Maintenance Information: Overview Toyota Paseo L40

Procedures 3 illustrations ~922 words

Driver's Side Instrument Panel Fuse Identification

  1. 1 - 15 Amp - Cigarette Lighter, Clock
  2. 2 - 10 Amp - Turn Signal Indicators, Clearance Lights
  3. 3 - 20 Amp - Front Wiper & Washer Switch, Front Wiper & Washer Relay
  4. 4 - 15 Amp - A/C Switch, AT Indicator Light, Overdrive Main Switch, Blower Switch, Cigarette Lighter, Clock, Combination Meter, Light Control Switch, Front Turn Signal Indicators, Clearance Lights
  5. 5 - 10 Amp - Cruise Control ECU, Engine ECU (M/T), Engine & ECT ECU (A/T)
  6. 6 - 15 Amp - Alternator, A/T Indicator Light, Overdrive Main Switch, Back-Up Lights, Brake Fluid Level Switch, Brake Level Warning Light, Check Engine Warning Light, Cruise Control Indicator, Combination Meter, Overdrive Off Indicator, Seat Belt Warning Light, Defogger Switch, Door Courtesy Lights

Scheme 1

Scheme 1: RIGHT PASSENGER COMPARTMENT FUSE PANEL ID (1992)
Scheme 1: RIGHT PASSENGER COMPARTMENT FUSE PANEL ID (1992)

Passenger's Side Kick Panel Fuse Identification

  1. 1 - 10 Amp - Cigarette Lighter, Radio & Clock
  2. 2 - 30 Amp - Turn Signal Lights
  3. 3 - Heater Relay

Scheme 2

Scheme 2: ENGINE COMPARTMENT FUSE PANEL IDENTIFICATION (1992)
Scheme 2: ENGINE COMPARTMENT FUSE PANEL IDENTIFICATION (1992)

Fuse & Circuit Breaker Identification

  1. 1 - 15 Amp - ACV (Idle Control), Check Connector, Theft Deterrent System Relay, Engine ECU (M/T), Engine & ECT ECU (A/T)
  2. 2 - 15 Amp - Turn Signal Indicators, Turn Signal, Horn Switch, Clearance Lights
  3. 3 - 15 Amp - AM2 (Ignition Switch)
  4. 4 - 15 Amp - Clock, Combination Meter, High Beam Indicators, Door Open Warning Light, Dimmer Switch, Cruise Control ECU, Door Courtesy Light Switch
  5. 5 - 10 Amp - Right Headlight
  6. 6 - 10 Amp - Left Headlight
  7. 7 - 30 Amp - Radiator Fan
  8. 8 - 30 Amp - Condenser Fan

Relay Identification

  1. A - Radiator Fan Relay No. 1
  2. B - Horn Relay
  3. C - EFI Main Relay
  4. D - Engine Main Relay
  5. E - 100 Amp Alternator
  6. F - 50 Amp AM1 (Ignition Switch)
  7. G - A/C Condenser Fan Relay No. 3
  8. H - A/C Condenser Fan Relay No. 2

Scheme 3

Scheme 3: FUSE PANEL IDENTIFICATION (1993-94)
Scheme 3: FUSE PANEL IDENTIFICATION (1993-94)
  1. 1 - 15 Amp - Cigarette Lighter, Radio, Clock
  2. 2 - 10 Amp - Turn Signal Indicators, Clearance Lights
  3. 3 - 20 Amp - Front Wiper & Washer Switch, Front Wiper & Washer Relay
  4. 4 - 15 Amp - Tail lights, Parking Lights, License Light, Instrument Panel
  5. 5 - 10 Amp - Stop lights, High mounted Stoplight, Cruise Control
  6. 6 - 30 Amp - Rear Window Defogger (without timer)
  7. 7 - 15 Amp - Gauges and Meters. Service Reminder Lights, Warning Buzzers Open Door Warning Light, Back-up Lights, Cruise Control
  8. 8 - 7.5 Amp - SRS Airbag System
  9. 9 - 7.5 Amp - ABS System
  1. 10 - 30 Amp - Air Conditioning System, A/C Fuse, Rear Window Defogger (with timer)
  2. 11 - 10 Amp - Air Conditioning System

