Ground Point Electrical-Wiring Diagram (1 Of 6). Scheme 234
Scheme 234: Ground Point Electrical-Wiring Diagram (1 Of 6)
Ground Point Electrical-Wiring Diagram (2 Of 6). Scheme 235
Scheme 235: Ground Point Electrical-Wiring Diagram (2 Of 6)
Ground Point Electrical-Wiring Diagram (3 Of 6). Scheme 236
Scheme 236: Ground Point Electrical-Wiring Diagram (3 Of 6)
Ground Point Electrical-Wiring Diagram (4 Of 6). Scheme 237
Scheme 237: Ground Point Electrical-Wiring Diagram (4 Of 6)
Ground Point Electrical-Wiring Diagram (5 Of 6). Scheme 238
Scheme 238: Ground Point Electrical-Wiring Diagram (5 Of 6)
Ground Point Electrical-Wiring Diagram (6 Of 6). Scheme 239
Scheme 239: Ground Point Electrical-Wiring Diagram (6 Of 6)
Parts Location
| Code | Refer to |
|---|
| A50 | POSITION OF PARTS IN INSTRUMENT PANEL |
| M46 | POSITION OF PARTS IN BODY |
Relay Blocks
| Code | Refer to | Relay Blocks (Relay Block Location) |
|---|
| 2 | ENGINE ROOM R/B NO. 2; : ENGINE ROOM J/B NO. 2: FRONT FENDER APRON RH | Engine Room R/B No. 2 (Front Fender Apron RH) |
Junction Block and Wire Harness Connector
| Code | Refer to | Junction Block and Wire Harness (Connector Location) |
|---|
| 2C | ENGINE ROOM R/B NO. 2; : ENGINE ROOM J/B NO. 2: FRONT FENDER APRON RH | Engine Room Main Wire and Engine Room J/B No. 2 (Front Fender Apron RH) |
| 2D |
| 3A | INSTRUMENT PANEL J/B ASSEMBLY INSTRUMENT PANEL REINFORCEMENT | Instrument Panel Wire and Instrument Panel J/B Assembly (Instrument Panel Reinforcement) |
| 3B |
| 3C | INSTRUMENT PANEL J/B ASSEMBLY INSTRUMENT PANEL REINFORCEMENT | Engine Room Main Wire and Instrument Panel J/B Assembly (Instrument Panel Reinforcement) |
| 3D | INSTRUMENT PANEL J/B ASSEMBLY INSTRUMENT PANEL REINFORCEMENT | Floor Wire and Instrument Panel J/B Assembly (Instrument Panel Reinforcement) |
| 6A | COWL SIDE J/B NO. 1 COWL SIDE PANEL RH | Instrument Panel Wire and Cowl Side J/B No. 1 (Cowl Side Panel RH) |
| 6B | COWL SIDE J/B NO. 1 COWL SIDE PANEL RH | Front Door RH Wire and Cowl Side J/B No. 1 (Cowl Side Panel RH) |
| 7A | COWL SIDE J/B NO. 2 COWL SIDE PANEL LH | Instrument Panel Wire and Cowl Side J/B No. 2 (Cowl Side Panel LH) |
| 7B | COWL SIDE J/B NO. 2 COWL SIDE PANEL LH | Front Door LH Wire and Cowl Side J/B No. 2 (Cowl Side Panel LH) |
Connector Joining Wire Harness and Wire Harness
| Code | Refer to | Joining Wire Harness and Wire Harness (Connector Location) |
|---|
| AM2 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Engine Room Main Wire and Floor Wire (Cowl Side Panel LH) |
| CA2 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Engine Wire and Engine Room Main Wire (Front Fender Apron LH) |
| KM1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Rear Door No. 1 Wire and Floor Wire (Center Body Pillar RH) |
| LM1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Rear Door No. 2 Wire and Floor Wire (Center Body Pillar LH) |
| MG2 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Floor Wire and Instrument Panel Wire (Cowl Side Panel LH) |
| MY1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Floor Wire and Front Seat RH Wire (FR Seat) |
| QG1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Roof Wire and Instrument Panel Wire (Front Body Inner Pillar LH) |
| SM1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Back Door No. 1 Wire and Floor Wire (Roof Side Inner Panel LH) |
| ST1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Back Door No. 1 Wire and Back Door No. 2 (Back Door Panel) |
| Code | Refer to | Ground Points Location |
|---|
| A1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Front Fender Apron LH |
| A2 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Cowl Side Panel LH |
| A3 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Front Fender Apron RH |
| A4 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Front Fender Apron LH |
| A5 |
| C1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Transmission |
| C2 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Engine Unit |
| G1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Cowl Side Panel RH |
| G2 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Cowl Side Panel LH |
| G3 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Instrument Panel Reinforcement |
| G4 |
| G5 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Cowl Side Panel RH |
| G6 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Cowl Side Panel LH |
| G7 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Instrument Panel Reinforcement |
| H1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Front Door Inner Panel RH |
| J1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Front Door Inner Panel LH |
| M1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Quarter Wheel House Panel LH |
| M2 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Quarter Panel RH |
| M3 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Quarter Wheel House Panel RH |
| T1 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Back Door Panel |
| U1 |
