Engine Lubrication System: Overview Toyota Matrix E130

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. CHECK ENGINE OIL LEVEL Warm up the engine, then stop the engine and wait for 5 minutes. Check that the engine oil level is between the low level and full level marks on the level gage. If low, check for leakage and add oil up to the full level mark. NOTE: Do not fill with engine oil above the full level mark.
2. CHECK ENGINE OIL QUALITY Check the oil for deterioration, entry of water, discoloring or thinning. If the quality is visibly poor, replace the oil. Oil grade: Use API grade SL "Energy-Conserving", or ILSAC multigrade engine oil. SAE 5W-30 is the best choice for good fuel economy, and good starting in cold weather. If SAE 5W-30 is not available, SAE 10W-30 may be used. However, it should be replaced with SAE 5W-30 at the next oil replacement.
3. INSPECT OIL PRESSURE Disconnect the oil pressure switch connector. Using a deep socket wrench 24 mm, remove the oil pressure switch. Install the oil pressure gauge. Warm up the engine. Inspect the oil pressure. OIL PRESSURE SPECIFICATION At idle 29 kPa (0.3 kgf/cm2, 4.3 psi) or more At 3,000 RPM 294 to 539 kPa (3.0 to 5.5 kgf/cm2, 43 to 78 psi) Apply adhesive to 2 or 3 threads of the oil pressure switch. Adhesive: Part No. 08833-00080, THREE BOND 1344, LOCTITE 242 or equivalent Using a deep socket wrench 24 mm, install the oil pressure switch. Torque: 15 N.m (153 kgf.cm, 11 ft.lbf) NOTE: Do not start the engine within 1 hour of Installation. Connect the oil pressure switch connector. Check for the engine oil leaks.

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. DISCONNECT BATTERY NEGATIVE TERMINAL
2. REMOVE FRONT WHEEL RH
3. REMOVE ENGINE UNDER COVER RH
4. REMOVE CYLINDER HEAD COVER NO.2 (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
5. DRAIN ENGINE OIL (See «OIL FILTER SUB-ASSY (1ZZ-FE)»(ref-225903-S15375004002006032300000) )
6. DRAIN ENGINE COOLANT (See «ENGINE COOLANT (1ZZ-FE)»(ref-225902-S38549849082006032300000) )
7. REMOVE FAN AND GENERATOR V BELT (See «FAN AND GENERATOR V BELT (1ZZ-FE)»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
8. SEPARATE VANE PUMP ASSY (See «OVERHAUL»(ref-225921-S14477676182006032300000) )
9. REMOVE GENERATOR ASSY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/charging-system/#starting-system-charging-system) )
10. REMOVE ENGINE MOUNTING INSULATOR RH (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
11. REMOVE IGNITION COIL ASSY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
12. REMOVE CYLINDER HEAD COVER SUB-ASSY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
13. REMOVE V-RIBBED BELT TENSIONER ASSY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
14. REMOVE ENGINE MOUNTING BRACKET RH (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
15. REMOVE WATER PUMP ASSY (See «WATER PUMP ASSY (1ZZ-FE)»(ref-225902-S25491164062006032300000) )
16. SEPARATE CRANKSHAFT POSITION SENSOR (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
17. SET NO. 1 CYLINDER TO TDC/COMPRESSION (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
18. REMOVE CRANKSHAFT PULLEY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) ) SST 09960-10010 (09962-01000, 09963-01000)
19. REMOVE CHAIN TENSIONER ASSY NO.1 (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
20. REMOVE TIMING CHAIN OR BELT COVER SUB-ASSY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
21. REMOVE TIMING CHAIN OR BELT COVER OIL SEAL (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
22. REMOVE CRANKSHAFT POSITION SENSOR PLATE NO.1 (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
23. REMOVE CHAIN TENSIONER SLIPPER (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
24. REMOVE CHAIN SUB-ASSY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
25. REMOVE CHAIN VIBRATION DAMPER NO.1 Remove the 2 bolts and chain vibration damper.
26. REMOVE OIL PUMP ASSY Remove the 5 bolts, then remove the oil pump. Remove the gasket from the cylinder block.
27. INSTALL OIL PUMP ASSY Install a new gasket onto the cylinder block. Align the spline teeth of the oil pump drive rotor with the large teeth of the crankshaft, then slide on the oil pump. Install the oil pump with the 5 bolts. Torque: 9.0 N.m (92 kgf.cm, 80 In.lbf)
28. INSTALL CHAIN VIBRATION DAMPER NO.1 Torque: 9.0 N.m (92 kgf.cm, 80 in.lbf)
29. INSTALL CHAIN SUB-ASSY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) ) SST 09223-22010
30. INSTALL CHAIN TENSIONER SLIPPER (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
31. INSTALL CRANKSHAFT POSITION SENSOR PLATE NO.1 (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
32. INSTALL TIMING CHAIN OR BELT COVER OIL SEAL (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) ) SST 09223-22010
33. INSTALL TIMING CHAIN OR BELT COVER SUB-ASSY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
34. INSTALL CHAIN TENSIONER ASSY NO.1 (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
35. INSTALL CRANKSHAFT PULLEY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) ) SST 09960-10010 (09962-01000, 09963-01000)
36. INSTALL CRANKSHAFT POSITION SENSOR (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
37. INSTALL WATER PUMP ASSY (See «WATER PUMP ASSY (1ZZ-FE)»(ref-225902-S25491164062006032300000) )
38. INSTALL ENGINE MOUNTING BRACKET RH (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
39. INSTALL V-RIBBED BELT TENSIONER ASSY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
40. INSTALL CYLINDER HEAD COVER SUB-ASSY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
41. INSTALL IGNITION COIL ASSY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
42. INSTALL ENGINE MOUNTING INSULATOR RH (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
43. INSTALL GENERATOR ASSY (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/charging-system/#starting-system-charging-system) )
44. INSTALL VANE PUMP ASSY (See «OVERHAUL»(ref-225921-S14477676182006032300000) )
45. INSTALL FAN AND GENERATOR V BELT
46. ADD ENGINE COOLANT (See «ENGINE COOLANT (1ZZ-FE)»(ref-225902-S38549849082006032300000) )
47. ADD ENGINE OIL (See «OIL FILTER SUB-ASSY (1ZZ-FE)»(ref-225903-S15375004002006032300000) )
48. CONNECT BATTERY NEGATIVE TERMINAL Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf)
49. CHECK FOR ENGINE COOLANT LEAKAGE (See «COOLING SYSTEM (1ZZ-FE)»(ref-225902-S31651659182006032300000) )
50. CHECK FOR ENGINE OIL LEAKAGE
51. INSTALL CYLINDER HEAD COVER NO.2 (See «REPLACEMENT»(/toyota/matrix/e130-2002-2008/remont/accessory-drive-belts/#engine-mechanical) )
52. INSTALL FRONT WHEEL RH Torque: 103 N.m (1,050 kgf.cm, 76 ft.lbf)

