Contents Section: Engine Control Systems All sections

Engine Control System (service Information) Toyota Land Cruiser 200 рестайлинг

Engine Control Systems 68 illustrations ~5548 words

Scheme 1

Scheme 1: ILLUSTRATION
Scheme 1: ILLUSTRATION

ON-VEHICLE INSPECTION

  1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2) or Control the VVT System (Bank 1) or Control the VVT System (Bank 2) or Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Tester Operation Specified Condition OCV OFF Normal engine speed OCV ON Soon after OCV switched from OFF to ON, engine idles roughly or stalls If the result is not as specified, check the oil control valve, wirings and camshaft timing gear. HINT: Control the VVT Linear (Bank 1): Command to activate exhaust and intake side oil control valves of bank 1 (Control range: Between -128 to 127%). Control the VVT Linear (Bank 2): Command to activate exhaust and intake side oil control valves of bank 2 (Control range: Between -128 to 127%). Control VVT System (Bank 1): Command to activate oil control valve of bank 1 (Control range: ON/OFF). Control VVT System (Bank 2): Command to activate oil control valve of bank 2 (Control range: ON/OFF). Control the VVT Exhaust Linear (Bank 1): Command to activate exhaust side oil control valve of bank 1 (Control range: Between -128 to 127%). Control the VVT Exhaust Linear (Bank 2): Command to activate exhaust side oil control valve of bank 2 (Control range: Between -128 to 127%).

Scheme 2

Scheme 2: REMOVAL
Scheme 2: REMOVAL

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 23»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  2. REMOVE AIR CLEANER HOSE ASSEMBLY . Refer to «REMOVAL - Step 9»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  3. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side of Bank 1) Disconnect the oil control valve connector. Remove the bolt and oil control valve. Remove the O-ring from the oil control valve.
  4. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side of Bank 1) Disconnect the oil control valve connector. Remove the bolt and oil control valve. Remove the O-ring from the oil control valve.
  5. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side of Bank 2) Disconnect the oil control valve connector. Remove the bolt and oil control valve. Remove the O-ring from the oil control valve.
  6. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side of Bank 2) Disconnect the oil control valve connector. Remove the bolt and oil control valve. Remove the O-ring from the oil control valve.

Scheme 6

Scheme 6: INSPECTION
Scheme 6: INSPECTION

Scheme 7

Scheme 7
Scheme 7
  1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms If the result is not as specified, replace the oil control valve assembly. Connect the battery positive (+) lead to terminal 1 and the negative (-) lead to terminal 2, and check the movement of the valve. OK Condition Specified Condition Battery positive (+) voltage is applied Valve moves in left arrow direction shown in the illustration Battery positive (+) voltage is cut off Valve moves in right arrow direction shown in the illustration If the result is not as specified, replace the oil control valve assembly. If the valve cannot return properly because of foreign matter, a small pressure leak in the advanced direction may occur and a DTC may be output.

INSTALLATION

  1. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side of Bank 1) Install a new O-ring to the oil control valve. Apply a light coat of engine oil to the O-ring. Install the oil control valve with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Do not allow foreign matter to contact the oil seal face of the oil control valve (connecting surface with cylinder head cover). Be careful that the O-ring is not cracked or moved out of place when installing the oil control valve. Connect the oil control valve connector.
  2. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side of Bank 1) Install a new O-ring to the oil control valve. Apply a light coat of engine oil to the O-ring. Install the oil control valve with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Do not allow foreign matter to contact the oil seal face of the oil control valve (connecting surface with cylinder head cover). Be careful that the O-ring is not cracked or moved out of place when installing the oil control valve. Connect the oil control valve connector.
  3. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side of Bank 2) Install a new O-ring to the oil control valve. Apply a light coat of engine oil to the O-ring. Install the oil control valve with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Do not allow foreign matter to contact the oil seal face of the oil control valve (connecting surface with cylinder head cover). Be careful that the O-ring is not cracked or moved out of place when installing the oil control valve. Connect the oil control valve connector.
  4. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side of Bank 2) Install a new O-ring to the oil control valve. Apply a light coat of engine oil to the O-ring. Install the oil control valve with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Do not allow foreign matter to contact the oil seal face of the oil control valve (connecting surface with cylinder head cover). Be careful that the O-ring is not cracked or moved out of place when installing the oil control valve. Connect the oil control valve connector.
  5. INSTALL AIR CLEANER HOSE ASSEMBLY . Refer to «INSTALLATION - Step 10»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  6. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 46»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)

