Contents Section: Heating / Air Conditioning All sections

DISASSEMBLY Toyota Land Cruiser 200

Heating / Air Conditioning 35 illustrations ~3093 words

DISASSEMBLY

  1. REMOVE REAR SIDE NO. 2 AIR DUCT Remove the 3 screws and duct.
  2. REMOVE REAR SIDE NO. 3 AIR DUCT Remove the 2 screws and duct.
  3. REMOVE DRAIN COOLER HOSE Remove the screw. Detach the claw and remove the drain hose.
  4. REMOVE REAR AIR MIX DAMPER SERVO SUBASSEMBLY Disconnect the connector. Remove the 2 screws and damper servo.
  5. REMOVE REAR MODE DAMPER SERVO SUBASSEMBLY Remove the 2 screws and plate cover. Disconnect the connector. Remove the 2 screws and damper servo.
  6. REMOVE NO. 2 AIR MIX DAMPER SERVO SUBASSEMBLY Disconnect the connector. Remove the 2 screws and damper servo.
  7. REMOVE AIR CONDITIONER ACCESSORY ASSEMBLY Remove the packing. Remove the bolt and 4 screws. Using pliers, grip the claws of the clips and slide the 2 clips. Remove the air conditioner accessory assembly. Remove the 2 O-rings from the air conditioner accessory assembly.
  8. REMOVE REAR COOLING UNIT EXPANSION VALVE Disconnect the connector. Detach the clamp. Using a 4 mm hexagon wrench, remove the 2 hexagon bolts and expansion valve.
  9. REMOVE HEATER RADIATOR UNIT SUB-ASSEMBLY Remove the screw and detach the claw. Remove the heater clamp. Remove the heater radiator.
  10. REMOVE BLOWER WITH FAN (REAR) MOTOR SUBASSEMBLY Disconnect the connector. Remove the 3 screws and blower motor.
  11. REMOVE BLOWER MOTOR CONTROL Disconnect the connector. Remove the 2 screws and blower motor control.
  12. REMOVE EVAPORATOR SUB-ASSEMBLY Remove the 12 screws and rear cooling unit case LH. Remove the evaporator. Remove the 2 O-rings from the evaporator.
  13. REMOVE REAR EVAPORATOR TEMPERATURE SENSOR Detach the 2 claws and remove the sensor.
  14. REMOVE WIRING AIR CONDITIONING HARNESS SUB-ASSEMBLY

Scheme 336

Scheme 336: INSPECTION
Scheme 336: INSPECTION
  1. INSPECT REAR EVAPORATOR TEMPERATURE SENSOR Measure the resistance according to the value (s) in the table below. Standard Resistance TESTER CONNECTION SPECIFIED CONDITION REFERENCE CHART Tester Connection Condition Specified Condition 8-7 -10°C (14°F) 7.30 to 9.10 kohms 8-7 -5°C (23°F) 5.65 to 6.95 kohms 8-7 0°C (32°F) 4.40 to 5.35 kohms 8-7 5°C (41 °F) 3.40 to 4.15 kohms 8-7 10°C (50°F) 2.70 to 3.25 kohms 8-7 15°C (59°F) 2.14 to 2.58 kohms 8-7 20°C (68°F) 1.71 to 2.05 kohms 8-7 25°C (77°F) 1.38 to 1.64 kohms 8-7 30°C (86°F) 1.11 to 1.32 kohms If the result is not as specified, replace the rear evaporator temperature sensor. NOTE: Even slightly touching the sensor may change the resistance value. Be sure to hold the connector of the sensor. When measuring the sensor temperature must be the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (Scheme 336)

