Audio & Visual System: Removal & Installation Toyota Highlander I рестайлинг

Entertainment Systems 54 illustrations ~2471 words

REPLACEMENT

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 159

Scheme 159
Scheme 159

Scheme 160

Scheme 160
Scheme 160

Scheme 161

Scheme 161
Scheme 161

Scheme 162

Scheme 162
Scheme 162

Scheme 163

Scheme 163
Scheme 163
  1. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY CENTER (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) )
  2. REMOVE INTEGRATION CONTROL & PANEL ASSY Remove the 6 bolts. Disconnect the connectors and remove the integration control & panel assy.
  3. REMOVE RADIO BRACKET NO.1 (W/O EMV & NAVIGATION SYSTEM) Remove the 4 bolts, 2 screws and radio bracket No. 1.
  4. REMOVE MULTI-DISPLAY CONTROLLER BRACKET A (W/ EMV & NAVIGATION SYSTEM) Remove the 7 screws and multi-display controller bracket A.
  5. REMOVE RADIO BRACKET NO.2 (W/O EMV & NAVIGATION SYSTEM) Remove the 4 bolts, 2 screws and radio bracket No. 2.
  6. REMOVE MULTI-DISPLAY CONTROLLER BRACKET B (W/ EMV & NAVIGATION SYSTEM) Remove the 7 screws and multi-display controller bracket B.
  7. REMOVE RADIO RECEIVER ASSY

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 164

Scheme 164
Scheme 164

Scheme 165

Scheme 165
Scheme 165

Scheme 166

Scheme 166
Scheme 166
  1. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY CENTER (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) )
  2. REMOVE INTEGRATION CONTROL & PANEL ASSY Remove the 6 bolts. Disconnect the connectors and remove the integration control & panel assy.
  3. REMOVE MULTI-DISPLAY CONTROLLER BRACKET A Remove the 7 screws and multi-display controller bracket A.
  4. REMOVE MULTI-DISPLAY CONTROLLER BRACKET B Remove the 7 screws and multi-display controller bracket B.
  5. REMOVE MULTI-DISPLAY (CRT DISPLAY) DISPLAY
  6. INSTALL MULTI-DISPLAY (CRT DISPLAY) DISPLAY HINT: Perform the screen noise automatic adjustment when screen noise occurs (see «SCREEN NOISE AUTOMATIC ADJUSTMENT»(ref-226393-S36826250022006032800000) ).

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 167

Scheme 167
Scheme 167

Scheme 168

Scheme 168
Scheme 168

Scheme 169

Scheme 169
Scheme 169
  1. REMOVE FRONT SEAT ASSEMBLY LH POWER SEAT (SEE «OVERHAUL»(ref-226448-S01001931032006032900000) ) MANUAL SEAT (SEE «OVERHAUL»(ref-226448-S42460727202006032900000) )
  2. REMOVE NAVIGATION ECU COVER Remove the 4 claws and the navigation ECU cover.
  3. REMOVE NAVIGATION ECU W/BRACKET Disconnect the connector. Remove the 2 bolts and the navigation ECU w/ bracket.
  4. REMOVE DISC PLAYER BRACKET Remove the 4 screws and the disc player bracket.
  5. REMOVE NAVIGATION ECU
  6. INSTALL NAVIGATION ECU HINT: Perform the screen noise automatic adjustment when screen noise occurs (see «SCREEN NOISE AUTOMATIC ADJUSTMENT»(ref-226393-S36826250022006032800000) ).
  7. INSTALL FRONT SEAT ASSEMBLY LH POWER SEAT (SEE «OVERHAUL»(ref-226448-S01001931032006032900000) ) MANUAL SEAT (SEE «OVERHAUL»(ref-226448-S42460727202006032900000) )

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 170

Scheme 170
Scheme 170

Scheme 171

Scheme 171
Scheme 171
  1. REMOVE MULTIPLEX NETWORK MASTER SWITCH ASSY (SEE «OVERHAUL»(ref-226451-S12890490472006032900000) )
  2. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (SEE «OVERHAUL»(ref-226451-S12890490472006032900000) )
  3. REMOVE DOOR PULL HANDLE (SEE «OVERHAUL»(ref-226451-S12890490472006032900000) )
  4. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (SEE «OVERHAUL»(ref-226451-S12890490472006032900000) )
  5. REMOVE FRONT DOOR INSIDE HANDLE SUB-ASSY LH (SEE «OVERHAUL»(ref-226451-S12890490472006032900000) )
  6. REMOVE FRONT NO.1 SPEAKER ASSY Disconnect the connector. Remove the 3 screws and front No. 1 speaker assy.
  7. INSTALL FRONT NO.1 SPEAKER ASSY Install the front No.1 speaker assy with the 3 screws. Connect the connector.