Scheme 8

Scheme 8: ILLUSTRATION
Scheme 8: ILLUSTRATION

Scheme 9

Scheme 9: ILLUSTRATION
Scheme 9: ILLUSTRATION
  1. CHECK THROTTLE BODY ASSEMBLY Check the throttle control motor operating sounds. Turn the engine switch on (IG). When depressing the accelerator pedal, check the operating sound of the running motor. Make sure that no friction noises are emitted from the motor. If friction noise exists, replace the throttle body. Check the throttle position sensor. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream main switch on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Throttle Sensor Volt %. Depress the accelerator pedal. When the throttle valve is fully opened, check that the value of "Throttle Sensor Volt %" is within the specification. Standard throttle valve opening percentage 60% or more HINT: When checking the standard throttle valve opening percentage, the shift lever should be in N. If the percentage is less than 60%, replace the throttle body.

Scheme 10

Scheme 10: REMOVAL
Scheme 10: REMOVAL

Scheme 11

Scheme 11
Scheme 11
  1. REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY LH . Refer to «REMOVAL - Step 3»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  2. REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY RH . Refer to «REMOVAL - Step 4»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  3. REMOVE NO. 1 ENGINE UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 18»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  4. DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 4»(/toyota/land-cruiser/200-2012-2015/remont/cooling-fan/#engine-cooling-system-3ur-fe-service-information)
  5. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 23»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  6. REMOVE AIR CLEANER HOSE ASSEMBLY . Refer to «REMOVAL - Step 9»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  7. REMOVE THROTTLE BODY ASSEMBLY Disconnect the 2 water by-pass hoses. Disconnect the throttle position sensor and control motor connector. Remove the 4 bolts, throttle body and gasket. Remove the 2 water by-pass hoses from the throttle body.

Scheme 12

Scheme 12: INSPECTION
Scheme 12: INSPECTION
  1. INSPECT THROTTLE BODY ASSEMBLY Check the throttle valve. Check that the throttle valve opens and closes smoothly. Check that there is no sludge accumulating around the throttle body. Check the throttle control motor. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (M-) - 2 (M+) 20°C (68°F) 0.3 to 100 ohms If the result is not as specified, replace the throttle body.

Scheme 13

Scheme 13: INSTALLATION
Scheme 13: INSTALLATION
  1. INSTALL THROTTLE BODY ASSEMBLY Install the 2 water by-pass hoses to the throttle body. Install a new gasket to the intake air surge tank. HINT: Align the protrusion of the gasket with the groove of the intake air surge tank. Install the throttle body with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the throttle position sensor and control motor connector. Connect the 2 water by-pass hoses.
  2. ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 5»(/toyota/land-cruiser/200-2012-2015/remont/cooling-fan/#engine-cooling-system-3ur-fe-service-information)
  3. INSTALL AIR CLEANER HOSE ASSEMBLY . Refer to «INSTALLATION - Step 10»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  4. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(/toyota/land-cruiser/200-2012-2015/remont/cooling-fan/#engine-cooling-system-3ur-fe-inspection)
  5. CHECK THROTTLE BODY ASSEMBLY See step 1
  6. INSTALL NO. 1 ENGINE UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 49»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  7. INSTALL FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY LH . Refer to «INSTALLATION - Step 13»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  8. INSTALL FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY RH . Refer to «INSTALLATION - Step 14»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  9. PERFORM INITIALIZATION NOTE: Perform the following procedure after replacing the ECM, throttle body assembly or any throttle body components. The following procedure should also be performed if the throttle body is cleaned. Disconnect the cable from the negative (-) battery terminal. Wait at least 60 seconds and reconnect the cable. Turn the ignition switch on (IG) without operating the accelerator pedal. NOTE: If the accelerator pedal is operated, perform the above steps again. Connect the Techstream to the DLC3 and clear the DTCs. Refer to «INITIALIZATION»(/toyota/land-cruiser/200-2012-2015/remont/hoistjack/#introduction) . Start the engine and check that the MIL is not illuminated and that the idle speed is within the specified range when the A/C is switched off after the engine is warmed up. Standard Condition Engine Idle Speed A/C switched off 650 to 750 RPM NOTE: Be sure to perform this step with all accessories off. Make sure that the shift lever is in N or P. Enter the following menus: Powertrain / Engine and ECT / Data List / Throttle Sensor Volt %. Fully depress the accelerator pedal and check that the value is 60% or more. Perform a road test and confirm that there are no abnormalities.
  10. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 46»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)

