CUSTOMIZE PARAMETERS

HINT

The following items can be customized.

Note. When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting.

Scheme 67

1. AIR CONDITIONING SYSTEM (for Automatic Air Conditioning System) AIR CONDITIONING SYSTEM: Display (Item) Default Contents Setting Set Temperature Shift NORMAL To control with shifted temperature against displayed temperature +2 C / +1 C / NORMAL / -1 C / -2 C Ambient Temperature Shift NORMAL To control with shifted temperature against displayed temperature +3 C / +2 C / +1 C / NORMAL / -1 C / -2 C / -3 C Air Inlet Mode AUTO Function to shift from INLET mode to RECIRCULATION mode when A/C is turned ON MANUAL / AUTO Compressor Mode AUTO Function to automatically turn A/C ON by pressing AUTO button when blower is ON and A/C is OFF MANUAL / AUTO Compressor / Air Inlet DEF Operation LINK Function to automatically turn A/C ON linked with FRONT DEF button when A/C is OFF NORMAL / LINK Evaporator Control AUTO Function to set evaporator control to AUTOMATIC position (AUTO) to save power, or to coldest position (MANUAL) to dehumidify air and to prevent windows from fogging up MANUAL / AUTO Foot / DEF Auto Mode ON Function to automatically turn airflow from FOOT/DEF ON when AUTO MODE is ON OFF / ON Foot / DEF Automatic Blow Up Function ON Function to automatically increase blower level when defroster is ON OFF / ON
2. THEFT DETERRENT SYSTEM (w/ Smart Key System) SECURITY: Display (Item) Default Contents Setting Passive Mode (Security System) OFF Passive Mode is a function that switches the theft deterrent system from the arming preparation state to the armed state 30 seconds after the key is removed from the actuation area and all doors, glass hatch * and engine hood are closed, even if the doors are not locked by wireless or door key lock operation. In Passive Mode, if the following operations are not performed within 14 seconds after a door is opened during armed state, the theft deterrent system will judge that condition as a theft and switch to the alarm sounding state. Unlock any door by key or wireless operation Turn the engine switch on (IG) ON / OFF Warning by Horn ON Function that allows the vehicle horn and theft deterrent horn to be used as warning devices. ON / OFF Entry Delay 14 s Function that changes entry delay time (time before warning starts) for Passive Mode 0 s / 14 s / 30 s HINT: *: w/ Glass Hatch Opener System
3. THEFT DETERRENT SYSTEM (w/o Smart Key System) SECURITY: Display (Item) Default Contents Setting Passive Mode (Security System) OFF Passive Mode is a function that switches the theft deterrent system from the arming preparation state to the armed state 30 seconds after the key is removed from the key cylinder and all doors, engine hood and luggage compartment door are closed, even if the doors are not locked by wireless or door key lock operation. In Passive Mode, if the following operations are not performed within 14 seconds after a door is opened during armed state, the theft deterrent system will judge that condition as a theft and switch to the alarm sounding state. Unlock any door by key or wireless operation Turn the ignition switch to the ON position Open the luggage compartment door by key or wireless operation ON/OFF Warning by Horn ON Function that allows the vehicle horn and theft deterrent horn to be used as warning devices ON/OFF Entry Delay 14 s Function that changes entry delay time (time before warning starts) for Passive Mode 0 s/14 s/30 s Warning by Glass Broken Sensor ON Function that turns the glass breakage sensor on/off. This function is only effective for vehicles with glass breakage sensor. ON/OFF
4. LIGHTING SYSTEM ILLUMINATED ENTRY: Display Default Contents Setting Lighting Time 15 s Changes the lighting time of the personal light, interior lights and ignition key cylinder light *1 /engine switch illumination *2 after closing all of the doors. (It will quickly fade out when the ignition switch is turned on (IG) 7.5 s / 15 s / 30 s I/L when ACC OFF ON Lights up the personal light, interior lights and ignition key cylinder light *1 /engine switch illumination *2 when the ignition switch is turned from on (ACC or IG) to off. ON / OFF I/L ON W/Door Key Unlock ON Lights up the personal light, interior lights and ignition key cylinder light *1 /engine switch illumination *2 when the doors are unlocked using the mechanical key. ON / OFF Mirr-Foot-Lgt Approached ON Lights up the door mirror foot lights when the key enters actuation area around the doors. ON / OFF Mirr-Foot-Lgt Unlocked ON Lights up the door mirror foot lights when the doors are unlocked using door control transmitter or mechanical key. ON / OFF Mirr-Foot-Lgt w/Master SW ON Lights up the door mirror foot lights when the doors are unlocked with the door control switch. ON / OFF Mirror Foot Light Time 15 s Changes the lighting time of the door mirror foot lights. 