INSPECTION
| WARNING | Vehicle is equipped with air bag supplemental restraint system. Before attempting ANY repairs involving steering column, instrument panel or related components, see SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in appropriate AIR BAG RESTRAINT SYSTEMS article in RESTRAINTS. |
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See appropriate section under appropriate COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
ENGINE ROOM RELAY/JUNCTION BLOCK
The engine room relay/junction block is located on left side of engine compartment. (Scheme 1)
Scheme 1
Scheme 2
Unit A - Fusible Links
Unit A is located in engine room relay/junction block. (Scheme 2)
Scheme 3
| Fuse | System | |
|---|---|---|
| 40A | MAIN | Automatic Light Control Back Door Opener Headlight Light Auto Turn Off System Smart Key System Theft Deterrent |
| 50A | A/PUMP NO.1 | Cruse Control Electronically Controlled Transmission and A/T Indicator Engine Control |
| 50A | A/PUMP NO.2 | Cruse Control Electronically Controlled Transmission and A/T Indicator Engine Control |
| 50A | HTR | Air Conditioning |
| 150A | LH-J/B | Automatic Light Control Back Door Opener Front Fog Light Illumination Light Auto Turn Off System Smart Key System Taillight Theft Deterrent Trailer Towing |
| 180A | ALT | Charging |
Fusible Link Block Components
Unit B
Unit B is located in engine room relay/junction block. (Scheme 2)
Scheme 4
| Fuse | System | |
|---|---|---|
| 5A | ALT-S | Charging |
| 5A | AM2 | Automatic Light Control Back Door Opener Door Lock Control Front Fog Light Headlight Illumination Interior Light Light Auto Turn Off System Multiplex Communication System (CAN) Power Window Remote Control Mirror Sliding Roof Smart Key System Taillight Theft Deterrent |
| 5A | DOME1 | Clock (w/o Multi-Display) Interior Light |
| 5A | ECU-B1 | ABS A-TRAC Back Door Opener Brake Assist Combination Meter Cool Box Crawl Cruse Control Door Lock Control EBD Electronically Controlled Transmission and A/T Indicator Engine Control Front Fog Light Garage Door Opener Headlight Hill-Start Assist Control Illumination Multi Mode 4WD Multiplex Communication System (CAN) Parking Assist (Intuitive Parking Assist) Power Tilt and Power Telescopic Pre-Collision System Seat Belt Warning Sliding Roof Smart Key System SRS Taillight Theft Deterrent Tire Pressure Warning System VSC |
| 5A | ECU-B2 | Power Seat (Driver's Seat) |
| 7.5A | DOME2 | Back Door Opener Interior Light Smart Key System Theft Deterrent |
| 7.5A | IMB | Back Door Opener Smart Key System Theft Deterrent |
| 7.5A | RSE | Audio System Multi-Display Navigation System Parking Assist (Rear View Monitor) |
| 10A | ETCS | Cruise Control Electronically Controlled Transmission and A/T Indicator Engine Control |
| 10A | RAD NO.1 | Audio System Multi-Display Navigation System Parking Assist (Rear View Monitor) |
| 15A | AM2 | Engine Control Ignition Starting |
| 15A | FR FOG | Front Fog Light Multiplex Communication System (BEAN) |
| 15A | HAZ-TRN | Turn Signal and Hazard Warning Light |
| 20A | EFI MAIN2 | Cruse Control Electronically Controlled Transmission and A/T Indicator Engine Control |
| 20A | STR LOCK | Back Door Opener Smart Key System Theft Deterrent |
| 25A | DOOR NO.2 | Automatic Light Control Door Lock Control Front Fog Light Headlight Illumination Interior Light Light Auto Turn Off System Multiplex Communication System (CAN) Power Window Remote Control Mirror Sliding Roof Taillight |
