Mirror System (Service Information): Overview Toyota Highlander II рестайлинг

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. SELECT COMPASS DISPLAY MODE The MULTIFUNCTION Button allows you to select the Display or Non-display mode of the compass.
2. SET ZONE Deviation between the "magnetic north" and "actual north" differs depending on the location. Therefore, adjustment of the magnetism is required. Because the magnetic condition differs depending on the area where the vehicle is used, it is necessary for each user to set the zone (Scheme 6) The zone setting can be changed using the MULTIFUNCTION Button of the inner mirror.
3. PERFORM CALIBRATION Because each vehicle has its own magnetic field, calibration should be performed for each individual vehicle. This compass function is used when storing the record of the vehicle's magnetic field.
4. WHEN COMPASS IS MAGNETIZED: A compass could be magnetized during shipping by vessels or freight cars. Therefore, make sure to perform calibration and ensure that calibration is performed properly before delivery. If this cannot be done (cannot be completed in spite of driving around several times), it may be caused by magnetization. Demagnetize the vehicle using a demagnetizer and perform calibration again.
5. SET COMPASS
6. ZONE SETTING MODE Pressing the MULTIFUNCTION Button for 3 seconds in the normal mode will activate the zone setting mode. A number (1 - 15) is displayed on the compass display. HINT: In the initial state, "8" is displayed. The displayed number increases +1 every time the MULTIFUNCTION Button is pressed. Referring to the map, check the number for the area where the vehicle will be used and set the zone number. Leave it untouched for several seconds after setting and check that the compass display shows an azimuthal direction (N, NE, E, SE, S, SW, W or NW) or "C".
7. CALIBRATION SETTING MODE Pressing the MULTIFUNCTION Button for 6 seconds in the normal mode will activate the calibration setting mode. "N" is displayed on the compass display. Drive the vehicle at a slow speed of 8 km/h (5 mph) or less in the circular direction. Driving around the circle 1 to 3 times will display the azimuthal direction on the display, completing the calibration. HINT: After the calibration is completed, it is not necessary to perform the above procedures unless the magnetic field strength is drastically changed. If this happens, the azimuthal display will be changed to "N".

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. REMOVE INNER REAR VIEW MIRROR ASSEMBLY (w/o EC Mirror) Disengage the 2 claws and the cover. Pull the lever in the direction indicated by the arrow shown in the illustration and slide the inner rear view mirror assembly upward to remove it.
2. REMOVE INNER REAR VIEW MIRROR STAY HOLDER COVER (w/ EC Mirror) Disengage the 2 claws and slide the inner rear view mirror stay holder cover as shown in the illustration. Disengage the 2 claws and remove the inner rear view mirror stay holder cover.
3. REMOVE INNER REAR VIEW MIRROR ASSEMBLY (w/ EC Mirror) Disconnect the connector. Using a "TORX" socket wrench (T20), remove the screw and the inner rear view mirror.

Scheme 13

1. INSPECT INNER REAR VIEW MIRROR ASSEMBLY Inspect the operation of the electronic inner mirror. Connect the positive (+) lead from the battery to terminal 6 and the negative (-) lead to terminal 3. Attach black colored tape to the forward sensor to prevent it from sensing. Light up the mirror with an electric light, and check that the mirror surface changes from bright to dark. OK Mirror surface changes from bright to dark. TEXT IN ILLUSTRATION *1 Battery *2 Black Colored Tape *3 Forward Sensor *4 Bright *5 Dark *a Components without harness connected (Inner Rear View Mirror Assembly) If the result is not as specified, replace the inner rear view mirror assembly.

Scheme 14

Scheme 15

Scheme 16

1. INSTALL INNER REAR VIEW MIRROR ASSEMBLY (w/ EC Mirror) Using a "TORX" socket wrench (T20), install the inner rear view mirror with the screw. Torque: 3.5 N*m (36 kgf*cm, 31 in.*lbf)
2. INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER (w/ EC Mirror) Engage the 2 claws and install the inner rear view mirror stay holder cover. Engage the 2 claws and install the inner rear view mirror stay holder cover as shown in the illustration.
3. INSTALL INNER REAR VIEW MIRROR ASSEMBLY (w/o EC Mirror) Slide the inner rear view mirror assembly in the direction indicated by the arrow shown in the illustration to install it. Engage the 2 claws and install the cover.

