ENGINE ROOM RELAY/JUNCTION BLOCK
The engine room relay block is located on the left side of the engine compartment. (Scheme 1)
Scheme 1
Scheme 2
| Fuses | System | |
|---|---|---|
| 7.5A | ALT-S | Charging |
| 7.5A | AM2 | Automatic Light Control Back Door Opener (w/o Power Back Door) Door Lock Control Electronically Controlled Transmission and A/T Indicator Engine Control Glass Hatch Opener Light Auto Turn Off System Power Back Door Power Window Seat Belt Warning Sliding Roof Smart Key System |
| 7.5A | S-HORN | Smart Key System Theft Deterrent Wireless Door Lock Control (w/o Smart Key System) |
| 10A | CRT | Audio System (Except JBL) Audio System (JBL) Navigation System |
| 10A | DEF RLY | Rear Window Defogger |
| 10A | DOME | ABS Air Conditioning Audio System (Except JBL) Audio System (JBL) Back Door Opener (w/o Power Back Door) Charging Combination Meter Cooling Fan Cruise Control Door Lock Control Downhill Assist Control Electronically Controlled Transmission and A/T Indicator Engine Control EPS Front Fog Light Glass Hatch Opener Garage Door Opener Headlight Hill-Start Assist Control Illumination Interior Light Key Reminder (w/o Smart Key System) Multi Display Navigation System Parking Assist (Rear View Monitor) Power Back Door Seat Belt Warning Sliding Roof Smart Key System SRS Taillight Theft Deterrent Tire Pressure Warning System TRAC VSC Wireless Door Lock Control (w/o Smart Key System) |
| 10A | ECU-B | ABS Air Conditioning Audio System (Except JBL) Audio System (JBL) Automatic Light Control Back Door Opener (w/o Power Back Door) Charging Clock (w/o Multi Display) Combination Meter Cooling Fan Cruise Control Door Lock Control Downhill Assist Control Electronically Controlled Transmission and A/T Indicator Engine Control Engine Immobiliser System (w/o Smart Key System) EPS Front Fog Light Glass Hatch Opener Headlight Hill-Start Assist Control Illumination Interior Light Key Reminder (w/o Smart Key System) Light Auto Turn Off System Multi Display Navigation System Parking Assist (Rear View Monitor) Power Back Door Power Window Seat Belt Warning Sliding Roof Smart Key System SRS Taillight Theft Deterrent Tire Pressure Warning System TRAC VSC Wireless Door Lock Control (w/o Smart Key System) |
| 10A | EFI NO.1 | Cruise Control Electronically Controlled Transmission and A/T Indicator Engine Control Smart Key System |
| 10A | EFI NO.2 | Engine Control Electronically Controlled Transmission and A/T Indicator Cruise Control |
| 10A | EFI NO.3 | Engine Control Electronically Controlled Transmission and A/T Indicator |
| 10A | ETCS | Cruise Control Engine Control Electronically Controlled Transmission and A/T Indicator |
| 10A | G/H | Back Door Opener (w/o Power Back Door) Door Lock Control Glass Hatch Opener Interior Light Mirror Heater Smart Key System Wireless Door Lock Control (w/o Smart Key System) |
| 10A | HORN | Horn Smart Key System Theft Deterrent Wireless Door Lock Control (w/o Smart Key System) |
| 10A | INJ NO.2 | Combination Meter Engine Control Multi Display Parking Assist (Rear View Monitor) |
| 15A | AMP | Audio System (JBL) Navigation System |
| 15A | HAZ | Turn Signal and Hazard Warning Light Trailer Towing |
| 15A | H-LP LH | Headlight |
| 15A | H-LP LL | Headlight |
| 15A | H-LP RH | Headlight |
| 15A | H-LP RL | Headlight |
| 15A | INJ NO.1 | Ignition |
| 15A | RADIO1 | Audio System (Except JBL) Audio System (JBL) Navigation System |
| 20A | A/F | Engine Control |
| 20A | MIR HTR | Mirror Heater |
| 20A | P/OUT | Power Outlet (115V) |
| 20A | STR LOCK | Smart Key System |
| 25A | DOOR1 | Automatic Light Control Back Door Opener (w/o Power Back Door) Door Lock Control Electronically Controlled Transmission and A/T Indicator Engine Control Front Fog Light Glass Hatch Opener Headlight Illumination Interior Light Key Reminder (w/o Smart Key System) Light Auto Turn Off System Multi Display Parking Assist (Rear View Monitor) Power Back Door Power Window Seat Belt Warning Sliding Roof Smart Key System Taillight Theft Deterrent Wireless Door Lock Control (w/o Smart Key System) |
| 25A | EFI MAIN | Cooling Fan Cruise Control Electronically Controlled Transmission and A/T Indicator Engine Control |
| 25A | IG2 | Electronically Controlled Transmission and A/T Indicator Engine Control Smart Key System |
| 30A | PBD | Power Back Door |
| 30A | PTC NO.2 | Air Conditioning |
| 30A | PTC NO.3 | Air Conditioning |
| 30A | RR DEF | Rear Window Defogger |
| 30A | ST | Electronically Controlled Transmission and A/T Indicator Engine Control Smart Key System Starting (w/o Smart Key System) |
| 30A | TOWING | Trailer Towing |
| 30A | VSC NO.2 | ABS Downhill Assist Control Hill-Start Assist Control TRAC VSC |
| 40A | RR CLR | Air Conditioning |
| 50A | FAN MAIN | Cooling Fan |
