Instrument cluster — Instrument cluster circuit Toyota Matrix E130
All systems — 27 systems
- Air conditioning
- Anti-lock brakes 2
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control 2
- Defoggers
- Engine performance 1.8l 3
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster 2
- Interior lights 2
- Power distribution
- Power door locks
- Power mirrors 2
- Power top/sunroof
- Power windows
- Radio 2
- Shift interlock
- Starting/charging 3
- Supplemental restraints
- Transmission 2
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams 29
Click a component to highlight it on every diagram it appears on.
