Steering Column (service Information) Toyota Prius C I

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. PRECAUTION Refer to «PRECAUTION»(/toyota/prius-c/i-2011-2015/remont/manual-power-steering/#steering-system-inspection-adjustment__precaution)
2. ALIGN FRONT WHEELS FACING STRAIGHT AHEAD
3. REMOVE HORN BUTTON ASSEMBLY Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/airbag/#supplemental-restraint-system-service-information__removal)
4. REMOVE STEERING WHEEL ASSEMBLY See step 3
5. REMOVE LOWER STEERING COLUMN COVER Remove the 3 screws. Disengage the 4 claws and remove the lower steering column cover.
6. REMOVE UPPER STEERING COLUMN COVER Disengage the 2 claws and remove the upper steering column cover.
7. REMOVE TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY NOTE: Do not replace the spiral cable with sensor sub-assembly with the negative (-) auxiliary battery cable connected and the ignition switch on (IG). Do not rotate the spiral cable with sensor sub-assembly without the steering wheel with the negative (-) auxiliary battery cable connected and the ignition switch on (IG). Ensure that the steering wheel is installed and aligned straight when inspecting the steering sensor. Do not remove the steering sensor from the spiral cable. Disconnect the connectors from the turn signal switch assembly with spiral cable sub-assembly. Using pliers, expand the clamp. TEXT IN ILLUSTRATION *1 Clamp *2 Claw While holding the clamp expanded, raise the claw using a screwdriver to disengage it, and then remove the turn signal switch assembly with spiral cable sub-assembly from the steering column assembly.
8. REMOVE LOWER NO. 1 INSTRUMENT PANEL AIR BAG ASSEMBLY Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/airbag/#supplemental-restraint-system-service-information)
9. REMOVE COLUMN HOLE COVER SILENCER SHEET Remove the 2 clips and the column hole cover silencer sheet.
10. SEPARATE STEERING SLIDING YOKE SUB-ASSEMBLY Put matchmarks on the steering sliding yoke sub-assembly and steering gear assembly. TEXT IN ILLUSTRATION *a Matchmark Loosen bolt A. Remove bolt B. Separate the steering sliding yoke sub-assembly from the steering gear assembly.
11. REMOVE STEERING SLIDING YOKE SUB-ASSEMBLY Put matchmarks on the steering sliding yoke sub-assembly and No. 2 steering intermediate shaft assembly. TEXT IN ILLUSTRATION *a Matchmark Remove the steering sliding yoke sub-assembly from the No. 2 steering intermediate shaft assembly.
12. REMOVE NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY Put matchmarks on the No. 2 steering intermediate shaft assembly and steering column assembly. TEXT IN ILLUSTRATION *a Matchmark Remove the bolt. Remove the steering intermediate shaft assembly from the steering column assembly.
13. REMOVE BRAKE PEDAL SUPPORT ASSEMBLY Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/mechanical-hydraulic/#brake-system-hydraulic-service-information)
14. REMOVE UPPER INSTRUMENT PANEL ASSEMBLY Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
15. REMOVE STEERING COLUMN ASSEMBLY Disconnect the 2 connectors from the power steering ECU assembly. Disengage the wire harness clamp. Disconnect the connectors and disengage the wire harness clamps from the steering column assembly. Remove the bolt, 2 nuts and steering column assembly.

