MODEL COVERAGE
| MODEL | ENGINE | ENGINE ID (1) | FUEL SYSTEM (2) | IGNITION SYSTEM |
|---|
| Avalon | 3.0L V6 (1MZ-FE) | F | SFI | DIS (3) |
| Camry | 2.4L 4-Cyl. (2AZ-FE) | E | SFI | DIS (3) |
| — | 3.0L V6 (1MZ-FE) | F | SFI | DIS (3) |
| Camry Solara | 2.4L 4-Cyl. (2AZ-FE) | E | SFI | DIS (3) |
| — | 3.0L V6 (1MZ-FE) | F | SFI | DIS (3) |
| Celica | 1.8L 4-Cyl. (1ZZ-FE) | R | SFI | DIS (3) |
| — | 1.8L 4-Cyl. (2ZZ-GE) | Y | SFI | DIS (3) |
| Corolla | 1.8L 4-Cyl. (1ZZ-FE) | R | SFI | DIS (3) |
| ECHO | 1.5L 4-Cyl. (1NZ-FE) | T | SFI | DIS (3) |
| Highlander | 2.4L 4-Cyl. (2AZ-FE) | D | SFI | DIS (3) |
| — | 3.0L V6 (1MZ-FE) | F | SFI | DIS (3) |
| Land Cruiser | 4.7L V8 (2UZ-FE) | T | SFI | DIS (3) |
| Matrix | 1.8L 4-Cyl. (1ZZ-FE) | R | SFI | DIS (3) |
| — | 1.8L 4-Cyl. (2ZZ-GE) | Y | SFI | DIS (3) |
| MR2 | 1.8L 4-Cyl. (1ZZ-FE) | R | SFI | DIS (3) |
| Prius (4) | 1.5L 4-Cyl. (1NZ-FXE) | K | SFI | DIS (3) |
| RAV4 | 2.0L 4-Cyl. (1AZ-FE) | H | SFI | DIS (3) |
| Sequoia | 4.7L V8 (2UZ-FE) | T | SFI | DIS (3) |
| Sienna | 3.0L V6 (1MZ-FE) | F | SFI | DIS (3) |
| Tacoma | 2.4L 4-Cyl. (2RZ-FE) | L | SFI | DIS (3) |
| — | 2.7L 4-Cyl. (3RZ-FE) | M | SFI | DIS (3) |
| — | 3.4L V6 (5VZ-FE) | N | SFI | DIS (3) |
| Tundra | 3.4L V6 (5VZ-FE) | N | SFI | DIS (3) |
| — | 4.7L V8 (2UZ-FE) | T | SFI | DIS (3) |
| 4Runner | 4.0L V6 (1GR-FE) | N | SFI | DIS (3) |
| — | 4.7L V8 (2UZ-FE) | T | SFI | DIS (3) |
| (1) Engine may be identified by Vehicle Identification Number (VIN). VIN is located on VIN plate on driver's side of instrument panel. (Scheme 2)- (Scheme 4). Engine serial number is stamped on cylinder block. (Scheme 5)- (Scheme 15). (2) Fuel injection system is a Sequential Multiport Fuel Injection (SFI) system. (3) Application uses a Distributorless Ignition System (DIS). (4) This is the hybrid vehicle which uses a gasoline engine along with the AC electric motor for vehicle operation. Only service procedures for the gasoline engine are covered. |
| (1) | Engine may be identified by Vehicle Identification Number (VIN). VIN is located on VIN plate on driver's side of instrument panel. (Scheme 2)- (Scheme 4). Engine serial number is stamped on cylinder block. (Scheme 5)- (Scheme 15). |
| (2) | Fuel injection system is a Sequential Multiport Fuel Injection (SFI) system. |
| (3) | Application uses a Distributorless Ignition System (DIS). |
| (4) | This is the hybrid vehicle which uses a gasoline engine along with the AC electric motor for vehicle operation. Only service procedures for the gasoline engine are covered. |
Scheme 1
MODEL/YEAR VIN CODE APPLICATIONS
| VIN Code | Model Year |
|---|
| 1 | 2001 |
| 2 | 2002 |
| 3 | 2003 |
MODEL/YEAR VIN CODE APPLICATION
Scheme 2
Scheme 3
Scheme 4
ENGINE SERIAL NUMBER LOCATION
Scheme 5
Scheme 5: ENGINE SERIAL NUMBER LOCATION
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