| 50A | HTR | Air Conditioning |
| 50A | PTC NO.1 | Air Conditioning |
| 50A | VSC NO.1 | ABS Downhill Assist Control Hill-Start Assist Control TRAC VSC |
| 80A | EPS | EPS |
| 140A | ALT | Automatic Light Control Charging Front Fog Light Illumination Light Auto Turn Off System Power Window Starting (w/o Smart Key System) Taillight Theft Deterrent Theft Deterrent |
Engine Room Relay/Junction Block Components
ENGINE ROOM RELAY BLOCK NO. 2
The engine room relay block No. 3 is located on the right side of the engine compartment. (Scheme 1)
Scheme 3
INSTRUMENT PANEL JUNCTION BLOCK
The instrument panel junction block is located under the left side of the instrument panel. (Scheme 4)
Scheme 4
Scheme 5
Scheme 6
Scheme 7
| Fuses | System | |
|---|---|---|
| 7.5A | AM1 | Starting (w/o Smart Key System) Engine Control Electronically Controlled Transmission and A/T Indicator |
| 7.5A | ECU IG NO.2 | ABS Downhill Assist Control Hill-Start Assist Control Smart Key System Stop Light TRAC Trailer Towing VSC |
| 7.5A | ECU-ACC | Automatic Light Control Back Door Opener (w/o Power Back Door) Door Lock Control Electronically Controlled Transmission and A/T Indicator Engine Control Front Fog Light Glass Hatch Opener Headlight Illumination Interior Light Key Reminder (w/o Smart Key System) Light Auto Turn Off System Multi Display Parking Assist (Rear View Monitor) Power Back Door Power Window Remote Control Mirror Seat Belt Warning Shift Lock Sliding Roof Smart Key System Taillight Theft Deterrent Wireless Door Lock Control (w/o Smart Key System) |
| 7.5A | GAUGE NO.2 | ABS Air Conditioning Audio System (Except JBL) Audio System (JBL) Back Door Opener (w/o Power Back Door) Charging Combination Meter Cooling Fan Cruise Control Door Lock Control Downhill Assist Control Electronically Controlled Transmission and A/T Indicator Engine Control EPS Front Fog Light Glass Hatch Opener Headlight Hill-Start Assist Control Illumination Key Reminder (w/o Smart Key System) Multi Display Navigation System Parking Assist (Rear View Monitor) Power Back Door Seat Belt Warning Sliding Roof Smart Key System SRS Taillight Tire Pressure Warning System TRAC VSC Wireless Door Lock Control (w/o Smart Key System) |
| 7.5A | OBD | Data Link Connector 3 |
| 7.5A | PANEL | Illumination Taillight |
| 7.5A | RAD NO. 2 | Audio System (Except JBL) Audio System (JBL) Clock (w/o Multi Display) Illumination Navigation System Taillight |
| 10A | A/C NO.2 | Air Conditioning Cooling Fan |
| 10A | ACC SOCK NO.1 | Power Outlet (12V) |
| 10A | ECU IG NO.1 | Automatic Glare-Resistant EC Mirror Automatic Light Control Back Door Opener (w/o Power Back Door) Cruise Control Door Lock Control Electronically Controlled Transmission and A/T Indicator Engine Control EPS Front Fog Light Glass Hatch Opener Headlight Illumination Interior Light Key Reminder (w/o Smart Key System) Light Auto Turn Off System Multi Display Parking Assist (Rear View Monitor) Power Back Door Power Window Seat Belt Warning Seat Heater Shift Lock Sliding Roof Smart Key System Taillight Theft Deterrent Tire Pressure Warning System Wireless Door Lock Control (w/o Smart Key System) |
| 10A | GAUGE NO.1 | Air Conditioning Audio System (JBL) Back Door Opener (w/o Power Back Door) Back-Up Light Charging Cruise Control Door Lock Control Electronically Controlled Transmission and A/T Indicator Front Window Deicer Glass Hatch Opener Interior Light Mirror Heater Multi Display Navigation System Parking Assist (Rear View Monitor) Power Back Door Power Outlet (115V) Rear Window Defogger Seat Belt Warning Trailer Towing Turn Signal and Hazard Warning Light |
| 10A | IGN | Cruise Control Electronically Controlled Transmission and A/T Indicator Engine Control Engine Immobiliser System (w/o Smart Key System) Seat Belt Warning Smart Key System SRS |
| 10A | STOP | ABS Cruise Control Downhill Assist Control Electronically Controlled Transmission and A/T Indicator Engine Control Hill-Start Assist Control Multi Display Parking Assist (Rear View Monitor) Shift Lock Smart Key System Stop Light TRAC Trailer Towing VSC |
| 15A | FR FOG | Front Fog Light |
| 15A | MIR HTR | Mirror Heater |
| 15A | RR WIP | Rear Wiper and Washer |
| 15A | TAIL | Front Fog Light Illumination Taillight Trailer Towing |
| 20A | ACC SOCK NO.2 | Power Outlet (12V) |
| 20A | S-HTR | Seat Heater |
| 20A | WASH | Front Wiper and Washer Rear Wiper and Washer |
| 25A | DOOR NO.2 | Power Window |
| 25A | FR DEF | Front Window Deicer |
| 25A | RR DOOR LH | Power Window |
| 25A | RR DOOR RH | Power Window |
| 30A | FR WIP | Front Wiper and Washer |
| 30A | P/SEAT | Power Seat (Driver's Seat) Power Seat (Front Passenger's Seat) |
| 30A | POWER | Power Window |
| 30A | S/ROOF | Sliding Roof |
Instrument Panel Junction Block Components