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. REMOVE TRANSPONDER KEY AMPLIFIER (w/o Smart Key System) Disengage the 2 claws and disconnect the transponder key amplifier.
2. REMOVE STEERING LOCK ACTUATOR ASSEMBLY (w/ Smart Key System) Secure the steering column assembly in a vise between aluminum plates. NOTE: Do not overtighten the vise. Using a drill, drill a hole in the steering lock set bolt, to insert a screw extractor. Using the screw extractor, remove the steering lock set bolt and remove the steering lock actuator assembly.
3. REMOVE UPPER STEERING COLUMN WITH SWITCH BRACKET ASSEMBLY (w/o Smart Key System) Secure the steering column assembly in a vise between aluminum plates. NOTE: Do not overtighten the vise. Using a drill, drill a hole in the steering lock set bolt, to insert a screw extractor. Using the screw extractor, remove the steering lock set bolt and remove the upper steering column with switch bracket assembly.
4. REMOVE UN-LOCK WARNING SWITCH ASSEMBLY (w/o Smart Key System) Insert the key. Remove the un-lock warning switch assembly by releasing the 2 claws. HINT: Slide the un-lock warning switch assembly, in the direction shown by the arrow in the illustration, to remove it.
5. REMOVE KEY INTER LOCK SOLENOID (w/o Smart Key System) Remove the screw and key lock solenoid from the upper steering column bracket assembly.
6. REMOVE IGNITION SWITCH LOCK CYLINDER ASSEMBLY (w/o Smart Key System) Turn the ignition switch to ACC. Insert the tip of a screwdriver into the hole in the upper steering column bracket assembly, as shown in the illustration, and pull the ignition switch lock cylinder assembly out until its claw comes into contact with the stopper of the upper steering column bracket assembly. TEXT IN ILLUSTRATION *1 Claw *2 Stopper Push Pull NOTE: Pull the ignition switch lock cylinder assembly out until the claw comes into contact with the stopper of the upper steering column bracket assembly. Otherwise, the following procedure cannot be conducted properly. Insert the tip of a screwdriver into the hole in the steering column bracket and tilt it downward, as shown in the illustration, to disengage the claw on the ignition switch lock cylinder. Then pull out the ignition switch lock cylinder. TEXT IN ILLUSTRATION *1 Claw *2 Stopper *a Claw disengaged *b Driver Insertion Hole Tilt Pull out
7. REMOVE IGNITION OR STARTER SWITCH ASSEMBLY (w/o Smart Key System) Disengage the 2 claws and remove the ignition or starter switch assembly from the upper steering column bracket assembly. NOTE: Be sure to start operation while the ignition or starter switch assembly faces upward, and while the upper steering column bracket assembly faces downward. Check the press in condition of the arrow inner part. If the inner part has loose fit, replace the upper steering column bracket assembly.
8. REMOVE POWER STEERING MOTOR ASSEMBLY NOTE: Do not drop the power steering motor assembly, strike it with tools or subject it to impacts. If the power steering motor assembly is subjected to an impact, replace it with a new one. Do not pull the wire harness and tilt steering support bond cable of the power steering motor assembly. Do not allow any moisture to come into contact with the power steering motor assembly. Do not loosen any bolts not mentioned in the procedure. Do not allow any foreign objects to contaminate the power steering motor assembly. Cut the clamp, and remove the clamp and the 3 pieces of tape from the wire harness. NOTE: When removing the clamp and the tape, be careful not to damage the wire harness. Remove the 2 bolts and power steering motor assembly from the electric power steering column sub-assembly.

