PROBLEM SYMPTOMS TABLE
HINT
Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
Malfunction System
| Symptom | Suspected Area | Reference |
|---|---|---|
| Entire Combination Meter does not Operate | CAN communication system | ENTIRE COMBINATION METER DOES NOT OPERATE |
| Combination meter assembly | ENTIRE COMBINATION METER DOES NOT OPERATE | |
| Fuses (ECU-B1, MET) | ENTIRE COMBINATION METER DOES NOT OPERATE | |
| Harness or connector | ENTIRE COMBINATION METER DOES NOT OPERATE | |
| Odo/Trip Switch Malfunction | Combination meter assembly | ODO/TRIP SWITCH MALFUNCTION |
| Light control rheostat | ODO/TRIP SWITCH MALFUNCTION | |
| Harness or connector | ODO/TRIP SWITCH MALFUNCTION | |
| Operating Light Control Rheostat does not Change Light Brightness | Combination meter assembly | OPERATING LIGHT CONTROL RHEOSTAT DOES NOT CHANGE LIGHT BRIGHTNESS |
| Light control rheostat | OPERATING LIGHT CONTROL RHEOSTAT DOES NOT CHANGE LIGHT BRIGHTNESS | |
| Harness or connector | OPERATING LIGHT CONTROL RHEOSTAT DOES NOT CHANGE LIGHT BRIGHTNESS | |
| Meter Illumination is Always Dark | CAN communication system | METER ILLUMINATION IS ALWAYS DARK |
| Lighting system | METER ILLUMINATION IS ALWAYS DARK | |
| Combination meter assembly | METER ILLUMINATION IS ALWAYS DARK | |
| Main body ECU (Cowl side junction block LH) | METER ILLUMINATION IS ALWAYS DARK | |
| Meter Illumination does not Dim at Night | CAN communication system | METER ILLUMINATION DOES NOT DIM AT NIGHT |
| Lighting system | METER ILLUMINATION DOES NOT DIM AT NIGHT | |
| Combination meter assembly | METER ILLUMINATION DOES NOT DIM AT NIGHT | |
| Multi-information display does not change using DISP switch | Inspect steering pad switch | INSPECTION |
| Inspect spiral cable | REMOVAL | |
| Perform Active Test (Meter display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| Multi-information display is missing dots | Perform Active Test (Meter display 1) | DTC CHECK / CLEAR |
| Replace combination meter assembly | COMBINATION METER |
MALFUNCTION SYSTEM - PROBLEM SYMPTOMS CHART
Meter Gauges
| Symptom | Suspected Area | Reference |
|---|---|---|
| Speedometer Malfunction | CAN communication system | SPEEDOMETER MALFUNCTION |
| Combination meter assembly | SPEEDOMETER MALFUNCTION | |
| Vehicle stability control system | SPEEDOMETER MALFUNCTION | |
| Tachometer Malfunction | CAN communication system | TACHOMETER MALFUNCTION |
| Combination meter assembly | TACHOMETER MALFUNCTION | |
| SFI system | TACHOMETER MALFUNCTION | |
| Fuel Receiver Gauge Malfunction | Fuel sender gauge (DTC B1500) | FUEL RECEIVER GAUGE MALFUNCTION |
| Combination meter assembly | FUEL RECEIVER GAUGE MALFUNCTION | |
| Engine Coolant Temperature Receiver Malfunction | CAN communication system | ENGINE COOLANT TEMPERATURE GAUGE MALFUNCTION |
| Combination meter assembly | ENGINE COOLANT TEMPERATURE GAUGE MALFUNCTION | |
| SFI system | ENGINE COOLANT TEMPERATURE GAUGE MALFUNCTION | |
| Oil Pressure Receiver Gauge Malfunction | CAN communication system | OIL PRESSURE GAUGE MALFUNCTION |
| Combination meter assembly | OIL PRESSURE GAUGE MALFUNCTION | |
| Oil pressure sensor | OIL PRESSURE GAUGE MALFUNCTION | |
| Harness or connector | OIL PRESSURE GAUGE MALFUNCTION | |
| Voltage Meter Malfunction | Fuse (MET) | VOLTAGE METER MALFUNCTION |
| Combination meter assembly | VOLTAGE METER MALFUNCTION | |
| Harness or connector | VOLTAGE METER MALFUNCTION |
METER GAUGES - PROBLEM SYMPTOMS CHART
Warning/Indicator Lights
| Symptom | Suspected Area | Reference |
|---|---|---|
| BEAM indicator light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Lighting system | LIGHTING SYSTEM | |
| Perform Active Test (Indicat. Lamp Beam) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| A/T P warning light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Transfer system | INSPECTION | |
| SFI system | SFI SYSTEM | |
| Perform Active Test (Indicat. A/T P) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| SRS warning light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Airbag system | AIRBAG SYSTEM | |
| Perform Active Test (Indicat. Lamp Airbag) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| DOOR indicator light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Lighting system | LIGHTING SYSTEM | |