Scheme 337

Scheme 337
Scheme 337

Scheme 338

Scheme 338
Scheme 338
  1. INSTALL WIRING AIR CONDITIONING HARNESS SUB-ASSEMBLY
  2. INSTALL REAR EVAPORATOR TEMPERATURE SENSOR Attach the 2 claws and to install the sensor.
  3. INSTALL EVAPORATOR SUB-ASSEMBLY Sufficiently apply compressor oil to 2 new O-rings and the fitting surface of the hose joint. Compressor oil: ND-OIL 8 or equivalent Install the 2 O-rings to the evaporator. Install the evaporator. Install the rear cooling unit case LH with the 12 screws.
  4. INSTALL BLOWER MOTOR CONTROL Install the blower motor control with the 2 screws. Connect the connector.
  5. INSTALL BLOWER WITH FAN (REAR) MOTOR SUBASSEMBLY Install the blower motor with the 3 screws. Connect the connector.
  6. INSTALL HEATER RADIATOR UNIT SUB-ASSEMBLY Install the radiator unit to the rear cooling unit. Install the heater clamp with the screw and attach the claw.
  7. INSTALL REAR COOLING UNIT EXPANSION VALVE Using a 4 mm hexagon wrench, install the expansion valve with the 2 hexagon bolts. Torque: 3.5 N*m (36 kgf*cm, 31 in.*lbf) Attach the clamp. Connect the connector.
  8. INSTALL AIR CONDITIONER ACCESSORY ASSEMBLY Sufficiently apply compressor oil to 2 new O-ring 5 and the fitting surface of the hose joint. Compressor oil: ND-OIL 8 or equivalent Install the 2 O-rings to the air conditioner accessory assembly. Install the air conditioner accessory assembly. Using pliers, grip the claws of the clips and slide the 2 clips. Install the bolt and 4 screws. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) Install hew packing as shown in the illustration see scheme 492
  9. INSTALL REAR MODE DAMPER SERVO SUBASSEMBLY Align the damper servo as shown in the illustration see scheme 493, and install it with the 2 screws. Connect the connector. Install the plate cover with the 2 screws.
  10. INSTALL NO. 2 AIR MIX DAMPER SERVO SUBASSEMBLY Align the damper servo as shown in the illustration see scheme 495, and install it with the 2 screws. Connect the connector.
  11. INSTALL REAR AIR MIX DAMPER SERVO SUBASSEMBLY Align the damper servo as shown in the illustration see scheme 496, and install it with the 2 screws. Connect the connector.
  12. INSTALL DRAIN COOLER HOSE Attach the claw to install the drain hose. Install the screw.
  13. INSTALL REAR SIDE NO. 3 AIR DUCT Install the duct with the 2 screws. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf)
  14. INSTALL REAR SIDE NO. 2 AIR DUCT Install the duct with the 3 screws. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf)
  1. INSTALL REAR COOLING UNIT ASSEMBLY Install the rear cooling unit assembly (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/automatic-hvac-system/#heating-air-conditioning) ).

Scheme 339

Scheme 339: COMPONENTS
Scheme 339: COMPONENTS

Scheme 340

Scheme 340: REMOVAL
Scheme 340: REMOVAL
  1. REMOVE NO. 1 SPEAKER OPENING COVER ASSEMBLY (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/entertainment-systems/#audiovideo) )
  2. REMOVE AUTOMATIC LIGHT CONTROL SENSOR (SOLAR SENSOR) Detach the 2 claws and remove the sensor.

Scheme 341

Scheme 341: INSPECTION
Scheme 341: INSPECTION
  1. INSPECT AUTOMATIC LIGHT CONTROL SENSOR (SOLAR SENSOR) Connect the battery positive (+) lead to terminal 6 and the negative (-) lead to terminal 3, then measure the according to the value (s) in the table below. Standard Voltage TESTER CONNECTION SPECIFIED CONDITION REFERENCE CHART Tester Connection Condition Specified Condition 1 (TSL) - 3 (CLTE) Sensor subject to electric light 0.5 to 3.0 V 1 (TSL) - 3 (CLTE) Sensor covered with a cloth 0.5 V or less 2 (TSR) - 3 (CLTE) Sensor subject to electric light 0.5 to 3.0 V 2 (TSR) - 3 (CLTE) Sensor covered with a cloth 0.8 V or less If the result is not as specified, replace the automatic light control sensor. NOTE: The connection procedure for using a digital tester such as a TOYOTA electrical tester is shown above. HINT: As the inspection light is moved away from the sensor, the voltage increases. Use an incandescent lamp for inspection. Bring it within 30 cm (11.8 in.) of the A/C solar sensor.