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

1. INSPECT PRELOAD Secure the steering column assembly in a vice using aluminum plates and wooden block as shown in the illustration. TEXT IN ILLUSTRATION *1 Aluminum Plate *2 Wooden Block NOTE: When using a vise, do not overtighten it. Using SST and a torque wrench, turn the main shaft at a constant speed of approximately 1 revolution every 4 seconds and measure the preload. SST: 09616-00011 Preload Torque: 1.4 N*m (14 kgf*cm, 12 in.*lbf) or less If the preload is not as specified, replace the electric power steering column sub-assembly or power steering motor sub-assembly with a new one.
2. INSPECT STEERING LOCK OPERATION (w/o Smart Key System) Remove the key and check that the steering lock function is activated. Insert the key, turn the ignition switch to ACC and check that the steering lock function has been deactivated.
3. INSPECT STEERING COLUMN ASSEMBLY Check that the 2 bushings are securely installed to the steering column assembly. If the bushings are deformed, missing or damaged, replace the electric power steering column sub-assembly with a new one. Check that the 2 capsules are securely installed to the electric power steering column sub-assembly as shown in the illustration. TEXT IN ILLUSTRATION *1 Capsule *a OK *b NG Standard Capsules do not overlap the corner parts of the brackets. NOTE: If the standard value is not satisfied, replace the electric power steering column sub-assembly with a new one. If the capsules have deformation, damage or misalignment, replace the electric power steering column sub-assembly with a new one.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. INSTALL POWER STEERING MOTOR ASSEMBLY NOTE: Do not drop the power steering motor assembly, strike it with tools or subject it to impacts. If the power steering motor assembly is subjected to an impact, replace it with a new one. Do not pull the wire harness and tilt steering support bond cable of the power steering motor assembly. Do not allow any moisture to come into contact with the power steering motor assembly. Do not loosen any bolts not mentioned in the procedure. Do not allow any foreign objects to contaminate the power steering motor assembly. Apply grease to the serrated part of the electric power steering column sub-assembly. TEXT IN ILLUSTRATION Grease NOTE: First wipe off the existing grease from the serrated part, and then apply the dedicated grease supplied with a new power steering motor assembly or electric power steering column sub-assembly. Temporarily install the power steering motor assembly to the electric power steering column sub-assembly with the 2 bolts. NOTE: When temporarily installing the 2 bolts to the power steering motor assembly, do not tighten them all the way down. Secure the steering column assembly in a vise using aluminum plates. TEXT IN ILLUSTRATION *1 Aluminum Plate *2 Wooden Block NOTE: Do not overtighten the vise, as the steering column assembly may become deformed. Secure the power steering motor assembly so that it is directly upright. Support the steering column assembly with a wooden block or similar item to ensure that it does not fall. Using SST, turn the steering main shaft once 180 degrees to the left and then 180 degrees to the right at a speed of 60 rpm, and repeat 2 to 3 times to adjust the axis centering of the power steering motor assembly. SST: 09616-00011 Tighten the 2 bolts. Torque: 19 N*m (189 kgf*cm, 14 ft.*lbf) Using SST, measure the turning torque of the steering main shaft. SST: 09616-00011 Turning torque Torque: 1.4 N*m (14 kgf*cm, 12 in.*lbf) or less NOTE: Ensure that there is no abnormal resistance during rotation. If the torque is not as specified, readjust the axis centering of the power steering motor assembly. Install a new clamp and tape to the wire harness as shown in the illustration. TEXT IN ILLUSTRATION *1 Torque Sensor Wire Harness *2 Power Steering Motor Wire Harness *3 Tape A *4 Clamp *5 Tape B - - *a 383 to 403 mm (1.26 to 1.32 ft.) *b 100 mm (3.934 in.) *c 80 to 100 mm (3.15 to 3.93 in.) *d 155 to 175 mm (6.11 to 6.89 in.) *e 74 to 94 mm (2.92 to 3.70 in.) *f 10 mm (0.394 in.) NOTE: Wrap the tape around the area marked as "A" in the illustration more than 1.5 times. Wrap the tape around the area marked as "B" in the illustration more than 2 times. As heat from the power steering motor assembly may generate smoke, use heat resistant tape (resistant to 100°C (212°F) or more). Cut off the excess length of the clamp.
2. INSTALL IGNITION OR STARTER SWITCH ASSEMBLY (w/o Smart Key System) Engage the 2 claws to install the ignition or starter switch assembly onto the upper steering column bracket assembly.
3. INSTALL KEY INTER LOCK SOLENOID (w/o Smart Key System) Install the key inter lock solenoid onto the upper steering column bracket assembly with the screw.
4. INSTALL UN-LOCK WARNING SWITCH ASSEMBLY (w/o Smart Key System) Engage the 2 claws to install the un-lock warning switch assembly onto the upper steering column bracket assembly. HINT: Slide the un-lock warning switch assembly, in the direction shown by the arrow in the illustration, to install it.
5. INSTALL IGNITION SWITCH LOCK CYLINDER ASSEMBLY (w/o Smart Key System) Turn the ignition switch to ACC. Install the ignition switch lock cylinder assembly into the upper steering column bracket assembly. Make sure that the ignition switch lock cylinder assembly is securely fixed onto the ignition switch lock cylinder assembly.
6. INSTALL UPPER STEERING COLUMN WITH SWITCH BRACKET ASSEMBLY (w/o Smart Key System) Set the steering column assembly in a vise between aluminum plates. NOTE: Do not overtighten the vise. Install the upper steering column with switch bracket assembly with a new steering lock set bolt, and then tighten the bolt until its head comes off.
7. INSTALL STEERING LOCK ACTUATOR ASSEMBLY (w/ Smart Key System) HINT: When replacing the steering lock actuator assembly, perform initialization. Refer to «REGISTRATION»(/toyota/prius-c/i-2011-2015/remont/door-locks-anti-theft-systems/#engine-immobiliser-with-smart-key-system-diagnostics-introduction) . Set the steering column assembly in a vise between aluminum plates. NOTE: Do not overtighten the vise. Install the steering lock actuator assembly with a new steering lock set bolt, and then tighten the bolt until its head comes off.
8. INSTALL TRANSPONDER KEY AMPLIFIER (w/o Smart Key System) Engage the 2 claws to install the transponder key amplifier.

