Seat Belt: Overview Toyota Matrix E130

Restraints Control Systems 3 illustrations

Scheme 1

Scheme 1: LOCATION

Scheme 1: LOCATION

Scheme 2

Scheme 2: PROBLEM SYMPTOMS TABLE

Scheme 2: PROBLEM SYMPTOMS TABLE

Note. The front seat inner belt RH cannot be inspected. When the front seat inner belt seems to be malfunctioning, use the hand-held tester to check for DTCs.

Scheme 3

Scheme 3: INSPECTION

Scheme 3: INSPECTION

INSPECT FRONT SEAT INNER BELT ASSY LH Measure the resistance of the buckle switch. RESISTANCE CONDITION Tester Connection Condition Specified Condition 5-6 Fasten seat belt 1 Mohms or higher 5-6 Release seat belt Below 1 ohms If the result is not as specified, replace the inner belt assy.