Scheme 342

Scheme 342: INSTALLATION
Scheme 342: INSTALLATION
  1. INSTALL AUTOMATIC LIGHT CONTROL SENSOR (SOLAR SENSOR) Attach the 2 claws to install the sensor.
  2. INSTALL NO. 1 SPEAKER OPENING COVER ASSEMBLY (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/entertainment-systems/#audiovideo) )

Scheme 343

Scheme 343: COMPONENTS
Scheme 343: COMPONENTS

Scheme 344

Scheme 344
Scheme 344

Scheme 345

Scheme 345: REMOVAL
Scheme 345: REMOVAL

Scheme 346

Scheme 346
Scheme 346

Scheme 347

Scheme 347
Scheme 347
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system.
  2. REMOVE REAR NO. 1 SEAT ASSEMBLY LH Remove the rear No. 1 seat assembly (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/seats/#seat) ).
  3. REMOVE REAR NO. 1 SEAT ASSEMBLY RH Remove the rear No. 1 seat assembly (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/seats/#seat) ).
  4. REMOVE REAR NO. 2 SEAT ASSEMBLY LH Remove the rear No. 2 seat assembly (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/seats/#seat) ).
  5. REMOVE REAR NO. 2 SEAT ASSEMBLY RH Remove the rear No. 2 seat assembly (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/seats/#seat) ).
  6. REMOVE REAR DOOR SCUFF PLATE LH (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  7. REMOVE REAR DOOR SCUFF PLATE RH (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  8. REMOVE REAR FLOOR MAT REAR SUPPORT PLATE (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  9. REMOVE REAR SEAT COVER CAP (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  10. REMOVE FRONT QUARTER TRIM PANEL ASSEMBLY LH (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  11. REMOVE REAR SEAT COVER CAP (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  12. REMOVE FRONT QUARTER TRIM PANEL ASSEMBLY RH (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  13. REMOVE REAR NO. 1 SEAT PROTECTOR (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/seats/#seat) )
  14. REMOVE REAR NO. 2 SEAT PROTECTOR (See «DISASSEMBLY»(/toyota/land-cruiser/200-2007-2012/remont/seats/#seat) )
  15. REMOVE FRONT FLOOR CARPET ASSEMBLY Fold back the floor carpet. HINT: Fold back the carpet until it is possible to remove the rear No. 6 air duct.
  16. REMOVE REAR NO. 6 AIR DUCT Disconnect the 2 connectors. Remove the 5 screws and duct.
  17. REMOVE DUCT TEMPERATURE SENSOR Detach the 4 claws and remove the 2 sensors.

Scheme 348

Scheme 348: INSPECTION
Scheme 348: INSPECTION
  1. INSPECT DUCT TEMPERATURE SENSOR Measure the resistance according to the value (s) in the table below. Standard Resistance TESTER CONNECTION SPECIFIED CONDITION REFERENCE CHART Tester Connection Condition Specified Condition 1-2 At 10°C (50°F) 9.4 to 10.5 kohms 1-2 At 15°C (59°F) 7.5 to 8.3 kohms 1-2 At 20°C (68°F) 6.0 to 6.5 kohms 1-2 At 25°C (77°F) 4.8 to 5.2 kohms 1-2 At 30°C (86°F) 3.8 to 4.2 kohms 1-2 At 35°C (95°F) 3.1 to 3.4 kohms 1-2 At 40°C (104°F) 2.5 to 2.8 kohms 1-2 At 45°C (113°F) 2.0 to 2.3 kohms 1-2 At 50°C (122°F) 1.6 to 2.0 kohms 1-2 At 55°C (131°F) 1.3 to 1.6 kohms 1-2 At 60°C (140°F) 1.1 to 1.4 kohms If the result is not as specified, replace the duct temperature sensor. NOTE: Touching the sensor even slightly may change the resistance value. Hold the connector of the sensor. When measuring the resistance, the sensor temperature must be the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (Scheme 348)

