Seat Belt(hybrid): Overview Toyota Highlander II

Scheme 78

Scheme 79

Scheme 80

Scheme 81

1. REMOVE CENTER INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/gauges-instrument-panels/#instrument-panel-hybrid) )
2. REMOVE CENTER INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/gauges-instrument-panels/#instrument-panel-hybrid) )
3. REMOVE HEATER CONTROL AND ACCESSORY ASSEMBLY (for Manual Air Conditioning System) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/automatic-hvac-system/#air-conditioning-hybrid) )
4. REMOVE AIR CONDITIONING CONTROL ASSEMBLY (for Automatic Air Conditioning System) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/automatic-hvac-system/#air-conditioning-hybrid) )
5. REMOVE RADIO RECEIVER ASSEMBLY WITH BRACKET (w/o Navigation System) (See «REMOVAL»(ref-305575-S05265029802008112800000) )
6. REMOVE NAVIGATION RECEIVER ASSEMBLY WITH BRACKET (w/ Navigation System) (See «REMOVAL»(ref-305576-S12360114142008112800000) )
7. REMOVE INTEGRATION CONTROL AND PANEL ASSEMBLY (w/o Navigation System) Disengage the claw and disconnect the connector. Disengage the 2 clips and remove the integration control and panel assembly.
8. REMOVE NO. 1 RADIO BRACKET (w/ Navigation System) (See «REMOVAL»(ref-305576-S12360114142008112800000) )
9. REMOVE NO. 2 RADIO BRACKET (w/ Navigation System) (See «REMOVAL»(ref-305576-S12360114142008112800000) )
10. REMOVE NAVIGATION RECEIVER ASSEMBLY (w/ Navigation System)

Scheme 82

1. INSPECT TELLTALE LIGHT ASSEMBLY Check that the telltale light assembly (front passenger seat belt warning light) condition. Apply battery voltage to the connector according to the table below. OK TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition Battery positive (+) --> E19-3 (PBEW) Battery negative (-) --> E19-5 (E) Seat belt is fastened Seat belt warning light comes on

Scheme 83

1. INSTALL NAVIGATION RECEIVER ASSEMBLY (w/ Navigation System)
2. INSTALL NO. 2 RADIO BRACKET (w/ Navigation System) (See «INSTALLATION»(ref-305576-S08925619602008112800000) )
3. INSTALL NO. 1 RADIO BRACKET (w/ Navigation System) (See «INSTALLATION»(ref-305576-S08925619602008112800000) )
4. INSTALL INTEGRATION CONTROL AND PANEL ASSEMBLY (w/o Navigation System) Engage the 2 clips and install the integration control and panel assembly. Engage the claw and connect the connector.
5. INSTALL NAVIGATION RECEIVER ASSEMBLY WITH BRACKET (w/ Navigation System) (See «INSTALLATION»(ref-305576-S08925619602008112800000) )
6. INSTALL RADIO RECEIVER ASSEMBLY WITH BRACKET (w/o Navigation System) (See «INSTALLATION»(ref-305575-S24185995892008112800000) )
7. INSTALL HEATER CONTROL AND ACCESSORY ASSEMBLY (for Manual Air Conditioning System) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/automatic-hvac-system/#air-conditioning-hybrid) )
8. INSTALL AIR CONDITIONING CONTROL ASSEMBLY (for Automatic Air Conditioning System) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/automatic-hvac-system/#air-conditioning-hybrid) )
9. INSTALL CENTER INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/gauges-instrument-panels/#instrument-panel-hybrid) )
10. INSTALL CENTER INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/gauges-instrument-panels/#instrument-panel-hybrid) )

SYSTEM DESCRIPTION

1. Driver seat belt warning light When the driver seat belt is not fastened with the power switch on (IG), the driver seat belt warning light on the combination meter assembly comes on to inform the driver. The center airbag assembly detects the driver seat belt condition and sends signals to the body ECU and the meter assembly via CAN communication.
2. Passenger seat belt warning When the passenger seat belt is not fastened with the power switch on (IG) position and the passenger seat occupied, check that the passenger seat belt warning light on navigation receiver *1 or hazard warning switch *2 blinks. The occupant detection sensor detects if the passenger seat is occupied and sends signals to the meter assembly. The inner belt detects the passenger seat belt condition and sends signals to the meter assembly. After receiving the signals from the occupant detection sensor and inner belt, the meter assembly sends signals to navigation receiver *1 or hazard warning switch *2 to request the passenger seat belt warning light to blink or go off. HINT: *1 : w/ Navigation System *2 : w/o Navigation System

DESCRIPTION

When the power switch is on (IG), the center airbag sensor assembly transmits front seat inner belt status signals to the combination meter assembly through CAN. If the driver seat belt is not fastened, the combination meter assembly blinks the driver seat belt warning light. If the seat belt is fastened, the warning light goes off.