| Perform Active Test (Indicat. Lamp Doors All Open) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| Driver side seat belt warning light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Seat belt warning system | CUSTOMIZE PARAMETERS | |
| Perform Active Test (Driver Side Seat Belt) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| Brake warning light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Vehicle stability control system | VEHICLE STABILITY CONTROL SYSTEM | |
| Perform Active Test (Indicat. Lamp Brake) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| CHARGE warning light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| SFI system | SFI SYSTEM | |
| Perform Active Test (Indicat. Lamp Charge) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| 4LO indicator light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Transfer system | TRANSFER SYSTEM | |
| Replace combination meter assembly | COMBINATION METER | |
| ABS warning light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Vehicle stability control system | VEHICLE STABILITY CONTROL SYSTEM | |
| Perform Active Test (Indicat. Lamp ABS) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| MIL does not come on | Replace ECM | ECM |
| Replace combination meter assembly | COMBINATION METER | |
| Harness or connector | ||
| FUEL warning light does not come on | Perform Active Test (Indicat | Lamp fuel) ME-37 |
| Replace combination meter assembly | COMBINATION METER | |
| Harness or connector | ||
| SLIP indicator light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Vehicle stability control system | VEHICLE STABILITY CONTROL SYSTEM | |
| Perform Active Test (Indicat. Lamp Slip) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| CRUISE main indicator light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Cruise control system | CRUISE CONTROL SYSTEM | |
| Perform Active Test (Indicat. Lamp Cruise) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| HEAD indicator light does not come on*1 | CAN communication system | CAN COMMUNICATION SYSTEM |
| Lighting system | LIGHTING SYSTEM | |
| Perform Active Test (Indicat. Lamp Head) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| TAIL indicator light does not come on*2 | CAN communication system | CAN COMMUNICATION SYSTEM |
| Lighting system | LIGHTING SYSTEM | |
| Perform Active Test (Indicat. Lamp Tail) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| Turn signal indicator light does not come on | Lighting system | LIGHTING SYSTEM |
| Replace combination meter assembly | COMBINATION METER | |
| Tire pressure warning light does not come on*1 | CAN communication system | CAN COMMUNICATION SYSTEM |
| Tire pressure warning system | TIRE PRESSURE WARNING SYSTEM | |
| Perform Active Test (Indicat. Lamp Tire Press) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| Master warning light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Perform Active Test (Indicat. Lamp Master warning) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| CRAWL indicator light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Vehicle stability control system | VEHICLE STABILITY CONTROL SYSTEM | |
| Perform Active Test (Indicat. CRAWL) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| ECT PWR indicator light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Automatic transmission system | AUTOMATIC TRANSMISSION SYSTEM | |
| Perform Active Test (Indicat. lamp ECT PWR) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| 2nd START indicator light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| SFI system | SFI SYSTEM | |
| Perform Active Test (Indicat. 2nd START) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| Center differential lock indicator light does not come on | CAN communication system | CAN COMMUNICATION SYSTEM |
| Transfer system | TRANSFER SYSTEM | |
| Perform Active Test (Indicat. Ctr DIFF LOCK) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| HINT: *1: for U.S.A. *2: except U.S.A. | ||
WARNING/INDICATOR LIGHTS - PROBLEM SYMPTOMS CHART
Multi-information Display
| Symptom | Suspected Area | Reference |
|---|---|---|
| "LAND CRUISER" multi-information display malfunction | Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR |
| Replace combination meter assembly | COMBINATION METER | |
| "CURRENT" multi-information display malfunction | Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR |
| Replace combination meter assembly | COMBINATION METER | |
| "AFTER REFUELING" multi-information display malfunction | Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR |
| Replace combination meter assembly | COMBINATION METER | |
| "CRUISING RANGE" multi-information display malfunction | Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR |
| Replace combination meter assembly | COMBINATION METER | |
| "AFTER START" multi-information display malfunction | Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR |
| Replace combination meter assembly | COMBINATION METER | |
| "TIRE PRESSURE" multi-information display malfunction*1 | Tire pressure warning system | TIRE PRESSURE WARNING SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Tire Pressure Test Mode" multi-information display malfunction*1 | Tire pressure warning system | TIRE PRESSURE WARNING SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Check Tire Pressure System" multi-information display malfunctions | Tire pressure warning system | TIRE PRESSURE WARNING SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Tire Pressure Reset Proceeding" multi-information display malfunction*1 | Tire pressure warning system | TIRE PRESSURE WARNING SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "NORMAL" multi-information display malfunction | Cruise Control system | CRUISE CONTROL SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "CRAWL has been deactivated" multi-information display malfunction | Vehicle stability control system | VEHICLE STABILITY CONTROL SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "CRAWL is activated" multi-information display malfunction | Vehicle stability control system | VEHICLE STABILITY CONTROL SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "CRAWL not available" multi-information display malfunction | Vehicle stability control system | VEHICLE STABILITY CONTROL SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "BRAKE!" multi-information display malfunction | Pre-collision system | PRE-COLLISION SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Check PCS System" multi-information display malfunction | Pre-Collision system | PRE-COLLISION SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "PCS Not available now" multi-information display malfunction | Pre-Collision system | PRE-COLLISION SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Key is not detected" multi-information display malfunction | Smart key system (Entry Function) | SMART KEY SYSTEM (ENTRY FUNCTION) |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Low Key Battery" multi-information display malfunction | Smart key system (Entry Function) | SMART KEY SYSTEM (ENTRY FUNCTION) |
| Replace transmitter battery | TRANSMITTER BATTERY | |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Shift to P position" multi-information display malfunction | SFI system | SFI SYSTEM |
| Smart key system (Start Function) | SMART KEY SYSTEM (START FUNCTION) | |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "P" does not display on multi-information display | SFI system | SFI SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "R" does not display on multi-information display | SFI system | SFI SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "N" does not display on multi-information display | SFI system | SFI SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "D" does not display on multi-information display | SFI system | SFI SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "S" does not display on multi-information display | SFI system | SFI SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "S1" does not display on multi-information display | SFI system | SFI SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "S2" does not display on multi-information display | SFI system | SFI SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "S3" does not display on multi-information display | SFI system | SFI SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "S4" does not display on multi-information display | SFI system | SFI SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "S5" does not display on multi-information display | SFI system | SFI SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "S6" does not display on multi-information display | SFI system | SFI SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Check Steering Lock System" multi-information display malfunction | Steering lock system | STEERING LOCK SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Steering Lock is still active" multi-information display malfunction | Steering lock system | STEERING LOCK SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Depress the brake pedal, and touch the engine switch with the key" multi-information display malfunction | Smart key system (Start Function) | SMART KEY SYSTEM (START FUNCTION) |
| Engine immobilizer system | ENGINE IMMOBILIZER SYSTEM | |
| Steering lock system | STEERING LOCK SYSTEM | |
| SFI system | SFI SYSTEM | |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "To start, depress the brake pedal, and push the engine switch" multi-information display malfunction | Smart key system (Start Function) | SMART KEY SYSTEM (START FUNCTION) |
| Engine Immobilizer system | ENGINE IMMOBILIZER SYSTEM | |
| Steering lock system | STEERING LOCK SYSTEM | |
| SFI system | SFI SYSTEM | |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Moon Roof Opened" multi-information display malfunction | Sliding roof system | PROBLEM SYMPTOMS TABLE |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Driver's door Open" multi-information display malfunction | Lighting system | LIGHTING SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Front Passenger's Door Open" multi-information display malfunction | Lighting system | LIGHTING SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Right Rear Door Open" multi-information display malfunction | Lighting system | LIGHTING SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Left Rear Door Open" multi-information display malfunction | Lighting system | LIGHTING SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Back Door Open" multi-information display malfunction | Lighting system | LIGHTING SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Check Sonar" multi-information display malfunction | Intuitive parking assist system | INTUITIVE PARKING ASSIST SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Clean Sonar" multi-information display malfunction | Intuitive parking assist system | INTUITIVE PARKING ASSIST SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Release the Parking Brake" multi-information display malfunction | Parking brake system | PARKING BRAKE SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Check VSC System" multi-information display malfunction | Vehicle stability control system | VEHICLE STABILITY CONTROL SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "VSC Test Mode" multi-information display malfunction | Vehicle stability control system | VEHICLE STABILITY CONTROL SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "VSC OFF" multi-information display malfunction | Vehicle stability control system | VEHICLE STABILITY CONTROL SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "High Transmission Fluid Temperature" multi-information display malfunction | Automatic transmission system | AUTOMATIC TRANSMISSION SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Low Engine Oil Level" multi-information display malfunction | Replace Oil level sensor | REMOVAL |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Low Washer Fluid" multi-information display malfunction | Wiper and washer system | PROBLEM SYMPTOMS TABLE |
| Replace windshield washer jar and tank | ||
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Low Fuel" multi-information display malfunction | Fuel system | FUEL SYSTEM |
| Replace fuel sender gauge assembly | REMOVAL | |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Check Fuel System" multi-information display malfunction | Fuel system | FUEL SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| "Oil Maintenance Reqd Soon" multi-information display malfunction | Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR |
| Replace combination meter assembly | COMBINATION METER | |