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. REMOVE OIL PUMP DRIVE AND DRIVEN ROTORS Remove the 3 screws, then remove the oil pump cover. Remove the oil pump drive and driven rotors from the oil pump.
2. REMOVE OIL PUMP RELIEF VALVE Remove the oil pump relief valve plug, then remove the oil pump relief valve spring and oil pump relief valve from the oil pump.
3. INSPECT OIL JET Apply air pressure to the path shown in the illustration, then check the oil jet for damage or clogging. If the air does not blow out from the oil jet, replace the oil pump.
4. INSPECT OIL PUMP RELIEF VALVE Coat the oil pump relief valve with engine oil, then check that it falls smoothly into the valve hole by its own weight. If this does not occur, replace the oil pump.
5. CHECK ROTOR TIP CLEARANCE Using a feeler gauge, measure the clearance between the drive and driven rotor tips. Standard tip clearance: 0.040 to 0.160 mm (0.0016 to 0.0063 in.) Maximum tip clearance: 0.160 mm (0.0063 in.) If the tip clearance is greater than maximum, replace the oil pump.
6. CHECK ROTOR SIDE CLEARANCE Using a feeler gauge and precision straight edge, measure the clearance between the 2 rotors and precision straight edge. Standard side clearance: 0.025 to 0.071 mm (0.0010 to 0.0028 in.) Maximum side clearance: 0.071 mm (0.0028 in.) If the side clearance is greater than maximum, replace the oil pump.
7. CHECK ROTOR BODY CLEARANCE Using a feeler gauge, measure the clearance between the driven rotor and oil pump body. Standard body clearance: 0.260 to 0.325 mm (0.0102 to 0.0128 in.) Maximum body clearance: 0.325 mm (0.0128 in.) If the body clearance is greater than maximum, replace the oil pump.
8. INSTALL OIL PUMP RELIEF VALVE Coat the oil pump relief valve with engine oil, then insert the oil pump relief valve and oil pump relief spring into the valve hole. Install the oil pump relief valve plug. Torque: 37 N.m (377 kgf.cm, 27 ft.lbf)
9. INSTALL OIL PUMP DRIVE AND DRIVEN ROTORS Coat the oil pump drive and driven rotors with engine oil, and place them into the oil pump with marks facing the oil pump cover side. Install the oil pump cover with the 3 screws. Torque: 10 N.m (102 kgf.cm, 7 ft.lbf)