| 30A | ABS2 | ABS A-TRAC Brake Assist Crawl EBD Hill-Start Assist Control VSC |
| 30A | AMP | Audio System Multi-Display Navigation System Parking Assist (Rear View Monitor) |
| 30A | ST | Back Door Opener Smart Key System Theft Deterrent |
| 30A | TOWING | Trailer Towing |
| 50A | ABS1 | ABS A-TRAC Brake Assist Crawl EBD Hill-Start Assist Control VSC |
ENGINE ROOM R/B (BACKSIDE) FUSES DESCRIPTION
Unit C
Unit C is located in engine room relay/junction block. (Scheme 2)
Scheme 5
| Fuse | System | |
|---|---|---|
| 10A | HORN | Back Door Opener Horn Smart Key System Theft Deterrent |
| 15A | A/F | Cruse Control Electronically Controlled Transmission and A/T Indicator Engine Control |
| 25A | EFI MAIN | Cruse Control Electronically Controlled Transmission and A/T Indicator Engine Control |
| 30A | IG2 MAIN | |
Engine Room Relay/Junction Block Unit C Fuses
Unit D
Unit D is located in engine room relay/junction block. (Scheme 2)
Scheme 6
| Fuse | System | |
|---|---|---|
| 5A | SECURITY | Back Door Opener Smart Key System Theft Deterrent |
| 10A | ALT-CDS | |
| 15A | FR FOG | Front Fog Light |
| 15A | STOP | ABS A-TRAC Back Door Opener Brake Assist Crawl Cruse Control EBD Electronically Controlled Transmission and A/T Indicator Engine Control Hill-Start Assist Control Multi Mode 4WD Pre-Collision System Shift Lock Smart Key System Stop Light Theft Deterrent Trailer Towing VSC |
| 20A | DEICER | Front Window Deicer |
| 20A | RR S/HTR | Seat Heater (Rear) |
| 25A | CDS FAN | Condenser Fan |
| 30A | DEFOG | Mirror Heater Rear Window Defogger |
| 30A | H-LP CLN | Headlight Cleaner |
| 30A | TOW BRK | Trailer Towing |
| 30A | TOW TAIL | Trailer Towing |
| 40A | RH-J/B | |
| 40A | SUB BATT | Trailer Towing |
| 50A | PTC-1 | Air Conditioning |
| 50A | PTC-2 | Air Conditioning |
| 50A | PTC-3 | Air Conditioning |
| 50A | RR AUTO A/C | Air Conditioning |
Engine Room Relay/Junction Block Unit D Fuses
Unit E
Unit E is located in engine room relay/junction block. (Scheme 2)
Scheme 7
| Fuse | System | |
|---|---|---|
| 5A | DEF NO.2 | Mirror Heater Rear Window Defogger |
| 5A | MET | ABS A-TRAC Back Door Opener Brake Assist Charging Combination Meter Crawl Cruse Control Door Lock Control EBD Electronically Controlled Transmission and A/T Indicator Engine Control Front Fog Light Headlight Hill-Start Assist Control Illumination Multi Mode 4WD Parking Assist (Intuitive Parking Assist) Pre-Collision System Seat Belt Warning Sliding Roof Smart Key System SRS Taillight Theft Deterrent Tire Pressure Warning System VSC |
| 7.5A | EFI NO.2 | |
| 10A | IGN | ABS A-TRAC Back Door Opener Brake Assist Crawl Cruse Control EBD Electronically Controlled Transmission and A/T Indicator Engine Control Hill-Start Assist Control Multiplex Communication System (CAN) Seat Belt Warning Smart Key System SRS Theft Deterrent VSC |
| 10A | INJ | Cruse Control Electronically Controlled Transmission and A/T Indicator Engine Control Ignition |
| 15A | HEAD LH | Headlight |
| 15A | HEAD LL | Headlight |
| 15A | HEAD RH | Headlight |
| 15A | HEAD RL | Headlight |
Engine Room Relay/Junction Block Unit E Fuses
COWL SIDE JUNCTION BLOCK LEFT HAND
The cowl side junction block left hand is located on the left end of the instrument panel. (Scheme 8)
Scheme 8
Scheme 9
| Fuse | System | |
|---|---|---|
| 5A | ECU-IG NO.1 | ABS A-TRAC Audio System Brake Assist Crawl Door Lock Control EBD Headlight Cleaner Hill-Start Assist Control Multi-Display Multiplex Communication System (CAN) Navigation System Parking Assist (Intuitive Parking Assist) Parking Assist (Rear View Monitor) Power Seat (Driver's Seat) Power Tilt and Power Telescopic Pre-Collision System Shift Lock VSC |
