PRECAUTION

1. PRECAUTION FOR DISCONNECTING THE BATTERY CABLE NOTE: When disconnecting the cable from the negative(-) battery terminal, initialize the following system after the cable is reconnected: System Name See Procedure Power back door system Refer to «INITIALIZATION»(ref-422289-S16028026952011092600000)
2. EXPRESSIONS OF IGNITION SWITCH The type of ignition switch used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this service information. Expression Switch Type Ignition Switch (Position) Engine Switch (Condition) Ignition Switch off LOCK Off Ignition Switch ON ON On (IG) Ignition Switch ACC ACC On (ACC) Engine Start START Start

Scheme 1772

Scheme 1773

Scheme 1774

1. CAN and direct line signals w/o Multi-information Display: w/ Multi-information Display
2. Input and output signals of the clock assembly w/o Multi-information Display: Communication Signal Sender Receiver Communication LIne Illumination signal Combination Meter Assembly Clock Assembly Direct Line w/ Multi information Display: Communication Signal Sender Receiver Communication Line Rheostat duty signal Combination Meter Assembly Main Body ECU A/C Control Amplifier CAN (CAN No. 1 Bus) Tail cancel signal

Scheme 1775

1. CLOCK ASSEMBLY w/o Multi-information Display: Item Detail Clock display The time is always displayed. In addition, the clock display dims according to the signal from the combination meter assembly. Adjustment display Keep DISP switch pressed for 1 second or more to enter the clock adjustment mode. w/ Multi information Display: Item Detail Clock and outside temperature display The clock and outside temperature are always displayed. Adjustment display Keep DISP switch pressed for 1 second or more to enter the clock adjustment and display adjustment modes. Cruise information display Five types of information can be displayed. For detail, refer to the meter/gauge system, refer to «SYSTEM DESCRIPTION»(ref-422539-S13424887692011092600000) . Warning display Interrupts the multi-information display immediately when a warning occurs. For detail, refer to the meter/gauge system, refer to «SYSTEM DESCRIPTION»(ref-422539-S13424887692011092600000) . Air conditioning display Interrupts the multi-information display immediately when air conditioning is operated. For detail, refer to the air conditioning system, refer to «CHECK MODE PROCEDURE»(ref-422458-S38964428812011092600000) . DTC (Diagnostic Trouble Code) display Displays the DTCs pertaining to the VSC function. For detail, refer to the vehicle stability control system, refer to «SYSTEM DESCRIPTION»(ref-422304-S01079002582011092600000) .
2. DISPLAY FLOW CHART (w/ Multi-information Display Display flow chart: HINT: Illustrations may differ from the actual screen displayed depending on the specifications of the vehicle and customized settings.
