Seat: Overview Toyota Highlander I рестайлинг

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. CHECK POWER SEAT FUNCTION Check the basic functions. Operate the power seat switches and check to make sure each seat function works: Sliding Front vertical (driver's seat only) Rear vertical (driver's seat only) Reclining Lumbar support (driver's seat only)
2. CHECK POWER SEAT MOTOR ASSY (SLIDING, FRONT VERTICAL, REAR VERTICAL AND RECLINING FUNCTIONS) HINT: The front vertical function and rear vertical function are only available for the driver's seat. Check the PTC operation inside the power seat motor. HINT: The PTC thermistor's resistance increases when the power seat switch is held down even after the power seat has been moved to the maximum in one direction. After the resistance increases, current is shut off to prevent a short circuit. NOTE: Perform steps (1) to (4) for the full range of motion for each power seat function. Choose a power seat function. Operate the power seat switch and move the seat to the maximum in one direction. Keep the seat in that position for approximately 60 seconds. Operate the power seat switch again and continue to try to move the seat in the same direction as in step (1). Measure the amount of time elapsed before the electrical current is automatically cut. Check if electrical current has shut off by making sure the sound of the motor has stopped. Standard: 4 to 90 seconds After the current has stopped, release the power seat switch and wait for approximately 60 seconds. Operate the same power seat switch and move the seat to the opposite extreme of the direction in step (1). Check that the motor operates. Repeat steps (1) to (4) for the remaining power seat functions.
3. Driver's seat only: CHECK LUMBAR SUPPORT ADJUSTER ASSY LH Check the PTC operation inside the power seat motor. NOTE: The inspection should be performed with the seat installed in the vehicle. Operate the lumbar support switch and move the lumbar support to either the foremost or rearmost position. Keep the seat in that position for approximately 60 seconds. Operate the lumbar support switch again and continue to try to move the lumbar support in the same direction as in step (1). Measure the amount of time elapsed before the electrical current is automatically cut. Check if electrical current has shut off by making sure the sound of the motor has stopped. Standard: 4 to 90 seconds After the current has stopped, release the lumbar support switch and wait for approximately 60 seconds. Operate the lumbar support switch and move the seat to the opposite extreme of the direction in step (1). Check that the motor operates.

