. Therefore, the necessary ISC flow rate for idling is maintained using the ISC learned value and feedback. The ECM stores this DTC if the ISC learned value approaches its limit. The ECM begins monitoring for the DTC detection conditions when the following preconditions are met

1. 1) The mass air flow meter sub-assembly is normal.
2. 2) Atmospheric pressure is 85 kPa(abs) [638 mmHg(abs)] or higher.
3. 3) The vehicle has been driven at a speed of 30 km/h (18.6 mph) or more at least once.
4. 4) The engine coolant temperature is 45°C (113°F) or less at engine start, the engine is warmed up and conditions for ISC learning are met, or the ignition switch has been turned to ON (IG) (include engine running) for 1 hour or more, the engine is warmed up and conditions for ISC learning are met.

HINT

1. Read freeze frame data using the Techstream. Freeze frame data records engine conditions when a malfunction occurs. This information can be useful when troubleshooting.
2. Since a pending DTC is not stored for this DTC, it takes time to confirm whether the malfunction has been successfully repaired by checking for this DTC. When confirming whether the malfunction has been successfully repaired, compare "ISC Learning Value" recorded in the freeze frame data with "ISC Learning Value" in the Data List after repairs have been made to save time.

Scheme 45

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2109) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2109 is output A DTC P2109 and other DTCs are output B HINT: If any DTCs other than P2109 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
2. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Using the Techstream, check "ISC Learning Value" in the freeze frame data. Refer to «FREEZE FRAME DATA»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . HINT: Be sure to confirm "ISC Learning Value" in the freeze frame data as it is used when confirming whether the malfunction has been successfully repaired. NEXT: Go to next step
3. REMOVE FOREIGN OBJECT (CLEAN THROTTLE BODY WITH MOTOR ASSEMBLY) Clean off any deposits from the inside of the throttle body with motor assembly. TEXT IN ILLUSTRATION *1 Bore *2 Valve *a Reference *b Throttle Body with Motor Assembly Cross-section Diagram *c When valve fully opened *d Deposits *e Do not directly apply cleaner Push open the throttle valve and wipe off any carbon from the valve and bore using a cloth soaked in non-residue solvent. NOTE: Make sure that the cloth or your fingers do not get caught in the valve. Make sure that foreign matter does not enter the throttle valve. Do not directly apply non-residue solvent to the throttle body with motor assembly or wash the throttle body with motor assembly. Cleaning solvent may leak into the motor from the shaft and cause problems such as rust or valve movement problems. If there is coating material on the edge of the valve, be careful not to remove it. Push the throttle valve open gently with your finger and check that the throttle valve moves smoothly. HINT: If the throttle valve does not open smoothly, replace the throttle body with motor assembly. NEXT: Go to next step
4. READ VALUE USING TECHSTREAM (ISC LEARNING VALUE) Perform "Inspection After Repair" after cleaning the throttle body with motor assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . Connect the Techstream to the DLC3. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / ISC Learning Value. Read the value. OK The value is half of "ISC Learning Value" recorded in the freeze frame data or less. HINT: Perform "Inspection After Repair" after replacing the throttle body with motor assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 6 OK --> END
5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__diagnostic-trouble-code-chart)
6. REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)

The throttle actuator is operated by the ECM, and opens and closes the throttle valve using gears. The opening angle of the throttle valve is detected by the throttle position sensor, which is mounted on the throttle body with motor assembly. The throttle position sensor provides feedback to the ECM. This feedback allows the ECM to appropriately control the throttle actuator and monitor the throttle opening angle as the ECM responds to driver inputs.

HINT

This Electronic Throttle Control System (ETCS) does not use a throttle cable.

The ECM determines that there is a malfunction in the ETCS when the throttle valve remains at a fixed angle despite a high drive current from the ECM. The ECM illuminates the MIL and stores a DTC.

ALL

P2111: THROTTLE ACTUATOR STUCK OPEN

P2112: THROTTLE ACTUATOR STUCK CLOSED

P2111: THROTTLE ACTUATOR STUCK OPEN

P2112: THROTTLE ACTUATOR STUCK CLOSED

Scheme 46

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) .
7. Start the engine and fully depress and release the accelerator pedal quickly (to fully open and close the throttle valve).
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P2111 or P2112.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
13. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When either of these DTCs or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 5.5° throttle angle by the return spring. The ECM stops the engine and the vehicle can be driver using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

WIRING DIAGRAM

Refer to DTC P2102. Refer to WIRING DIAGRAM .

HINT

1. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
2. Refer to "Data List / Active Test" [Throttle Position Command, Throttle Position No. 1, Throttle Motor Current, Throttle Motor Duty (Open), Throttle Motor Duty (Close)]. Refer to «DATA LIST / ACTIVE TEST»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) .

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2111 or P2112 is output A DTC P2111 or P2112 and other DTCs are output B HINT: If any DTCs other than P2111 or P2112 are output, troubleshoot those DTCs first. B --> See step 8 A: Go to next step
2. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and housing. If necessary, clean the throttle body with motor assembly. Also check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. HINT: Perform "Inspection After Repair" after cleaning the throttle body with motor assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 5 OK: Go to next step
3. READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / Throttle Position No. 1, Throttle Position No. 2 and Throttle Position Command. Read the values displayed on the Techstream while wiggling the ECM wire harness. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to Value in Data List changes when wire harness is wiggled, or DTC is output A Other than above B B --> See step 6 A: Go to next step
4. REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - THROTTLE BODY WITH MOTOR ASSEMBLY) As the DTC was stored due to a change in the contact resistance of the connector, repair or replace the wire harness or connector. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . NEXT --> END
5. REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY Replace the throttle body with motor assembly. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the throttle body with motor assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NEXT: Go to next step
6. CHECK WHETHER DTC OUTPUT RECURS (DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P2111 or P2112 is output B B --> See step 7 A --> END
7. REPLACE ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
8. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__diagnostic-trouble-code-chart)

The electronic throttle control system has a dedicated power supply circuit. The voltage (+BM) is monitored and when it is low (below 4 V), the ECM determines that there is a malfunction in the electronic throttle control system and cuts off the current to the throttle actuator.

When the voltage becomes unstable, the electronic throttle control system itself becomes unstable. For this reason, when the voltage is low, the current to the throttle actuator is cut. If repairs are made and the system returns to normal, turn the ignition switch off. The ECM then allows the current to flow to the throttle actuator so that it can be restarted.

HINT

The electronic throttle control system does not use a throttle cable.

Scheme 47

The ECM monitors the auxiliary battery supply voltage applied to the throttle actuator.

When the power supply voltage (+BM) is less than 4 V for 0.8 seconds or more, the ECM interprets this as an open in the power supply circuit (+BM). The ECM illuminates the MIL and stores the DTC.

COMPONENT OPERATING RANGE

Scheme 48

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) .
7. Start the engine.
8. Slowly depress the accelerator pedal, raise the engine speed to approximately 2500 rpm over approximately 5 seconds, and then idle the engine [B]. HINT: During charging control, the engine speed is set at idle. Therefore, the engine speed does not increase when depressing the accelerator pedal. In this case, perform step [B] after charging control has completed.
9. Check that 16 seconds or more have elapsed since the engine was started.
10. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
11. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
13. Input the DTC: P2118.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
15. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When this DTC or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 5.5° throttle angle by the return spring. The ECM stops the engine and the vehicle can be driver using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

Refer to DTC P2102. Refer to WIRING DIAGRAM .

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ VALUE USING TECHSTREAM (+BM VOLTAGE) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / +BM Voltage. Read the value displayed on the Techstream. RESULT Result Proceed to Less than 4 V A 11 to 16 V B B --> See step 4 A: Go to next step
2. CHECK HARNESS AND CONNECTOR (ECM - AUXILIARY BATTERY, BODY GROUND) Disconnect the ECM connectors. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C10-29 (+BM) - Body ground Ignition switch off 11 to 16 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C10-59 (ME01) - Body ground Always Below 1 ohms C10-16 (E1) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 3
3. REPLACE ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
4. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__check-for-intermittent-problems)

The electronic throttle control system is composed of the throttle actuator, throttle position sensor, accelerator pedal position sensor, and ECM. The ECM operates the throttle actuator to regulate the throttle valve in response to driver inputs. The throttle position sensor detects the opening angle of the throttle valve, and provides the ECM with feedback so that the throttle valve can be appropriately controlled by the ECM.

The ECM determines the actual opening angle of the throttle valve from the throttle position sensor signal. The actual opening angle is compared to the target opening angle commanded by the ECM. If the difference between these two values is outside the standard range, the ECM interprets this as a malfunction in the electronic throttle control system. The ECM then illuminates the MIL and stores the DTC.

Scheme 49

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) .
7. Start the engine.
8. Idle the engine for 20 seconds.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P2119.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, fully depress and release the accelerator pedal 3 times, and then check the DTC judgment result [C].
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When this DTC or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 5.5° throttle angle by the return spring. The ECM stops the engine and the vehicle can be driver using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

Refer to DTC P2102. Refer to WIRING DIAGRAM .

HINT

1. Refer to "Data List / Active Test" [Throttle Position Commanded, Throttle Position No. 1, Throttle Motor Current, Throttle Motor Duty (Open) and Throttle Motor Duty (Close)]. Refer to «DATA LIST / ACTIVE TEST»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) .
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2119 is output A DTC P2119 and other DTCs are output B HINT: If any DTCs other than P2119 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
2. READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG) and turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / Throttle Position No. 1 and Throttle Position Command. Read the values displayed on the Techstream while fully depressing and releasing the accelerator pedal quickly. RESULT Result Proceed to Throttle Position No. 1 does not change A Throttle Position No. 1 changes even a little B HINT: When a DTC is output, the system changes to fail-safe mode. Therefore, only use the data up until the time the DTC is stored for confirmation. B --> See step 4 A: Go to next step
3. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY (RESISTANCE OF THROTTLE ACTUATOR) Inspect the throttle body with motor assembly. Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . NG --> See step 7 OK: Go to next step
4. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and housing. If necessary, clean the throttle body with motor assembly. Also, check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. HINT: Perform "Inspection After Repair" after cleaning the throttle body with motor assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 7 OK: Go to next step
5. READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / Throttle Position No. 1, Throttle Position No. 2 and Throttle Position Command. Read the values displayed on the Techstream while wiggling the ECM wire harness. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to Value in Data List changes when wire harness is wiggled, or DTC is output A Other than above B B --> See step 8 A: Go to next step
6. REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - THROTTLE BODY WITH MOTOR ASSEMBLY) As the DTC was stored due to a change in the contact resistance of the connector, repair or replace the wire harness or connector. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . NEXT --> END
7. REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY Replace the throttle body with motor assembly. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the throttle body with motor assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NEXT: Go to next step
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P2119 is output B B --> See step 10 A --> END
9. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__diagnostic-trouble-code-chart)
10. REPLACE ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)

HINT

Although the DTC titles say oxygen sensor, these DTCs relate to the air fuel ratio sensor.

The air fuel ratio sensor generates a voltage* that corresponds to the actual air fuel ratio. This sensor voltage is used to provide the ECM with feedback so that it can control the air fuel ratio. The ECM determines the deviation from the stoichiometric air fuel ratio level, and regulates the fuel injection duration. If the air fuel ratio sensor malfunctions, the ECM is unable to control the air fuel ratio accurately.

The air fuel ratio sensor is a planar type and is integrated with the heater, which heats the solid electrolyte (zirconia element). This heater is controlled by the ECM. When the intake air volume is low (the exhaust gas temperature is low), a current flows into the heater to heat the sensor, in order to facilitate accurate oxygen concentration detection. In addition, the sensor and heater portions are a narrow type. The heat generated by the heater is conducted to the solid electrolyte through the alumina, and therefore sensor activation is accelerated.

In order to obtain a high purification rate of the carbon monoxide (CO), hydrocarbon (HC) and nitrogen oxide (NOx) components in the exhaust gas, a three-way catalytic converter is used. For the most efficient use of the three-way catalytic converter, the air fuel ratio must be precisely controlled so that it is always close to the stoichiometric level.

*: Value changes inside the ECM. Since the air fuel ratio sensor is a current output element, the current is converted into a voltage inside the ECM. Any measurements taken at the air fuel ratio sensor or ECM connectors will show a constant voltage.