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 172

Scheme 172
Scheme 172
  1. REMOVE MULTIPLEX NETWORK MASTER SWITCH ASSY (SEE «OVERHAUL»(ref-226451-S12890490472006032900000) )
  2. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (SEE «OVERHAUL»(ref-226451-S12890490472006032900000) )
  3. REMOVE DOOR PULL HANDLE (SEE «OVERHAUL»(ref-226451-S12890490472006032900000) )
  4. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (SEE «OVERHAUL»(ref-226451-S12890490472006032900000) )
  5. REMOVE FRONT DOOR INSIDE HANDLE SUB-ASSY LH (SEE «OVERHAUL»(ref-226451-S12890490472006032900000) )
  6. REMOVE FRONT NO.2 SPEAKER ASSY Disconnect the connector. Remove the screw and front No. 2 speaker assy.

HINT

  1. COMPONENTS: See «OVERHAUL»(ref-226451-S18478694062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 173

Scheme 173
Scheme 173

Scheme 174

Scheme 174
Scheme 174
  1. REMOVE DOOR PULL HANDLE (SEE «OVERHAUL»(ref-226451-S18478694062006032900000) )
  2. REMOVE REAR DOOR TRIM BOARD SUB-ASSY LH (SEE «OVERHAUL»(ref-226451-S18478694062006032900000) )
  3. REMOVE REAR DOOR INSIDE HANDLE SUB-ASSY LH (SEE «OVERHAUL»(ref-226451-S18478694062006032900000) )
  4. REMOVE REAR DOOR SERVICE HOLE COVER LH (SEE «OVERHAUL»(ref-226451-S18478694062006032900000) )
  5. REMOVE REAR SPEAKER ASSY Disconnect the connector. Remove the 3 screws and rear speaker assy.
  6. INSTALL REAR SPEAKER ASSY Install the rear speaker assy with the 3 screws. Connect the connector.

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 175

Scheme 175
Scheme 175
  1. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/PASSENGER AIR BAG ASSY (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) ) HINT: Go to the procedures up to "REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/ PASSENGER AIRBAG ASSY".
  2. REMOVE ANTENNA CORD SUB-ASSY NO.2 Remove the 4 clamps and antenna cord sub-assy.
  3. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/PASSENGER AIR BAG ASSY (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) ) Go to the procedures from "INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/ PASSENGER AIRBAG ASSY".

HINT

  1. COMPONENTS: See «REPLACEMENT»(ref-226452-S19685221352006032900000)
  2. Installation is in the reverse order of removal.

Scheme 176

Scheme 176
Scheme 176
  1. REMOVE ROOF HEADLINING ASSY (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) ) HINT: Go to the procedures up to "REMOVE ROOF HEAD LINING ASSY".
  2. REMOVE ANTENNA CORD SUB-ASSY NO.3 Remove the antenna cord sub assy No. 3 from the roof headlining.
  3. INSTALL ANTENNA CORD SUB-ASSY NO.3 Tape the antenna cord sub-assy No. 3 at the position of the roof headlining shown in the illustration. NOTE: The antenna cord sub assy should come to the center of the tape (100 mm x 25 mm) when taped. Try not to touch the adhesive side of the tape when taping.
  4. INSTALL ROOF HEADLINING ASSY (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) ) HINT: Go to the procedures from "INSTALL ROOF HEAD LINING ASSY".

HINT

  1. COMPONENTS: See «REPLACEMENT»(ref-226452-S19685221352006032900000)
  2. Installation is in the reverse order of removal.