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. INSPECT FRONT POWER SEAT SWITCH LH Check the resistance between the terminals when each switch is operated. Standard: Slide switch SLIDE SWITCH SPECIFICATION Tester Connection Switch Condition Specified Condition 1 - 9 FRONT Below 1 ohm 4 - 6 FRONT Below 1ohm 4 - 6 OFF Below 1ohm 4 - 9 OFF Below 1 ohm 1 - 6 REAR Below 1 ohm 4 - 9 REAR Below 1 ohm Driver's seat only: Front vertical switch FRONT VERTICAL SWITCH SPECIFICATION Tester Connection Switch Condition Specified Condition 1 - 10 UP Below 1 ohm 4 - 5 UP Below 1 ohm 4 - 5 OFF Below 1 ohm 4 - 10 OFF Below 1 ohm 1 - 5 DOWN Below 1 ohm 4 - 10 DOWN Below 1 ohm Driver's seat only: Rear vertical switch REAR VERTICAL SWITCH SPECIFICATION Tester Connection Switch Condition Specified Condition 1 - 7 UP Below 1 ohm 4 - 8 UP Below 1 ohm 4 - 7 OFF Below 1 ohm 4 - 8 OFF Below 1 ohm 1 - 8 DOWN Below 1 ohm 4 - 7 DOWN Below 1 ohm Reclining switch RECLINING SWITCH SPECIFICATION Tester Connection Switch Condition Specified Condition 1 - 3 FRONT Below 1 ohm 2 - 4 FRONT Below 1 ohm 2 - 4 OFF Below 1 ohm 3 - 4 OFF Below 1 ohm 1 - 2 REAR Below 1 ohm 3 - 4 REAR Below 1 ohm If the result is not as specified, replace the switch.
2. INSPECT FRONT POWER SEAT SWITCH RH Check the resistance between the terminals when each switch is operated. Standard: Slide switch SLIDE SWITCH SPECIFICATION Tester Connection Switch Condition Specified Condition 1 - 9 FRONT Below 1 ohm 4 - 6 FRONT Below 1 ohm 4 - 6 OFF Below 1 ohm 4 - 9 OFF Below 1 ohm 1 - 6 REAR Below 1 ohm 4 - 9 REAR Below 1 ohm Reclining switch RECLINING SWITCH SPECIFICATION Tester Connection Switch Condition Specified Condition 1 - 3 FRONT Below 1 ohm 2 - 4 FRONT Below 1 ohm 2 - 4 OFF Below 1 ohm 3 - 4 OFF Below 1 ohm 1 - 2 REAR Below 1 ohm 3 - 4 REAR Below 1 ohm If the result is not as specified, replace the switch.
3. Driver's seat only: INSPECT POWER SEAT SWITCH ASSY (LUMBAR SUPPORT) Check the resistance between the terminals when the switch is operated. Standard: TESTER CONNECTION - SWITCH CONDITION SPECIFICATION Tester Connection Switch Condition Specified Condition 1 - 2 HOLD Below 1 ohm 3 - 4 HOLD Below 1 ohm 1 - 2 OFF Below 1 ohm 4 - 5 OFF Below 1 ohm 1 - 3 RELEASE Below 1 ohm 4 - 5 RELEASE Below 1 ohm If the result is not as specified, replace the switch assy.
4. INSPECT FRONT SEAT ADJUSTER ASSY Check operation of the slide motor. Check if the motor rotates smoothly when the battery is connected to the slide motor connector terminals. Standard: MEASUREMENT CONDITION - OPERATION DIRECTION SPECIFICATION Measurement Condition Operational Direction Battery positive (+) --> 1 Battery negative (-) --> 2 Clockwise Battery positive (+) --> 2 Battery negative (-) --> 1 Counterclockwise If the result is not as specified, replace the slide motor. Driver's seat only: Check operation of the front vertical motor. Check if the motor rotates smoothly when the battery is connected to the front vertical motor connector terminals. Standard: MEASUREMENT CONDITION - OPERATION DIRECTION SPECIFICATION Measurement Condition Operational Direction Battery positive (+) --> 1 Battery negative (-) --> 2 Clockwise Battery positive (+) --> 2 Battery negative (-) --> 1 Counterclockwise If the result is not as specified, replace the front vertical motor. Driver's seat only: Check operation of the rear vertical motor. Check if the motor rotates smoothly when the battery is connected to the rear vertical motor connector terminals. Standard: MEASUREMENT CONDITION - OPERATION DIRECTION SPECIFICATION Measurement Condition Operational Direction Battery positive (+) --> 1 Battery negative (-) --> 2 Clockwise Battery positive (+) --> 2 Battery negative (-) --> 1 Counterclockwise If the result is not as specified, replace the rear vertical motor. Check operation of the reclining motor. Check if the motor rotates smoothly when the battery is connected to the reclining motor connector terminals. Standard: MEASUREMENT CONDITION - OPERATION DIRECTION SPECIFICATION Measurement Condition Operational Direction Battery positive (+) --> 1 Battery negative (-) --> 2 Clockwise Battery positive (+) --> 2 Battery negative (-) --> 1 Counterclockwise If the result is not as specified, replace the rear vertical motor.
5. Driver's seat only: INSPECT LUMBAR SUPPORT ADJUSTER ASSY Check operation of the lumbar support adjuster motor. Check if the motor rotates smoothly when the battery is connected to the lumbar support adjuster motor connector terminals. Standard: MEASUREMENT CONDITION - OPERATION DIRECTION SPECIFICATION Measurement Condition Operational Direction Battery positive (+) --> 1 Battery negative (-) --> 2 Clockwise Battery positive (+) --> 2 Battery negative (-) --> 1 Counterclockwise If the result is not as specified, replace the rear vertical motor.

Scheme 13