Scheme 43

Scheme 44

Scheme 45

1. INSPECT STEERING COLUMN ASSEMBLY See step 3
2. INSTALL STEERING COLUMN ASSEMBLY Install the steering column assembly with a new bolt and 2 nuts. Bolt Torque: 36 N*m (367 kgf*cm, 27 ft.*lbf) Nut Torque: 25 N*m (255 kgf*cm, 18 ft.*lbf) NOTE: Be sure there is no interference around the wire harness. There are two different bolt sizes (12 mm (0.472 in.) or 14 mm (0.551 in.)) available. Engage the wire harness clamp. Connect the 2 connectors to the power steering ECU assembly. Connect the connectors and engage the wire harness clamps to the steering column assembly.
3. INSTALL UPPER INSTRUMENT PANEL ASSEMBLY Refer to «INSTALLATION»(/toyota/prius-c/i-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
4. INSTALL BRAKE PEDAL SUPPORT ASSEMBLY Refer to «INSTALLATION»(/toyota/prius-c/i-2011-2015/remont/mechanical-hydraulic/#brake-system-hydraulic-service-information)
5. CONNECT NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY When reusing the electric power steering column sub-assembly and No. 2 steering intermediate shaft assembly: Align the matchmarks on the No. 2 steering intermediate shaft assembly and the steering column assembly, and install them. TEXT IN ILLUSTRATION *a Matchmark When replacing the electric power steering column sub-assembly or No. 2 steering intermediate shaft assembly: Align the marking (pink) on the steering column assembly shaft with the slit of the No. 2 steering intermediate shaft assembly, and install them. TEXT IN ILLUSTRATION *a Marking (Pink) *b Slit Install the bolt while aligning the No. 2 steering intermediate shaft assembly with the position A as shown in the illustration. Standard A 17.5 to 18.7 mm (0.689 to 0.736 in.) Torque: 35 N*m (360 kgf*cm, 26 ft.*lbf)
6. INSTALL STEERING SLIDING YOKE SUB-ASSEMBLY Install the steering sliding yoke sub-assembly to the No. 2 steering intermediate shaft assembly. TEXT IN ILLUSTRATION *a Matchmark NOTE: Align the matchmarks on the steering sliding yoke sub-assembly and the No. 2 steering intermediate shaft assembly. Temporarily install the bolt. HINT: Fully tighten the bolt after installing the steering sliding yoke sub-assembly to the steering gear assembly.
7. CONNECT STEERING SLIDING YOKE SUB-ASSEMBLY Install the steering sliding yoke sub-assembly to the steering gear assembly. TEXT IN ILLUSTRATION *a Matchmark NOTE: Align the matchmarks on the steering sliding yoke sub-assembly and the steering gear assembly. When the steering sliding yoke sub-assembly is replaced with a new one, it has no matchmarks, so install it while the head of the bolt B faces the back of the vehicle. Install bolt B. Torque: 35 N*m (360 kgf*cm, 26 ft.*lbf) Tighten bolt A. Torque: 35 N*m (360 kgf*cm, 26 ft.*lbf)
8. INSTALL COLUMN HOLE COVER SILENCER SHEET Install the column hole cover silencer sheet with the 2 clips. Install the floor carpet.
9. INSTALL LOWER NO. 1 INSTRUMENT PANEL AIR BAG ASSEMBLY Refer to «INSTALLATION»(/toyota/prius-c/i-2011-2015/remont/airbag/#supplemental-restraint-system-service-information)