Scheme 177

Scheme 177
Scheme 177

Scheme 178

Scheme 178
Scheme 178
  1. REMOVE ROOF HEADLINING ASSY (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) ) HINT: Go to the procedures up to "REMOVE ROOF HEAD LINING ASSY".
  2. REMOVE ROOF SIDE RAIL BRACKET LH Remove the 4 bolts and roof side rail bracket LH.
  3. REMOVE AMPLIFIER ANTENNA ASSY Disconnect the 2 connectors. Remove the 4 clamps, bolt and amplifier antenna assy.
  4. INSTALL ROOF HEADLINING ASSY (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) ) HINT: Go to the procedures from "INSTALL ROOF HEAD LINING ASSY".

HINT

  1. COMPONENTS: See «REPLACEMENT»(ref-226452-S19685221352006032900000)
  2. Installation is in the reverse order of removal.

Scheme 179

Scheme 179
Scheme 179

Scheme 180

Scheme 180
Scheme 180
  1. REMOVE ROOF HEADLINING ASSY (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) ) HINT: Go to the procedures up to "REMOVE ROOF HEAD LINING ASSY".
  2. REMOVE ROOF SIDE RAIL BRACKET RH Remove the 4 bolts and roof side rail bracket RH.
  3. REMOVE AMPLIFIER ANTENNA ASSY Disconnect the 2 connectors. Remove the 3 clamps, bolt and amplifier antenna assy.
  4. INSTALL ROOF HEADLINING ASSY (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) ) HINT: Go to the procedures from "INSTALL ROOF HEAD LINING ASSY".

HINT

  1. COMPONENTS: See «REPLACEMENT»(ref-226452-S19685221352006032900000)
  2. Installation is in the reverse order of removal.

Scheme 181

Scheme 181
Scheme 181

Scheme 182

Scheme 182
Scheme 182

Scheme 183

Scheme 183
Scheme 183
  1. REMOVE GLOVE COMPARTMENT DOOR ASSY (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) )
  2. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER NO.2 (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) )
  3. REMOVE FRONT PILLAR GARNISH RH (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) )
  4. REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSY LH (SEE «REPLACEMENT»(ref-226452-S23835840052006032900000) )
  5. REMOVE W/HOLDER ANTENNA ASSY Disconnect the connector, and remove the bolt. Remove the 2 clamps. Tie the string at the tip of the cable of the w/holder antenna assy. Remove the antenna nut and ornament antenna. Remove the nut and w/holder antenna assy.
  6. INSTALL W/HOLDER ANTENNA ASSY Install the w/holder antenna assy with the nut. Install the antenna nut and ornament antenna. Use the string to put the cable of the w/holder antenna assy. Install the 2 clamps. Connect the connector, install the bolt.

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 184

Scheme 184
Scheme 184
  1. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/PASSENGER AIR BAG ASSY (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) ) HINT: Go to the procedures up to "REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/ PASSENGER AIRBAG ASSY".
  2. REMOVE NAVIGATION ANTENNA ASSY Release the 3 clamps and remove the 2 screws and the navigation antenna assy.
  3. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/PASSENGER AIR BAG ASSY (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) ) HINT: Go to the procedures from "INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/PASSENGER AIRBAG ASSY".

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 185

Scheme 185
Scheme 185
  1. REMOVE TONNEAU COVER ASSY (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  2. REMOVE DECK BOARD SUB-ASSY NO.2 (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  3. REMOVE DECK BOARD SUB-ASSY NO.3 (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  4. REMOVE DECK FLOOR BOX REAR (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  5. REMOVE DECK FLOOR BOX FRONT (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  6. REMOVE REAR FLOOR FINISH PLATE (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  7. REMOVE DECK SIDE TRIM BOX RH (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  8. REMOVE DECK TRIM SIDE PANEL ASSY RH (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  9. REMOVE STEREO COMPONENT AMPLIFIER ASSY Remove the 2 nuts and bolt. Disconnect the connectors, then remove the stereo component amplifier assy.

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 186

Scheme 186
Scheme 186
  1. REMOVE GLOVE COMPARTMENT DOOR ASSY (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) )
  2. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER NO.2 (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) )
  3. REMOVE NETWORK GATEWAY ECU Disconnect the connector. Remove the bolt and the network gateway ECU.

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 187

Scheme 187
Scheme 187
  1. REMOVE INSTRUMENT CLUSTER FINISH PANEL ASSY CENTER (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) )
  2. REMOVE FRONT SEAT ARMREST ASSY CENTER (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) )
  3. REMOVE CONSOLE BOX ASSY (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) )
  4. REMOVE VOLTAGE INVERTER ASSY Disconnect the connector. Remove the 2 clamps and the voltage inverter assy.