Scheme 349

Scheme 349
Scheme 349
  1. INSTALL COOLER THERMISTOR Attach the 4 claws to install the 2 sensors.
  2. INSTALL REAR NO. 6 AIR DUCT Install the duct with the 5 screws. Connect the 2 connectors.
  3. INSTALL FRONT FLOOR CARPET ASSEMBLY Install the floor carpet.
  4. INSTALL REAR NO. 1 SEAT PROTECTOR (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/seats/#seat) )
  5. INSTALL REAR NO. 2 SEAT PROTECTOR (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/seats/#seat) )
  6. INSTALL FRONT QUARTER TRIM PANEL ASSEMBLY LH (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  7. INSTALL REAR SEAT COVER CAP (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  8. INSTALL FRONT QUARTER TRIM PANEL ASSEMBLY RH (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  9. INSTALL REAR SEAT COVER CAP (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  10. INSTALL REAR FLOOR MAT SUPPORT PLATE REAR (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  11. INSTALL REAR DOOR SCUFF PLATE LH (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  12. INSTALL REAR DOOR SCUFF PLATE RH (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  13. INSTALL REAR NO. 2 SEAT ASSEMBLY LH Install the rear No. 2 seat assembly (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/seats/#seat) ).
  14. INSTALL REAR NO. 2 SEAT ASSEMBLY RH Install the rear No. 2 seat assembly (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/seats/#seat) ).
  15. INSTALL REAR NO. 1 SEAT ASSEMBLY LH Install the rear No. 1 seat assembly (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/seats/#seat) ).
  16. INSTALL REAR NO. 1 SEAT ASSEMBLY RH Install the rear No. 1 seat assembly (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/seats/#seat) ).
  17. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  18. CHECK SRS WARNING LIGHT Check the SRS warning light (See «CHECK MODE PROCEDURE»(/toyota/land-cruiser/200-2007-2012/remont/airbag/#supplemental-restraint-systems) ).

Scheme 350

Scheme 350: COMPONENTS
Scheme 350: COMPONENTS

Scheme 351

Scheme 351: REMOVAL
Scheme 351: REMOVAL
  1. REMOVE FRONT BUMPER COVER Remove the front bumper cover (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#exterior-panels-trim) ).
  2. RECOVER REFRIGERANT FROM REFRIGERATION SYSTEM (See «REPLACEMENT»(/toyota/land-cruiser/200-2007-2012/remont/automatic-hvac-system/#heating-air-conditioning) )
  3. REMOVE AIR CONDITIONER PRESSURE SENSOR Disconnect the connector. Remove the pressure sensor. Remove the O-ring from the pressure sensor. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent moisture and foreign matter from entering them.
  1. INSTALL AIR CONDITIONER PRESSURE SENSOR Sufficiently apply compressor oil to a new O-ring and the fitting surface of the pressure sensor. Compressor oil: ND-OIL 8 or equivalent Install the O-ring on the pressure sensor. Install the pressure sensor. Torque: 10.8 N*m (110 kgf*cm, 8 ft.*lbf) Connect the connector.
  2. CHARGE REFRIGERANT (See «REPLACEMENT»(/toyota/land-cruiser/200-2007-2012/remont/automatic-hvac-system/#heating-air-conditioning) )
  3. WARM UP ENGINE (See «REPLACEMENT»(/toyota/land-cruiser/200-2007-2012/remont/automatic-hvac-system/#heating-air-conditioning) )
  4. CHECK FOR REFRIGERANT GAS LEAK (See «REPLACEMENT»(/toyota/land-cruiser/200-2007-2012/remont/automatic-hvac-system/#heating-air-conditioning) )
  5. INSTALL FRONT BUMPER COVER Install the front bumper cover (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#exterior-panels-trim) ).

Scheme 352

Scheme 352: COMPONENTS
Scheme 352: COMPONENTS

Scheme 353

Scheme 353: REMOVAL
Scheme 353: REMOVAL
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system.
  2. REMOVE NO. 1 SPEAKER OPENING COVER ASSEMBLY (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/entertainment-systems/#audiovideo) )
  3. REMOVE NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  4. REMOVE NO. 4 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  5. REMOVE MULTI-DISPLAY ASSEMBLY WITH BRACKET Remove the 4 bolts. Pull the radio receiver to detach the 8 claws on the backside of the radio receiver. Disconnect the connectors and remove the radio receiver.

