Wiring diagram: Shift interlock — Shift interlock circuit, except hybrid with smart key system Toyota Highlander III
All systems — 36 systems
- Air conditioning 2
- Anti-lock brakes 2
- Anti-theft 4
- Body control modules 4
- Computer data lines 2
- Cooling fan 3
- Cruise control 4
- Defoggers 2
- Electronic power steering
- Engine performance 2.7l
- Engine performance 3.5l
- Engine performance 3.5l hybrid 2
- Exterior lights 4
- Ground distribution 2
- Headlights
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems 2
- Navigation 7
- Power distribution 2
- Power door locks 3
- Power mirrors 3
- Power seats 6
- Power top/sunroof 2
- Power windows 2
- Radio 3
- Shift interlock 4
- Starting/charging 3
- Supplemental restraints
- Transmission 2.7l 2
- Transmission 3.5l 2
- Transmission 3.5l hybrid
- Trunk, tailgate, fuel door 4
- Warning systems 2
- Wiper/washer
Shift interlock
# Shift interlock circuit, except hybrid with smart key system
Components on the diagram
Components on these wiring diagrams 11
Click a component to highlight it on every diagram it appears on.