0 s / 7.5 s / 15 s / 30 s HINT: *1: w/o Smart Key System *2: w/ Smart Key System LIGHT CONTROL: Display Default Contents Setting Disp Ex ON Sen Normal Changes the ambient brightness level required to dim the lights such as the indicator lights of the combination meter, A/C indicator light, and clock. Light2 / Light1 / Normal / Dark1 / Dark2 Disp Ex OFF Sen Normal Changes the ambient brightness level required to cancel the dimming of the combination meter indicator lights, A/C indicator light, and clock. Light2 / Light1 / Normal / Dark1 / Dark2 Light Auto OFF Delay 30 s Keeps the headlights on for a certain period of time after turning the ignition switch off and closing all the doors with the headlights on. OFF / 30 s / 60 s / 90 s Sensitivity Normal Adjusts the sensitivity of the automatic light control function. Light2 / Light1 / Normal / Dark1 / Dark2 DRL Function ON ON / OFF of the DRL function. ON / OFF
5. POWER DOOR LOCK CONTROL SYSTEM MAIN BODY (MAIN BODY ECU): Display Default Contents Setting Unlock Key Twice ON Function that unlocks only driver side door when driver side door key cylinder is turned to UNLOCK once, and unlock all doors when it is turned to UNLOCK twice. For OFF setting, turning it once unlocks all doors. ON / OFF Auto Lock/Shift ON Function that locks all doors when shift lever is shifted to P from any other position with engine running and all doors closed ON / OFF Auto Unlock/Shift ON Function that unlocks all doors when shift lever is shifted to P from any other position while the ignition switch is on (IG) ON / OFF All Unlock/Open-Close OFF Function that unlocks all doors when opening driver door within 10 seconds after turning the ignition switch on (IG) ON / OFF Auto Lock OFF Function that locks all doors when the vehicle reaches a certain speed ON / OFF
6. WIRELESS DOOR LOCK CONTROL SYSTEM (w/ Smart Key System) WIRELESS DOOR LOCK Display (Item) Default Contents Setting Wireless Control ON ON/OFF of wireless door lock function ON/OFF Hazard Answer Back ON When LOCK switch on transmitter pressed, all hazard warning lights illuminate once. When UNLOCK switch pressed, all hazard warning lights illuminate twice ON/OFF Wireless Buzzer Resp ON Function that makes wireless buzzer sound for answer-back when transmitter LOCK/UNLOCK switch pressed ON/OFF Wireless Auto Lock ON Function to control automatic relocking of doors after unlocking with wireless door lock function. ON/OFF Open Door Warning ON If door is not completely closed and transmitter LOCK switch is pressed, this function sounds a buzzer for 10 seconds ON/OFF Unlock 2 Operation ON Function that unlocks driver side door when unlock switch on transmitter is pressed once, and unlocks all doors when pressed twice. If setting is OFF, pressing unlock switch once makes all doors unlock. ON/OFF Auto Lock Time 60s This function controls amount of time from unlocking doors to automatic re-locking function 30s/60s/120s Panic Alarm Function ON Function to operate theft deterrent system by continuously pressing panic switch on transmitter for 0.8 seconds ON/OFF
7. WIRELESS DOOR LOCK CONTROL SYSTEM (w/o Smart Key System) WIRELESS DOOR LOCK Display (Item) Default Contents Setting Wireless Control ON ON/OFF of wireless door lock function ON/OFF Hazard Answer Back ON When LOCK switch on transmitter pressed, all hazard warning lights illuminate once. When UNLOCK switch pressed, all hazard warning lights illuminate twice ON/OFF Wireless Buzzer Resp ON Function that makes wireless buzzer sound for answer-back when transmitter LOCK/UNLOCK switch pressed ON/OFF Wireless Auto Lock ON Function to control automatic relocking of doors after unlocking with wireless door lock function. ON/OFF Open Door Warning ON If door is not completely closed and transmitter LOCK switch is pressed, this function sounds a buzzer for 10 seconds ON/OFF Unlock 2 Operation ON Function that unlocks driver side door when unlock switch on transmitter is pressed once, and unlocks all doors when pressed twice. If setting is OFF, pressing unlock switch once makes all doors unlock. ON/OFF Panic Function ON This function operates the theft deterrent system when PANIC is pressed and held for 0.8 second or more. ON/OFF Auto Lock Time 60s This function controls amount of time from unlocking doors to automatic re-locking function. 30s/60s/120s Wireless Glass Hatch Open * Long 1 This function changes operation method of transmitter to glass hatch. 1tim ON: Push once 2tim ON: Push twice Long 1: Push and hold for 0.6 seconds Long 2: Push and hold for 0.8 seconds Prohibit: Does not operate HINT: *: w/ Glass Hatch Opener System
