Ground Points
| Code | See Page | Ground Points Location |
|---|---|---|
| EE | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Near the Front Left Suspension Tower |
| IF | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Set Bolt of Cowl Side J/B LH |
| II | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Set Bolt of Cowl Side J/B RH |
Starting System Wiring Diagram. Scheme 41
| Code | See Page | Relay Blocks (Relay Block Location) |
|---|---|---|
| 1 | ENGINE ROOM J/B; : ENGINE ROOM R/B: ENGINE COMPARTMENT LEFT (SEE PAGE 20) | Engine Room R/B (Engine Compartment Left) |
| Code | See Page | Junction Block and Wire Harness (Connector Location) |
|---|---|---|
| 1B | ENGINE ROOM J/B ENGINE COMPARTMENT LEFT (SEE PAGE 20) | Engine Room No.2 Wire and Engine Room J/B (Engine Compartment Left) |
| 1C | ||
| 1D | ||
| 2A | COWL SIDE J/B LH LEFT KICK PANEL (SEE PAGE 20) | Engine Room No.2 Wire and Cowl Side J/B LH (Left Kick Panel) |
| 2E | COWL SIDE J/B LH LEFT KICK PANEL (SEE PAGE 20) | Dash Wire and Cowl Side J/B LH (Left Kick Panel) |
| 5C | J/B NO.5 BEHIND THE COMBINATION METER (SEE PAGE 20) | Dash Wire and J/B No.5 (Behind the Combination Meter) |
| 5D | J/B NO.5 BEHIND THE COMBINATION METER (SEE PAGE 20) | Engine Room No.2 Wire and J/B No.5 (Behind the Combination Meter) |
| 6B | J/B NO.6 BEHIND THE GLOVE BOX (SEE PAGE 20) | Dash Wire and J/B No.6 (Behind the Glove Box) |
| 6C | ||
| 6D | J/B NO.6 BEHIND THE GLOVE BOX (SEE PAGE 20) | Engine Wire and J/B No.6 (Behind the Glove Box) |
| Code | See Page | Joining Wire Harness and Wire Harness (Connector Location) |
|---|---|---|
| ED2 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Engine No.2 Wire and Engine Room No.2 Wire (Near the Engine Room J/B) |
| If1 | LOCATION OF GROUND POINTS | Engine Wire and Engine Wire (Behind the Glove Box) |
| Code | See Page | Ground Points Location |
|---|---|---|
| EE | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Near the Front Left Suspension Tower |
Ignition System Wiring Diagram (1 Of 2). Scheme 42
Ignition System Wiring Diagram (2 Of 2). Scheme 43
| Code | See Page | Junction Block and Wire Harness (Connector Location) |
|---|---|---|
| 1B | ENGINE ROOM J/B ENGINE COMPARTMENT LEFT (SEE PAGE 20) | Engine Room No.2 Wire and Engine Room J/B (Engine Compartment Left) |
| 1C | ||
| 2A | COWL SIDE J/B LH LEFT KICK PANEL (SEE PAGE 20) | Engine Room No.2 Wire and Cowl Side J/B LH (Left Kick Panel) |
| 2E | COWL SIDE J/B LH LEFT KICK PANEL (SEE PAGE 20) | Dash Wire and Cowl Side J/B LH (Left Kick Panel) |
| Code | See Page | Joining Wire Harness and Wire Harness (Connector Location) |
|---|---|---|
| IN2 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Engine Wire and Dash Wire (Behind the Glove Box) |
| Ia4 | LOCATION OF GROUND POINTS | Dash Wire and Dash Wire (Instrument Panel LH) |
| If1 | LOCATION OF GROUND POINTS | Engine Wire and Engine Wire (Behind the Glove Box) |
| Code | See Page | Ground Points Location |
|---|---|---|
| ED | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Rear Side of Left Cylinder Head |
| EO | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Front Side of Left Cylinder Head |
Charging System Wiring Diagram. Scheme 44
| Code | See Page | Junction Block and Wire Harness (Connector Location) |
|---|---|---|
| 1A | ENGINE ROOM J/B ENGINE COMPARTMENT LEFT (SEE PAGE 20) | Engine Room Main Wire and Engine Room J/B (Engine Compartment Left) |
| 1B | ENGINE ROOM J/B ENGINE COMPARTMENT LEFT (SEE PAGE 20) | Engine Room No.2 Wire and Engine Room J/B (Engine Compartment Left) |
| 2B | COWL SIDE J/B LH LEFT KICK PANEL (SEE PAGE 20) | Engine Room No.2 Wire and Cowl Side J/B LH (Left Kick Panel) |
| 2E | COWL SIDE J/B LH LEFT KICK PANEL (SEE PAGE 20) | Dash Wire and Cowl Side J/B LH (Left Kick Panel) |
| 2G | ||
| 2Q | COWL SIDE J/B LH LEFT KICK PANEL (SEE PAGE 20) | Instrument Panel Integration Wire and Cowl Side J/B LH (Left Kick Panel) |
| 3Q | COWL SIDE J/B RH RIGHT KICK PANEL (SEE PAGE 20) | Instrument Panel Integration Wire and Cowl Side J/B RH (Right Kick Panel) |
| Code | See Page | Joining Wire Harness and Wire Harness (Connector Location) |
|---|---|---|
| EE2 | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS | Engine Room Main Wire and Alternator Wire (Near the Battery) |