| "Oil Maintenance Reqd" multi-information display malfunction | Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR |
| Replace combination meter assembly | COMBINATION METER | |
| "Oil Maintenance Reqd Reset" multi-information display malfunction | Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR |
| Replace combination meter assembly | COMBINATION METER | |
| "Oil Maintenance Reqd Reset UNFINISHED" multi-information display malfunction | Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR |
| Replace combination meter assembly | COMBINATION METER | |
| "DIAG VSC" multi-information display malfunction | Vehicle stability control system | VEHICLE STABILITY CONTROL SYSTEM |
| Perform Active Test (Meter Display 1) | DTC CHECK / CLEAR | |
| Replace combination meter assembly | COMBINATION METER | |
| HINT: *1: for U.S.A. | ||
MULTI-INFORMATION DISPLAY - PROBLEM SYMPTOMS CHART
Buzzer
| Symptom | Suspected Area | Reference |
|---|---|---|
| Driver seat belt warning buzzer (buzzer that sounds intermittently, and then sounds 5 times) does not sound | CAN communication system | CAN COMMUNICATION SYSTEM |
| Seat belt warning system | CUSTOMIZE PARAMETERS | |
| Replace combination meter assembly | COMBINATION METER | |
| Smart key buzzer (buzzer that sounds intermittently) does not sound | CAN communication system | CAN COMMUNICATION SYSTEM |
| Smart key system (Entry Function) | SMART KEY SYSTEM (ENTRY FUNCTION) | |
| Replace combination meter assembly | COMBINATION METER | |
| Immobilizer confirmed buzzer (buzzer that sounds once) does not sound | CAN communication system | CAN COMMUNICATION SYSTEM |
| Engine immobilizer system | ENGINE IMMOBILIZER SYSTEM | |
| Replace combination meter assembly | COMBINATION METER | |
| Multi-display warning buzzer (buzzer that sounds once) does not sound | Replace combination meter assembly | COMBINATION METER |
| Smart key buzzer (buzzer that sounds once) does not sound | CAN communication system | CAN COMMUNICATION SYSTEM |
| Smart key system (Entry Function) | SMART KEY SYSTEM (ENTRY FUNCTION) | |
| Replace combination meter assembly | COMBINATION METER | |
| Seat belt warning LEVEL 1 buzzer (buzzer that sounds continuously) does not sound | CAN communication system | CAN COMMUNICATION SYSTEM |
| Seat belt warning system | CUSTOMIZE PARAMETERS | |
| Replace combination meter assembly | COMBINATION METER | |
| Seat belt warning LEVEL 2 buzzer (buzzer that sounds continuously) does not sound | CAN communication system | CAN COMMUNICATION SYSTEM |
| Seat belt warning system | CUSTOMIZE PARAMETERS | |
| Replace combination meter assembly | COMBINATION METER | |
| Smart key buzzer (buzzer that sounds continuously) does not sound | CAN communication system | CAN COMMUNICATION SYSTEM |
| Smart key system (Entry Function) | SMART KEY SYSTEM (ENTRY FUNCTION) | |
| Replace combination meter assembly | COMBINATION METER | |
| PKB-ON running buzzer (buzzer that sounds intermittently) does not sound | CAN communication system | CAN COMMUNICATION SYSTEM |
| Replace combination meter assembly | COMBINATION METER | |
| Door ajar running warning buzzer (buzzer that sounds once) does not sound | CAN communication system | CAN COMMUNICATION SYSTEM |
| Replace combination meter assembly | COMBINATION METER | |
| Sports shift reject buzzer (buzzer that sounds twice) does not sound | CAN communication system | CAN COMMUNICATION SYSTEM |
| Automatic transmission system | AUTOMATIC TRANSMISSION SYSTEM | |
| Replace combination meter assembly | COMBINATION METER | |
| Light reminder buzzer (buzzer that sounds continuously) does not sound | CAN communication system | CAN COMMUNICATION SYSTEM |
| Lighting system | LIGHTING SYSTEM | |
| Replace combination meter assembly | COMBINATION METER | |
| Sliding roof buzzer (buzzer that sounds once) does not sound | Sliding roof system | PROBLEM SYMPTOMS TABLE |
| Replace combination meter assembly | COMBINATION METER | |
| Four wheel drive buzzer (buzzer that does not sound, sounds intermittently, and then sounds 3 times) does not sound | CAN communication system | CAN COMMUNICATION SYSTEM |
| Transfer system | TRANSFER SYSTEM | |
| Replace combination meter assembly | COMBINATION METER |
BUZZER - PROBLEM SYMPTOMS CHART
Scheme 19
Scheme 20
Scheme 21
Scheme 22