10. INSTALL TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY NOTE: Do not replace the spiral cable with sensor sub-assembly with the negative (-) auxiliary battery cable connected and the ignition switch on (IG). Do not rotate the spiral cable with sensor sub-assembly without the steering wheel with the negative (-) auxiliary battery cable connected and the ignition switch on (IG). Ensure that the steering wheel is installed and aligned straight when inspecting the steering sensor. Do not remove the spiral cable from the steering sensor. Using pliers, expand the clamp. While holding the clamp expanded, install the turn signal switch assembly with spiral cable sub-assembly to the steering column assembly and engage the claw. Return the clamp to its original position. Connect the connectors to the turn signal switch assembly with spiral cable sub-assembly.
11. INSTALL UPPER STEERING COLUMN COVER Engage the 2 claws to install the upper steering column cover.
12. INSTALL LOWER STEERING COLUMN COVER Engage the 4 claws to install the lower steering column cover. Install the 3 screws.
13. ALIGN FRONT WHEELS FACING STRAIGHT AHEAD
14. ADJUST SPIRAL CABLE WITH SENSOR SUB-ASSEMBLY . Refer to «INSTALLATION - Step 5»(/toyota/prius-c/i-2011-2015/remont/airbag/#supplemental-restraint-system-service-information)
15. INSTALL STEERING WHEEL ASSEMBLY See step 7
16. INSTALL HORN BUTTON ASSEMBLY Refer to «INSTALLATION»(/toyota/prius-c/i-2011-2015/remont/airbag/#supplemental-restraint-system-service-information__installation)
17. PERFORM CALIBRATION OF TORQUE SENSOR ZERO POINT Refer to «CALIBRATION»(/toyota/prius-c/i-2011-2015/remont/manual-power-steering/#power-steering-system-diagnostics-introduction)

Scheme 46

Scheme 47

REMOVAL

Note. Do not replace the spiral cable with sensor sub-assembly with the negative (-) auxiliary battery cable connected and the ignition switch on (IG). Do not rotate the spiral cable with sensor sub-assembly without the steering wheel with the negative (-) auxiliary battery cable connected and the ignition switch on (IG). Ensure that the steering wheel is installed and aligned straight when inspecting the steering sensor. Do not remove the steering sensor from the spiral cable.

Scheme 48

Scheme 49

Scheme 50

1. ALIGN FRONT WHEELS FACING STRAIGHT AHEAD
2. REMOVE HORN BUTTON ASSEMBLY Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/airbag/#supplemental-restraint-system-service-information__removal)
3. REMOVE STEERING WHEEL ASSEMBLY Remove the steering wheel assembly set nut. TEXT IN ILLUSTRATION *a Matchmark Put matchmarks on the steering wheel assembly and steering main shaft. Disconnect the connectors from the spiral cable. Using SST, remove the steering wheel assembly. TEXT IN ILLUSTRATION *a Turn *b Hold SST: 09950-50013 09951-05010 09952-05010 09953-05020 09954-05070 NOTE: Apply a small amount of grease to the threads and tip of SST (09953-05020) before use.
4. REMOVE STEERING PAD SWITCH ASSEMBLY See step 2
5. REMOVE CRUISE CONTROL SWITCH (w/ Cruise Control System) . Refer to «REMOVAL - Step 2»(/toyota/prius-c/i-2011-2015/remont/cruise-control-systems/#cruise-control-system-service-information)
6. REMOVE CRUISE CONTROL SWITCH WIRE (w/ Cruise Control System)
7. REMOVE LOWER STEERING WHEEL BOSS COVER Disengage the 2 pins and 4 claws to remove the lower steering wheel boss cover from the steering wheel sub-assembly.