Scheme 14

Scheme 14: ILLUSTRATION
Scheme 14: ILLUSTRATION

Scheme 15

Scheme 15: REMOVAL
Scheme 15: REMOVAL

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. PRECAUTION NOTE: After turning the engine switch off, waiting time may be required before disconnecting the cable from the battery terminal. Therefore, make sure to read the disconnecting the cable from the battery terminal notice before proceeding with work. Refer to «PRECAUTION»(/toyota/land-cruiser/200-2012-2015/remont/hoistjack/#introduction) .
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
  3. DISCONNECT CONNECTOR HOLDER BLOCK Remove the 3 bolts and move the connector holder block so that the ECM can be removed in the next step.
  4. REMOVE ECM Raise the 2 levers while pushing the locks on the 2 levers. NOTE: Make sure that the lock levers are raised 90° as shown in the illustration before disconnecting the connectors. Failure to do this may cause the connectors to break. Disconnect the 2 connectors. Remove the 4 bolts and ECM.
  5. REMOVE GASKET Peel off the gasket. Spray gasket remover or equivalent on the remaining tape of the gasket. NOTE: When using gasket remover or equivalent, cover the ECM connectors with a cloth. Remove the tape of the gasket without using bladed objects.

Scheme 21

Scheme 21
Scheme 21
  1. INSTALL GASKET Clean the ECM seal surface with non-residue solvent. Attach a new gasket to the ECM.
  2. INSTALL ECM Install the ECM with the 4 bolts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) NOTE: Make sure the gasket is not folded or caught on any area of the surrounding part. Make sure there is no foreign matter caught between the gasket and surrounding part. Do not damage the gasket. Connect the 2 ECM connectors and push each lock lever down to lock the ECM connectors. NOTE: Be careful not to allow dirt, water, or other foreign matter to adhere to the connecting parts when connecting the connectors. Do not twist the wire harness when connecting the ECM connectors. Make sure that the lock levers are raised 90° before connecting the ECM connectors. Failure to do this may cause the lock lever and terminals to break. Make sure that the levers are securely locked.
  3. INSTALL CONNECTOR HOLDER BLOCK Install the connector holder block with the 3 bolts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf)
  4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Scheme 22

Scheme 22: ILLUSTRATION
Scheme 22: ILLUSTRATION
  1. INSPECT ACCELERATOR PEDAL ASSEMBLY Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream main switch on. Enter the following menus: Powertrain / Engine and ECT / Data List / ETCS / Accel Sensor Out No. 1 and Accel Sensor Out No. 2. Read the value displayed on the Techstream. Standard Voltage Accelerator Pedal Operations Accel Sensor Out No. 1 Accel Sensor Out No. 2 Released 0.5 to 1.1 V 1.2 to 2.0 V Depressed 2.6 to 4.5 V 3.4 to 5.3 V If the result is not as specified, check the accelerator pedal, wire harness and ECM.

Scheme 23

Scheme 23: REMOVAL
Scheme 23: REMOVAL
  1. REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  2. REMOVE ACCELERATOR PEDAL ASSEMBLY Disconnect the accelerator pedal position sensor connector. Remove the 2 nuts and accelerator pedal.
  1. INSTALL ACCELERATOR PEDAL ASSEMBLY NOTE: Avoid physical shocks to the accelerator pedal. Do not disassemble the accelerator pedal. Install the accelerator pedal with the 2 nuts. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) Connect the accelerator pedal position sensor connector.
  2. INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 33»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)

Scheme 24

Scheme 24: ILLUSTRATION
Scheme 24: ILLUSTRATION

Scheme 25

Scheme 25: ON-VEHICLE INSPECTION
Scheme 25: ON-VEHICLE INSPECTION
  1. CHECK MASS AIR FLOW METER Check the mass air flow value. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream main switch on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF. Blow air into the MAF meter, and check that the MAF value fluctuates. If the result is not as specified, check the MAF meter. Refer to «INSPECTION»(/toyota/land-cruiser/200-2012-2015/remont/engine-control-systems/#engine-control-system-service-information) , or wiring and ECM. Refer to «DTC P0102: Mass or Volume Air Flow Circuit Low Input; DTC P0103: Mass or Volume Air Flow Circuit High Input»(/toyota/land-cruiser/200-2012-2015/remont/testing-diagnostics/#engine-control-system-3ur-fe-diagnostic-codes-p0010-p0415) .

Scheme 26

Scheme 26: REMOVAL
Scheme 26: REMOVAL
  1. REMOVE MASS AIR FLOW METER Disconnect the MAF connector. Remove the 2 screws and MAF meter.