Note. The seat belt warning system uses CAN. Before troubleshooting the seat belt warning system, perform "COMMUNICATION FUNCTION CHECK" by following "HOW TO PROCEED WITH TROUBLESHOOTING" to confirm that the communication systems are normal (See HOW TO PROCEED WITH TROUBLESHOOTING ).

Scheme 84

The occupant detection ECU detects the state of the front seat inner belt assembly RH and road sensor when the front passenger seat is occupied with the power switch on (IG). If the front passenger seat belt is not fastened, the front seat belt warning light on the navigation receiver assembly *1 or hazard warning light *2 blinks. If the seat belt is fastened, the warning light goes off.

HINT

1. *1 : w/ Navigation System
2. *2 : w/o Navigation System

Scheme 85

Scheme 86

Scheme 87

1. CHECK FOR DTCs Check for DTCs. Result RESULT CHART Result Proceed to No output DTC A Output DTC (CAN communication) B Output DTC (Occupant detection) C B: GO TO CAN COMMUNICATION SYSTEM (See «DIAGNOSTIC TROUBLE CODE CHART»(ref-305555-S15116636062008112800000) ) C: GO TO OCCUPANT CLASSIFICATION SYSTEM (See «DIAGNOSTIC TROUBLE CODE CHART»(/toyota/highlander/ii-2007-2010/remont/airbag/#supplemental-restraint-system-hybrid) ) A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM Connect Techstream to the DLC3. Turn the power switch on (IG). Read the DATA LIST according to the displays on the tester screen. Combination Meter DIAGNOSTIC NOTE CHART Tester Display Test Part Control Range Diagnostic Note Front Passenger Side Seat Belt Front passenger side seat belt warning light Front passenger side seat belt warning light is OFF / ON Confirm that the vehicle is stopped, engine idling OK: Switch condition (ON or OFF) can be switched by "ACTIVE TEST" NG: Go to step 3 OK: REPLACE COMBINATION METER (See «REMOVAL»(ref-305557-S38033790702008112800000) )
3. CHECK WIRE HARNESS (BATTERY POSITIVE AND BODY GROUND) Disconnect the E19 connector. Measure the voltage and resistance according to the value(s) in the table below. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition E19-1 (B) - Body ground Power switch on (IG) 11 to 14 V Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition E19-5 (E) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR, OR REPLACE FUSE OK: Go to next step
4. CHECK HARNESS OR CONNECTOR Disconnect the E1 connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition E1-31 (PBLT) - E19-3 (PBEW) Always Below 1 ohms E1-31 (PBLT) or E19-3 (PBEW) - Body ground Always 10 kohms or higher Proceed to the next step based on the inspection result. Result RESULT CHART Result Proceed to NG A OK (w/ Navigation System) B OK (w/o Navigation System) C A: REPAIR OR REPLACE HARNESS OR CONNECTOR B: REPLACE NAVIGATION RECEIVER ASSEMBLY (See «REMOVAL»(ref-305576-S12360114142008112800000) ) C: REPLACE HAZARD WARNING SWITCH (See «REMOVAL»(ref-305572-S09672661062008112800000) )