Scheme 50

HINT

1. When any of these DTCs is stored, check the air fuel ratio sensor voltage output by entering the following menus on the Techstream: Powertrain / Engine and ECT / Data List / Gas AF Control / AFS Voltage B1S1.
2. Short-term fuel trim values can also be read using the Techstream.
3. The ECM regulates the voltages at the A1A+ and A1A- terminals of the ECM to a constant level. Therefore, the air fuel ratio sensor voltage output cannot be confirmed without using the Techstream.
4. If an air fuel ratio sensor malfunction is detected, the ECM stores a DTC.

Sensor Voltage Detection Monitor

Under air fuel ratio feedback control, If the air fuel ratio sensor output voltage is less than 2.8 V (very rich condition) for 5 seconds despite the heated oxygen sensor output voltage being less than 0.69 V, the ECM stores DTC P2196. Alternatively, if the air fuel ratio sensor output voltage is higher than 3.8 V (very lean condition) for 5 seconds despite the heated oxygen sensor output voltage being 0.21 V or higher, DTC P2195 is stored.

Sensor Current Detection Monitor

A rich air fuel mixture causes a low air fuel ratio sensor current, and a lean air fuel mixture causes a high air fuel ratio sensor current. Therefore, the sensor output becomes low during acceleration, and it becomes high during deceleration with the throttle valve fully closed. The ECM monitors the air fuel ratio sensor current during fuel-cut and detects any abnormal current values.

If the air fuel ratio sensor output is 2.2 mA or higher for more than 3 seconds of cumulative time, the ECM interprets this as a malfunction in the air fuel ratio sensor and stores DTC P2195 (stuck on high side). If the air fuel ratio sensor output is less than 0.7 mA for more than 3 seconds of cumulative time, the ECM stores DTC P2196 (stuck on low side).

Scheme 51

ALL

SENSOR VOLTAGE DETECTION MONITOR

SENSOR CURRENT DETECTION MONITOR

P2195: SENSOR VOLTAGE DETECTION MONITOR (LEAN SIDE MALFUNCTION)

P2196: SENSOR VOLTAGE DETECTION MONITOR (RICH SIDE MALFUNCTION)

P2195: SENSOR CURRENT DETECTION MONITOR (HIGH SIDE MALFUNCTION)

P2196: SENSOR CURRENT DETECTION MONITOR (LOW SIDE MALFUNCTION)

MONITOR RESULT

Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

P2195, P2196: O2 SENSOR / RANGE B1S1

Scheme 52

Scheme 53

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON (IG).
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON (IG) and turn the Techstream on.
7. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) .
8. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [A].
9. On the Techstream, enter the following menus to check the fuel-cut status: Powertrain / Engine and ECT / Data List / Primary / Idle Fuel Cut.
10. Drive the vehicle at a speed between 75 and 120 km/h (47 and 75 mph) for at least 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
11. With the shift lever in B position [C], accelerate the vehicle to 75 km/h (47 mph) or more by depressing the accelerator pedal for at least 10 seconds [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
12. Soon after performing step [D] above, release the accelerator pedal for at least 4 seconds without depressing the brake pedal in order to execute fuel-cut control [E]. HINT: While "Idle Fuel Cut" on the Data List is ON, fuel-cut control is being executed.
13. Allow the vehicle to decelerate until the vehicle speed decreases to less than 10 km/h (6 mph).
14. Repeat steps [C] through [E] above at least 3 times in one driving cycle.
15. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [F].
16. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
17. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
18. Input the DTC: P2195 or P2196.
19. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [F] again.
20. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Refer to DTC P0031. Refer to WIRING DIAGRAM .

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

1. Sensor 1 refers to the sensor closest to the engine assembly.
2. Sensor 2 refers to the sensor farthest away from the engine assembly.
3. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
4. A low air fuel ratio sensor voltage could be caused by a rich air fuel mixture. Check for conditions that would cause the engine to run rich.
5. A high air fuel ratio sensor voltage could be caused by a lean air fuel mixture. Check for conditions that would cause the engine to run lean.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2195 or P2196 is output A DTC P2195 or P2196 and P0136, P0137 or P0138 are output A DTC P2195 or P2196 and other DTCs are output B HINT: If any DTCs relating to the air fuel ratio sensor (DTCs for the air fuel ratio sensor heater or air fuel ratio sensor admittance) are output, troubleshoot those DTCs first. B --> See step 19 A: Go to next step
2. CONFIRM IF VEHICLE HAS RUN OUT OF FUEL IN PAST Has the vehicle run out of fuel in the past? NO --> See step 4 YES: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2195 or P2196 is output) B B --> See step 4 A --> DTC CAUSED BY RUNNING OUT OF FUEL
4. READ VALUE USING TECHSTREAM (TEST VALUE OF AIR FUEL RATIO SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / Current. Check that the status of O2 Sensor is Complete. If the status is still Incomplete, drive the vehicle according to the driving pattern again. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / Details / RANGE B1S1. Check the test value of the air fuel ratio sensor output current during fuel-cut. RESULT Result Proceed to Within normal range (0.7 mA or higher, and lower than 2.2 mA) A Outside normal range (lower than 0.7 mA, or 2.2 mA or higher) B B --> See step 16 A: Go to next step
5. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine. Warm up the engine and run the engine at an engine speed of 2500 rpm for 90 seconds. HINT: During charging control, the engine speed is set at idle. Therefore, the engine speed does not increase when depressing the accelerator pedal. In this case, warm up the engine after charging control has completed. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / AFS Voltage B1S1 and O2S B1S2. Perform the Control the Injection Volume for A/F Sensor operation with the engine idling. Monitor the output voltages of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 12.5%. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) 12.5% Rich Below 3.1 V -12.5% Lean Higher than 3.4 V O2S B1S2 (Heated oxygen) 12.5% Rich Higher than 0.55 V -12.5% Lean Below 0.4 V RESULT Status of AFS Voltage B1S1 Status of O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Proceed to Lean Lean Actual air fuel ratio lean A Rich Rich Actual air fuel ratio rich A Lean Lean/Rich Air fuel ratio sensor malfunction B Rich Lean/Rich Air fuel ratio sensor malfunction B Lean/Rich Lean/Rich Normal B Lean: During the Control the Injection Volume for A/F Sensor Active Test, the air fuel ratio sensor output voltage (AFS Voltage B1S1) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S B1S2) is consistently below 0.4 V. Rich: During the Control the Injection Volume for A/F Sensor Active Test, the AFS Voltage B1S1 is consistently below 3.1 V, and the O2S B1S2 is consistently higher than 0.55 V. Lean/Rich: During the Control the Injection Volume for A/F Sensor Active Test, the output voltage of the air fuel ratio sensor and heated oxygen sensor alternates correctly. HINT: Refer to "Data List / Active Test" [AFS Voltage B1S1 and O2S B1S2]. Refer to «DATA LIST / ACTIVE TEST»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . B --> See step 16 A: Go to next step
6. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(/toyota/prius-c/i-2011-2015/remont/mechanical/#engine-intake-system-inspection) . OK No leaks in the intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
7. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
8. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(/toyota/prius-c/i-2011-2015/remont/fuel-system/#fuel-system-inspection) . NG --> See step 18 OK: Go to next step
9. INSPECT FUEL INJECTOR ASSEMBLY Inspect the fuel injector assembly injection (whether fuel volume is high or low, and whether injection pattern is poor). Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/fuel-system/#fuel-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 20 OK: Go to next step
10. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NEXT: Go to next step
11. CHECK WHETHER DTC OUTPUT RECURS (DTC P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P2195 or P2196 is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
12. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / Throttle Idle Position and MAP. Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during Active Test. Be sure to return the EGR valve to step 0 when Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in EGR valve. RESULT Result Proceed to NG A OK B B --> See step 14 A: Go to next step
13. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. HINT: Perform "Inspection After Repair" after replacing the EGR valve assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 23 OK: Go to next step
14. REPLACE ECM Replace the ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . NEXT: Go to next step
15. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit NEXT --> END
16. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NEXT: Go to next step
17. CHECK WHETHER DTC OUTPUT RECURS (DTC P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2195 or P2196 is output) B B --> See step 21 A --> END
18. CHECK FUEL LINE Check the fuel lines for leaks or blockage. HINT: Perform "Inspection After Repair" after replacing the fuel pump with filter assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> REPAIR OR REPLACE FUEL LINE OK --> See step 22
19. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__diagnostic-trouble-code-chart)
20. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/fuel-system/#fuel-system-service-information__removal)
21. REPLACE ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
22. REPLACE FUEL PUMP WITH FILTER ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/fuel-system/#fuel-system-service-information)
23. REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information)

Refer to DTC P0300. Refer to DESCRIPTION .

Refer to DTC P2195. Refer to DESCRIPTION .

Fuel System Air Fuel Ratio Cylinder Imbalance Monitor

The ECM uses the air fuel ratio sensor and crank position sensor to monitor the difference in air fuel ratios between the cylinders caused by differences in injection volumes between the cylinders, leakage in the intake or exhaust system, etc.

When the air fuel ratios of the cylinders are lean or rich with respect to each other, the ECM determines that a problem is present and stores a DTC.

Air Fuel Ratio Sensor Monitoring Method

When the system detects a difference in air fuel ratios between the cylinders due to fluctuation in the air fuel ratio sensor output over 1 engine cycle (2 crankshaft revolutions), the system determines that there is a problem.

Crank Position Sensor Monitoring Method

The system monitors the engine speed variation and when the variation becomes large, the system determines that there is a difference in air fuel ratios between the cylinders, which it determines to be a problem.

ALL

AIR FUEL RATIO SENSOR MONITORING METHOD

CRANK POSITION SENSOR MONITORING METHOD (FIRST JUDGMENT)

CRANK POSITION SENSOR MONITORING METHOD (SECOND JUDGMENT)

AIR FUEL RATIO SENSOR MONITORING METHOD

CRANK POSITION SENSOR MONITORING METHOD (FIRST JUDGMENT)

CRANK POSITION SENSOR MONITORING METHOD (SECOND JUDGMENT)

HINT

If the first judgment while driving shows that the value of Engine Speed Fluctuation Avg (worst value) is between 0.5 and 1.5, then second judgment will be performed when the vehicle is stopped and the engine is idling.

Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

P219A: FUEL SYSTEM / A/F SENSOR DETERMINATION B1

P219A: FUEL SYSTEM / ENGINE SPEED FLUCTUATION AVERAGE B1

Scheme 54

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) .
4. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [A].
5. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). WARNING: Use the Techstream to clear the DTCs. (Do not disconnect the cable from negative (-) auxiliary battery terminal to clear the DTCs.)
6. Drive the vehicle at 40 km/h (25 mph).
7. Gradually accelerate the vehicle from 40 km/h (25 mph) to 80 km/h (50 mph) taking approximately 10 to 20 seconds [B]. HINT: Refer to Typical Enabling Conditions for mass air flow and engine speed, and then accelerate the vehicle from 80 km/h (50 mph).
8. Drive the vehicle at 80 km/h (50 mph) or higher for 1 minute or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Electrical load can be applied while the vehicle is driven.
9. Idle the engine for 1 minute or more [D]. HINT: With the shift lever in D.
10. Repeat steps [B] and [D] above at least 3 times [E].
11. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [F].
12. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
13. Drive the vehicle at 80 km/h (50 mph).
14. Gradually accelerate the vehicle from 80 km/h (50 mph) to 100 km/h (62 mph) taking approximately 5 to 15 seconds [G]. HINT: Refer to Typical Enabling Conditions for mass air flow and engine speed, and then accelerate the vehicle from 100 km/h (62 mph).
15. Drive the vehicle at 100 km/h (62 mph) or higher for 1 minute or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Electrical load can be applied while the vehicle is driven.
16. Idle the engine for 1 minute or more [I]. HINT: With the shift lever in D.
17. Repeat steps [G] and [I] above at least 2 times [J].
18. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [K].
19. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
20. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
21. Input the DTC: P219A.
22. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
23. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Refer to Fuel Injector Circuit. Refer to WIRING DIAGRAM .