Scheme 354

Scheme 354: INSTALLATION
Scheme 354: INSTALLATION

Scheme 355

Scheme 355
Scheme 355
  1. INSTALL MULTI-DISPLAY ASSEMBLY WITH BRACKET Connect the connectors. Insert the radio receiver and attach the 8 claws on its backside. NOTE: When inserting the radio receiver, do not press the knobs on it. Install the radio receiver with the 4 bolts.
  2. INSTALL NO. 4 INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  3. INSTALL NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  4. INSTALL NO. 1 SPEAKER OPENING COVER ASSEMBLY (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/entertainment-systems/#audiovideo) )
  5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Scheme 356

Scheme 356: COMPONENTS
Scheme 356: COMPONENTS
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system.
  2. REMOVE NO. 1 SPEAKER OPENING COVER ASSEMBLY (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/entertainment-systems/#audiovideo) )
  3. REMOVE NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  4. REMOVE NO. 4 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  5. REMOVE RADIO RECEIVER ASSEMBLY WITH BRACKET (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/entertainment-systems/#audiovideo) )
  6. REMOVE NO. 2 INSTRUMENT PANEL FINISH PANEL CUSHION (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  7. REMOVE LOWER INSTRUMENT PANEL PAD SUBASSEMBLY LH (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  8. REMOVE NO. 1 INSTRUMENT PANEL FINISH PANEL CUSHION (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  9. REMOVE LOWER INSTRUMENT PANEL PAD SUBASSEMBLY RH (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  10. REMOVE LOWER CENTER INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  11. REMOVE AIR CONDITIONING CONTROL ASSEMBLY Pull the radio receiver to detach the 5 claws on the backside of the radio receiver. Disconnect the connectors and remove the radio receiver.

Scheme 357

Scheme 357: INSTALLATION
Scheme 357: INSTALLATION

Scheme 358

Scheme 358
Scheme 358
  1. INSTALL AIR CONDITIONING CONTROL ASSEMBLY Connect the connectors. Insert the radio receiver and attach the 5 claws on its backside. NOTE: When inserting the radio receiver, do not press the knobs on it.
  2. INSTALL LOWER CENTER INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  3. INSTALL LOWER INSTRUMENT PANEL PAD SUBASSEMBLY RH (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  4. INSTALL NO. 1 INSTRUMENT PANEL FINISH PANEL CUSHION (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  5. INSTALL LOWER INSTRUMENT PANEL PAD SUBASSEMBLY LH (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  6. INSTALL NO. 2 INSTRUMENT PANEL FINISH PANEL CUSHION (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  7. INSTALL RADIO RECEIVER ASSEMBLY WITH BRACKET (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/entertainment-systems/#audiovideo) )
  8. INSTALL NO. 4 INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  9. INSTALL NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  10. INSTALL NO. 1 SPEAKER OPENING COVER ASSEMBLY (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/entertainment-systems/#audiovideo) )
  11. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Scheme 359

Scheme 359: COMPONENTS
Scheme 359: COMPONENTS

Scheme 360

Scheme 360
Scheme 360

Scheme 361

Scheme 361: REMOVAL
Scheme 361: REMOVAL
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system.
  2. REMOVE FRONT DOOR SCUFF PLATE RH (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  3. REMOVE NO. 1 INSTRUMENT PANEL FINISH CUSHION (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  4. REMOVE LOWER INSTRUMENT PANEL PAD SUBASSEMBLY RH (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  5. REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  6. REMOVE FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/airbag/#supplemental-restraint-systems) )
  7. REMOVE NO. 3 INSTRUMENT CLUSTER FINISH PANEL GARNISH (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  8. REMOVE LOWER NO. 2 INSTRUMENT PANEL FINISH PANEL (See «REMOVAL»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__removal) )
  9. REMOVE AIR CONDITIONING AMPLIFIER ASSEMBLY Disconnect the connector. Remove the screw and amplifier.

Scheme 362

Scheme 362: INSTALLATION
Scheme 362: INSTALLATION
  1. INSTALL AIR CONDITIONING AMPLIFIER ASSEMBLY Install the amplifier with the screw. Connect the connector.
  2. INSTALL LOWER NO. 2 INSTRUMENT PANEL FINISH PANEL (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  3. INSTALL NO. 3 INSTRUMENT CLUSTER FINISH PANEL GARNISH (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  4. INSTALL FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/airbag/#supplemental-restraint-systems) )
  5. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  6. INSTALL LOWER INSTRUMENT PANEL PAD SUBASSEMBLY RH (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  7. INSTALL NO. 1 INSTRUMENT PANEL FINISH CUSHION (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim__installation) )
  8. INSTALL FRONT DOOR SCUFF PLATE RH (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  9. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  10. CHECK SRS WARNING LIGHT Check the SRS warning light (See «CHECK MODE PROCEDURE»(/toyota/land-cruiser/200-2007-2012/remont/airbag/#supplemental-restraint-systems) ).