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH . Refer to «DISASSEMBLY - Step 2»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)
2. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG . Refer to «DISASSEMBLY - Step 3»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)
3. REMOVE FRONT ARMREST UPPER BASE PANEL . Refer to «DISASSEMBLY - Step 4»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)
4. REMOVE ASSIST GRIP COVER . Refer to «DISASSEMBLY - Step 8»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)
5. REMOVE COURTESY LIGHT ASSEMBLY . Refer to «DISASSEMBLY - Step 9»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)
6. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY . Refer to «DISASSEMBLY - Step 10»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)
7. REMOVE OUTER REAR VIEW MIRROR ASSEMBLY WITH COVER Disconnect the connector and disengage the clamp. Disengage the clip. Remove the 3 nuts. Disengage the claw and remove the outer rear view mirror assembly with cover.

Scheme 21

Scheme 22

1. REMOVE OUTER MIRROR GLASS (w/o Heater) See step 1
2. REMOVE OUTER MIRROR GLASS (w/ Heater) See step 2
3. REMOVE LENS COVER (w/ Foot light) Remove the 2 screws. Disengage the 2 guides. Remove the lens cover as shown in the illustration. Remove the outer mirror holder.
4. REMOVE OUTER MIRROR COVER See step 3

Scheme 23

Scheme 24

Scheme 25

Scheme 26

1. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY RH Disconnect the mirror connector. Apply battery voltage and check the operation of the mirror. OK w/ Door Mirror Foot Light Measurement Condition Specified Condition Battery positive (+) --> Terminal 3 (MV) Battery negative (-) --> Terminal 7 (M+) Turns upward Battery positive (+) --> Terminal 7 (M+) Battery negative (-) --> Terminal 3 (MV) Turns downward Battery positive (+) --> Terminal 6 (MH) Battery negative (-) --> Terminal 7 (M+) Turns left Battery positive (+) --> Terminal 7 (M+) Battery negative (-) --> Terminal 6 (MH) Turns right w/o Door Mirror Foot Light Measurement Condition Specified Condition Battery positive (+) --> Terminal 3 (MV) Battery negative (-) --> Terminal 1 (M+) Turns upward Battery positive (+) --> Terminal 1 (M+) Battery negative (-) --> Terminal 3 (MV) Turns downward Battery positive (+) --> Terminal 2 (MH) Battery negative (-) --> Terminal 1 (M+) Turns left Battery positive (+) --> Terminal 1 (M+) Battery negative (-) --> Terminal 2 (MH) Turns right If the result is not as specified, replace the mirror assembly. with Mirror Heater: Check the resistance. Measure the resistance according to the value(s) in the table bellow. Standard resistance w/ Door Mirror Foot Light Tester Connection Condition Specified Condition 2 (H+) - 1 (H-) Always 3.8 to 4.8 ohms w/o Door Mirror Foot Light Tester Connection Condition Specified Condition 4 (H+) - 5 (H-) Always 3.8 to 4.8 ohms If the result is not as specified, replace the outer rear view mirror. Connect the cable from the positive battery (+) terminal to terminal 2 *1 or 4 *2 and the negative battery (-) terminal to terminal 1 *1 or 5 *2 , then check that the mirror becomes warm. HINT: *1 : w/ Door Mirror Foot Light *2 : w/o Door Mirror Foot Light OK Mirror becomes warm. HINT: It takes a short time for the mirror to become warm. If the result is not as specified, replace the outer rear view mirror.
2. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY LH Disconnect the mirror connector. Apply battery voltage and check the operation of the mirror. OK w/ Door Mirror Foot Light Measurement Condition Specified Condition Battery positive (+) --> Terminal 3 (MV) Battery negative (-) --> Terminal 7 (M+) Turns upward Battery positive (+) --> Terminal 7 (M+) Battery negative (-) --> Terminal 3 (MV) Turns downward Battery positive (+) --> Terminal 6 (MH) Battery negative (-) --> Terminal 7 (M+) Turns left Battery positive (+) --> Terminal 7 (M+) Battery negative (-) --> Terminal 6 (MH) Turns right w/o Door Mirror Foot Light Measurement Condition Specified Condition Battery positive (+) --> Terminal 3 (MV) Battery negative (-) --> Terminal 1 (M+) Turns upward Battery positive (+) --> Terminal 1 (M+) Battery negative (-) --> Terminal 3 (MV) Turns downward Battery positive (+) --> Terminal 2 (MH) Battery negative (-) --> Terminal 1 (M+) Turns left Battery positive (+) --> Terminal 1 (M+) Battery negative (-) --> Terminal 2 (MH) Turns right If the result is not as specified, replace the mirror assembly. with Mirror Heater: Check the resistance. Measure the resistance according to the value(s) in the table bellow. Standard resistance w/ Door Mirror Foot Light Tester Connection Condition Specified Condition 2 (H+) - 1 (H-) Always 3.8 to 4.8 ohms w/o Door Mirror Foot Light Tester Connection Condition Specified Condition 4 (H+) - 5 (H-) Always 3.8 to 4.8 ohms If the result is not as specified, replace the outer rear view mirror. Connect the cable from the positive battery (+) terminal to terminal 2 *1 or 4 *2 and the negative battery (-) terminal to terminal 1 *1 or 5 *2 , then check that the mirror becomes warm. HINT: *1 : w/ Door Mirror Foot Light *2 : w/o Door Mirror Foot Light OK Mirror becomes warm. HINT: It takes a short time for the mirror to become warm. If the result is not as specified, replace the outer rear view mirror.