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 188

Scheme 188
Scheme 188

Scheme 189

Scheme 189
Scheme 189

Scheme 190

Scheme 190
Scheme 190

Scheme 191

Scheme 191
Scheme 191

Scheme 192

Scheme 192
Scheme 192

Scheme 193

Scheme 193
Scheme 193

Scheme 194

Scheme 194
Scheme 194
  1. REMOVE REAR SEAT ASSY RH (SEE «OVERHAUL»(ref-226448-S07607932952006032900000) )
  2. REMOVE REAR SEAT ASSY LH (SEE «OVERHAUL»(ref-226448-S10798381172006032900000) )
  3. REMOVE REAR DOOR SCUFF PLATE RH (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  4. REMOVE REAR DOOR SCUFF PLATE LH (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  5. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  6. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  7. REMOVE TONNEAU COVER ASSY (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  8. REMOVE DECK BOARD SUB-ASSY (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  9. REMOVE DECK BOARD SUB-ASSY NO.2 (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  10. REMOVE DECK BOARD SUB-ASSY NO.3 (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  11. REMOVE DECK SIDE TRIM BOX RH (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  12. REMOVE DECK SIDE TRIM BOX LH (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  13. REMOVE REAR FLOOR FINISH PLATE (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  14. REMOVE DECK TRIM SIDE PANEL ASSY RH (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  15. REMOVE DECK TRIM SIDE PANEL ASSY LH (SEE «REPLACEMENT»(ref-226452-S19685221352006032900000) )
  16. REMOVE REAR SEAT SUB FLOOR PANEL ASSY (W/O RR NO.2 SEAT) Remove the 3 bolts, 3 nuts and rear seat sub floor panel.
  17. REMOVE MULTI-DISPLAY CONTROLLER W/BRACKET Disconnect the connectors. W/o RR No.2 Seat: Remove the 2 bolts and nut and the multi-display controller w/bracket. W/ RR No.2 Seat: Remove the 2 nuts and bolt and the multi-display controller w/bracket.
  18. REMOVE MULTI-DISPLAY CONTROLLER BRACKET A Remove the 2 screws and the multi-display controller bracket A.
  19. REMOVE MULTI-DISPLAY CONTROLLER BRACKET B Remove the 2 screws and the multi-display controller bracket B.
  20. REMOVE MULTI-DISPLAY CONTROLLER SUB-ASSY

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 195

Scheme 195
Scheme 195

Scheme 196

Scheme 196
Scheme 196
  1. REMOVE TELEVISION BASE Release the 4 claws and remove the television base.
  2. REMOVE TELEVISION DISPLAY ASSY Disconnect the connector and remove the 4 nuts and the television display assy.

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 197

Scheme 197
Scheme 197

Scheme 198

Scheme 198
Scheme 198
  1. REMOVE VIDEO (VIDEO ADAPTER) TERMINAL Remove the video (video adapter) terminal together with the console box rear cover as shown in the illustration. Disconnect the connector. Release the 4 claw fittings and remove the video (video adapter) terminal.

HINT

  1. COMPONENTS: See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 199

Scheme 199
Scheme 199

Scheme 200

Scheme 200
Scheme 200
  1. PRECAUTION (SEE «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-226436) )
  2. SEPARATE BATTERY NEGATIVE TERMINAL (SEE «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-226436) )
  3. REMOVE STEERING WHEEL COVER LOWER NO.2 (SEE «OVERHAUL»(ref-226425-S14118475362006032900000) )
  4. REMOVE STEERING WHEEL COVER LOWER NO.3 (SEE «OVERHAUL»(ref-226425-S14118475362006032900000) )
  5. REMOVE HORN BUTTON ASSY (SEE «OVERHAUL»(ref-226425-S14118475362006032900000) )
  6. REMOVE STEERING PAD SWITCH LH Disconnect the connector. Disconnect the connector of cruise control main switch. Remove the screw. Release the 2 pin fittings and remove the steering pad switch LH.
  7. INSTALL HORN BUTTON ASSY (SEE «ON-VEHICLE INSPECTION»(ref-226436-S22404861942006032900000) )
  8. CONNECT BATTERY NEGATIVE TERMINAL
  9. INSPECT HORN BUTTON ASSY (SEE «OVERHAUL»(ref-226425-S14118475362006032900000) )
  10. INSPECT SRS WARNING LIGHT (SEE «DIAGNOSIS SYSTEM»(ref-226387-S14136422472006032800000) )