8. SMART KEY SYSTEM SMART KEY (CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) (SMART): Display (Item) Default Contents Setting Ignition Available Area ALL Function to choose the available area for electrical key to start engine and release the steering lock. FRONT / ALL Park Wait Time 2.5s Function that sets waiting time to permit opening door after door is locked with entry lock function. 0.5 s / 1.5 s / 2.5 s / 5.0 s Glass Hatch Open Operation ON Function to open the glass hatch when the driver has the electrical key and presses glass hatch opener switch. ON / OFF Back Door Opening Operation LONG Function to open the back door when the driver has the electrical key and presses back door opener switch. LONG / TWICE / OFF SMART KEY (CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) (WARNING): Display (Item) Default Contents Setting Passenger Take Key ON Function to warn that the electrical key is taken out by passengers (It means that the key is taken out from except the driver's door) when engine is running. ON / OFF Key Out Range Warning ON Function to set a warning function for trying to start the engine before key is still out of its range. ON / OFF Key Low Battery Warning ON Function to set a warning function for the time when a key battery becomes weak. ON / OFF
9. ENTRY UNLOCK MODE SWITCHING FUNCTION (Smart Key System) HINT: The function only changes the entry unlock mode of the smart key system. This function is not for the wireless door lock control. To change the vehicle to entry unlock mode switching function: Driver door unlock mode: When the driver door's touch sensor is touched, only the driver door unlocks. When another touch sensor is touched, all doors unlock. All door unlock mode: When any touch sensor is touched, all doors unlock. Check that the power source mode is OFF and the LED on the electrical key is not blinking. Press the lock switch and one of the other switches on the electrical key at the same time for approximately 5 seconds while the electrical key is in the detection area. The certification ECU (smart key ECU assembly) receives this signal from the door control receiver and switches the entry unlock mode. The certification ECU (smart key ECU assembly) sounds the wireless door lock buzzer and the buzzer in the combination meter to inform the user that the mode has been switched. If the entry unlock mode needs to be switched again, press the lock switch and one of the other switches on the electrical key at the same time for approximately 5 seconds after the LED of the key goes off. NOTE: After pressing and holding the switches for 5 seconds, wait 5 seconds before performing the same procedure again. The certification ECU (smart key ECU assembly) receives this signal from the door control receiver and changes the smart key system to the entry unlock mode. The certification ECU (smart key ECU assembly) sounds the wireless door lock buzzer and the buzzer of the combination meter to inform the user that the mode has been switched.
10. ELECTRICAL KEY CANCEL (Smart Key System) The electrical key cancel operation disables the following functions: Entry Unlock/Lock Entry Back Door Open Entry Glass Hatch Open Electrical Key Lock-in Prevention Warning The operation procedures are as follows: Precondition: Engine switch off, driver side door closed and unlocked. Unlock the driver side door once with the UNLOCK switch of the electrical key. Open the driver door within 5 seconds. Unlock the driver side door twice with the UNLOCK switch of the electrical key within 5 seconds. Close and open the driver door twice within 30 seconds. (Driver Door: Close --> Open --> Close --> Open) Unlock the driver side door twice with the UNLOCK switch of the electrical key within 5 seconds. Close and open the driver door within 30 seconds. (Driver Door: Close --> Open) Close the driver door within 5 seconds. When electrical key cancel is activated, the wireless door lock buzzer sounds twice. To return to the original condition, perform the procedures again. When the original condition is returned, the wireless door lock buzzer sounds once.
