REPLACEMENT — Part 6 Toyota Matrix E130

Scheme 458

Scheme 459

Scheme 460

Scheme 461

Scheme 462

Scheme 463

Scheme 464

Scheme 465

Scheme 466

Scheme 467

Scheme 468

Scheme 469

Scheme 470

Scheme 471

Scheme 472

Scheme 473

Scheme 474

Scheme 475

Scheme 476

Scheme 477

Scheme 478

Scheme 479

Scheme 480

Scheme 481

Scheme 482

Scheme 483

Scheme 484

Scheme 485

Scheme 486

Scheme 487

Scheme 488

Scheme 489

Scheme 490

Scheme 491

Scheme 492

Scheme 493

Scheme 494

Scheme 495

Scheme 496

Scheme 497

Scheme 498

Scheme 499

Scheme 500

Scheme 501

Scheme 502

Scheme 503

Scheme 504

Scheme 505

1. INSPECT 1st GEAR THRUST CLEARANCE Using a feeler gauge, measure the 1st gear thrust clearance. Standard clearance: 0.10 to 0.40 mm (0.0039 to 0.0157 in.)
2. INSPECT 2nd GEAR THRUST CLEARANCE Using a dial indicator, measure the 2nd gear thrust clearance. Standard clearance: 0.10 to 0.45 mm (0.0039 to 0.0177 in.)
3. INSPECT 1st GEAR RADIAL CLEARANCE Using a dial indicator, measure the 1st gear radial clearance. STANDARD CLEARANCE SPECIFICATIONS (1 OF 2) Bearing Clearance: mm (in.) KOYO made 0.015 to 0.058 (0.0006 to 0.0023) NSK made 0.015 to 0.056 (0.0006 to 0.0022) If the clearance is out of specification, replace the 1st gear needle roller bearing.
4. INSPECT 2nd GEAR RADIAL CLEARANCE Using a dial indicator, measure the 2nd gear radial clearance. STANDARD CLEARANCE SPECIFICATIONS (2 OF 2) Bearing Clearance: mm (in.) KOYO made 0.015 to 0.058 (0.0006 to 0.0023) NSK made 0.015 to 0.056 (0.0006 to 0.0022) If the clearance is out of specification, replace the 2nd gear needle roller bearing.
5. REMOVE 4th DRIVEN GEAR Using SST and a press, remove the output shaft rear bearing with 4th driven gear from the output shaft. SST 09950-00020
6. REMOVE OUTPUT GEAR SPACER Remove the output gear spacer from the output shaft.
7. REMOVE 2nd GEAR Using SST and a press, remove the 3rd driven gear with 2nd gear from the output shaft. SST 09950-00020
8. REMOVE 2nd GEAR NEEDLE ROLLER BEARING Remove the 2nd gear needle roller bearing and 2nd gear bearing spacer from the output shaft.
9. REMOVE SYNCHRONIZER RING SET NO. 2 Remove the synchronizer ring set No.2 from the output shaft.
10. REMOVE 1st GEAR Using 2 screwdrivers and a hammer, tap out the snap ring. HINT: Use a shop rag to keep the snap ring from flying. Using SST and a press, remove the transmission clutch hub No.1 with 1st gear from the output shaft. SST 09950-00020 NOTE: Do not tighten SST excessively. Support the input shaft by hand so that it will not be dropped off.
11. REMOVE SYNCHRONIZER RING NO. 1 Remove the synchronizer ring No.1 from the 1st gear.
12. REMOVE 1st GEAR NEEDLE ROLLER BEARING Remove the 1st. gear needle roller bearing from the output shaft.
13. REMOVE 1st GEAR THRUST WASHER Remove the 1st gear thrust washer from the output shaft.
14. REMOVE 1st GEAR THRUST WASHER PIN OR BALL Remove the 1st gear thrust washer pin or ball from the output shaft.
15. REMOVE REVERSE GEAR Remove the 3 synchromesh shifting keys, 3 synchromesh shifting key springs and reverse gear. HINT: Use a shop rag to keep the shifting key and shifting key spring from flying.
16. REMOVE OUTPUT SHAFT FRONT BEARING Using 2 screwdrivers, remove the snap ring. HINT: Use a shop rag to keep the snap ring from flying. Using SST and a press, remove the output shaft front bearing from the output shaft. SST 09950-00020