HINT

1. Read freeze frame data using the Techstream. Freeze frame data records the engine condition when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
2. Refer to A/F Sensor Determination (worst value) #1, Engine Speed Fluctuation Avg (worst value) #1 to #4, Cylinder #1 to #4 Misfire Count, Short FT #1 and Long FT #1 in the Data List / Active Test. Refer to «DATA LIST / ACTIVE TEST»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) .
3. Sensor 1 refers to the sensor closest to the engine assembly.
4. Sensor 2 refers to the sensor farthest away from the engine assembly.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P219A) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P219A is output A DTC P219A and other DTCs are output B HINT: If any DTCs other than P219A are output, troubleshoot those DTCs first. B --> See step 14 A: Go to next step
2. READ VALUE USING TECHSTREAM (FREEZE FRAME DATA) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . Freeze Frame Data Items for DTC P219A Vehicle Speed Engine Speed Calculate Load Short FT #1 Long FT #1 Cylinder #1 Misfire Count to Cylinder #4 Misfire Count A/F Sensor Determination (worst value) #1 Engine Speed Fluctuation Avg (worst value) #1 to #4 HINT: When the sum of Short FT #1 and Long FT #1 is positive, the engine is running lean, and when the sum is negative, the engine is running rich. NEXT: Go to next step
3. READ VALUE USING TECHSTREAM (MONITOR RESULT) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. HINT: If any misfire count ("Cylinder #1 Misfire Count" to "Cylinder #4 Misfire Count) increases while idling or driving the vehicle, proceed to step 6. Perform inspections while focusing on the cylinder whose misfire count has increased. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / Fuel System / Details / A/F SENSOR DETERMINATION B1 and ENGINE SPEED FLUCTUATION AVERAGE B1. Check the Test Result (A/F SENSOR DETERMINATION B1 and ENGINE SPEED FLUCTUATION AVERAGE B1). RESULT Result Proceed to A/F SENSOR DETERMINATION is Fail A A/F SENSOR DETERMINATION and ENGINE SPEED FLUCTUATION AVERAGE are Fail B ENGINE SPEED FLUCTUATION AVERAGE is Fail B* HINT: When the results of A/F SENSOR DETERMINATION and ENGINE SPEED FLUCTUATION AVERAGE are both Pass, drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern again. If both results are still Pass, proceed to step 4. *: Perform inspections while focusing on the cylinder whose engine speed fluctuation value ("Engine Speed Fluctuation Avg (worst value) #1" to "Engine Speed Fluctuation Avg (worst value) #4") was the largest. B --> See step 6 A: Go to next step
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine. Warm up the engine. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume / Gas Misfire / Cylinder #1 to #4 Misfire Count. HINT: When the "Control the Injection Volume" Active Test is selected (injection volume is 0%), if a misfire count increases, proceed to step 6 (Check Intake System). Perform the Control the Injection Volume operation with the engine idling. Check the misfire counts ("Cylinder #1 Misfire Count" to "Cylinder #4 Misfire Count") while decreasing the injection volume in 5% increments. NOTE: Do not decrease the injection volume by higher than 20%. Result The cylinder whose misfire count has not increased can be assumed to be running rich. Therefore, perform inspections while focusing on that cylinder. NEXT: Go to next step
5. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
6. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(/toyota/prius-c/i-2011-2015/remont/mechanical/#engine-intake-system-inspection) . OK No leaks in intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
7. INSPECT SPARK PLUG Inspect the spark plug of the cylinder causing the imbalance. Refer to «ON-VEHICLE INSPECTION - Step 3»(/toyota/prius-c/i-2011-2015/remont/ignition-system/#ignition-system-inspection) . HINT: Perform "Inspection After Repair" after replacing the spark plug. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 15 OK: Go to next step
8. CHECK FOR SPARK (SPARK TEST) Perform a spark test. Refer to «ON-VEHICLE INSPECTION - Step 1»(/toyota/prius-c/i-2011-2015/remont/ignition-system/#ignition-system-inspection) . HINT: If the result of the spark test is normal, proceed to the next step. Perform "Inspection After Repair" after repairing or replacing the ignition system. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NEXT: Go to next step
9. CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «ON-VEHICLE INSPECTION - Step 8»(/toyota/prius-c/i-2011-2015/remont/mechanical/#engine-mechanical-service-information) . HINT: Perform "Inspection After Repair" after repairing or replacing the engine assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
10. CHECK TERMINAL VOLTAGE (POWER SOURCE OF FUEL INJECTOR ASSEMBLY). Refer to «PROCEDURE - Step 8»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostic-codes-p0300-p0657__procedure) NG --> See step 16 OK: Go to next step
11. CHECK FUEL INJECTOR ASSEMBLY OF CYLINDER CAUSING IMBALANCE Check the fuel injector assembly injection [whether fuel volume is high or low, and whether injection pattern is poor]. Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/fuel-system/#fuel-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 17 OK: Go to next step
12. CHECK FOR CAUSE OF FAILURE If the cause of the problem has not been found even after performing the troubleshooting procedure, perform the inspection below. Check the intake valve for deposits. HINT: As the DTC may have been stored due to deposits on the intake valve, remove the cylinder head sub-assembly and check the intake valve. Check for deposits in the EGR delivery chamber. HINT: The DTC may have been stored due to deposits that have accumulated in the EGR delivery chamber. Therefore, remove and inspect the EGR delivery chamber. NEXT: Go to next step
13. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check for DTCs. Result P219A is not output. NEXT --> END
14. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__diagnostic-trouble-code-chart)
15. REPLACE SPARK PLUG. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
16. GO TO FUEL INJECTOR CIRCUIT. Refer to «Fuel Injector Circuit»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostic-codes-p1604-u0293-circuit-tests)
17. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/fuel-system/#fuel-system-service-information__removal)

HINT

1. Although the DTC titles say oxygen sensor, these DTCs relate to the air fuel ratio sensor.
2. Refer to DTC P2195. Refer to «DESCRIPTION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostic-codes-p1604-u0293-circuit-tests) .

These DTCs are output when there is an open or short in the air fuel ratio sensor circuit, or if the air fuel ratio sensor output drops. To detect these problems, the voltage of the air fuel ratio sensor is monitored when turning the ignition switch to ON (IG), and the admittance (admittance is an electrical term that indicates the ease of flow of current) is checked while driving. If the voltage of the air fuel ratio sensor is higher than 0.5 V, and 4.5 V or less it is considered normal. If the voltage is out of the specified range, or the admittance is less than the standard value, the ECM determines that there is a malfunction in the air fuel ratio sensor. If the same malfunction is detected in next driving cycle, the MIL is illuminated and a DTC is stored.

P2237 AND P2238

P2239, P2252 AND P2253

P2237: AIR FUEL RATIO SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A

P2238: AIR FUEL RATIO SENSOR LOW IMPEDANCE

P2238: AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND GND

P2238: AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND A1A

P2239: AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND +B

P2252: AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND GND

P2253: AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND +B

P2237: (AIR FUEL RATIO SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A-)

P2238: (AIR FUEL RATIO SENSOR LOW ADMITTANCE)

P2238: (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND GND)

P2238: (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND A1A-)

P2239: (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND +B)

P2252: (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND GND)

P2253: (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND +B)

CONFIRMATION DRIVING PATTERN

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) .
7. Start the engine and wait 5 minutes.
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P2237, P2238, P2239, P2252 or P2253.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 5 minutes and check the DTC judgment result again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Refer to DTC P0031. Refer to WIRING DIAGRAM .

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

1. Sensor 1 refers to the sensor closest to the engine assembly.
2. Sensor 2 refers to the sensor farthest away from the engine assembly.
3. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
4. Refer to "Data List / Active Test" [AFS Voltage B1S1]. Refer to «DATA LIST / ACTIVE TEST»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) .

1. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C17-1 (HA1A) - C10-23 (HA1A) Always Below 1 ohms C17-3 (A1A+) - C10-133 (A1A+) Always Below 1 ohms C17-4 (A1A-) - C10-134 (A1A-) Always Below 1 ohms C17-1 (HA1A) or C10-23 (HA1A) - Body ground Always 10 kohms or higher C17-3 (A1A+) or C10-133 (A1A+) - Body ground Always 10 kohms or higher C17-4 (A1A-) or C10-134 (A1A-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NEXT: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P2237, P2238, P2239, P2252 OR P2253) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2237, P2238, P2239, P2252 or P2253. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2237, P2238, P2239, P2252 or P2253 is output) B B --> See step 4 A --> END
4. REPLACE ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)

DTC SUMMARY

HINT

The vent valve is built into the canister pump module.

The description can be found in EVAP (Evaporative Emission) System. Refer to DESCRIPTION .

5 hours* after the ignition switch is turned off, the leak detection pump creates negative pressure (vacuum) in the EVAP (Evaporative Emission) system. The ECM monitors for leaks and actuator malfunctions based on the EVAP pressure.

HINT

*: If the engine coolant temperature is not less than 35°C (95°F) 5 hours after the ignition switch is turned off, the monitor check starts 2 hours later. If it is still not less than 35°C (95°F) 7 hours after the ignition switch is turned off, the monitor check starts 2.5 hours later.

*: If only a small amount of fuel is in the fuel tank, it takes longer for the EVAP pressure to stabilize.

Scheme 55

TEXT IN ILLUSTRATION

P2420: Vent valve stuck open (vent)

In operation C, the vent valve turns on (closed) and the EVAP system pressure is then measured by the ECM using the canister pressure sensor to conduct an EVAP leak check. If the pressure does not increase when the vent valve is open, the ECM interprets this as the vent valve being stuck open. The ECM illuminates the MIL and stores the DTC.

Scheme 56

Refer to EVAP system. Refer to MONITOR RESULT .

Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON (IG) and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
7. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
8. Input the DTC: P2420.
9. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
10. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Refer to EVAP System. Refer to INSPECTION PROCEDURE .

The soak timer operates after the ignition switch is turned off. When a certain amount of time has elapsed after turning the ignition switch off, the soak timer activates the ECM to perform malfunction checks which can only be performed after the engine is stopped. The soak timer is built into the ECM.

Scheme 57

1. While the engine is running, the ECM monitors the synchronization of the soak timer and the CPU clock. If these two are not synchronized, the ECM interprets this as a malfunction, illuminates the MIL and stores the DTC.
2. If the soak timer activates the ECM even though only a short amount of time has elapsed since the ignition switch was turned off, or if the soak timer does not activate the ECM even though a considerable amount of time has elapsed since the ignition switch was turned off, the ECM determines that the soak timer is malfunctioning, illuminates the MIL and stores a DTC the next time the ignition switch is turned to ON (IG).

ALL

CASE 1

CASE 2

CASE 3

CASE 1

CASE 2

CASE 3

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) .
7. Start the engine.
8. Idle the engine for 10 minutes or more.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P2610.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
14. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. DTC P2610 is set if an internal ECM problem is detected. Diagnostic procedures are not required. ECM replacement is required.
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. REPLACE ECM Replace the ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . NEXT: Go to next step
2. CHECK WHETHER DTC OUTPUT RECURS (DTC P2610) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine and wait for 10 minutes or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. If no pending DTC is output, the repair has been successfully completed. NEXT --> END

The ECM controls the engine water pump assembly by calculating the necessary amount of coolant flow based on engine coolant temperature, engine speed and vehicle speed information. The speed of the engine water pump assembly is controlled steplessly using a duty cycle signal sent from the ECM. This optimal control enhances warm-up performance and reduces cooling losses, thus reducing the specific fuel consumption of the engine.

The ECM calculates the speed of the engine water pump assembly using a duty cycle signal sent from the engine water pump assembly. When the speed of the engine water pump assembly becomes less than 900 rpm while it is operating, the ECM detects the malfunction and stores DTC P261B.

The engine water pump assembly operates steplessly based on a duty cycle signal sent from the ECM. If actual drive duty cycle ratio does not correspond to the target drive duty cycle of the engine water pump assembly, the ECM detects the malfunction.