Scheme 27

1. INSTALL OUTER MIRROR COVER See step 1
2. INSTALL LENS COVER (w/ Foot light) Pass the wire harness through the outer mirror holder. Install the lens cover as shown in the illustration. Engage the 2 guides. Install the lens cover with the 2 screws.
3. INSTALL OUTER MIRROR GLASS (w/o Heater) See step 2
4. INSTALL OUTER MIRROR GLASS (w/ Heater) See step 1

Scheme 28

Scheme 29

1. INSTALL OUTER REAR VIEW MIRROR ASSEMBLY WITH COVER Engage the claw, and temporarily install the outer rear view mirror assembly with cover. Tighten the 3 nuts in the order shown in the illustration to install the outer rear view mirror assembly with cover. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Engage the clamp and connect the connector. Install the clip.
2. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY . Refer to «REASSEMBLY - Step 37»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)
3. INSTALL COURTESY LIGHT ASSEMBLY . Refer to «REASSEMBLY - Step 38»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)
4. INSTALL ASSIST GRIP COVER . Refer to «REASSEMBLY - Step 39»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)
5. INSTALL FRONT ARMREST UPPER BASE PANEL . Refer to «REASSEMBLY - Step 43»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)
6. INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG . Refer to «REASSEMBLY - Step 44»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)
7. INSTALL FRONT DOOR LOWER FRAME BRACKET GARNISH . Refer to «REASSEMBLY - Step 45»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. REMOVE OUTER MIRROR GLASS (w/o Heater) Apply protective tape to the bottom of the visor of the door mirror. Tilt and push the upper part of the mirror surface. Using a screwdriver with the tip wrapped with protective tape, disengage the 2 claws. Disengage the 2 claws at the upper part of the outer mirror. Remove the outer mirror glass.
2. REMOVE OUTER MIRROR GLASS (w/ Heater) Apply protective tape to the bottom of the visor of the door mirror. Tilt and push the upper part of the mirror surface. Using a screwdriver with the tip wrapped with protective tape, disengage the 2 claws. Disengage the 2 claws at the upper part of the outer mirror. Disconnect the 2 connectors and remove the outer mirror glass.

Scheme 34

Scheme 35

1. INSTALL OUTER MIRROR GLASS (w/ Heater) Connect the 2 connectors. Engage the 2 claws on the upper part of the outer mirror glass to the outer mirror. Engage the 2 claws on the lower part of the outer mirror glass to the outer mirror as shown in the illustration.
2. INSTALL OUTER MIRROR GLASS (w/o Heater) Engage the 2 claws on the upper part of the outer mirror glass to the outer mirror. Engage the 2 claws on the lower part of the outer mirror glass to the outer mirror as shown in the illustration.

Scheme 36

Scheme 37

1. REMOVE OUTER MIRROR GLASS (w/o Heater) See step 1
2. REMOVE OUTER MIRROR GLASS (w/ Heater) See step 2
3. REMOVE OUTER MIRROR COVER Disengage the 8 claws and remove the outer mirror cover from the outer rear view mirror assembly with cover.
