Wiring diagram: Headlights — Headlights circuit Toyota Matrix E140
All systems — 32 systems
- Air conditioning 1.8l
- Air conditioning 2.4l
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan 1.8l
- Cooling fan 2.4l
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 1.8l
- Engine performance 2.4l
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster 2
- Interior lights 2
- Power distribution
- Power door locks
- Power mirrors 2
- Power top/sunroof
- Power windows
- Radio
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 1.8l 2
- Transmission 2.4l 2
- Warning systems 2
- Wiper/washer 2
Components on these wiring diagrams 29
Click a component to highlight it on every diagram it appears on.