ALL

P261B

P261C AND P261D

P261B

P261C

P261D

P261B

P261C AND P261D

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) .
7. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher).
8. Idle the engine for 20 seconds or more [A].
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P261B, P261C or P261D.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 58

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 59

Scheme 60

Scheme 61

Scheme 62

1. PERFORM ACTIVE TEST USING TECHSTREAM (ACTIVATE THE ELECTRIC WATER PUMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Activate the Electric Water Pump. Touch the engine water pump and check that the pump assembly is operating (vibrating). OK The engine water pump assembly is operating (vibrating). NG --> See step 4 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (ENGINE WATER PUMP ASSEMBLY - ECM) HINT: Confirm a good connection at the engine water pump assembly and ECM connectors. Disconnect the engine water pump assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C27-2 (NWP) - A40-28 (WPI) Always Below 1 ohms C27-4 (SWP) - A40-29 (WPO) Always Below 1 ohms C27-2 (NWP) or A40-28 (WPI) - Body ground Always 10 kohms or higher C27-4 (SWP) or A40-29 (WPO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK TERMINAL VOLTAGE (WPI VOLTAGE) Disconnect the engine water pump assembly connector. Turn the ignition switch to ON (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C27-2 (NWP) - Body ground Ignition switch ON (IG) 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Engine Water Pump Assembly) NG --> See step 15 OK --> See step 13
4. CHECK TERMINAL VOLTAGE (POWER SOURCE OF ENGINE WATER PUMP ASSEMBLY) HINT: Confirm a good connection at the engine water pump assembly and ECM connectors. Disconnect the engine water pump assembly connector. Turn the ignition switch to ON (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C27-1 (+B) - Body ground Ignition switch ON (IG) 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Engine Water Pump Assembly) NG --> See step 9 OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (ENGINE WATER PUMP ASSEMBLY - BODY GROUND) Disconnect the engine water pump assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C27-5 (PGND) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (ENGINE WATER PUMP ASSEMBLY - ECM) Disconnect the engine water pump assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C27-2 (NWP) - A40-28 (WPI) Always Below 1 ohms C27-4 (SWP) - A40-29 (WPO) Always Below 1 ohms C27-2 (NWP) or A40-28 (WPI) - Body ground Always 10 kohms or higher C27-4 (SWP) or A40-29 (WPO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
7. REPLACE ENGINE WATER PUMP ASSEMBLY Replace the engine water pump assembly. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/cooling-fan/#engine-cooling-system-service-information) . NEXT: Go to next step
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P261B, P261C OR P261D) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P261B, P261C or P261D is output A DTC is not output B B --> END A --> See step 14
9. INSPECT RELAY (ENG W/PMP RELAY) Remove the ENG W/PMP relay from the No. 2 engine room relay block and No. 2 junction block assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 No auxiliary battery voltage applied between terminals 1 and 2 10 kohms or higher 3 - 5 Auxiliary battery voltage applied between terminals 1 and 2 Below 1 ohms NG --> REPLACE RELAY (ENG W/PMP RELAY) OK: Go to next step
10. CHECK HARNESS AND CONNECTOR (ENG W/PMP RELAY - ENGINE WATER PUMP ASSEMBLY) Remove the ENG W/PMP relay from the No. 2 engine room relay block and No. 2 junction block assembly. Disconnect the engine water pump assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition ENG W/PMP relay terminal 3 - C27-1 (+B) Always Below 1 ohms ENG W/PMP relay terminal 3 or C27-1 (+B) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
11. CHECK TERMINAL VOLTAGE (POWER SOURCE OF ENG W/PMP RELAY) Remove the ENG W/PMP relay from the No. 2 engine room relay block and No. 2 junction block assembly. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition ENG W/PMP relay terminal 5 - Body ground Always 11 to 14 V TEXT IN ILLUSTRATION *1 No. 2 Engine Room Relay Block and No. 2 Junction Block Assembly *2 ENG W/PMP Relay NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AUXILIARY BATTERY - ENG W/PMP RELAY) OK: Go to next step
12. CHECK HARNESS AND CONNECTOR (ENG W/PMP RELAY - BODY GROUND) Remove the ENG W/PMP relay from the No. 2 engine room relay block and No. 2 junction block assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition ENG W/PMP relay terminal 1 - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ENG W/PMP RELAY - EFI MAIN RELAY)
13. REPLACE ENGINE WATER PUMP ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/cooling-fan/#engine-cooling-system-service-information)
14. REPLACE ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
15. REPLACE ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)

From the power management control ECU, the ECM receives data such as engine power output required (required output), estimated torque produced by the engine (estimated torque), engine speed target (target speed), and whether the engine is in start mode or not. Then, based on the required output and target speed, the ECM calculates a target torque that is to be produced by the engine and compares it with the estimated torque. If the estimated torque is very low compared with the target torque, or the engine start mode continues for the specific duration calculated by the coolant temperature, an abnormal condition is detected.

The ECM and power management control ECU are connected using CAN communication. The ECM sends engine speed data and other data to the power management control ECU while the power management control ECU sends information such as a requirement for engine power to the ECM using CAN communication. When the communication between the ECM and power management control ECU is normal and the following items meet the specified conditions, the ECM stores a DTC.

1. Engine speed
2. Target torque
3. Ratio of target torque against estimated torque
4. Fuel level

P3190

P3191

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) .
7. Start the engine.
8. Allow the engine to idle for 10 seconds or more.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P3190, P3191 or P3193.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
14. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. Repeating this inspection for symptom confirmation may cause the SOC to drop, preventing the system from entering the READY-on state. In this case, use the THS charger to charge the HV battery.
2. Cranking the engine once causes the SOC to drop approximately 1%.
3. Charging the HV battery once (10 minutes) using the THS charger restores the SOC approximately 2%.
4. Charging the HV battery using the THS charger takes approximately 10 minutes when the HV battery temperature is 25°C (77°F) or approximately 30 minutes when the HV battery temperature is 0°C (32°F).
5. The THS charger is a supplemental charging device that charges the HV battery enough to enable the engine to start (the vehicle can enter the READY-on state).
6. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P3190, P3191 AND/OR P3193) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P3190, P3191 and/or P3193 are output A DTC P3190, P3191 and/or P3193 and other DTCs are output B HINT: If any other codes besides P3190, P3191 and/or P3193 are output, perform troubleshooting for those DTCs first. B --> See step 17 A: Go to next step
2. CHECK SHORTAGE OF FUEL Check the amount of fuel remaining. OK There is enough fuel. HINT: DTCs P3190, P3191 and/or P3193 may be output if the vehicle run out of fuel in the past. When an insufficient amount of fuel is added to the vehicle and when the hybrid control system will not engage because the DTCs P3190, P3191 and/or P3193 that are output regard the vehicle as out of fuel, continue refueling the vehicle until the fuel level warning light turns off. NG --> REFILL FUEL OK: Go to next step
3. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(/toyota/prius-c/i-2011-2015/remont/mechanical/#engine-intake-system-inspection) . OK No leaks in intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
4. CHECK FOR UNUSUAL NOISE OR VIBRATION WHEN STARTING ENGINE OR REVVING UP OK Unusual noise and vibration do not occur. NG --> REPAIR OR REPLACE MALFUNCTIONING PART OK: Go to next step
5. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(/toyota/prius-c/i-2011-2015/remont/fuel-system/#fuel-system-inspection) . NG --> See step 22 OK: Go to next step
6. INSPECT FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT Trouble Codes / Freeze Frame Data. Calculate the requested torque* and compare it with Actual Engine Torque. HINT: *: The requested torque is calculated by putting "Requested Engine Torque" and "HV Target Engine Speed" from the freeze frame data into the following formula: Requested torque = Requested Engine Torque (kW) / HV Target Engine Speed (rpm) x 9554 Standard Actual Engine Torque is 60% or more of the request torque. RESULT Result Proceed to NG A OK B B --> See step 8 A: Go to next step
7. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY Inspect the throttle body with motor assembly. Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the throttle body with motor assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 21 OK: Go to next step
8. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY Inspect the mass air flow meter sub-assembly. Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 18 OK: Go to next step
9. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 19 OK: Go to next step
10. INSPECT CRANK POSITION SENSOR Inspect the crank position sensor. Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . NG --> See step 20 OK: Go to next step
11. REPLACE CAM POSITION SENSOR Replace the cam position sensor. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . NEXT: Go to next step
12. CHECK WHETHER DTC OUTPUT RECURS (DTC P3190, P3191 AND/OR P3193) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG) and turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine. Allow the engine to idle for 10 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the pending DTCs. RESULT Result Proceed to DTC P3190, P3191 and/or P3193 is output A DTC is not output B B --> END A: Go to next step
13. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / Throttle Idle Position and MAP. Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. RESULT Result Proceed to NG A OK B B --> See step 15 A: Go to next step
14. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. HINT: Perform "Inspection After Repair" after replacing the EGR valve assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 23 OK: Go to next step
15. REPLACE ECM Replace the ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . NEXT: Go to next step
16. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON (IG) and turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine. Allow the engine to idle for 10 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P3190, P3191 or P3193. Check the DTC judgment result. NEXT --> END
17. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__diagnostic-trouble-code-chart)
18. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
19. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
20. REPLACE CRANK POSITION SENSOR. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
21. REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
22. CHECK FUEL PUMP CONTROL CIRCUIT. Refer to «Fuel Pump Control Circuit»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostic-codes-p1604-u0293-circuit-tests)
23. REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information)

The Controller Area Network (CAN) is a serial data communication system for real-time application. It is a multiplex communication system designed for on-vehicle use that provides a superior communication speed of 500 kbps and a capability to detect malfunctions. Through the combination of the CANH and CANL bus lines, the CAN is able to maintain communication based on differential voltage.

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON (IG) and turn the Techstream on.
6. Wait 5 seconds or more.
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: U0293.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 63

Refer to the CAN Communication System. Refer to HOW TO PROCEED WITH TROUBLESHOOTING .

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

RELATED DTCS

If any EVAP system DTCs are output, the malfunctioning area can be determined using the table below.

Scheme 64

Note. If the reference pressure difference between the first and second checks is more than the specification, all the DTCs relating to the reference pressure (P043E, P043F, P2401, P2402 and P2419) will all be stored.

Scheme 65

TEXT IN ILLUSTRATION

HINT

The canister pressure sensor, the leak detection pump and the vent valve are built into the canister pump module.

Scheme 66

TEXT IN ILLUSTRATION

Note. In the EVAP system of this vehicle, turning on the vent valve does not seal off the EVAP system. To check for leaks in the EVAP system, disconnect the air inlet vent hose and apply pressure from the atmospheric side of the canister.

While the engine is running, if a predetermined condition (closed-loop, etc.) is met, the purge VSV is opened by the ECM and fuel vapors stored in the canister are purged to the intake manifold. The ECM changes the duty cycle ratio of the purge VSV to control purge flow volume.

The purge flow volume is also determined by the intake manifold pressure. Atmospheric pressure is allowed into the canister through the vent valve to ensure that the purge flow is maintained when negative pressure (vacuum) is applied to the canister.

The following two monitors run to confirm appropriate EVAP system operation.