Scheme 27

Scheme 27: INSPECTION
Scheme 27: INSPECTION

Scheme 28

Scheme 28
Scheme 28
  1. INSPECT MASS AIR FLOW METER Perform a visual check for any foreign matter on the platinum hot wire (heater) of the mass air flow meter shown in the illustration. OK There is no foreign matter. If the result is not as specified, replace the mass air flow meter. Check the IAT sensor. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 4 (THA) - 5 (E2) -20°C (-4°F) 12.5 to 16.9 kohms 20°C (68°F) 2.19 to 2.67 kohms 60°C (140°F) 0.50 to 0.68 kohms If the result is not as specified, replace the MAF meter.
  1. INSTALL MASS AIR FLOW METER Install the MAF meter with the 2 screws. Torque: 1.7 N*m (17 kgf*cm, 15 in.*lbf) Connect the MAF connector.

Scheme 29

Scheme 29: ILLUSTRATION
Scheme 29: ILLUSTRATION

Scheme 30

Scheme 30: ILLUSTRATION
Scheme 30: ILLUSTRATION

Scheme 31

Scheme 31: REMOVAL
Scheme 31: REMOVAL

Scheme 32

Scheme 32
Scheme 32
  1. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 23»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  2. REMOVE AIR CLEANER HOSE ASSEMBLY . Refer to «REMOVAL - Step 9»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  3. REMOVE CAMSHAFT POSITION SENSOR Disconnect the sensor connector. Remove the bolt and sensor.
  4. REMOVE VVT SENSOR Disconnect the 4 sensor connectors. Remove the 4 bolts and 4 sensors.
  1. INSTALL VVT SENSOR Install the 4 sensors with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the 4 sensor connectors.
  2. INSTALL CAMSHAFT POSITION SENSOR Install the sensor with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the sensor connector.
  3. INSTALL AIR CLEANER HOSE ASSEMBLY . Refer to «INSTALLATION - Step 10»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  4. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 46»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)

Scheme 33

Scheme 33: ILLUSTRATION
Scheme 33: ILLUSTRATION

Scheme 34

Scheme 34: REMOVAL
Scheme 34: REMOVAL

Scheme 35

Scheme 35
Scheme 35
  1. REMOVE NO. 2 ENGINE UNDER COVER . Refer to «REMOVAL - Step 19»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  2. REMOVE CRANKSHAFT POSITION SENSOR PROTECTOR Remove the 2 bolts and sensor protector.
  3. REMOVE CRANKSHAFT POSITION SENSOR Disconnect the sensor connector. Remove the bolt and sensor.
  1. INSTALL CRANKSHAFT POSITION SENSOR Install the sensor with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the sensor connector.
  2. INSTALL CRANKSHAFT POSITION SENSOR PROTECTOR Install the sensor protector with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
  3. INSTALL NO. 2 ENGINE UNDER COVER . Refer to «INSTALLATION - Step 48»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)

Scheme 36

Scheme 36: ILLUSTRATION
Scheme 36: ILLUSTRATION

Scheme 37

Scheme 37: ILLUSTRATION
Scheme 37: ILLUSTRATION

Scheme 38

Scheme 38: ILLUSTRATION
Scheme 38: ILLUSTRATION

Scheme 39

Scheme 39: REMOVAL
Scheme 39: REMOVAL

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41
  1. REMOVE NO. 2 ENGINE UNDER COVER . Refer to «REMOVAL - Step 19»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  2. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 23»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  3. REMOVE AIR CLEANER HOSE ASSEMBLY . Refer to «REMOVAL - Step 9»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  4. REMOVE AIR CLEANER ASSEMBLY . Refer to «REMOVAL - Step 25»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  5. DISCONNECT WATER BY-PASS PIPE ASSEMBLY Remove the 2 bolts and disconnect the water by-pass pipe from the cylinder head cover and timing chain cover. Remove the 3 bolts and disconnect the water by-pass pipe from the cylinder head cover.
  6. REMOVE IGNITION COIL ASSEMBLY Disconnect the 8 ignition coil connectors. Remove the 8 bolts and 8 ignition coils.
  7. REMOVE SPARK PLUG Remove the 8 spark plugs.
  1. INSTALL SPARK PLUG Install the 8 spark plugs. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
  2. INSTALL IGNITION COIL ASSEMBLY Install the 8 ignition coils with the 8 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the 8 ignition coil connectors.
  3. CONNECT WATER BY-PASS PIPE ASSEMBLY Connect the water by-pass pipe to the cylinder head cover and automatic transmission with the 3 bolts. Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf) Connect the water by-pass pipe to the cylinder head cover and timing chain cover with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
  4. INSTALL AIR CLEANER ASSEMBLY . Refer to «INSTALLATION - Step 36»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  5. INSTALL AIR CLEANER HOSE ASSEMBLY . Refer to «INSTALLATION - Step 10»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  6. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 46»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  7. INSTALL NO. 2 ENGINE UNDER COVER . Refer to «INSTALLATION - Step 48»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)