Scheme 88

Scheme 89

Scheme 90

Scheme 91

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL (for Manual Seat) CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system (See «PRECAUTION»(/toyota/highlander/ii-2007-2010/remont/airbag/#supplemental-restraint-system-hybrid) ). NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-305531-S14384376742008112800000) ).
2. REMOVE FRONT SEAT HEADREST ASSEMBLY (for Manual Seat) (See «REMOVAL»(ref-305570-S11573706662008112800000) )
3. REMOVE FRONT OUTER SEAT TRACK COVER (for Manual Seat) (See «REMOVAL»(ref-305570-S11573706662008112800000) )
4. REMOVE FRONT INNER SEAT TRACK COVER (for Manual Seat) (See «REMOVAL»(ref-305570-S11573706662008112800000) )
5. REMOVE REAR SEAT TRACK COVER (for Manual Seat) (See «REMOVAL»(ref-305570-S11573706662008112800000) )
6. REMOVE FRONT SEAT ASSEMBLY (for Manual Seat) (See «REMOVAL»(ref-305570-S11573706662008112800000) )
7. REMOVE FRONT SEAT HEADREST ASSEMBLY (for Power Seat) (See «REMOVAL»(ref-305570-S29873822322008112800000) )
8. REMOVE FRONT OUTER SEAT TRACK COVER (for Power Seat) (See «REMOVAL»(ref-305570-S29873822322008112800000) )
9. REMOVE FRONT INNER SEAT TRACK COVER (for Power Seat) (See «REMOVAL»(ref-305570-S29873822322008112800000) )
10. REMOVE REAR OUTER SEAT TRACK COVER (for Power Seat) (See «REMOVAL»(ref-305570-S29873822322008112800000) )
11. REMOVE REAR INNER SEAT TRACK COVER (for Power Seat) (See «REMOVAL»(ref-305570-S29873822322008112800000) )
12. REMOVE FRONT SEAT ASSEMBLY (for Power Seat) (See «REMOVAL»(ref-305570-S29873822322008112800000) )
13. REMOVE FRONT SEAT INNER BELT ASSEMBLY (for Manual Seat) Disconnect each connector and clamp. Remove the nut and the front seat inner belt assembly.
14. REMOVE FRONT SEAT INNER BELT ASSEMBLY (for Power Seat) Disconnect each connector and clamp. Remove the nut and the front seat inner belt assembly.

Scheme 92

1. INSPECT FRONT SEAT INNER BELT ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance: for LH TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition O10-1 - O10-3 Seat belt is unfastened Below 1 ohms O10-1 - O10-3 Seat belt is fastened 1 Mohms or higher for RH TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition a5-1 - a5-2 Seat belt is unfastened Below 1 ohms a5-1 - a5-2 Seat belt is fastened 1 Mohms or higher If the result is not as specified, replace the inner belt assembly.

Scheme 93

Scheme 94

1. INSTALL FRONT SEAT INNER BELT ASSEMBLY (for Power Seat) Install the front seat inner belt assembly with the nut. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) NOTE: Do not allow the anchor part of the front seat inner belt assembly to overlap the protruding part of the front seat adjuster. Connect each connector and clamp.
2. INSTALL FRONT SEAT INNER BELT ASSEMBLY (for Manual Seat) Install the front seat inner belt assembly with the nut. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) NOTE: Do not allow the anchor part of the front seat inner belt assembly to overlap the protruding part of the front seat adjuster. Connect each connector and clamp.
3. INSTALL FRONT SEAT ASSEMBLY (for Power Seat) (See «INSTALLATION»(ref-305570-S10456642772008112800000) )
4. INSTALL REAR INNER SEAT TRACK COVER (for Power Seat) (See «INSTALLATION»(ref-305570-S10456642772008112800000) )
5. INSTALL REAR OUTER SEAT TRACK COVER (for Power Seat) (See «INSTALLATION»(ref-305570-S10456642772008112800000) )
6. INSTALL FRONT INNER SEAT TRACK COVER (for Power Seat) (See «INSTALLATION»(ref-305570-S10456642772008112800000) )
7. INSTALL FRONT OUTER SEAT TRACK COVER (for Power Seat) (See «INSTALLATION»(ref-305570-S10456642772008112800000) )
8. INSTALL FRONT SEAT HEADREST ASSEMBLY (for Power Seat) (See «INSTALLATION»(ref-305570-S10456642772008112800000) )
9. INSTALL FRONT SEAT ASSEMBLY (for Manual Seat) (See «INSTALLATION»(ref-305570-S38718851682008112800000) )
10. INSPECT FRONT SEAT SLIDE ADJUSTER LOCK (for Manual Seat) (See «INSTALLATION»(ref-305570-S38718851682008112800000) )
11. INSTALL REAR SEAT TRACK COVER (for Manual Seat) (See «INSTALLATION»(ref-305570-S38718851682008112800000) )
12. INSTALL FRONT INNER SEAT TRACK COVER (for Manual Seat) (See «INSTALLATION»(ref-305570-S38718851682008112800000) )
13. INSTALL FRONT OUTER SEAT TRACK COVER (for Manual Seat) (See «INSTALLATION»(ref-305570-S38718851682008112800000) )
14. INSTALL FRONT SEAT HEADREST ASSEMBLY (for Manual Seat) (See «INSTALLATION»(ref-305570-S38718851682008112800000) )
15. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL (for Manual Seat) NOTE: Some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-305531-S14384376742008112800000) ).
16. INSPECT FRONT SEAT ASSEMBLY (for Power Seat) (See «INSTALLATION»(ref-305570-S10456642772008112800000) )
17. INSPECT SRS WARNING LIGHT (See «DIAGNOSIS SYSTEM»(/toyota/highlander/ii-2007-2010/remont/airbag/#supplemental-restraint-system-hybrid) )