11. METER / GAUGE SYSTEM COMBINATION METER: Tester Display Default Contents Setting Key Remind Volume Large Function to change the volume of the key reminder buzzer. Large, Medium, Small Key Remind Sound Slow Function to change the frequency of the key reminder buzzer. Fast, Normal, Slow Driver Side Seatbelt Warning Buzzer (*) On Function to change the seat belt warning buzzer. On, Off Front Passenger Side Seatbelt Warning Buzzer (*) On Function to change the seat belt warning buzzer. On, Off HINT: *: This setting is only valid for the buzzer which sounds at the 20 km/h (12 mph) or more.
12. POWER WINDOW CONTROL SYSTEM POWER WINDOW (MAIN BODY ECU): Tester Display Default Contents Setting Door Key P/W Up ON Function that raises all power windows when, with engine switch off, key is used to hold driver door key cylinder to lock position for more than 2.3 seconds ON / OFF Door Key P/W Down ON Function that lowers all power windows when, with engine switch off, key is used to hold driver door key cylinder to unlock position for more than 2.3 seconds ON / OFF P/W Down W/ Transmit ON Function that lowers all power windows when, with engine switch off, unlock switch on transmitter is pressed and held for more than 3.0 seconds ON / OFF
13. POWER BACK DOOR SYSTEM POWER BACK DOOR SYSTEM Display (Item) Default Function Setting PBD SW Operation 0.8 s Function that turns power back door closer switch ON when switch is pushed once or held down for 0.8 sec. 0.8s / ON PBD Buzzer ON This function makes the power back door buzzer sound when power back door is operating ON / OFF Wirels PBD SW Operation 0.8 s Function that operates power back door when transmitter switch is pressed in specified way ON / 2 times / 0.8 s / OFF

INITIALIZATION

1. PROCEDURES NECESSARY WHEN BATTERY TERMINAL IS DISCONNECTED/RECONNECTED Necessary Procedure Effect / Inoperative Function When Necessary Procedure is not Performed See Reset back door close position Power back door function Refer to «INITIALIZATION»(ref-422294-S28308986042011092600000) NOTE: It may not be possible to release the steering lock or start the engine when the battery voltage is low. If this occurs, initialization of the steering lock system is required, refer to «INITIALIZATION»(ref-422295-S37447316372011092600000)
2. PROCEDURES NECESSARY WHEN ECU OR OTHER PARTS ARE REPLACED Replacement Part Necessary Procedure Effect / Inoperative Function when Necessary Procedure are not Performed See for 2GR Engine: ECM Reset memory Large shift shock The deterioration of fuel efficiency Refer to «INITIALIZATION»(ref-422296-S17226167862011092600000) *1 Refer to «INITIALIZATION»(ref-422297-S21564875322011092600000) *2 ECU communication ID registration Engine start Refer to «REGISTRATION»(ref-422298-S03991542592011092600000) *3 Refer to «REGISTRATION»(ref-422299-S18826597582011092600000) *4 Vehicle Identification Number (VIN) registration MIL comes on Refer to «REGISTRATION»(ref-422300-S30318423972011092600000) for 1AR Engine: ECM ECU communication ID registration Engine start Refer to «REGISTRATION»(ref-422299-S18826597582011092600000) Vehicle Identification Number (VIN) registration MIL comes on Refer to «REGISTRATION»(ref-422301-S06954773852011092600000) for U151E, U151F Transaxle: Automatic transaxle assembly Engine assembly Reset memory Large shift shock The deterioration of fuel efficiency Refer to «INITIALIZATION»(ref-422296-S17226167862011092600000) *1 Refer to «INITIALIZATION»(ref-422297-S21564875322011092600000) *2 for U760E Transaxle: Automatic transaxle assembly Reset memory Large shift shock The deterioration of fuel efficiency Refer to «INITIALIZATION»(ref-422302-S28524454492011092600000) Transaxle Compensation Code Input Large shift shock The deterioration of fuel efficiency Refer to «REGISTRATION»(ref-422302-S20023125312011092600000) Perform road test to allow TCM to Learn Large shift shock The deterioration of fuel efficiency Refer to «INITIALIZATION»(ref-422302-S28524454492011092600000) for U760E Transaxle: Valve Body Assembly Shift Solenoid Valve SL3 and/or SL4 Reset memory Reset transaxle Compensation Code Perform road test to allow TCM to Learn Large shift shock The deterioration of fuel efficiency Refer to «INITIALIZATION»(ref-422302-S28524454492011092600000) for U760E Transaxle: Shift