Scheme 67

Scheme 68

Scheme 69

Scheme 70

1. Key-off monitor This monitor checks for EVAP (evaporative emission) system leaks and canister pump module malfunctions. The monitor starts 5 hours* after the ignition switch is turned off. At least 5 hours are required for the fuel to cool down to stabilize the EVAP pressure, thus making the EVAP system monitor more accurate. The leak detection pump creates negative pressure (vacuum) in the EVAP system and the pressure is measured. Finally, the ECM monitors for leaks from the EVAP system, and malfunctions in both the canister pump module and purge VSV based on the EVAP pressure. HINT: *: If the engine coolant temperature is not less than 35°C (95°F) 5 hours after the ignition switch is turned off, the monitor check starts 2 hours later. If it is still not less than 35°C (95°F) 7 hours after the ignition switch is turned off, the monitor check starts 2.5 hours later.
2. Purge flow monitor The purge flow monitor consists of the 2 monitors. The 1st monitor is conducted every time and the 2nd monitor is activated if necessary. The 1st monitor While the engine is running and the purge VSV (Vacuum Switching Valve) is on (open), the ECM monitors the purge flow by measuring the EVAP pressure change. If negative pressure is not created, the ECM begins the 2nd monitor. The 2nd monitor The vent valve is turned on (closed) and the EVAP pressure is then measured. If the variation in the pressure is less than 0.5 kPa(gauge) [3.751 mmHg(gauge)], the ECM interprets this as the purge VSV being stuck closed, illuminates the MIL and stores DTC P0441 (2 trip detection logic). Atmospheric pressure check: In order to ensure reliable malfunction detection, the variation between the atmospheric pressures, before and after of the purge flow monitor, is measured by the ECM. TEXT IN ILLUSTRATION *1 ECM *2 Soak Timer *3 Fuel Cap *4 Canister Filter *5 Fuel Tank *6 Canister Pressure Sensor *7 Canister Pump Module *8 Canister *9 No. 1 Canister - - *a EVAP Purge Flow *b to Intake Manifold *c Purge VSV: on *d Leak Detection Pump: off *e Reference Orifice (0.02 inch) *f Vent Valve: off Component Operation Canister, No. 1 canister Contains activated charcoal to absorb EVAP (Evaporative Emissions) generated in fuel tank. Cut-off valve Located in fuel tank. Valve floats and closes when fuel tank is 100% full. Purge VSV (Vacuum Switching Valve) Opens or closes line between canister and intake manifold. ECM uses purge VSV to control EVAP purge flow. In order to discharge EVAP absorbed by canister to intake manifold, ECM opens purge VSV. EVAP discharge volume to intake manifold controlled by purge VSV duty cycle (current-carrying time). (Open: on, Close: off) Soak timer Built into ECM. To ensure accurate EVAP monitor, measures 5 hours (+/-15 min) after ignition switch is turned off. This allows fuel to cool down, stabilizing EVAP pressure. When approximately 5 hours elapsed, ECM activates (Scheme 44) Canister pump module Consists of (a) to (d) below. Canister pump module cannot be disassembled. (a) Vent valve Vents and closes EVAP system. When ECM turns valve on, EVAP system is closed. When ECM turns valve off, EVAP system is vented. Negative pressure (vacuum) is created in EVAP system to check for EVAP leaks by closing purge VSV, turning on vent valve (closing it) and operating leak detection pump (Scheme 42) (b) Canister pressure sensor Indicates pressure as voltages. ECM supplies regulated 5 V to pressure sensor, and uses feedback from sensor to monitor EVAP system pressure (Scheme 43) (c) Leak detection pump Creates negative pressure (vacuum) in EVAP system for leak check. (d) Reference orifice Has opening with 0.02 inch diameter. Vacuum is produced through orifice by closing purge VSV, turning off vent valve and operating leak detection pump, to monitor reference pressure. Reference pressure is used when checking for small EVAP leaks. TEXT IN ILLUSTRATION *1 Canister *2 Reference Orifice (0.02 Inch) *3 Canister Pressure Sensor - - *a Canister Pump Module (Scheme 42) *b Airflow *c Condition: Purge Flow *d Condition: Leak Check *e Vent Valve: Off (vent) *f to Canister Filter (Atmosphere) *g Leak Detection Pump: Off *h Vent Valve: On (closed) *i Leak Detection Pump: On

Refer to DTC P0451. Refer to WIRING DIAGRAM .

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure. The Techstream is required to conduct the following diagnostic troubleshooting procedure.

HINT

1. Using the Techstream monitor results enables the EVAP (Evaporative Emission) system to be confirmed.
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