| 5A | LH-IG | ABS A-TRAC Brake Assist Charging Crawl Cruse Control EBD Electric Tension Reducer Electronically Controlled Transmission and A/T Indicator Engine Control Front Window Deicer Hill-Start Assist Control Power Outlet (115V) Seat Heater (Front) Trailer Towing Turn Signal and Hazard Warning Light VSC |
| 7.5A | A/C | Air Conditioning |
| 7.5A | ACC | Audio System Automatic Light Control Back Door Opener Clock (w/o Multi-Display) Door Lock Control Front Fog Light Headlight Illumination Interior Light Light Auto Turn Off System Multi-Display Multiplex Communication System (CAN) Navigation System Parking Assist (Rear View Monitor) Power Window Remote Control Mirror Sliding Roof Smart Key System Taillight Theft Deterrent |
| 7.5A | OBD-2 | Data Link Connector 3 |
| 10A | A/C IG | Air Conditioning Condenser Fan Cool Box Mirror Heater Rear Window Defogger |
| 10A | BK/UP LP | ABS A-TRAC Audio System Back-Up Light Brake Assist Crawl Cruse Control Door Lock Control EBD Electronically Controlled Transmission and A/T Indicator Engine Control Hill-Start Assist Control Interior Light Multi Mode 4WD Multi-Display Navigation System Parking Assist (Intuitive Parking Assist) Parking Assist (Rear View Monitor) Power Seat (Driver's Seat) Power Tilt and Power Telescopic Remote Control Mirror Trailer Towing VSC |
| 10A | ECU-IG NO.2 | ABS Air Conditioning A-TRAC Automatic Glare-Resistant EC Mirror Automatic Light Control Brake Assist Clock (w/o Multi-Display) Compass Crawl Door Lock Control EBD Front Fog Light Headlight Hill-Start Assist Control Illumination Interior Light Light Auto Turn Off System Multiplex Communication System (CAN) Power Window Remote Control Mirror Seat Heater (Rear) Sliding Roof Stop Light Taillight VSC |
| 10A | PANEL | Illumination Taillight Trailer Towing |
| 15A | CIG | Cigarette Lighter |
| 15A | INVERTER | Power Outlet (115V) |
| 15A | MIR | Mirror Heater Rear Window Defogger Remote Control Mirror |
| 15A | PWR OUTLET | Power Outlet (12V) |
| 15A | RR WIPER | Rear Wiper and Washer |
| 15A | TAIL | Front Fog Light Illumination Taillight |
| 15A | TI&TE | Power Tilt and Power Telescopic |
| 20A | 4WD | Multi Mode 4WD |
| 20A | FR DOOR LH | Door Lock Control Power Window |
| 20A | FR DOOR RH | Power Window |
| 20A | RR DOOR LH | Power Window |
| 20A | RR DOOR RH | Power Window |
| 20A | WSH | Front Wiper and Washer |
| 25A | DOOR NO.1 | Automatic Light Control Door Lock Control Front Fog Light Headlight Illumination Interior Light Key Reminder Light Auto Turn Off System Multiplex Communication System (CAN) Power Window Remote Control Mirror Sliding Roof Taillight Wireless Door Lock Control |
| 25A | S/ROOF | Sliding Roof |
| 30A | FR P/SEAT LH | Power Seat (Driver's Seat) |
| 30A | FR P/SEAT RH | Power Seat (Front Passenger's Seat) |
| 30A | PSB | Pre-Collision System |
| 30A | WIPER | Front Wiper and Washer |
COWL SIDE J/B FUSES (LH)
COWL SIDE JUNCTION BLOCK RIGHT HAND
The cowl side junction block right hand is located on the right end of the instrument panel. (Scheme 8)
Scheme 10
| Fuse | System | |
|---|---|---|
| 5A | ECU-IG NO.4 | Tire Pressure Warning System |
| 10A | TV | Audio System Multi-Display Navigation System Parking Assist (Rear View Monitor) |
| 20A | SEAT-HTR | Seat Heater (Front) |
COWL SIDE J/B FUSES (RH)