Solenoid Valve SL1 and/or SL2 Perform road test to allow TCM to Learn Large shift shock The deterioration of fuel efficiency for U760E Transaxle: TCM (If possible, read the transaxle compensation code from the previous TCM) Possible Reset memory Large shift shock The deterioration of fuel efficiency Refer to «INITIALIZATION»(ref-422302-S28524454492011092600000) Transaxle Compensation Code Input (Into new TCM) Large shift shock The deterioration of fuel efficiency Refer to «REGISTRATION»(ref-422302-S20023125312011092600000) Perform road test to allow TCM to Learn Large shift shock The deterioration of fuel efficiency Refer to «INITIALIZATION»(ref-422302-S28524454492011092600000) Impossible Reset memory Reset transaxle Compensation Code Perform road test to allow TCM to Learn Large shift shock The deterioration of fuel efficiency Refer to «INITIALIZATION»(ref-422302-S28524454492011092600000) Tire pressure warning ECU Register transmitter IDs Initialize tire pressure warning system When DTC detection conditions of "transmitter ID not received" DTC are met, TPWS indicator blinks for 1 minute, and then illuminates. Tire pressure monitoring function Refer to «INITIALIZATION»(ref-422303-S04431004032011092600000) for Initialization Refer to «REGISTRATION»(ref-422303-S29748758752011092600000) for Registration Tire pressure warning valve and transmitter Register transmitter IDs Initialize tire pressure warning system When DTC detection conditions of "transmitter ID not received" DTC are met, TPWS indicator blinks for 1 minute, and then illuminates. Tire pressure monitoring function of replaced wheel Yaw rate and acceleration sensor Brake actuator assembly (Skid control ECU) Clear zero point calibration data Perform yaw rate and acceleration sensor zero point calibration Slip indicator light comes on VSC disabled or malfunctioning Refer to «CALIBRATION»(ref-422304-S03851352502011092600000) Steering lock actuator (Steering lock ECU) *3 ECU code registration Engine start Refer to «REGISTRATION»(ref-422298-S03991542592011092600000) Occupant Classification ECU Front seat assembly Perform zero point calibration Sensitivity check Occupant classification system Passenger airbag ON/OFF indicator Airbag system (Front passenger side) Seat belt warning system (Front passenger side) Refer to «INITIALIZATION»(ref-422305-S17263488592011092600000) Certification ECU *3 Electrical key transmitter *3 Key ID registration Wireless door lock control system Smart key System Engine start Refer to «REGISTRATION»(ref-422298-S03991542592011092600000) ID code box *3 ECU code registration ECU communication ID registration Wireless door lock control system Smart key System Engine start Refer to «REGISTRATION»(ref-422298-S03991542592011092600000) Transponder key ECU *4 Key code registration ECU communication ID registration Engine start Refer to «REGISTRATION»(ref-422299-S18826597582011092600000) Door control transmitter *4 Key code registration Engine start Refer to «REGISTRATION»(ref-422299-S18826597582011092600000) Refer to wireless door lock control system (w/o Smart key System) "Registration" procedures Wireless door lock control system Refer to «REGISTRATION»(ref-422306-S12069973552011092600000) Door control receiver *4 Refer to wireless door lock control system (w/o Smart key System) "Registration" procedures Wireless door lock control system Power window regulator motor (Driver door) Front door window regulator (Driver door) Perform power window reset (initialization of pulse sensor) Automatic door glass open/close function Jam protection function Operation function after ignition switch off Operation of each passenger window using power window switch at the driver door Refer to «INITIALIZATION»(ref-422307-S33663556452011092600000) Back door lock motor Reset back door close position Power back door function Refer to «INITIALIZATION»(ref-422294-S28308986042011092600000) Sliding roof drive gear sub-assembly (Sliding roof ECU) Sliding roof housing Sliding roof drive cable Perform sliding roof drive gear reset Automatic open/close function of roof glass Jam protection function Operation function after ignition switch off Refer to «INITIALIZATION»(ref-422308-S01949564722011092600000) HINT: *1: for U151E *2: for U151F *3: w/ Smart key System *4: w/o Smart key System