INSTALLATION

Note. Do not replace the spiral cable with sensor sub-assembly with the negative (-) auxiliary battery cable connected and the ignition switch on (IG). Do not rotate the spiral cable with sensor sub-assembly without the steering wheel with the negative (-) auxiliary battery cable connected and the ignition switch on (IG). Ensure that the steering wheel is installed and aligned straight when inspecting the steering sensor. Do not remove the steering sensor from the spiral cable.

1. INSTALL LOWER STEERING WHEEL BOSS COVER Engage the 2 pins and 4 claws to install the lower steering wheel boss cover to the steering wheel sub-assembly.
2. INSTALL CRUISE CONTROL SWITCH WIRE (w/ Cruise Control System)
3. INSTALL CRUISE CONTROL SWITCH (w/ Cruise Control System) . Refer to «INSTALLATION - Step 1»(/toyota/prius-c/i-2011-2015/remont/cruise-control-systems/#cruise-control-system-service-information)
4. INSTALL STEERING PAD SWITCH ASSEMBLY See step 2
5. ALIGN FRONT WHEELS FACING STRAIGHT AHEAD
6. ADJUST SPIRAL CABLE WITH SENSOR SUB-ASSEMBLY . Refer to «INSTALLATION - Step 5»(/toyota/prius-c/i-2011-2015/remont/airbag/#supplemental-restraint-system-service-information)
7. INSTALL STEERING WHEEL ASSEMBLY Align the matchmarks on the steering wheel assembly and steering main shaft to install the steering wheel assembly. TEXT IN ILLUSTRATION *a Matchmark Install the steering wheel assembly set nut. Torque: 50 N*m (510 kgf*cm, 37 ft.*lbf) Connect the connectors to the spiral cable sub-assembly.
8. CHECK STEERING WHEEL CENTER POINT
9. INSTALL HORN BUTTON ASSEMBLY Refer to «INSTALLATION»(/toyota/prius-c/i-2011-2015/remont/airbag/#supplemental-restraint-system-service-information__installation)

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

1. REMOVE HORN BUTTON ASSEMBLY Refer to «REMOVAL»(/toyota/prius-c/i-2011-2015/remont/airbag/#supplemental-restraint-system-service-information__removal)
2. REMOVE STEERING PAD SWITCH ASSEMBLY Disconnect the steering pad switch connector from the spiral cable. Remove the 2 screws. Disengage the 2 claws to remove the steering pad switch assembly (RH side) from the steering wheel sub-assembly. Remove the 2 screws. Disengage the 2 claws to remove the steering pad switch assembly (LH side) from the steering wheel sub-assembly.
3. REMOVE STEERING PAD SWITCH LH Remove the clamp. Disconnect the connector to remove the steering pad switch LH from the steering pad switch RH.

