STARTER SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Brush Minimum Length | ||
| Planetary 0.8 kW | .354" (9.0 mm) | |
| Reduction 1.0 kW | .335" (8.5 mm) | |
| Brush Spring Load | ||
| Planetary 0.8 kW | 2.0-4.0 Lbs. (9-18 N) | |
| Reduction 1.0 kW | 2.6-5.3 Lbs. (12-24 N) | |
| Commutator Minimum Diameter | ||
| 0.8 kW | 1.06" (27 mm) | |
| 1.0 kW | 1.14" (29.0 mm) | |
| Commutator Minimum Undercut Depth | .008" (.2 mm) | |
| Commutator Runout | .002" (.05 mm) | |
| Armature Core Runout | .002" (.05 mm) | |
STARTER SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Intake Manifold Support | 13 (18) |
| Starter Mounting Bolts | 27 (37) |
TORQUE SPECIFICATIONS