17. INSPECT OUTPUT SHAFT Using a dial indicator and 2 V-blocks, measure the shaft runout. Maximum runout: 0.015 mm (0.0006 in.) If the runout exceeds the maximum, replace the output shaft. Using a micrometer, measure the outer diameter of the output shaft journal surface. Outer diameter: Part A: 31.985 mm (1.2592 in.) Part B: 37.985 mm (1.4955 in) Part C: 32.985 mm (1.2986 in) If the outer diameter is below the minimum, replace the output shaft.
18. INSPECT 2nd GEAR Using a cylinder gauge, measure the inside diameter of the 2nd gear. INSIDE DIAMETER SPECIFICATIONS (1 OF 2) New gear: mm (in.) Maximum inside diameter: mm (in.) 38.015 to 38.031 (1.4967 to 1.4973) 38.031 (1.4973) If the inside diameter exceeds the maximum, replace the 2nd gear.
19. INSPECT 1st GEAR Using a cylinder gauge, measure the inside diameter of the 1st gear. INSIDE DIAMETER SPECIFICATIONS (2 OF 2) New gear: mm (in.) Maximum inside diameter: mm (in.) 44.015 to 44.031 (1.7329 to 1.7335) 44.031 (1.7335) If the inside diameter exceeds the maximum, replace the 1st gear.
20. INSPECT 1st GEAR THRUST WASHER Using a micrometer, measure the thickness of 1st gear thrust washer. THICKNESS SPECIFICATIONS New thrust washer: mm (in.) Minimum thickness: mm (in.) 5.975 to 6.025 (0.2352 to 0.2372) 5.975 (0.2352) If the thickness is below the minimum, replace the 1st gear thrust washer.
21. INSPECT SYNCHRONIZER RING SET NO. 2 Coat the 2nd gear cone with gear oil. Turn the synchronizer ring in one direction while pushing it against the 2nd gear cone. Check that the ring locks. If the synchronizer ring does not lock, replace the ring or 2nd gear. Using a feeler gauge, measure the clearance between the synchronizer ring back and gear spline end. Standard clearance: 0.7 to 1.3 mm (0.0276 to 0.0512 in.) If the clearance is out of specification, replace the synchronizer ring set No.2.
22. INSPECT SYNCHRONIZER RING NO. 1 Coat the 1st gear cone with gear oil. Turn the synchronizer ring in one direction while pushing it against the 1st gear cone. Check that the ring locks. If the synchronizer ring does not lock, replace the ring or 1st gear. Using a feeler gauge, measure the clearance between the synchronizer ring back and gear spline end. Standard clearance: 0.75 to 1.65 mm (0.0295 to 0.065) If the clearance is out of specification, replace the synchronizer ring No.1.
23. INSPECT REVERSE GEAR Using a vernier calipers, measure the width of the reverse gear groove (A) and the thickness of the claw part on the reverse shift fork (B), and calculate the clearance. Standard clearance (A - B): 0.15 to 0.35 mm (0.0059 to 0.0138 in.) If the clearance is out of specification, replace the reverse gear and reverse shift fork.
24. INSPECT TRANSMISSION CLUTCH HUB NO. 1 Check that the transmission clutch hub No.1 and reverse gear sub-assy slides smoothly. Check that the spline gear's edges of the reverse gear sub-assy is not worn down.
25. INSTALL REVERSE GEAR Coat the reverse gear with gear oil, install it to the transmission clutch hub No.1. NOTE: Be sure to set the reverse gear and transmission clutch hub No.1 in incorrect orientation. Using a screwdriver, install the 3 synchromesh shifting key springs and 3 synchromesh shifting keys.
26. INSTALL OUTPUT SHAFT FRONT BEARING Using SST and a press, install the new output shaft front bearing (inner race) to the output shaft. SST 09223-50010 Select a snap ring from the table below that will make the thrust clearance of the output shaft front bearing (inner race) below 0.1 mm (0.004 in.). SNAP RING THICKNESS SPECIFICATIONS (1 OF 2) Part No. Thickness: mm (in.) Mark 90520-30032 1.85 to 1.90 (0.0728 to 0.0748) 7 90520-30033 1.90 to 1.95 (0.0748 to 0.0768) 8 90520-30002 1.95 to 2.00 (0.0768 to 0.0787) 1 90520-30003 2.00 to 2.05 (0.0787 to 0.0807) 2 90520-30004 2.05 to 2.10 (0.0807 to 0.0827) 3 90520-30005 2.10 to 2.15 (0.0827 to 0.0846) 4 90520-30006 2.15 to 2.20 (0.0846 to 0.0866) 5 90520-30007 2.20 to 2.25 (0.0866 to 0.0886) 6 Using a brass bar and a hammer, tap in the snap ring. NOTE: Take care not to damage the journal surface of the output shaft.