1. CONFIRM DTC Turn the ignition switch off and wait for 10 seconds. Turn the ignition switch to ON (IG). Turn the ignition switch off and wait for 10 seconds. Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Confirm DTCs and freeze frame data. If any EVAP system DTCs are set, the malfunctioning area can be determined using the table below. NOTE: If the reference pressure difference between the first and second checks is greater than the specification, all the DTCs relating to the reference pressure (P043E, P043F, P2401, P2402 and P2419) are stored. NEXT: Go to next step
2. PERFORM EVAPORATIVE SYSTEM CHECK (AUTOMATIC MODE) NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the temperature less than 35°C (95°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode. After the Evaporative System Check is completed, check for pending DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes. HINT: If no pending DTCs are displayed, perform the Confirmation Driving Pattern. After this confirmation, check for pending DTCs. If no DTCs are displayed, the EVAP system is normal. NEXT: Go to next step
3. PERFORM EVAPORATIVE SYSTEM CHECK (MANUAL MODE) NOTE: In the Evaporative System Check (Manual Mode), the series of 6 Evaporative System Check steps are performed manually using the Techstream. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the temperature less than 35°C (95°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Manual Mode. NEXT: Go to next step
4. PERFORM EVAPORATIVE SYSTEM CHECK (STEP 1/6) Check the EVAP pressure in step 1/6. RESULT DTC *1 Result Suspected Trouble Area Proceed to - Virtually no variation in EVAP pressure Not yet determined A P0451 EVAP pressure fluctuates by +/-0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher Canister pressure sensor signal noise B (P0452 or P0453) *2 EVAP pressure is below 42.11 kPa(abs) [315.867 mmHg(abs)], or higher than 123.761 kPa(abs) [928.331 mmHg(abs)] EVAP pressure deviates +/-10 kPa(gauge) [+/-75 mmHg(gauge)] from actual atmosphere pressure *3 Canister pressure sensor or its circuit has malfunction C *1: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. *2: If the canister pressure sensor circuit has an open or short, DTC P0452 or P0453 is stored 0.5 seconds after the ignition switch is turned to ON (IG). HINT: *3: Canister pressure sensor standard output range is 70 to 110 kPa(abs) [525 to 825 mmHg(abs)]. This varies by weather. B --> See step 40 C --> See step 12 A: Go to next step
5. PERFORM EVAPORATIVE SYSTEM CHECK (STEP 1/6 TO 2/6) Check the EVAP pressure in steps 1/6 and 2/6. RESULT DTC* Result Suspected Trouble Area Proceed to - Virtually no variation in EVAP pressure during step 1/6. Then decreases to reference pressure Not yet determined A P2402 Small difference between EVAP pressures during steps 1/6 and 2/6 Leak detection pump stuck ON B *: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. HINT: The first reference pressure is the value determined in step 2/6. B --> See step 32 A: Go to next step
6. PERFORM EVAPORATIVE SYSTEM CHECK (STEP 2/6) HINT: Make a note of the pressures checked in inspection items (A) and (B) below. Check the EVAP pressure 4 seconds after the leak detection pump is activated*1 (A). *1: The leak detection pump begins to operate as step 1/6 finishes and step 2/6 starts. Check the EVAP pressure again when it has stabilized. This pressure is the reference pressure (B). RESULT DTC*2 Result Suspected Trouble Area Proceed to - EVAP pressure in inspection item (B) is between -4.85 kPa(gauge) and -1.057 kPa(gauge) [-36.38 mmHg(gauge) and -7.929 mmHg(gauge)] Not yet determined A P043F and P2401 EVAP pressure in inspection item (B) is -1.057 kPa(gauge) [-7.929 mmHg(gauge)] or higher Reference orifice high-flow Leak detection pump stuck OFF B P043E EVAP pressure in inspection item (B) is less than -4.85 kPa(gauge) [-36.38 mmHg(gauge)] Reference orifice clogged C P2419 EVAP pressure in inspection item (A) is higher than -0.25 kPa(gauge) [-1.875 mmHg(gauge)] Vent valve stuck closed Leak detection pump performance deteriorates Leak detection pump circuit malfunctioning (large resistance exists in the circuit) D *2: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. B --> See step 11 C --> See step 40 D --> See step 13 A: Go to next step
7. PERFORM EVAPORATIVE SYSTEM CHECK (STEP 2/6 TO 3/6) Check the EVAP pressure in step 3/6. RESULT DTC* Result Suspected Trouble Area Proceed to - EVAP pressure increases by 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher within 10 seconds of proceeding from step 2/6 to step 3/6 Not yet determined A P2420 No variation in EVAP pressure even after proceeding from step 2/6 to step 3/6 Vent valve stuck open (vent) Canister (charcoal filter inside canister) clogged No. 1 canister (charcoal filter inside canister) clogged B *: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. B --> See step 28 A: Go to next step
8. PERFORM EVAPORATIVE SYSTEM CHECK (STEP 3/6) Wait until the EVAP pressure change is less than 0.12 kPa(gauge) [0.9 mmHg(gauge)] for 40 seconds. Measure the EVAP pressure and record it. HINT: A few minutes are required for the EVAP pressure to become saturated. When there is little fuel in the fuel tank, it takes up to 15 minutes. NEXT: Go to next step
9. PERFORM EVAPORATIVE SYSTEM CHECK (STEP 4/6) Check the EVAP pressure in step 4/6. RESULT DTC*1 Result Suspected Trouble Area Proceed to - EVAP pressure increases by 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher within 10 seconds of proceeding from step 3/6 to step 4/6 Not yet determined A P0441 *2 EVAP pressure increases by 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher more within 10 seconds of proceeding from step 3/6 to step 4/6 Purge VSV Purge VSV circuit Problems in EVAP hose between purge VSV and intake manifold Problems in EVAP hose between canister and purge VSV ECM B P0441 Variation in EVAP pressure is less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] for 10 seconds, after proceeding from step 3/6 to step 4/6 Purge VSV stuck closed Purge VSV circuit Canister (charcoal filter inside canister) clogged No. 1 canister (charcoal filter inside canister) clogged Problems in EVAP hose between purge VSV and intake manifold Problems in EVAP hose between canister and purge VSV ECM C *1: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. *2: This result suggests that due to purge line blockage or purge VSV malfunction, the DTC was stored by the purge flow monitor while the engine was running, or that key-off monitor test result were nearly borderline values. B --> See step 23 C --> See step 17 A: Go to next step
10. PERFORM EVAPORATIVE SYSTEM CHECK (STEP 5/6) Check the EVAP pressure in step 5/6. Compare the EVAP pressure in step 3/6 and the second reference pressure (step 5/6). RESULT DTC* Result Suspected Trouble Area Proceed to - EVAP pressure from step 3/6 lower than second reference pressure (step 5/6) Not yet determined (no leakage from EVAP system) A P0441 and P0455 EVAP pressure from step 3/6 higher than [second reference pressure (step 5/6) x 0.2] Purge VSV stuck open EVAP gross leak B P0456 EVAP pressure from step 3/6 higher than second reference pressure (step 5/6) EVAP small leak B *: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. A --> See step 45 B --> See step 17
11. PERFORM EVAPORATIVE SYSTEM CHECK (STEP 3/6) Check the EVAP pressure in step 3/6. RESULT DTC* Result Suspected Trouble Area Proceed to P043F EVAP pressure less than [reference pressure] measured in step 2/6 Reference orifice high-flow A P2401 EVAP pressure almost same as [reference pressure] measured in step 2/6 Leak detection pump stuck off B *: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. HINT: The first reference pressure is the value determined in step 2/6. A --> See step 40 B --> See step 33
12. INSPECT CANISTER PUMP MODULE (CANISTER PRESSURE SENSOR CIRCUIT) Check the canister pressure sensor circuit, referring to DTC P0451 canister pressure sensor circuit inspection procedure. Refer to «INSPECTION PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostic-codes-p0300-p0657) . NEXT --> See step 52
13. INSPECT CANISTER PUMP MODULE (VENT VALVE OPERATION) Turn the ignition switch off. Disconnect the canister pump module connector. TEXT IN ILLUSTRATION *a Component without harness connected (Canister Pump Module) Apply the auxiliary battery voltage to terminals VLVB and VGND of the canister pump module. Touch the canister pump module to confirm the vent valve operation. RESULT Condition Tester Result Suspected Trouble Area Proceed to Apply auxiliary battery voltage to terminals VLVB and VGND Operating Wire harness or connector between vent valve and ECM Leak detection pump performance deteriorates Leak detection pump circuit malfunctioning (large resistance exists in the circuit) ECM A Not operating Vent valve B B --> See step 40 A: Go to next step
14. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Turn the ignition switch off. Disconnect the ECM connector. Disconnect the canister pump module connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition M21-1 (VGND) - A40-5 (VPMP) Always Below 1 ohms M21-1 (VGND) or A40-5 (VPMP) - Body ground Always 10 kohms or higher RESULT Result Suspected Trouble Area Proceed to OK Leak detection pump performance deteriorates Leak detection pump circuit malfunctioning (large resistance exists in the circuit) ECM A NG Wire harness or connector between ECM and canister pump module B B --> See step 42 A: Go to next step
15. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - BODY GROUND) Disconnect the canister pump module connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to M21-4 (MGND) - Body ground Always Below 1 ohms Canister pump module Wire harness or connector between canister pump module and ECM ECM A 10 kohms or higher Wire harness or connector between canister pump module and body ground B B --> See step 42 A: Go to next step
16. CHECK HARNESS AND CONNECTOR (ECM - CANISTER PUMP MODULE) Disconnect the canister pump module connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to A40-18 (MPMP) - M21-3 (MTRB) Always Below 1 ohms Canister pump module ECM A 10 kohms or higher Wire harness or connector between ECM and canister pump module B A --> See step 47 B --> See step 42
17. PERFORM ACTIVE TEST USING TECHSTREAM (ACTIVATE THE VSV FOR EVAP CONTROL) Enter the following menus: Powertrain / Engine and ECT / Active Test / Activate the VSV for EVAP Control. Disconnect the fuel vapor feed hose (connected to the canister) from the purge VSV. TEXT IN ILLUSTRATION *1 Purge VSV *2 Fuel Vapor Feed Hose (to Canister) Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine. Using the Techstream, turn off the purge VSV (Activate the VSV for Evap Control: OFF). Use your finger to confirm that the purge VSV has no suction. Using the Techstream, turn on the purge VSV (Activate the VSV for Evap Control: ON). Use your finger to confirm that the purge VSV has suction. RESULT Test Result Suspected Trouble Area Proceed to No suction when purge VSV turned off, and suction applied when turned on Blockage in the purge line is considered (based on result of step 9): Problems with EVAP hose between canister and purge VSV Canister (charcoal filter inside canister) clogged No. 1 canister (charcoal filter inside canister) clogged ECM A Leakage is considered (based on result of step 10): Fuel cap Leakage from EVAP line, fuel tank, canister, or No. 1 canister B Suction applied when purge VSV turned off Purge VSV stuck open C No suction when purge VSV turned on Purge VSV stuck closed Problems with EVAP hose between purge VSV and intake manifold D B --> See step 21 C --> See step 22 D --> See step 24 A: Go to next step
18. INSPECT EVAP HOSE (PURGE VSV - CANISTER) Check for blockages in the EVAP purge line between the purge VSV and canister. OK No blockages in the EVAP purge line between the purge VSV and canister. NG --> See step 46 OK: Go to next step
19. INSPECT CANISTER (CHARCOAL FILTER INSIDE CANISTER) Check for filter blockage in the canister. Refer to «INSPECTION - Step 1»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information) . OK No blockages in the canister. NG --> See step 50 OK: Go to next step
20. INSPECT NO. 1 CANISTER (CHARCOAL FILTER INSIDE CANISTER) Check for filter blockage in the No. 1 canister. Refer to «INSPECTION - Step 2»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information) . OK No blockages in the No. 1 canister. OK --> See step 49 NG --> See step 51
21. CHECK FUEL CAP Check that the fuel cap is correctly installed and confirm that the fuel cap meets OEM specifications. Tighten the fuel cap firmly (only one click sound could be heard). HINT: If an EVAP tester is available, check the fuel cap using the tester. Remove the fuel cap and install it onto a fuel cap adapter. Connect an EVAP tester pump hose to the adapter, and pressurize the cap to 3.2 to 3.7 kPa(gauge) [24 to 27.75 mmHg(gauge)] using an EVAP tester pump. Seal the adapter and wait for 2 minutes. Check the pressure. If the pressure is 2 kPa(gauge) [15 mmHg(gauge)] or higher, the fuel cap is normal. RESULT Test Result Suspected Trouble Area Proceed to Fuel cap correctly installed - A Fuel cap loose Fuel cap improperly installed Defective fuel cap Fuel cap does not meet OEM specifications B Defective fuel cap - B No fuel cap - C A --> See step 39 B --> See step 37 C --> See step 38
22. INSPECT PURGE VSV Turn the ignition switch off. Disconnect the purge VSV connector. TEXT IN ILLUSTRATION *1 Fuel Vapor Feed Hose (to Canister) *2 Connector *3 Purge VSV Disconnect the fuel vapor feed hose (connected to the canister) from the purge VSV. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine. Use your finger to confirm that the purge VSV has no suction. RESULT Test Result Suspected Trouble Area Proceed to No suction Wire harness or connector between purge VSV and ECM ECM A Suction applied Purge VSV B A --> See step 27 B --> See step 41
23. INSPECT EVAP HOSE (PURGE VSV - CANISTER) Check for blockages in the EVAP purge line between the purge VSV and canister. OK No blockages in the EVAP purge line between the purge VSV and canister. NG --> See step 46 OK: Go to next step
24. CHECK EVAP HOSE (PURGE VSV - INTAKE MANIFOLD) Disconnect the fuel vapor feed hose (connected to the intake manifold) from the purge VSV. TEXT IN ILLUSTRATION *1 Purge VSV *2 Fuel Vapor Feed Hose (to intake manifold) Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine. Use your finger to confirm that the fuel vapor feed hose has suction. RESULT Test Result Suspected Trouble Area Proceed to Suction applied EVAP hose between purge VSV and intake manifold normal Purge VSV Purge VSV power source Wire harness or connector between purge VSV and ECM A No suction Intake manifold port EVAP hose between purge VSV and intake manifold B B --> See step 36 A: Go to next step
25. INSPECT PURGE VSV Remove the purge VSV. Apply auxiliary battery voltage to the terminals of the purge VSV. TEXT IN ILLUSTRATION *1 Purge VSV Confirm that air flows from port E to port F. RESULT Test Result Condition Suspected Trouble Area Proceed to Air flows Auxiliary battery voltage is applied to purge VSV terminals Purge VSV normal Purge VSV power source Wire harness or connector between purge VSV and ECM A No air flow Auxiliary battery voltage is applied to purge VSV terminals Purge VSV B B --> See step 41 A: Go to next step
26. CHECK TERMINAL VOLTAGE (POWER SOURCE OF PURGE VSV) Disconnect the purge VSV connector. Turn the ignition switch to ON (IG). TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Purge VSV) Measure the voltage according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to C19-1 - Body ground Ignition switch ON (IG) 11 to 14 V Purge VSV power source normal Wire harness or connector between purge VSV and ECM A Other than result above Wire harness or connectors between purge VSV and auxiliary battery B B --> See step 42 A: Go to next step
27. CHECK HARNESS AND CONNECTOR (PURGE VSV - ECM) Disconnect the ECM connector. Disconnect the purge VSV connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C19-2 - C10-76 (PRG) Always Below 1 ohms C19-2 or C10-76 (PRG) - Body ground Always 10 kohms or higher OK --> See step 49 NG --> See step 42
28. INSPECT CANISTER PUMP MODULE (POWER SOURCE FOR VENT VALVE) Turn the ignition switch off. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Canister Pump Module) - - Disconnect the canister pump module connector. Turn the ignition switch to ON (IG). Measure the voltage according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to M21-5 (VLVB) - Body ground Ignition switch ON (IG) 11 to 14 V Wire harness or connector between vent valve and ECM Vent valve Canister (charcoal filter inside canister) clogged No. 1 canister (charcoal filter inside canister) clogged ECM A Below 3 V Power source wire harness of vent valve B B --> See step 42 A: Go to next step
29. INSPECT CANISTER PUMP MODULE (VENT VALVE OPERATION) Turn the ignition switch off. Disconnect the canister pump module connector. TEXT IN ILLUSTRATION *a Component without harness connected (Canister Pump Module) Apply the auxiliary battery voltage to terminals VLVB and VGND of the canister pump module. Touch the canister pump module to confirm the vent valve operation. RESULT Condition Tester Result Suspected Trouble Area Proceed to Apply auxiliary battery voltage to terminals VLVB and VGND Operating Wire harness or connector between vent valve and ECM Canister (charcoal filter inside canister) clogged No. 1 canister (charcoal filter inside canister) clogged ECM A Not operating Vent valve B B --> See step 40 A: Go to next step
30. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Turn the ignition switch off. Disconnect the ECM connector. Disconnect the canister pump module connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Test Result Suspected Trouble Area Proceed to M21-1 (VGND) - A40-5 (VPMP) Always Below 1 ohms Canister (charcoal filter inside canister) clogged ECM A 10 kohms or higher Wire harness or connector between ECM and canister pump module B B --> See step 42 A: Go to next step
31. INSPECT CANISTER (CHARCOAL FILTER INSIDE CANISTER) Check for filter blockage in the canister. Refer to «INSPECTION - Step 1»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information) . OK No blockages in the canister. NG --> See step 50 OK: Go to next step
32. INSPECT NO. 1 CANISTER (CHARCOAL FILTER INSIDE CANISTER) Check for filter blockage in the No. 1 canister. Refer to «INSPECTION - Step 2»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information) . OK No blockages in the No. 1 canister. OK --> See step 49 NG --> See step 51
33. CHECK TERMINAL VOLTAGE (CANISTER PUMP MODULE) Turn the ignition switch off. Disconnect the canister pump module connector. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Canister Pump Module) - - Turn the ignition switch to ON (IG). Measure the voltage according to the value(s) in the table below. RESULT Tester Connection Condition Test Result Suspected Trouble Area Proceed to M21-3 (MTRB) - Body ground Ignition switch ON (IG) 9 to 14 V Wire harness or connector between leak detection pump and body ground Leak detection pump A Below 3 V Wire harness or connector between leak detection pump and ECM ECM B B --> See step 35 A: Go to next step
34. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - BODY GROUND) Turn the ignition switch off. Disconnect the canister pump module connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to M21-4 (MGND) - Body ground Always Below 1 ohms Leak detection pump A 10 kohms or higher Wire harness or connector between canister pump module and body ground B A --> See step 40 B --> See step 42
35. CHECK HARNESS AND CONNECTOR (ECM - CANISTER PUMP MODULE) Turn the ignition switch off. Disconnect the canister pump module connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A40-18 (MPMP) - M21-3 (MTRB) Always Below 1 ohms A40-18 (MPMP) or M21-3 (MTRB) - Body ground Always 10 kohms or higher RESULT Result Suspected Trouble Area Proceed to OK ECM A NG Wire harness or connector between ECM and canister pump module B A --> See step 49 B --> See step 42
36. INSPECT INTAKE MANIFOLD (EVAP PURGE PORT) Stop the engine. Disconnect the EVAP hose from the intake manifold. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine. Use your finger to confirm that the port of the intake manifold has suction. RESULT Tester Connection Suspected Trouble Area Proceed to Suction applied EVAP hose between intake manifold and purge VSV A No suction Intake manifold B A --> See step 43 B --> See step 44
37. CORRECTLY REINSTALL OR REPLACE FUEL CAP HINT: When reinstalling the fuel cap, tighten it firmly (only one click sound could be head). When replacing the fuel cap, use a fuel cap that meets OEM specifications, and install it firmly. NEXT --> See step 52
38. REPLACE FUEL CAP HINT: When installing the fuel cap, tighten it firmly (only one click sound could be head). NEXT --> See step 52
39. LOCATE EVAP LEAK PART Disconnect the vent hose. TEXT IN ILLUSTRATION *1 Fuel Tank *2 Canister *3 No. 1 Canister *4 Canister Filter *5 Fuel Cap *6 Canister Pump Module *a Disconnect the vent hose - - Connect the EVAP pressure tester tool to the canister pump module with the adapter. TEXT IN ILLUSTRATION *1 Canister Pump Module *2 Adapter *3 EVAP Pressure Tester Tool - - Pressurize the EVAP system to 3.2 to 3.7 kPa(gauge) [24 to 27.75 mmHg(gauge)]. Apply soapy water to the piping and connecting parts of the EVAP system. Look for areas where bubbles appear. This indicates the leak point. Repair or replace the leak point. HINT: Disconnect the hose between the canister and fuel tank from the canister. Block the canister side and conduct an inspection. In this way, the fuel tank can be excluded as an area suspected of causing fuel leaks. NEXT --> See step 52
40. REPLACE CANISTER PUMP MODULE Replace the canister pump module. Refer to «REMOVAL - Step 6»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information) . NOTE: When replacing the canister pump module, check the canister pump module interior, canister interior and No. 1 canister interior related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. If liquids are present in the canister interior or No. 1 canister interior, replace the canister, No. 1 canister and canister pump module together. Check for filter blockage in the canister and No. 1 canister. If the charcoal filter inside the canister or No. 1 canister is clogged, replace the canister, No. 1 canister and canister pump module together. Check for filter blockage in the canister filter. TEXT IN ILLUSTRATION *1 Fuel Tank Vent Hose *2 Air Inlet Port *3 Vent Hose *4 Fuel Tank *5 Canister Pump Module *6 Canister *7 No. 1 Canister *8 Canister Filter *a Inspection Area (check for disconnection and/or cracks) - - NEXT --> See step 52
41. REPLACE PURGE VSV Replace the purge VSV. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information) . NEXT --> See step 52
42. REPAIR OR REPLACE HARNESS OR CONNECTOR NEXT --> See step 52
43. REPAIR OR REPLACE EVAP PURGE LINE (INTAKE MANIFOLD - PURGE VSV) NEXT --> See step 52
44. INSPECT INTAKE MANIFOLD (EVAP PURGE PORT) Check that the EVAP purge port of the intake manifold is not clogged. If necessary, replace the intake manifold. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/exhaust/#intake-system-exhaust-system-service-information) . NEXT --> See step 52
45. REPAIR OR REPLACE PARTS AND COMPONENTS INDICATED BY OUTPUT DTCS Repair the malfunctioning areas indicated by the DTCs that had been confirmed when the vehicle was brought in. NEXT --> See step 52
46. REPAIR OR REPLACE EVAP PURGE LINE (PURGE VSV - CANISTER) NEXT --> See step 52
47. REPLACE CANISTER PUMP MODULE Replace the canister pump module. Refer to «REMOVAL - Step 6»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information) . NOTE: When replacing the canister pump module, check the canister pump module interior, canister interior and No. 1 canister interior related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to the canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. If liquids are present in the canister interior or No. 1 canister interior, replace the canister, No. 1 canister and canister pump module together. Check for filter blockage in the canister and No. 1 canister. If the charcoal filter inside the canister or No. 1 canister is clogged, replace the canister, No. 1 canister and canister pump module together. Check for filter blockage in the canister filter. If the canister filter has blockages, replace the canister filter. TEXT IN ILLUSTRATION *1 Fuel Tank Vent Hose *2 Air Inlet Port *3 Vent Hose *4 Fuel Tank *5 Canister Pump Module *6 Canister *7 No. 1 Canister *8 Canister Filter *a Inspection Area (check for disconnection and/or cracks) - - NEXT: Go to next step
48. PERFORM EVAPORATIVE SYSTEM CHECK (AUTOMATIC MODE) NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine in this step. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing an Evaporative System Check, keep the fuel temperature less than 35°C (95°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode. After the Evaporative System Check is completed, check for pending DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes. Result Proceed to EVAP system DTCs are output A DTC is not output (Pending DTC is not output) B B --> END A: Go to next step
49. REPLACE ECM Replace the ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . NEXT --> See step 52
50. REPLACE CANISTER Replace the canister. Refer to «REMOVAL - Step 1»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information) . NOTE: When replacing the canister, check the canister pump module interior and No. 1 canister interior related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to the canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. Check for filter blockage in the canister filter. If the canister filter has blockages, replace the canister filter. TEXT IN ILLUSTRATION *1 Fuel Tank Vent Hose *2 Air Inlet Port *3 Vent Hose *4 Fuel Tank *5 Canister Pump Module *6 Canister *7 No. 1 Canister *8 Canister Filter *a Inspection Area (check for disconnection and/or cracks) - - NEXT --> See step 52
51. REPLACE NO. 1 CANISTER Replace the No. 1 canister. Refer to «REMOVAL - Step 5»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information) . NOTE: When replacing the No. 1 canister, check the canister pump module interior and canister interior related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to the canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. Check for filter blockage in the canister filter. If the canister filter has blockages, replace the canister filter. TEXT IN ILLUSTRATION *1 Fuel Tank Vent Hose *2 Air Inlet Port *3 Vent Hose *4 Fuel Tank *5 Canister Pump Module *6 Canister *7 No. 1 Canister *8 Canister Filter *a Inspection Area (check for disconnection and/or cracks) - - NEXT: Go to next step
52. PERFORM EVAPORATIVE SYSTEM CHECK (AUTOMATIC MODE) NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine in this step. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing an Evaporative System Check, keep the fuel temperature below 35°C (95°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__dtc-check-clear) . Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode. After the Evaporative System Check is completed, check for pending DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes. HINT: If no pending DTCs are found, the repair has been successfully completed. NEXT --> END