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 201

Scheme 201
Scheme 201

Scheme 202

Scheme 202
Scheme 202
  1. REMOVE INSTRUMENT CLUSTER FINISH PANEL ASSY CENTER (SEE «REPLACEMENT»(ref-226443-S32618601872006032900000) )
  2. REMOVE CIGARETTE LIGHTER ASSY Remove the cigarette lighter cover. Disengage the meshing of the cigarette lighter and the cigarette lighter indicator lens by rotating the cigarette lighter assy. Pull out the cigarette lighter assy.
  3. INSTALL CIGARETTE LIGHTER ASSY Aligning the socket with the cutout of the socket cover, fully push it to install.

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 203

Scheme 203
Scheme 203
  1. REMOVE POWER OUTLET SOCKET ASSY CTR Turn the socket in the circumference direction as shown in the illustration, disengage the claw between the socket and the power point socket cover, and push out the socket to the room side.
  2. INSTALL POWER OUTLET SOCKET ASSY CTR Align the socket with the notch on the power point socket cover CTR and install the power socket assy CTR by pushing it in as hard as possible.

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 204

Scheme 204
Scheme 204

Scheme 205

Scheme 205
Scheme 205

Scheme 206

Scheme 206
Scheme 206
  1. REMOVE POWER POINT SOCKET ASSY RR Using a screwdriver, disengage the claw on the power point socket cover from the hole in the power point socket, then pull out the power point socket approx. 10 mm (0.39 in.). HINT: Tape the screwdriver tip before use. Using a screwdriver, disengage the claw on the power point socket cover from the body and remove the power point socket and cover as a unit. HINT: Tape the screwdriver tip before use. Disconnect the connector. Disassemble the power point socket from the socket cover.
  2. INSTALL POWER POINT SOCKET ASSY RR Assemble the power point socket to the power point socket cover at the position 10 mm (0.39 in.) away from full lock position and ensure that they are temporarily locked. Align the cut-out on the body with the claw on the power point socket cover and install the power point socket and cover to the body. After installing them, push in the power point socket approx. 10 mm (0.39 in.) to lock it.

HINT

  1. See «COMPONENTS»(ref-226440-S11645230062006032900000)
  2. Installation is in the reverse order of removal.

Scheme 207

Scheme 207
Scheme 207

Scheme 208

Scheme 208
Scheme 208
  1. REMOVE INSTRUMENT CLUSTER FINISH PANEL ASSY CENTER
  2. REMOVE FRONT SEAT ARMREST ASSY CENTER
  3. REMOVE CONSOLE BOX ASSY
  4. REMOVE POWER OUTLET SOCKET ASSY Remove the power outlet socket assy together with the console box rear cover as shown in the illustration. Disconnect the connector. Release the 2 claw fittings and remove the power outlet socket assy.

Scheme 209

Scheme 209: REPAIR
Scheme 209: REPAIR

Scheme 210

Scheme 210
Scheme 210

Scheme 211

Scheme 211
Scheme 211

Scheme 212

Scheme 212
Scheme 212
  1. INSPECT WINDOW GLASS (ANTENNA WIRE) NOTE: When cleaning the glass, use a soft, dry cloth, and wipe the glass in the direction of the wire. Take care not to damage the wires. Do not use detergents or glass cleaners with abrasive ingredients. When measuring voltage, wind a piece of tin foil around the top of the negative probe and press the foil against the wire with your finger, as shown in the illustration. Inspect the continuity at the center of each antenna wire as shown in the illustration.
  2. REPAIR WINDOW GLASS (ANTENNA WIRE) Clean the broken wire tips with a grease, wax and silicone remover. Place the masking tape along both sides of the wire to be repaired. Thoroughly mix the repair agent (DuPont paste No. 4817). Using a fine tip brush, apply a small amount to the wire. After a few minutes, remove the masking tape. Do not repair the defogger wire for at least 24 hours.

More articles — Audio & Visual System
