Engine Ignition System: Removal & Installation Toyota Highlander I рестайлинг

REPLACEMENT

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 11

1. REMOVE AIR CLEANER ASSY (See «REPLACEMENT»(ref-226410-S11713569722006032800000) )
2. REMOVE CAMSHAFT POSITION SENSOR Disconnect the sensor connector. Remove the bolt and sensor.
3. INSTALL CAMSHAFT POSITION SENSOR Apply a light coat of engine oil to a new O-ring. Install the O-ring onto the sensor. Install the sensor with the bolt. Torque: 9.0 N.m (92 kgf.cm, 80 in..Ibf)
4. INSTALL AIR CLEANER ASSY (See «REPLACEMENT»(ref-226410-S37790286992006032800000) )

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 12

Scheme 13

Scheme 14

1. REMOVE ENGINE UNDER COVER NO.1 Remove the 6 screws, 2 clips and under cover.
2. REMOVE FRONT FENDER APRON SEAL RH Remove the clip, 2 bolts and apron seal.
3. REMOVE CRANKSHAFT POSITION SENSOR Disconnect the sensor connector. Remove the bolt, clamp and sensor.
4. INSTALL CRANKSHAFT POSITION SENSOR Install the sensor and clamp with the bolt. Torque: 9.0 N.m (92 kgf.cm, 80 in..lbf) Connect the sensor connector.
5. INSTALL FRONT FENDER APRON SEAL RH Install the clip, 2 bolts and apron seal.
6. INSTALL ENGINE UNDER COVER NO.1 Install the 6 screws, 2 clips and under cover.

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 15

1. REMOVE AIR CLEANER ASSY
2. REMOVE VVT SENSOR Disconnect the sensor connector. Remove the bolt and sensor.
3. INSTALL VVT SENSOR Apply a light coat of engine oil to a new O-ring. Install the O-ring onto the sensor. Install the sensor with the bolt. Torque: 8.0 N.m (82 kgf.cm, 71 in.lbf) Connect the sensor connector.
4. INSTALL AIR CLEANER ASSY (See «REPLACEMENT»(ref-226410-S11713569722006032800000) )

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 16

Scheme 17

Scheme 18

1. REMOVE ENGINE UNDER COVER NO.1 Remove the 6 screws, 2 clips and under cover.
2. REMOVE FRONT FENDER APRON SEAL RH Remove the clip, 2 bolts and apron seal.
3. REMOVE CRANKSHAFT POSITION SENSOR Disconnect the sensor connector. Remove the bolt and sensor.
4. INSTALL CRANKSHAFT POSITION SENSOR Install the sensor with the bolt. Torque: 8.0 N.m (82 kgf.cm, 71 in..Ibf) Connect the sensor connector.
5. INSTALL FRONT FENDER APRON SEAL RH Install the clip, 2 bolts and apron seal.
6. INSTALL ENGINE UNDER COVER NO.1 Install the 6 screws, 2 clips and under cover.