Scheme 95

1. ROAD TEST (IN SAFE AREA) CAUTION: Conduct this test in a safe area. Fasten the front seat belt. Drive the vehicle at 16 km/h (10 mph) and firmly depress the brake pedal. Check that the belts lock and cannot be extended at this time. If a belt does not lock, replace the seat belt assembly (See «FRONT SEAT OUTER BELT ASSEMBLY»(ref-305534-S26169899532008112800000) ). HINT: Inspect the seat belt assembly before installing it (See «INSPECTION»(ref-305534-S18794193052008112800000) ).

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system (See «PRECAUTION»(/toyota/highlander/ii-2007-2010/remont/airbag/#supplemental-restraint-system-hybrid) ). NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-305531-S14384376742008112800000) ).
2. REMOVE FRONT DOOR SCUFF PLATE (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-hybrid) )
3. DISCONNECT FRONT DOOR OPENING TRIM WEATHERSTRIP
4. REMOVE REAR DOOR SCUFF PLATE (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-hybrid) )
5. DISCONNECT REAR DOOR OPENING TRIM WEATHERSTRIP
6. REMOVE LOWER CENTER PILLAR GARNISH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-hybrid) )
7. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY Remove the bolt and disconnect the floor end of the front seat outer belt assembly.
8. REMOVE CENTER PILLAR GARNISH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-hybrid) )
9. REMOVE FRONT SEAT OUTER BELT ASSEMBLY Remove the nut and disconnect the shoulder anchor of the front seat outer belt assembly. Using a screwdriver, pull out the locking button in the direction shown by the arrow to release the lock, and disconnect the pretensioner connector as shown in the illustration. HINT: Tape the screwdriver tip before use. Remove the 2 bolts and front seat outer belt assembly.
10. REMOVE FRONT SHOULDER BELT ANCHOR ADJUSTER ASSEMBLY Remove the 2 bolts and front shoulder belt anchor adjuster assembly.

Scheme 102

1. INSPECT FRONT SEAT OUTER BELT ASSEMBLY NOTE: Do not disassemble the retractor. Before installing the outer belt, check the ELR. When the inclination of the retractor is 15° or less, check that the belt can be pulled from the retractor. When the inclination of the retractor is over 45°, check that the belt locks. If the result is not as specified, replace the outer belt assembly.

Scheme 103

Scheme 104

1. INSTALL FRONT SHOULDER BELT ANCHOR ADJUSTER ASSEMBLY Engage the adjuster positioning hole with the claw and install the front shoulder belt anchor adjuster assembly with the 2 bolts. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf)
2. INSTALL FRONT SEAT OUTER BELT ASSEMBLY Temporarily install the front seat outer belt assembly with the 2 bolts. Fully tighten the bolt first, then the bolt to install the front seat outer belt assembly. Torque: Bolt 7.5 N*m (77 kgf*cm, 66 in.*lbf) Bolt 42 N*m (428 kgf*cm, 31 ft.*lbf) Connect the connector and lock the locking button as shown in the illustration. NOTE: Securely lock the locking button. Connect the shoulder anchor of the front seat outer belt assembly with the nut. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf)
3. INSTALL CENTER PILLAR GARNISH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-hybrid) )
4. CONNECT FRONT SEAT OUTER BELT ASSEMBLY Install the floor end of the front seat outer belt assembly with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) Check if the ELR locks. NOTE: The check should be performed with the outer belt assembly installed. With the belt assembly installed, check that the belt locks when it is pulled out quickly.
5. INSTALL LOWER CENTER PILLAR GARNISH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-hybrid) )
6. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-hybrid) )
7. INSTALL REAR DOOR SCUFF PLATE (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-hybrid) )
8. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-hybrid) )
9. INSTALL FRONT DOOR SCUFF PLATE (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-hybrid) )
10. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: Some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-305531-S14384376742008112800000) ).
11. INSPECT SRS WARNING LIGHT (See «DIAGNOSIS SYSTEM»(/toyota/highlander/ii-2007-2010/remont/airbag/#supplemental-restraint-system-hybrid) )
