Multiplex Communication (Except Hybrid): Overview Toyota Highlander II

Communication Devices 7 illustrations ~563 words

SYSTEM DESCRIPTION

  1. LIN COMMUNICATION SYSTEM DESCRIPTION Multiplex communication system (LIN) is used to control communication between the ECUs of the body system. If communication cannot be performed through LIN because of an open in the communication lines or other reason, the master control ECU of the relevant system will output a DTC. For the communication system and the connected ECUs, refer to the table below. HINT: Each ECU has a fail safe function which activates to maintain the minimum performance of the system and protect the system. Door System LIN Communication System DOOR SYSTEM LIN COMMUNICATION SYSTEM REFERENCE ECU Master Control (UN Communication DTC Output Function) Main Body ECU o (with output function) Front Power Window ECU x (without output function) Sliding Roof ECU *1 x (without output function) HINT: *1: Models with Sliding Roof Certification System LIN Communication System CERTIFICATION SYSTEM LIN COMMUNICATION SYSTEM REFERENCE ECU Master Control (LIN Communication DTC Output Function) Certification ECU o (with output function) Main Body ECU x (without output function) Steering Lock ECU x (without output function) ID Code Box x (without output function) Air Conditioning LIN Communication System AIR CONDITIONING LIN COMMUNICATION SYSTEM REFERENCE Component Master Control (LIN Communication DTC Output Function) Air Conditioning Amplifier Assembly o (with output function) A/C Control Assembly (for Front) x (without output function) A/C Control Assembly (for Rear) x (without output function)

DESCRIPTION

This DTC is output when LIN communication between the sliding roof ECU (sliding roof drive gear) and main body ECU (instrument panel junction block assembly) stops for more than 10 seconds.

DTC No.DTC Detection ConditionTrouble Area
B1273No communication between sliding roof drive gear and main body ECU (instrument panel junction block assembly) for more than 10 secondsSliding roof ECU (Sliding roof drive gear sub-assembly) Main body ECU (Instrument panel junction block assembly) Wire harness

DIAGNOSTIC TROUBLE CODE TABLE

Scheme 253

Scheme 253: WIRING DIAGRAM

This DTC is output when there is an open, short or ECU communication malfunction between the main body ECU (instrument panel junction block assembly) and certification ECU (smart key ECU assembly).

DTC No.DTC Detection ConditionTrouble Area
B2287There is an open, short or ECU communication malfunction between main body ECU (instrument panel junction block assembly) and certification ECU (smart key ECU assembly).Certification ECU (Smart key ECU assembly) Main body ECU (Instrument panel junction block assembly) Wire harness

DIAGNOSTIC TROUBLE CODE TABLE

Scheme 254

Scheme 254: WIRING DIAGRAM

This DTC is output when LIN communication between the front power window regulator motor assembly LH and main body ECU (instrument panel junction block assembly) stops for more than 10 seconds.

DTC No.DTC Detection ConditionTrouble Area
B2321No communication between front power window regulator motor assembly LH and main body ECU (instrument panel junction block assembly) for more than 10 secondsFront power window regulator motor assembly LH Main body ECU (Instrument panel junction block assembly) Wire harness

DIAGNOSTIC TROUBLE CODE TABLE

Scheme 255

Scheme 255: WIRING DIAGRAM

The main body ECU (instrument panel junction block assembly) monitors communication between all the ECUs connected to the door system LIN bus lines. When the main body ECU (instrument panel junction block assembly) detects errors in communication with all the ECUs connected to the door system LIN bus lines at 2.6-second intervals and 3 times in a row, DTC B2325 will be output.

DTC No.DTC Detection ConditionTrouble Area
B2325Main body ECU (instrument panel junction block assembly) detects errors in communication with the ECUs connected to the door system LIN bus lines 3 times in a row.Front power window regulator motor assembly LH Sliding roof ECU (Sliding roof drive gear sub-assembly)*1 Main body ECU (Instrument panel junction block assembly) Wire harness
HINT: *1: w/ Sliding Roof

DIAGNOSTIC TROUBLE CODE TABLE

Scheme 256

Scheme 256: WIRING DIAGRAM

The certification ECU (smart key ECU assembly) monitors communication between all the ECUs connected to the certification ECU (smart key ECU assembly) system LIN bus lines. When the certification ECU (smart key ECU assembly) detects errors in communication with all the ECUs connected to the certification ECU (smart key ECU assembly) system LIN bus lines at a set interval and 3 times in a row, DTC B2785 will be output.

DTC No.DTC Detection ConditionTrouble Area
B2785Error in LIN communication between ECUs and an open or short in communication lines LIN communication from certification ECU (smart key ECU assembly) stops for a set amount of time or moreCertification ECU (Smart key ECU assembly) Main body ECU (Instrument panel junction block assembly) Steering lock ECU (Steering lock actuator assembly) ID code box (Immobiliser code ECU) Wire harness

DIAGNOSTIC TROUBLE CODE TABLE

Scheme 257

Scheme 257: WIRING DIAGRAM

This DTC is output when LIN communication between the certification ECU (smart key ECU assembly) and steering lock ECU (steering lock actuator assembly) stops for more than 10 seconds.

DTC No.DTC Detection ConditionTrouble Area
B2786No communication between steering lock ECU (steering lock actuator assembly) and certification ECU (smart key ECU assembly) for more than 10 secondsSteering lock ECU (Steering lock actuator assembly) Certification ECU (Smart key ECU assembly) Wire harness

DIAGNOSTIC TROUBLE CODE TABLE

Scheme 258

Scheme 258: WIRING DIAGRAM

This DTC is output when LIN communication between the certification ECU (smart key ECU assembly) and ID code box (immobilizer code ECU) stops for more than 10 seconds.

DTC No.DTC Detection ConditionTrouble Area
B2789No communication between certification ECU (smart key ECU assembly) and ID code box (immobilizer code ECU) for more than 10 secondsID code box (Immobilizer code ECU) Certification ECU (Smart key ECU assembly) Wire harness

DIAGNOSTIC TROUBLE CODE TABLE

Scheme 259

Scheme 259: WIRING DIAGRAM