Scheme 42

Scheme 42: ILLUSTRATION
Scheme 42: ILLUSTRATION

Scheme 43

Scheme 43: REMOVAL
Scheme 43: REMOVAL
  1. REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY RH . Refer to «REMOVAL - Step 4»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  2. REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY LH . Refer to «REMOVAL - Step 3»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  3. REMOVE NO. 1 ENGINE UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 18»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  4. DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 4»(/toyota/land-cruiser/200-2012-2015/remont/cooling-fan/#engine-cooling-system-3ur-fe-service-information)
  5. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 23»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  6. REMOVE ENGINE COOLANT TEMPERATURE SENSOR Disconnect the sensor connector. Using a 19 mm deep socket wrench, remove the sensor. Remove the gasket from the sensor.

Scheme 44

Scheme 44: INSPECTION
Scheme 44: INSPECTION
  1. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Partially immerse the sensor in water and warm up the water. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 Approximately. 20°C (68°F) 2.32 to 2.59 kohms 1 - 2 Approximately. 80°C (176°F) 0.310 to 0.326 kohms NOTE: When checking the sensor in water, keep the terminals dry. After the check, wipe the sensor dry. If the result is not as specified, replace the sensor.
  1. INSTALL ENGINE COOLANT TEMPERATURE SENSOR Install a new gasket to the sensor. Using a 19 mm deep socked wrench, install the sensor. Torque: 20 N*m (200 kgf*cm, 14 ft.*lbf) Connect the sensor connector.
  2. ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 5»(/toyota/land-cruiser/200-2012-2015/remont/cooling-fan/#engine-cooling-system-3ur-fe-service-information)
  3. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(/toyota/land-cruiser/200-2012-2015/remont/cooling-fan/#engine-cooling-system-3ur-fe-inspection)
  4. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 46»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  5. INSTALL NO. 1 ENGINE UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 49»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  6. INSTALL FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY LH . Refer to «INSTALLATION - Step 13»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  7. INSTALL FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY RH . Refer to «INSTALLATION - Step 14»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)

Scheme 45

Scheme 45: ILLUSTRATION
Scheme 45: ILLUSTRATION

Scheme 46

Scheme 46: ILLUSTRATION
Scheme 46: ILLUSTRATION

Scheme 47

Scheme 47: ILLUSTRATION
Scheme 47: ILLUSTRATION

Scheme 48

Scheme 48: ILLUSTRATION
Scheme 48: ILLUSTRATION

Scheme 49

Scheme 49: REMOVAL
Scheme 49: REMOVAL
  1. REMOVE INTAKE MANIFOLD Remove the intake manifold. Refer to «REMOVAL»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information__removal) .
  2. REMOVE NO. 2 CYLINDER HEAD COVER . Refer to «REMOVAL - Step 6»(/toyota/land-cruiser/200-2012-2015/remont/auxiliary-emission-control-systems/#emission-control-system-3ur-fe-service-information)
  3. REMOVE NO. 1 ENGINE COVER . Refer to «REMOVAL - Step 8»(/toyota/land-cruiser/200-2012-2015/remont/auxiliary-emission-control-systems/#emission-control-system-3ur-fe-service-information)
  4. REMOVE KNOCK SENSOR Disconnect the 4 knock sensor connectors. Remove the 4 bolts and 4 knock sensors.

Scheme 50

Scheme 50: INSPECTION
Scheme 50: INSPECTION
  1. INSPECT KNOCK SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 120 k to 280 kohms If the result is not as specified, replace the sensor.

Scheme 51

Scheme 51: INSTALLATION
Scheme 51: INSTALLATION
  1. INSTALL KNOCK SENSOR Install the 4 sensors with the 4 bolts so that the sensors are angled as shown in the illustration. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) NOTE: The acceptable installation angle of the sensor is between 10° upward and downward from the horizontal position. Connect the 4 sensor connectors.
  2. INSTALL NO. 1 ENGINE COVER . Refer to «INSTALLATION - Step 9»(/toyota/land-cruiser/200-2012-2015/remont/auxiliary-emission-control-systems/#emission-control-system-3ur-fe-service-information)
  3. INSTALL NO. 2 CYLINDER HEAD COVER . Refer to «INSTALLATION - Step 11»(/toyota/land-cruiser/200-2012-2015/remont/auxiliary-emission-control-systems/#emission-control-system-3ur-fe-service-information)
  4. INSTALL INTAKE MANIFOLD Install the intake manifold. Refer to «INSTALLATION»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information) .