27. INSTALL 1st GEAR THRUST WASHER PIN OR BALL Coat the 1st gear thrust washer pin or ball with MP grease, install it to the output shaft.
28. INSTALL 1st GEAR THRUST WASHER Coat the 1st gear thrust washer with gear oil, install it to the output shaft.
29. INSTALL 1st GEAR NEEDLE ROLLER BEARING Coat the 1st gear needle roller bearing with gear oil, install it to the output shaft.
30. INSTALL 1st GEAR Coat the 1st gear with gear oil, install it to the output shaft.
31. INSTALL SYNCHRONIZER RING NO. 1 Coat the synchronizer ring No.1 with gear oil, install it to the 1st gear.
32. INSTALL TRANSMISSION CLUTCH HUB NO. 1 Using SST and a press, install the transmission clutch hub No.1 to the output shaft. SST 09316-60011 (09316-00031) NOTE: The 1st gear can be turned. Select a snap ring from the table below that will make the thrust clearance of the transmission clutch hub No.1 below 0.1 mm (0.004 in.). SNAP RING THICKNESS SPECIFICATIONS (2 OF 2) Part No. Thickness: mm (in.) Mark 90520-29018 2.50 (0.0984) A 90520-29019 2.56 (0.1008) B 90520-29020 2.62 (0.1031) C 90520-29021 2.68 (0.1055) D 90520-29022 2.74 (0.1079) E 90520-29023 2.80 (0.1102) F Using a brass bar and a hammer, install the snap ring to the output shaft. NOTE: Take care not to damage the journal surface of the output shaft.
33. INSTALL 2nd GEAR NEEDLE ROLLER BEARING Coat the 2nd gear needle roller bearing and 2nd gear bearing spacer with gear oil, install them to the output shaft.
34. INSTALL SYNCHRONIZER RING SET NO. 2 Coat the synchronizer ring set No.2 with gear oil, install it to the 2nd gear.
35. INSTALL 2nd GEAR Coat the 2nd gear with gear oil, install it to the output shaft. NOTE: Fit the synchronizer inner ring claws into the slots in the transmission clutch hub No.1.
36. INSTALL 3rd DRIVEN GEAR Using SST and a press, install the 3rd driven gear to the output shaft. SST 09309-36100 (09309-03610), 09608-00071, 09950-60010 (09951-00450)
37. INSTALL OUTPUT GEAR SPACER Install the output gear spacer to the output shaft.
38. INSTALL 4th DRIVEN GEAR Using SST and a press, install 4th driven gear to the output shaft. SST 09612-22011
39. INSTALL OUTPUT SHAFT REAR BEARING Using SST and a press, install output shaft rear bearing to the output shaft. SST 09612-22011
40. INSPECT 2nd GEAR RADIAL CLEARANCE Using a dial indicator, measure the 2nd gear radial clearance. STANDARD CLEARANCE SPECIFICATIONS (1 OF 2) Bearing Clearance: mm (in.) KOYO made 0.015 to 0.058 (0.0006 to 0.0023) NSK made 0.015 to 0.056 (0.0006 to 0.0022) If the clearance is out of specification, replace the 2nd gear needle roller bearing.
41. INSPECT 1st GEAR RADIAL CLEARANCE Using a dial indicator, measure the 1st gear radial clearance. STANDARD CLEARANCE SPECIFICATIONS (2 OF 2) Bearing Clearance: mm (in.) KOYO made 0.015 to 0.058 (0.0006 to 0.0023) NSK made 0.015 to 0.056 (0.0006 to 0.0022) If the clearance is out of specification, replace the 1st gear needle roller bearing.
42. INSPECT 2nd GEAR THRUST CLEARANCE Using a dial indicator, measure the 2nd gear thrust clearance. Standard clearance: 0.10 to 0.45 mm (0.0039 to 0.0177 in.)
43. INSPECT 1st GEAR THRUST CLEARANCE Using a feeler gauge, measure the 1st gear thrust clearance. Standard clearance: 0.10 to 0.40 mm (0.0039 to 0.0157 in.)