Scheme 363

Scheme 363: ON-VEHICLE INSPECTION
Scheme 363: ON-VEHICLE INSPECTION

Scheme 364

Scheme 364
Scheme 364
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system.
  2. REMOVE MAGNET CLUTCH RELAY Remove the magnet clutch relay from the engine room relay block.
  3. INSPECT MAGNET CLUTCH RELAY Measure the resistance of the magnet clutch relay. Standard Resistance TESTER CONNECTION SPECIFIED CONDITION REFERENCE CHART Tester Connection Condition Specified Condition 3-5 Battery voltage not applied between terminals 1 and 2 10 kohms or higher Battery voltage applied to terminal 1 and 2 Below 1 ohms If the result is not as specified, replace the relay.
  4. INSTALL MAGNET CLUTCH RELAY Install the magnet clutch relay to the engine room relay block.
  5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Scheme 365

Scheme 365: ON-VEHICLE INSPECTION
Scheme 365: ON-VEHICLE INSPECTION

Scheme 366

Scheme 366
Scheme 366
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system.
  2. REMOVE REAR COOLER RELAY Remove the rear cooler relay from the engine room relay block.
  3. INSPECT REAR COOLER RELAY Measure the resistance of the relay. Standard Resistance TESTER CONNECTION SPECIFIED CONDITION REFERENCE CHART Tester Connection Specified Condition 3-4 Below 1 ohms 3-5 10 kohms or higher 3-4 10 kohms or higher (when battery voltage is applied to terminals 1 and 2) 3-5 Below 1 ohms (when battery voltage is applied to terminals 1 and 2)
  4. INSTALL REAR COOLER RELAY Install the rear cooler relay to the engine room relay block.
  5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Scheme 367

Scheme 367: ON-VEHICLE INSPECTION
Scheme 367: ON-VEHICLE INSPECTION

Scheme 368

Scheme 368
Scheme 368
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system.
  2. REMOVE PTC HEATER RELAY (PTC HTR 1, PTC HTR 2, PTC HTR 3) Remove the 3 PTC heater relays from the engine room relay block.
  3. INSPECT PTC HEATER RELAY (PTC HTR 1, PTC HTR 2, PTC HTR 3) Measure the resistance of the relay. Standard Resistance TESTER CONNECTION SPECIFIED CONDITION REFERENCE CHART Tester Connection Condition Specified Condition 3-5 Battery voltage not applied between terminals 1 and 2 10 kohms or higher Battery voltage applied to terminal 1 and 2 Below 1 ohms If the result is not as specified, replace the relay.
  4. INSTALL PTC HEATER RELAY (PTC HTR 1, PTC HTR 2, PTC HTR 3) Install the 3 PTC heater relays to the engine room relay block.
  5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Scheme 369

Scheme 369: COMPONENTS
Scheme 369: COMPONENTS

Scheme 370

Scheme 370: REMOVAL
Scheme 370: REMOVAL
  1. REMOVE REAR CONSOLE END PANEL SUBASSEMBLY W/ Cool Box: Remove the rear console end panel (See «DISASSEMBLY»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) ). W/O Cool Box: Remove the rear console end panel (See «DISASSEMBLY»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
  2. REMOVE NO. 2 AIR CONDITIONING CONTROL ASSEMBLY Remove the 4 screws. Detach the 5 claws and remove the air conditioning control.
  1. INSTALL NO. 2 AIR CONDITIONING CONTROL ASSEMBLY Attach the 5 claws to install the air conditioning control. Install the 4 screws.
  2. INSTALL REAR CONSOLE END PANEL SUBASSEMBLY W/ Cool Box: Install the rear console end panel (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) ). W/O Cool Box: Install the rear console end panel (See «INSTALLATION»(/toyota/land-cruiser/200-2007-2012/remont/exteriorinterior-trim/#interior-panels-trim) )