Scheme 52

Scheme 52: ILLUSTRATION
Scheme 52: ILLUSTRATION

REMOVAL

WARNINGWear protective gloves when removing the exhaust pipe. The exhaust pipe is extremely hot immediately after the engine has stopped. Confirm that the exhaust pipe has cooled down before removing it.

Scheme 53

Scheme 53
Scheme 53
  1. REMOVE NO. 2 ENGINE UNDER COVER . Refer to «REMOVAL - Step 19»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  2. REMOVE TAILPIPE ASSEMBLY . Refer to «REMOVAL - Step 2»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  3. REMOVE CENTER EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 4»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  4. REMOVE FRONT NO. 2 EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 5»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  5. REMOVE FRONT EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 6»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  6. REMOVE AIR FUEL RATIO SENSOR (for Bank 1 Sensor 1) Using SST, remove the sensor. SST: 09224-00010
  7. REMOVE AIR FUEL RATIO SENSOR (for Bank 2 Sensor 1) Using SST, remove the sensor. SST: 09224-00010

Scheme 54

Scheme 54: INSPECTION
Scheme 54: INSPECTION
  1. INSPECT AIR FUEL RATIO SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (HA1A) - 2 (+B) (for Bank 1) 20°C (68°F) 1.6 to 3.2 ohms 1 (HA2A) - 2 (+B) (for Bank 2) If the result is not as specified, replace the sensor.

Scheme 55

Scheme 55: INSTALLATION
Scheme 55: INSTALLATION

Scheme 56

Scheme 56
Scheme 56
  1. INSTALL AIR FUEL RATIO SENSOR (for Bank 2 Sensor 1) Temporarily install the sensor to the exhaust pipe by hand. Using SST, tighten the sensor. SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) HINT: Use a torque wrench with a fulcrum length of 300 mm (11.8 in.). If using a torque wrench with a length that is not 300 mm (11.8 in.), calculate the torque specification for the torque wrench and SST based on the "without SST" torque specification. Refer to «PRECAUTION»(/toyota/land-cruiser/200-2012-2015/remont/hoistjack/#introduction) . Make sure SST and the wrench are connected in a straight line.
  2. INSTALL AIR FUEL RATIO SENSOR (for Bank 1 Sensor 1) Temporarily install the sensor to the exhaust pipe by hand. Using SST, tighten the sensor. SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) HINT: Use a torque wrench with a fulcrum length of 300 mm (11.8 in.). If using a torque wrench with a length that is not 300 mm (11.8 in.), calculate the torque specification for the torque wrench and SST based on the "without SST" torque specification. Refer to «PRECAUTION»(/toyota/land-cruiser/200-2012-2015/remont/hoistjack/#introduction) . Make sure SST and the wrench are connected in a straight line.
  3. INSTALL FRONT EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 5»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  4. INSTALL FRONT NO. 2 EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 6»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  5. INSTALL CENTER EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 7»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  6. INSTALL TAILPIPE ASSEMBLY . Refer to «INSTALLATION - Step 9»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  7. INSTALL NO. 2 ENGINE UNDER COVER . Refer to «INSTALLATION - Step 48»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  8. INSPECT FOR EXHAUST GAS LEAK . Refer to «INSTALLATION - Step 13»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)

Scheme 57

Scheme 57: ILLUSTRATION
Scheme 57: ILLUSTRATION
WARNINGThe procedures should be performed by at least 2 people. Wear protective gloves when removing the exhaust pipe. The exhaust pipe is extremely hot immediately after the engine has stopped. Confirm that the exhaust pipe has cooled down before removing it.

Scheme 58

Scheme 58
Scheme 58
  1. REMOVE NO. 2 ENGINE UNDER COVER . Refer to «REMOVAL - Step 19»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  2. REMOVE TAILPIPE ASSEMBLY . Refer to «REMOVAL - Step 2»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  3. REMOVE CENTER EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 4»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  4. REMOVE FRONT NO. 2 EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 5»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  5. REMOVE FRONT EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 6»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  6. REMOVE HEATED OXYGEN SENSOR (for Bank 2 Sensor 2) Using SST, remove the sensor. SST: 09224-00010
  7. REMOVE NO. 2 HEATED OXYGEN SENSOR (for Bank 1 Sensor 2) Using SST, remove the sensor. SST: 09224-00010

Scheme 59

Scheme 59: INSPECTION
Scheme 59: INSPECTION
  1. INSPECT HEATED OXYGEN SENSOR Measure the heater resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (HT1B) - 2 (+B) (for Bank 1) 20°C (68°F) 11 to 16 ohms 1 (HT2B) - 2 (+B) (for Bank 2) If the result is not as specified, replace the sensor.