- CHECK COMBINATION METER Measure the resistance and voltage according to the value(s) in the table below. RESISTANCE AND VOLTAGE REFERENCE CHART Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition E7-3 (SI) - Body ground V - Body ground Speed signal (input) Engine switch on (IG), wheel turned slowly Pulse generation E7-4 (+S) - Body ground V - Body ground Speed signal (output) Engine switch on (IG), wheel turned slowly Pulse generation E7-5 (WLVL) - Body ground V - Body ground Washer level warning signal Washer fluid level sensor ON Below 1 V Washer fluid level sensor OFF 11 to 14 V E7-6 (OIL) - Body ground L - Body ground Oil level signal Oil level sensor ON Below 1 V Oil level sensor OFF 11 to 14 V E7-11 (R/O) - Body ground P - Body ground RSCA OFF indicator light input signal Engine switch on (IG), RSCA OFF indicator light on Below 1 V Engine switch on (IG), RSCA OFF indicator light off 8 to 14 V E7-12 (CHG-) - Body ground B - Body ground CHARGE warning light Engine switch on (IG), CHARGE warning light on Below 1 V Engine switch on (IG), CHARGE warning light off 11 to 14 V E7-14 (EP) - Body ground W-B - Body ground Ground Always Below 1 V E7-15 (ET) - Body ground BR - Body ground Ground Always Below 1 V E7-17 (B) - Body ground R - Body ground Power source Always 11 to 14 V E7-18 (IG+) - Body ground B - Body ground Engine switch signal Engine switch off Below 1 V Engine switch on (IG) 11 to 14 V E7-19 (ILL-) - Body ground W - Body ground Light control rheostat signal Light control rheostat knob fully turned left Below 1 V Light control rheostat knob fully turned from left to right Resistance increases when turned to right E7-20 (ILL-) - Body ground W - Body ground Light control rheostat signal Light control rheostat knob fully turned left Below 1 V Light control rheostat knob fully turned from left to right Resistance increases when turned to right E7-22 (WRNP) - Body ground Y - Body ground Seat belt condition signal (Passenger side) Passenger seat belt indicator is off Below 1 V Passenger seat belt indicator blinks Alternating between below 1 and 11 to 14 V E7-27 (B) - Body ground R - Body ground Turn signal R Engine switch on (IG), turn signal switch neutral position Below 1 V Engine switch on (IG), turn signal switch turned to left Alternating between below 1 and 11 to 14 V E7-28 (B) - Body ground L - Body ground Turn signal L Engine switch on (IG), turn signal switch neutral position Below 1 V Engine switch on (IG), turn signal switch turned to right Alternating between below 1 and 11 to 14 V E8-3 (MSSL) - Body ground L - Body ground Spiral cable signal Engine switch on (IG), steering pad switch signal DISP OFF Below 1 V Engine switch on (IG), steering pad switch signal DISP ON 11 to 14 V E8-4 (RSET) - Body ground B - Body ground Light control rheostat signal Engine switch on (IG), light control rheostat trip switch OFF Below 1 V Engine switch on (IG), light control rheostat trip switch ON 11 to 14 V E8-9 (L) - Body ground Y - Body ground Fuel sender gauge signal Always Below 1 V E8-11 (S) - Body ground L - Body ground Oil pressure receiver gauge signal Engine switch on (IG), Oil pressure receiver gauge H Below 1 V Engine switch on (IG), Oil pressure receiver gauge L 11 to 14 V E8-12 (CHK) - Body ground R - Body ground MIL input signal Engine switch on (IG), MIL on Below 3 V Engine switch on (IG), MIL off 11 to 14 V E8-18 (ILL+) - Body ground G - Body ground Light control rheostat signal Engine switch on (IG) 4.6 to 5.4 V E8-19 (TR) - Body ground W - Body ground Light control rheostat knob input Light control rheostat knob fully turned left Below 1 V Light control rheostat knob fully turned right 10 kohms or higher E8-20 (TC) - Body ground B - Body ground Light control rheostat signal Engine switch on (IG), light control rheostat TAIL cancel switch OFF Below 1 V Engine switch on (IG), light control rheostat TAIL cancel switch ON 10 kohms or higher E8-21 (E) - Body ground B - Body ground Fuel sender gauge ground Always Below 1 ohms E8-23 (E2) - Body ground L - Body ground Light control rheostat ground Always Below 1 V If the result is not as specified, the meter may have a malfunction.
- CHECK COMBINATION METER INNER CIRCUIT HINT: *1: w/Multi-display *2: w/o Multi-display *3: for U.S.A. *4: except U.S.A.