Engine Compartment Fuse & Relay Identification

  1. 12 - 7.5 Amp - Charging System
  2. 13 - 10 Amp - Left Headlight
  3. 14 - 10 Amp - Right Headlight
  4. 15 - 10 Amp - SRS Airbag System
  5. 16 - 15 Amp - Interior & Trunk Lights, Door Warning Light, Clock, Radio
  6. 17 - 15 Amp - Electronic Ignition System
  7. 18 - 15 Amp - Horns & Turn Signal Lights
  8. 19 - 15 Amp - Fuel Injection System
  9. 20 - 30 Amp - Electric Underhood Cooling Fan
  10. 21 - 30 Amp - Electric Underhood Cooling Fan
  11. 22 - 50 Amp - Electronic Ignition System
  12. 23 - 100 Amp - Charging System
  13. 24 - 60 Amp - ABS System
  1. A - EFI Main
  2. B - A/C Fan No. 3
  3. C - Engine Main
  4. D - Headlight
  5. E - A/C Fan No. 2
  6. F - Radiator Fan No. 1
  7. G - Horn
  1. 1 - 5 Amp - Charging System
  2. 2 - 5 Amp - Air Bag System (SRS)
  3. 3 - 10 Amp - Interior Light, Door Open Warning Light, Trunk Light, Clock, Radio, Cruise Control System
  4. 4 - 15 Amp - Multiport Fuel Injection/Sequential Multiport Fuel Injection
  5. 5 - 15 Amp - Horns, Turn Signals
  6. 6 - 15 Amp - Electronic Ignition System, Distributor Ignition System
  7. 7 - 10 Amp - Right-Hand Headlight
  8. 8 - 10 Amp - Left-Hand Headlight
  9. 9 - 5 Amp - Daytime Running Light System (DRL)
  10. 10 - 10 Amp - Left-Hand Headlight (HI-Beam)
  11. 11 - 10 Amp - Right-Hand Headlight (HI-Beam)
  12. 12 - 10 Amp - Left-Hand Headlight (LO-Beam)
  13. 13 - 10 Amp - Right-Hand Headlight (LO-Beam)
  14. 14 - 15 Amp - Cigarette Lighter, Radio, Clock
  15. 15 - 15 Amp - Turn Signal Lights
  16. 16 - 20 Amp - Windshield Wipers and Washers
  17. 17 - 15 Amp - Tail Lights, Parking Lights, License Plate Lights, Instrument Panel Lights
  18. 18 - 10 Amp - Stop Lights, High Mounted Stoplight, Cruise Control System
  19. 19 - 7.5 Amp - ABS System
  20. 20 - 15 Amp - Gauges & Meters, Back-up Lights, Cruise Control System, Service Reminder Indicator & Warning Buzzer (Except Discharge and Open Door Warning)
  21. 21 - 7.5 Amp - Air Bag System (SRS) (USA)
  22. 22 - 10 Amp - Air Conditioning System
  23. 23 - 40 Amp - Air Conditioning System, Rear Window Defroster (Timer)
  24. 24 - 30 Amp - Electric Cooling Fan (Radiator)
  25. 25 - 30 Amp - Electric Cooling Fan (Condenser)
  26. 26 - 30 Amp - Staring System
  27. 27 - 30 Amp - Dimmer Switch (Fuses 10, 11, 12 & 13)
  28. 28 - 50 Amp - Electronic Ignition System, Distributor Ignition System
  29. 29 - 60 Amp - ABS System
  30. 30 - 100 Amp - Charging System
  1. A - EFI Main
  2. B - A/C Fan No. 3
  3. C - Engine Main
  4. D - Headlight
  5. E - A/C Fan No. 2
  6. F - Radiator Fan No. 1
  7. G - Horn