Scheme 60

Scheme 60: INSTALLATION
Scheme 60: INSTALLATION

Scheme 61

Scheme 61
Scheme 61
  1. INSTALL NO. 2 HEATED OXYGEN SENSOR (for Bank 1 Sensor 2) Temporarily install the sensor to the exhaust pipe by hand. Using SST, tighten the sensor. SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) HINT: Use a torque wrench with a fulcrum length of 300 mm (11.8 in.). If using a torque wrench with a length that is not 300 mm (11.8 in.), calculate the torque specification for the torque wrench and SST based on the "without SST" torque specification. Refer to «PRECAUTION»(/toyota/land-cruiser/200-2012-2015/remont/hoistjack/#introduction) . Make sure SST and the wrench are connected in a straight line.
  2. INSTALL HEATED OXYGEN SENSOR (for Bank 2 Sensor 2) Temporarily install the sensor to the exhaust pipe by hand. Using SST, tighten the sensor. SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) HINT: Use a torque wrench with a fulcrum length of 300 mm (11.8 in.). If using a torque wrench with a length that is not 300 mm (11.8 in.), calculate the torque specification for the torque wrench and SST based on the "without SST" torque specification. Refer to «PRECAUTION»(/toyota/land-cruiser/200-2012-2015/remont/hoistjack/#introduction) . Make sure SST and the wrench are connected in a straight line.
  3. INSTALL FRONT EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 5»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  4. INSTALL FRONT NO. 2 EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 6»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  5. INSTALL CENTER EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 7»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  6. INSTALL TAILPIPE ASSEMBLY . Refer to «INSTALLATION - Step 9»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  7. INSPECT FOR EXHAUST GAS LEAK . Refer to «INSTALLATION - Step 13»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  8. INSTALL NO. 2 ENGINE UNDER COVER . Refer to «INSTALLATION - Step 48»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)

Scheme 62

Scheme 62: ILLUSTRATION
Scheme 62: ILLUSTRATION

Scheme 63

Scheme 63: ILLUSTRATION
Scheme 63: ILLUSTRATION
  1. INSPECT POWER STEERING OIL PRESSURE SWITCH Check the oil pressure switch. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream main switch on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Power Steering pressure. Start the engine. Operate the steering wheel while idling, and read the value on the Techstream. Standard Condition Specified Condition Power steering not operating 0 to 2 MPa (0 to 20kgf/cm 2 , 0 to 2%psi) Power steering operating Values change from above value If not as specified, check for DTCs. Refer to «DTC CHECK / CLEAR»(/toyota/land-cruiser/200-2012-2015/remont/testing-diagnostics/#engine-control-system-3ur-fe-diagnostics-introduction__dtc-check-clear) . If the power steering system inspection results are normal and a DTC is not output, replace the power steering oil pressure switch. Inspect the power steering system. Refer to «ON-VEHICLE INSPECTION»(/toyota/land-cruiser/200-2012-2015/remont/manual-power-steering/#power-steering-system-inspection) . If the power steering system inspection results are normal and a DTC is not output, replace the power steering oil pressure switch.

Scheme 64

Scheme 64: REMOVAL
Scheme 64: REMOVAL
  1. REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY LH . Refer to «REMOVAL - Step 3»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  2. REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY RH . Refer to «REMOVAL - Step 4»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  3. REMOVE NO. 1 ENGINE UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 18»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  4. REMOVE AIR CLEANER HOSE ASSEMBLY . Refer to «REMOVAL - Step 9»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  5. REMOVE AIR CLEANER ASSEMBLY . Refer to «REMOVAL - Step 25»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  6. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 23»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  7. REMOVE FAN & GENERATOR V BELT . Refer to «REMOVAL - Step 5»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  8. DRAIN POWER STEERING FLUID
  9. REMOVE FRONT WHEEL
  10. REMOVE FRONT FENDER APRON SEAL FRONT RH . Refer to «REMOVAL - Step 5»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  11. REMOVE POWER STEERING OIL PRESSURE SWITCH Disconnect the switch connector. Using a 24 mm deep socket wrench, remove the oil pressure switch. Remove the O-ring.
  1. INSTALL POWER STEERING OIL PRESSURE SWITCH Install a new O-ring to the oil pressure switch. Apply a light coat of engine oil to the O-ring of the oil pressure switch. NOTE: When reusing the oil pressure switch, inspect the O-ring. If the O-ring has scratches or cuts, replace the new O-ring. Using a 24 mm deep socket wrench, install the oil pressure switch. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Connect the oil pressure switch connector.
  2. INSTALL FAN & GENERATOR V BELT . Refer to «INSTALLATION - Step 1»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  3. INSTALL AIR CLEANER ASSEMBLY . Refer to «INSTALLATION - Step 36»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  4. INSTALL AIR CLEANER HOSE ASSEMBLY . Refer to «INSTALLATION - Step 10»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  5. ADD POWER STEERING FLUID
  6. BLEED POWER STEERING FLUID . Refer to «ON-VEHICLE INSPECTION - Step 2»(/toyota/land-cruiser/200-2012-2015/remont/manual-power-steering/#power-steering-system-inspection)
  7. INSPECT FOR POWER STEERING FLUID LEAK
  8. INSTALL FRONT FENDER APRON SEAL FRONT RH . Refer to «INSTALLATION - Step 16»(/toyota/land-cruiser/200-2012-2015/remont/exhaust/#intake-system-exhaust-system-3ur-fe-service-information)
  9. INSTALL FRONT WHEEL
  10. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 46»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  11. INSTALL NO. 1 ENGINE UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 49»(/toyota/land-cruiser/200-2012-2015/remont/mechanical/#engine-mechanical-3ur-fe-service-information)
  12. INSTALL FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY LH . Refer to «INSTALLATION - Step 13»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  13. INSTALL FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY RH . Refer to «INSTALLATION - Step 14»(/toyota/land-cruiser/200-2012-2015/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)