HINT

After a repair, check Monitor Status by performing the Key-Off Monitor Confirmation and Purge Flow Monitor Confirmation described below.

1. KEY-OFF MONITOR CONFIRMATION Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway). The fuel tank is less than 90% full. The altitude is less than 2400 m (7874 ft). The engine coolant temperature is between 4.4 and 35°C (40 and 95°F). The intake air temperature is between 4.4 and 35°C (40 and 95°F). The vehicle remains stationary (the vehicle speed is 0 km/h [0 mph]). Monitor Conditions Allow the engine to idle for at least 5 minutes. Turn the ignition switch off and wait for 6 hours (8 or 10.5 hours). HINT: Do not start the engine until checking Monitor Status. If the engine is started, the steps described above must be repeated. Monitor Status Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor. Check the Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor did not complete. Make sure that the preconditions have been met, and perform the Monitor Conditions again.
2. PURGE FLOW MONITOR CONFIRMATION (P0441) HINT: Perform this monitor confirmation after the Key-Off Monitor Confirmation shows Complete. Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway). The engine coolant temperature is 4.4°C (40°F) or higher. The intake air temperature is 4.4°C (40°F) or higher. Monitor Conditions Release the pressure from the fuel tank by removing and reinstalling the fuel tank cap assembly. Warm the engine up until the engine coolant temperature reaches higher than 75°C (167°F). Increase the engine speed to 2500 rpm once. Allow the engine to idle and turn the A/C switch on for 1 minute. Monitor Status Turn the ignition switch off (if ON (IG)) or if the engine is running). Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor. Check the Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor did not complete. Make sure that the preconditions have been met, and perform the Monitor Conditions again.

Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

P0456: EVAPORATIVE SYSTEM / SMALL LEAK

P0455: EVAPORATIVE SYSTEM / GROSS LEAK

P2401: EVAPORATIVE SYSTEM / VACUUM PMP OFF

P2402: EVAPORATIVE SYSTEM / VACUUM PMP ON

P2420: EVAPORATIVE SYSTEM / VENT VALVE OFF

P2419: EVAPORATIVE SYSTEM / VENT VALVE ON

P043E: EVAPORATIVE SYSTEM / ORIFICE CLOGGED

P043F: EVAPORATIVE SYSTEM / ORIFICE HI-FLW

P0441: EVAPORATIVE SYSTEM / PURGE VSV CLOSED

P0441: EVAPORATIVE SYSTEM / PURGE VSV OPENED

P0441: EVAPORATIVE SYSTEM / PURGE FLOW

When the ignition switch is turned to ON (IG), auxiliary battery voltage is applied to the IGSW terminal of the ECM. The output signal from the MREL terminal of the ECM causes current to flow to the coil of the No. 1 integration relay (EFI MAIN relay), closing the contact and supplying power to terminals +B and +B2 of the ECM.

Scheme 91

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 92

Scheme 93

1. CHECK HARNESS AND CONNECTOR (ECM - BODY GROUND) Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C10-16 (E1) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. CHECK TERMINAL VOLTAGE (IGSW VOLTAGE) Disconnect the ECM connector. Turn the ignition switch to ON (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A40-37 (IGSW) - Body ground Ignition switch ON (IG) 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> See step 6 OK: Go to next step
3. INSPECT NO. 1 INTEGRATION RELAY (EFI MAIN RELAY) Inspect the No. 1 integration relay (EFI MAIN relay). Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . NG --> See step 13 OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (NO. 1 INTEGRATION RELAY - ECM) Remove the No. 1 integration relay from the No. 2 engine room relay block and No. 2 junction block assembly. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2C-4 - A40-2 (+B) Always Below 1 ohms 2C-4 - A40-3 (+B2) Always Below 1 ohms 2C-3 - A40-46 (MREL) Always Below 1 ohms 2C-4 or A40-2 (+B) - Body ground Always 10 kohms or higher 2C-4 or A40-3 (+B2) - Body ground Always 10 kohms or higher 2C-3 or A40-46 (MREL) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK TERMINAL VOLTAGE (POWER SOURCE OF NO. 1 INTEGRATION RELAY) Remove the No. 1 integration relay from the No. 2 engine room relay block and No. 2 junction block assembly. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition 2E-1 - Body ground Always 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to No. 1 Integration Relay) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AUXILIARY BATTERY - NO. 1 INTEGRATION RELAY) OK --> See step 15
6. INSPECT NO. 1 INTEGRATION RELAY (IG2 RELAY) Inspect the No. 1 integration relay (IG2 relay). Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . NG --> See step 14 OK: Go to next step
7. CHECK HARNESS AND CONNECTOR (NO. 1 INTEGRATION RELAY - ECM) Remove the No. 1 integration relay from the No. 2 engine room relay block and No. 2 junction block assembly. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2D-4 - A40-37 (IGSW) Always Below 1 ohms 2D-4 or A40-37 (IGSW) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
8. CHECK TERMINAL VOLTAGE (POWER SOURCE OF NO. 1 INTEGRATION RELAY) Remove the No. 1 integration relay from the No. 2 engine room relay block and No. 2 junction block assembly. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition 2E-1 - Body ground Always 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to No. 1 Integration Relay) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AUXILIARY BATTERY - NO. 1 INTEGRATION RELAY) OK: Go to next step
9. CHECK HARNESS AND CONNECTOR (NO. 1 INTEGRATION RELAY - BODY GROUND) Remove the No. 1 integration relay from the No. 2 engine room relay block and No. 2 junction block assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2D-2 - Body ground Always Below 1 ohms RESULT Result Proceed to OK (w/ Smart key system) A OK (w/o Smart key system) B NG C B --> See step 11 C --> REPAIR OR REPLACE HARNESS OR CONNECTOR A: Go to next step
10. CHECK HARNESS AND CONNECTOR (POWER MANAGEMENT CONTROL ECU - NO. 1 INTEGRATION RELAY) Disconnect the power management control ECU connector. Remove the No. 1 integration relay from the No. 2 engine room relay block and No. 2 junction block assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A39-2 (IG2D) - 2D-3 Always Below 1 ohms A39-2 (IG2D) or 2D-3 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 16
11. CHECK HARNESS AND CONNECTOR (IGNITION OR STARTER SWITCH ASSEMBLY - NO. 1 INTEGRATION RELAY) Disconnect the ignition or starter switch assembly connector. Remove the No. 1 integration relay from the No. 2 engine room relay block and No. 2 junction block assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition G15-6 (IG2) - 2D-3 Always Below 1 ohms G15-6 (IG2) or 2D-3 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
12. INSPECT IGNITION OR STARTER SWITCH ASSEMBLY Inspect the ignition or starter switch assembly. Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/starter/#starting-system-service-information) . NG --> See step 17 OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IGNITION OR STARTER SWITCH ASSEMBLY - AUXILIARY BATTERY)
13. REPLACE NO. 1 INTEGRATION RELAY (EFI MAIN RELAY). Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
14. REPLACE NO. 1 INTEGRATION RELAY (IG2 RELAY). Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
15. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__problem-symptoms-table)
16. GO TO SMART KEY SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(/toyota/prius-c/i-2011-2015/remont/starter/#smart-key-system-for-start-function-diagnostics-introduction__how-to-proceed-with-troubleshooting)
17. REPLACE IGNITION OR STARTER SWITCH ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/starter/#starting-system-service-information)

The ECM constantly generates a 5 V power source voltage from the auxiliary battery voltage supplied to the +B (BATT) terminal to operate the microprocessor. The ECM also provides this power source voltage to the sensors through the VC output circuit.

Scheme 94

When the VC circuit is short-circuited, the microprocessor in the ECM and the sensors that are supplied with power through the VC circuit are inactivated because power is not supplied from the VC circuit. Under this condition, the system does not start up and the MIL does not illuminate even if the system malfunctions.