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. INSPECT STEERING PAD SWITCH LH Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 1 (IL+2) - 2 (IL+2) No switch pushed Below 1 ohms 3 (AU1) - 5 (EAU) No switch pushed 95 to 105 kohms Seek+ switch pushed Below 2.5 ohms Seek- switch pushed 323 to 335 ohms Volume+ switch pushed 980 to 1020 ohms Volume- switch pushed 3048 to 3172 ohms 4 (AU2) - 5 (EAU) No switch pushed 95 to 105 kohms MODE switch pushed Below 2.5 ohms On hook switch pushed 323 to 335 ohms Off hook switch pushed 980 to 1020 ohms Voice switch pushed*1 3048 to 3172 ohms *1: w/ Voice Switch of Steering Pad Switch LH HINT: If the result is not as specified, replace the steering pad switch LH. TEXT IN ILLUSTRATION *A w/ Voice Switch of Steering Pad Switch LH - - *a Component without harness connected (Steering Pad Switch LH) *b Volume+ *c Volume- *d MODE *e Seek+ *f Seek- *g Voice *h On hook *i Off hook - - Check the illumination. Connect an auxiliary battery positive (+) lead to terminal IL+2 and a negative (-) lead to terminal EAU of the steering pad switch LH connector. Check that the switch illumination comes on. OK Steering pad switch illumination comes on. HINT: If the result is not as specified, replace the steering pad switch LH. TEXT IN ILLUSTRATION *a Component without harness connected (Steering Pad Switch LH)
2. INSPECT STEERING PAD SWITCH RH Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition z2-1 (HO) - Terminal-A Always Below 1 ohms z2-2 (TRIP) - z2-8 (EAU)*1 TRIP switch pushed Below 2.5 ohms z2-3 (AC1) - z2-8 (EAU) No switch pushed 95 to 105 kohms R/F switch pushed 323 to 335 ohms TEMP+ switch pushed 980 to 1020 ohms TEMP- switch pushed 3048 to 3172 ohms z2-7 (DISP) - z2-8 (EAU)*1 DISP switch pushed Below 2.5 ohms SR1-2 (IL+2) - z2-5 (IL+2) No switch pushed Below 1 ohms SR1-3 (AU1) - z2-10 (AU1) No switch pushed Below 1 ohms SR1-4 (AU2) - z2-9 (AU2) No switch pushed Below 1 ohms SR1-5 (EAU) - z2-8 (EAU) No switch pushed Below 1 ohms *1: w/o Touch Tracer Display HINT: If the result is not as specified, replace the steering pad switch RH. TEXT IN ILLUSTRATION *A w/o Touch Tracer Display - - *a Component without harness connected (Steering Pad Switch RH) *b TEMP+ *c TEMP- *d DISP *e R/F *f TRIP *g Terminal-A - - Check the illumination. Connect an auxiliary battery positive (+) lead to terminal IL+2 and a negative (-) lead to terminal EAU of the steering pad switch RH connector. Check that the switch illumination comes on. OK Steering pad switch illumination comes on. HINT: If the result is not as specified, replace the steering pad switch RH. TEXT IN ILLUSTRATION *a Component without harness connected (Steering Pad Switch RH)

Scheme 60

1. INSTALL STEERING PAD SWITCH LH Connect the connector to install the steering pad switch LH to the steering pad switch RH. Align a new clamp with the groove and install it as shown in the illustration. TEXT IN ILLUSTRATION *1 Clamp *a 70 to 85 mm (2.76 to 3.35 in.) *b 10 mm (0.394 in.) or less *c 1 to 3 mm (0.0394 to 0.118 in.) Front of the Vehicle NOTE: Make sure to install the clamp in the correct direction. After installation, cut off the excess length of the clamp within the specified range *c shown in the illustration.
2. INSTALL STEERING PAD SWITCH ASSEMBLY Engage the 2 claws to install the steering pad switch assembly (RH side) to the steering wheel sub-assembly. Install the 2 screws. Torque: 2.4 N*m (25 kgf*cm, 21 in.*lbf) Engage the 2 claws to install the steering pad switch assembly (LH side) to the steering wheel sub-assembly. Install the 2 screws. Torque: 2.4 N*m (25 kgf*cm, 21 in.*lbf) Connect the steering pad switch connector to the spiral cable.
3. INSTALL HORN BUTTON ASSEMBLY Refer to «INSTALLATION»(/toyota/prius-c/i-2011-2015/remont/airbag/#supplemental-restraint-system-service-information__installation)
