PRECAUTION
- NOTICES OF INSPECTION WITH REMOVAL AND INSTALLATION PROCEDURES Before performing operations related to the front door lock assy RH and door lock cylinder, disconnect the battery terminal or the connectors of the power window regulator master switch assy. CAUTION: If the operation is performed with the connectors being connected, the door control switch (interlocked with key) inside the door lock might be unexpectedly actuated, which results in injury.
PRE-CHECK
- POWER WINDOW OPERATION MODE HINT: The initial condition that the customizing function by the hand-held tester is not chosen is shown. Standard: INITIAL CONDITION CHART Power window operation Ignition switch ON Ignition switch OFF Operative after key-OFF Ignition switch OFF Inoperative after key-OFF Manual UP Operative Jam protection function operative Inoperative Manual DOWN Operative Operative Inoperative AUTO UP Jam protection function operative Jam protection function operative Inoperative AUTO DOWN Operative Operative Inoperative UP operation interlocked with key Inoperative Jam protection function operative Jam protection function operative DOWN operation interlocked with key Inoperative Operative Operative
- POWER WINDOW FAIL-SAFE FUNCTION When an abnormality is detected in the limit switch and pulse sensor for operating the jam protection function (DTC: B 1231/31, B1232/32), the following power window operations will be prohibited by the fail-safe function. Standard: POWER WINDOW FAIL-SAFE FUNCTION CHART Power window operation Ignition switch ON Ignition switch OFF Operative after key-OFF Ignition switch OFF Inoperative after key-OFF Manual UP Operative Operation prohibited - Manual DOWN Operative Operation prohibited - AUTO UP Operation prohibited Operation prohibited - AUTO DOWN Operation prohibited Operation prohibited - UP operation interlocked with key - Operation prohibited Operation prohibited DOWN operation interlocked with key - Operation prohibited Operation prohibited HINT: In case of normal limit switch, the prohibition (fail-safe function) will be cancelled by fully opening the door glass that is fully closed by the manual operation, then AUTO operations will be possible.
- CHECK HAND-HELD TESTER ECU Data Monitor: The ECU data monitor will indicate if the part is normal or malfunctioning. Standard: Door ECU (driver side) (switch condition) DOOR ECU (DRIVER SIDE) SWITCH CONDITION CHART Item Inspecting condition Standard value Driver side power window AUTO switch Pressed-->Not pressed ON/OFF Jam protection limit switch Power window fully open-->fully closed ON/OFF Door ECU (driver side) (jam protection threshold) DOOR ECU (DRIVER SIDE) INSPECTING CONDITION Item Inspecting condition Standard value Window full-close position-->1/4 open position Power window is going UP by manual operation OK/CAUTION (1) Window 1/4 open position-->2/4 open position Power window is going UP by manual operation OK/CAUTION (1) Window 2/4 open position-->3/4 open position Power window is going UP by manual operation OK/CAUTION (1) Window 3/4 open position-->full-open position Power window is going UP by manual operation OK/CAUTION (1) (1) "CAUTION" is indicated when something is detected in being caught in the window. Active Test: The active test will indicate if the part is normal or malfunctioning. Standard: Door ECU (driver side) ITEM AND OPERATION Item Operation Power window UP/DOWN Customizing Function (reference): Using the hand-held tester, select a setting from the following items on the power window. Standard: Door ECU (driver side) ITEM AND SETTING Item Setting Power window UP operation interlocked with door With/Without function Power window DOWN operation interlocked with door With/Without function