HINT

Under normal conditions, the MIL is illuminated when the ignition switch is turned to ON (IG). The MIL goes off when the ignition switch ON (READY).

Scheme 95

1. CHECK MIL Check that the Malfunction Indicator Lamp (MIL) lights up when the ignition switch is turned to ON (IG). OK MIL lights up. NG --> See step 2 OK --> See step 7
2. CHECK COMMUNICATION BETWEEN TECHSTREAM AND ECM Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Check the communication between the Techstream and ECM. RESULT Result Proceed to Communication is not possible A Communication is possible B B --> See step 8 A: Go to next step
3. CHECK MIL (THROTTLE POSITION SENSOR) Disconnect the throttle body with motor assembly connector. Turn the ignition switch to ON (IG). Check the MIL. RESULT Result Proceed to MIL does not illuminate A MIL illuminates B HINT: Perform "Inspection After Repair" after replacing the throttle body with motor assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . B --> See step 9 A: Go to next step
4. CHECK MIL (MANIFOLD ABSOLUTE PRESSURE SENSOR) Disconnect the manifold absolute pressure sensor connector. Turn the ignition switch to ON (IG). Check the MIL. RESULT Result Proceed to MIL does not illuminate A MIL illuminates B B --> See step 12 A: Go to next step
5. CHECK MIL (CANISTER PUMP MODULE) Disconnect the canister pump module connector. Turn the ignition switch to ON (IG). Check the MIL. RESULT Result Proceed to MIL does not illuminate A MIL illuminates B B --> See step 10 A: Go to next step
6. CHECK HARNESS AND CONNECTOR Disconnect the throttle body with motor assembly connector. Disconnect the manifold absolute pressure sensor connector. Disconnect the canister pump module connector. Disconnect the ECM connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C10-115 (VCTA) - Body ground Always 10 kohms or higher C10-118 (VCPM) - Body ground Always 10 kohms or higher A40-34 (VCPP) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 11
7. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__problem-symptoms-table)
8. GO TO MIL CIRCUIT. Refer to «MIL Circuit»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostic-codes-p1604-u0293-circuit-tests)
9. REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
10. REPLACE CANISTER PUMP MODULE. Refer to «REMOVAL - Step 6»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information)
11. REPLACE ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
12. REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/auxiliary-emission-control-systems/#emission-control-system-service-information)

When the engine is cranked, the start request signal output from the power management control ECU *1, or ignition or starter switch assembly*2 is input to the ECM, and the NE signal generated by the crank position sensor is also input to the NE+ terminal. Thus, the ECM interprets that the engine has been cranked, and turns transistor Tr1 in the ECM internal circuit on. Current flows to the C/OPN (Circuit Opening) relay by turning Tr1 on. Then, the fuel pump with filter assembly operates.

While the NE signal is input to the ECM with the engine running, the ECM turns Tr1 on continuously.

1. *1: w/ Smart Key System
2. *2: w/o Smart Key System

Scheme 96

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

1. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Fuel Pump / Speed. Check whether the fuel pump with filter assembly operating sound occurs when performing the Active Test on the Techstream. RESULT Result Proceed to Fuel pump with filter assembly operating sound does not occur A Fuel pump with filter assembly operating sound occurs B B --> See step 7 A: Go to next step
2. CHECK HARNESS AND CONNECTOR (NO. 1 INTEGRATION RELAY - ECM) Remove the No. 1 integration relay from the No. 2 engine room relay block and No. 2 junction block assembly. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2D-4 - A40-21 (FC) Always Below 1 ohms 2D-4 or A40-21 (FC) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (NO. 1 INTEGRATION RELAY - FUEL PUMP WITH FILTER ASSEMBLY) Remove the No. 1 integration relay from the No. 2 engine room relay block and No. 2 junction block assembly. Disconnect the fuel pump with filter assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2D-8 - M22-4 (B) Always Below 1 ohms 2D-8 or M22-4 (B) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (FUEL PUMP WITH FILTER ASSEMBLY - BODY GROUND) Disconnect the fuel pump with filter assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition M22-5 (E) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. INSPECT FUEL PUMP WITH FILTER ASSEMBLY Inspect the fuel pump with filter assembly. Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/fuel-system/#fuel-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the fuel pump with filter assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 10 OK: Go to next step
6. INSPECT NO. 1 INTEGRATION RELAY (C/OPN RELAY) Inspect the No. 1 integration relay (C/OPN relay). Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information) . NG --> See step 9 OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (NO. 1 INTEGRATION RELAY - NO. 1 INTEGRATION RELAY)
7. READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Starter Signal. Check the result when the ignition switch to ON (IG) and the engine starts. OK Condition Starter Signal Ignition switch ON Close (OFF) Engine started Open (ON) NG --> See step 12 OK: Go to next step
8. READ VALUE USING TECHSTREAM (ENGINE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Engine Speed. Read the values displayed on the Techstream while cranking. OK Values are displayed continuously. NG --> See step 13 OK --> See step 11
9. REPLACE NO. 1 INTEGRATION RELAY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
10. REPLACE FUEL PUMP WITH FILTER ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/fuel-system/#fuel-system-service-information)
11. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__problem-symptoms-table)
12. GO TO HYBRID CONTROL SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#hybrid-control-system-diagnostics-introduction__how-to-proceed-with-troubleshooting)
13. CHECK CRANK POSITION SENSOR CIRCUIT. Refer to «DTC P0335: Crankshaft Position Sensor "A" Circuit»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostic-codes-p0300-p0657)

The fuel injectors are located on the intake port. They inject fuel into the cylinders based on the signals from the ECM.

Scheme 97

Scheme 98

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 99

1. CHECK TERMINAL VOLTAGE (POWER SOURCE OF FUEL INJECTOR ASSEMBLY) Disconnect the fuel injector assembly connectors. Turn the ignition switch to ON (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C1-2 - Body ground Ignition switch ON (IG) 11 to 14 V C2-2 - Body ground Ignition switch ON (IG) 11 to 14 V C3-2 - Body ground Ignition switch ON (IG) 11 to 14 V C4-2 - Body ground Ignition switch ON (IG) 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly) NG --> See step 4 OK: Go to next step
2. INSPECT FUEL INJECTOR ASSEMBLY Check the fuel injector assembly. Refer to «INSPECTION»(/toyota/prius-c/i-2011-2015/remont/fuel-system/#fuel-system-service-information) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction) . NG --> See step 6 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (FUEL INJECTOR ASSEMBLY - ECM) Disconnect the fuel injector assembly connectors. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C1-1 - C10-20 (#10) Always Below 1 ohms C2-1 - C10-17 (#20) Always Below 1 ohms C3-1 - C10-18 (#30) Always Below 1 ohms C4-1 - C10-19 (#40) Always Below 1 ohms C1-1 or C10-20 (#10) - Body ground Always 10 kohms or higher C2-1 or C10-17 (#20) - Body ground Always 10 kohms or higher C3-1 or C10-18 (#30) - Body ground Always 10 kohms or higher C4-1 or C10-19 (#40) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 7
4. CHECK HARNESS AND CONNECTOR (NO. 1 INTEGRATION RELAY - FUEL INJECTOR ASSEMBLY) Remove the No. 1 integration relay from the No. 2 engine room relay block and No. 2 junction block assembly. Disconnect the fuel injector assembly connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2D-4 - C1-2 Always Below 1 ohms 2D-4 - C2-2 Always Below 1 ohms 2D-4 - C3-2 Always Below 1 ohms 2D-4 - C4-2 Always Below 1 ohms 2D-4 or C1-2 - Body ground Always 10 kohms or higher 2D-4 or C2-2 - Body ground Always 10 kohms or higher 2D-4 or C3-2 - Body ground Always 10 kohms or higher 2D-4 or C4-2 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
5. CHECK ECM POWER SOURCE CIRCUIT. Refer to «ECM Power Source Circuit»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostic-codes-p1604-u0293-circuit-tests)
6. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/fuel-system/#fuel-system-service-information__removal)
7. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__problem-symptoms-table)

The MIL (Malfunction Indicator Lamp) is used to indicate vehicle malfunctions detected by the ECM. When the ignition switch is turned to ON (IG), power is supplied to the MIL circuit, and the ECM provides the circuit ground which illuminates the MIL.

The MIL operation can be checked visually: When the ignition switch is turned to ON (IG), the MIL should be illuminated and should turn off after ignition switch ON (READY). If the MIL remains illuminated or is not illuminated, conduct the following troubleshooting procedure using the Techstream.

Scheme 100

Scheme 101

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 102

1. CHECK THAT MIL IS ILLUMINATED Perform troubleshooting in accordance with the table below. RESULT Result Proceed to MIL remains on A MIL does not illuminate B B --> See step 5 A: Go to next step
2. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check if any DTCs have been detected. Note down any DTCs. RESULT Result Proceed to DTC is not detected A Any DTCs are detected B HINT: Check for detected DTCs output from other ECUs which relate to the MIL. B --> See step 8 A: Go to next step
3. CHECK HARNESS AND CONNECTOR (CHECK FOR SHORT IN WIRE HARNESS) Disconnect the A40 ECM connector. Turn the ignition switch to ON (IG). Check that the MIL is not illuminated. OK MIL is not illuminated. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> See step 4 OK --> See step 9
4. CHECK HARNESS AND CONNECTOR (COMBINATION METER SUB-ASSEMBLY - ECM) Disconnect the combination meter sub-assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition G1-24 (EFI) or A40-27 (W) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 10
5. CHECK THAT MIL IS ILLUMINATED Check if the MIL is illuminated when the ignition switch is turned to ON (IG). OK MIL should be illuminated. NG --> See step 6 OK --> See step 11
6. CHECK THAT ENGINE STARTS Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(/toyota/prius-c/i-2011-2015/remont/hoistjack/#introduction) . Start the engine. RESULT Result Proceed to Engine starts A Engine does not start* B HINT: *: The Techstream cannot communicate with the ECM. B --> See step 12 A: Go to next step
7. CHECK HARNESS AND CONNECTOR (COMBINATION METER SUB-ASSEMBLY - ECM) Disconnect the combination meter sub-assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition G1-24 (EFI) - A40-27 (W) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 13
8. REPAIR CIRCUITS INDICATED BY OUTPUT DTCS. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__diagnostic-trouble-code-chart)
9. REPLACE ECM. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/engine-control-systems/#engine-control-system-service-information)
10. REPLACE COMBINATION METER SUB-ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/gauges-instrument-panels/#meter-gauge-display-service-information)
11. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostics-introduction__check-for-intermittent-problems)
12. GO TO VC OUTPUT CIRCUIT. Refer to «VC Output Circuit»(/toyota/prius-c/i-2011-2015/remont/testing-diagnostics/#engine-control-system-diagnostic-codes-p1604-u0293-circuit-tests)
13. REPLACE COMBINATION METER SUB-ASSEMBLY. Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/gauges-instrument-panels/#meter-gauge-display-service-information)

See also:
• FREEZE FRAME DATA
• DIAGNOSTIC TROUBLE CODE CHART
• CHECK FOR INTERMITTENT PROBLEMS
• INSPECTION MODE PROCEDURE
• DTC CHECK / CLEAR
• INSPECTION
• CHECKING MONITOR STATUS
• WIRING DIAGRAM
• ON-VEHICLE INSPECTION
• ON-VEHICLE INSPECTION - Step 2
• INSPECTION
• REMOVAL
• REMOVAL
• DESCRIPTION
• ON-VEHICLE INSPECTION - Step 3
• ON-VEHICLE INSPECTION - Step 8
• PROCEDURE - Step 8
• REMOVAL
• HOW TO PROCEED WITH TROUBLESHOOTING
• DTC P043E: Evaporative Emission System Leak Detection Reference Orifice Low Flow; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission Leak Detection Pump Stuck OFF; DTC P2402: Evaporative Emission Leak Detection Pump Stuck ON; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low
• REMOVAL
• INSPECTION
• PROBLEM SYMPTOMS TABLE
• HOW TO PROCEED WITH TROUBLESHOOTING
• HOW TO PROCEED WITH TROUBLESHOOTING
• REMOVAL
• WIRING DIAGRAM
• DESCRIPTION