Scheme 65

Scheme 65: ON-VEHICLE INSPECTION
Scheme 65: ON-VEHICLE INSPECTION

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68
  1. INSPECT INTEGRATION RELAY (IG2) Measure the resistance of the IG2 MAIN fuse. Remove the IG2 MAIN fuse from the integration relay. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition IG2 MAIN fuse Always Below 1 ohms If the result is not as specified, replace the IG2 MAIN fuse. Install the IG2 MAIN fuse to the integration relay. Measure the resistance of the ignition relay No. 2 (IG2) circuit. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1C-1 - 1B-8 Battery voltage is not applied to terminals 1B-6 and 1B-7 10 kohms or higher Battery voltage is applied to terminals 1B-6 and 1B-7 Below 1 ohms If the result is not as specified, replace the integration relay.
  2. INSPECT INTEGRATION RELAY (EFI) Measure the resistance of the EFI MAIN fuse. Remove the EFI MAIN fuse from the integration relay Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition EFI MAIN fuse Always Below 1 ohms If the result is not as specified, replace the EFI MAIN fuse. Install the EFI MAIN fuse to the integration relay. Measure the resistance of the EFI relay circuit. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1C-1 - 1B-4 Battery voltage is not applied to terminals 1B-2 and 1B-3 10 kohms or higher Battery voltage is applied to terminals 1B-2 and 1B-3 Below 1 ohms If the result is not as specified, replace the integration relay.
  3. INSPECT EFI NO. 2 RELAY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Battery voltage is not applied to terminals 1 and 2 10 kohms or higher Battery voltage is applied to terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the relay.
  4. INSPECT INTEGRATION RELAY (A/F) Measure the resistance of the A/F fuse. Remove the A/F fuse from the integration relay. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A/F fuse Always Below 1 ohms If the result is not as specified, replace the A/F fuse. Install the A/F fuse to the integration relay. Measure the resistance of the A/F sensor heater relay circuit. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1C-1 - 1A-4 Battery voltage is not applied to terminals 1A-2 and 1A-3 10 kohms or higher Battery voltage is applied to terminals 1 A-2 and 1A-3 Below 1 ohms If the result is not as specified, replace the integration relay.
  5. INSPECT MAIN BODY ECU (IG1 NO. 1) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2A-1 - 2B-17 Battery voltage is not applied to terminals 2B-5 and 2D-43 10 kohms or higher Battery voltage is applied to terminals 2B-5 and 2D-43 Below 1 ohms If the result is not as specified, replace the main body ECU.
  6. INSPECT STARTER RELAY (ST) . Refer to «ON-VEHICLE INSPECTION - Step 1»(/toyota/land-cruiser/200-2012-2015/remont/starter/#starting-system-3ur-fe-service-information)
  7. INSPECT STARTER CUT RELAY (ST CUT) . Refer to «ON-VEHICLE INSPECTION - Step 2»(/toyota/land-cruiser/200-2012-2015/remont/starter/#starting-system-3ur-fe-service-information)
  8. INSPECT MAIN BODY ECU (ACC RELAY) . Refer to «ON-VEHICLE INSPECTION - Step 3»(/toyota/land-cruiser/200-2012-2015/remont/starter/#starting-system-3ur-fe-service-information)

More articles — Engine
