Starting System & Charging System: Removal & Installation Toyota Highlander I рестайлинг

REPLACEMENT

Note. Before changing the starter, check the following again

1. Connector connection
2. Accessory Installation

Scheme 7

1. REMOVE BATTERY
2. REMOVE BATTERY TRAY
3. REMOVE STARTER ASSY Disconnect the starter connector. Open the terminal cap, remove the nut and disconnect the starter wire. Remove the 2 bolts and starter.
4. INSTALL STARTER ASSY Install the starter with the 2 bolts. Torque: 37 N. m (377 kgf.cm, 27 ft.lbf) Install the starter wire with the nut. Torque: 9.8 N. m (100 kgf.cm, 7 ft.lbf) Connect the starter connector.
5. INSTALL BATTERY TRAY
6. INSTALL BATTERY Install the battery clamp with the bolt and nut. Torque: 5.5 N. m (56 kgf.cm, 49 in.lbf) Connect the cables to the battery terminals. Torque: 3.5 N.m (36 kgf.cm, 31 in.lbf)

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

1. REMOVE MAGNETIC SWITCH ASSY Remove the nut and disconnect the lead wire from the magnetic switch. Remove the 2 screws holding the magnetic switch to the starter drive housing. Remove the magnetic switch. Remove the return spring and plunger from the drive housing.
2. REMOVE STARTER YOKE ASSY Remove the 2 through bolts, and pull out the yoke together with the commutator end frame. Remove the yoke from the commutator end frame.
3. REMOVE STARTER ARMATURE PLATE Remove the armature plate from the yoke.
4. REMOVE STARTER COMMUTATOR END FRAME COVER Using a screwdriver, remove the frame cover.
5. REMOVE STARTER ARMATURE ASSY Using snap ring pliers, remove the snap ring and plate washer. Remove the armature from the commutator end frame.
6. REMOVE PLANETARY GEAR Remove the 3 planetary gears from the drive housing.
7. INSPECT MAGNETIC SWITCH ASSY Check the plunger. Push in the plunger and check that it returns quickly to its original position. If necessary, replace the magnetic switch assy. Check if the pull-in coil has an open circuit. Check the resistance between terminals 50 and C. Standard: Below 1 ohm If the result is not as specified, replace the magnetic switch assy. Check if the hold-in coil has an open circuit. Check the resistance between terminal 50 and the switch body. Standard: Below 2 ohm If the result is not as specified, replace the magnetic switch assy. INSPECT STARTER ARMATURE ASSY Check the commutator for contamination and burns on its surface. If the surface is dirty or burnt, correct it with sandpaper (No. 400) or a lathe. Check if the commutator has an open circuit. Check the resistance between the segments of the commutator. Standard: Below 1 ohm If the result is not as specified, replace the armature assy. Check if the commutator is grounded. Check the resistance between the commutator and armature coil core. Standard: 10 kohm or higher If the result is not as specified, replace the armature assy. Using a vernier caliper, measure the commutator's depth. Specified depth: 3.1 mm (0.122 In.) Maximum depth: 3.8 mm (0.150 In.) If the depth is greater than the maximum, replace the starter armature.
8. INSPECT STARTER COMMUTATOR END FRAME ASSY Using a vernier caliper, measure the brush length. Standard length: 9.0 mm (0.354 in.) Minimum length: 4.0 mm (0.157 in.) If the length is less than the minimum, replace the end frame assy.
9. Check the brush insulation. Check the resistance between the positive (+) and negative (-) brush. Standard: 10 kohm or higher If the result is not as specified, repair or replace the end frame assy.
10. INSPECT STARTER DRIVE HOUSING ASSY Check the starter clutch. Rotate the clutch pinion gear counterclockwise and check that it turns freely. Try to rotate the clutch pinion gear clockwise and check that it locks. If necessary, replace the drive housing assy.
11. INSTALL PLANETARY GEAR Apply grease to the planetary gears and pin parts of the planetary shaft. Install the 3 planetary gears.
12. INSTALL STARTER ARMATURE ASSY Apply grease to the plate washer and the armature shaft. Install the armature to the starter commutator end frame. Using snap ring pliers, install the plate washer and a new snap ring. Using a vernier caliper, measure the length of the snap ring. Maximum length: 5.0 mm (0.197 in.) If the length is greater than the maximum, replace it with a new snap ring.
13. INSTALL STARTER COMMUTATOR END FRAME COVER Install the end frame cover to the commutator end frame.
14. INSTALL STARTER ARMATURE PLATE Align the keyway of the starter plate with the key inside the field frame, and install the plate.
15. INSTALL STARTER COMMUTATOR END FRAME ASSY Align the rubber of the end frame with the cutout of the yoke. Install the end frame to the yoke.
16. INSTALL STARTER YOKE ASSY Align the protrusion of the yoke with the cutout of the drive housing. Install the yoke with the 2 through bolts. Torque: 6.0 N.m (61 kgf.cm, 53 in.lbf)
17. INSTALL MAGNETIC SWITCH ASSY Apply grease to the plunger and the hook. Hang the plunger hook of the magnetic switch to the drive lever. Install the plunger and return spring. Install the magnetic switch with the 2 screws. Torque: 7.5 N. m (76 kgf.cm, 66 in.lbf) Connect the lead wire to the magnetic switch with the nut. Torque: 10 N.m (102 kgf. cm, 7 ft.lbf)

Note. Before changing the starter, check the following again

1. Connector connection
2. Accessory installation

Scheme 36

Scheme 37

Scheme 38

1. REMOVE BATTERY
2. REMOVE BATTERY TRAY
3. REMOVE STARTER ASSY Disconnect the starter connector. Open the terminal cap, remove the nut and disconnect the starter wire. Remove the 2 bolts and starter.
4. INSTALL STARTER ASSY Install the starter with the 2 bolts. Torque: 37 N.m (377 kgf.cm, 27 ft.lbf) Install the terminal nut and cover the nut with the cap. Torque: 9.8 N.m (100 kgf.cm, 7 ft.lbf) Connect the starter wire.
5. INSTALL BATTERY TRAY
6. INSTALL BATTERY Install the battery clamp with the bolt and nut. Torque: 5.5 N.m (56 kgf.cm, 49 in..lbf) Connect the cables to the battery terminals. Torque: 3.5 N.m (36 kgf.cm, 31 in..lbf)

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. REMOVE MAGNETIC SWITCH ASSY Remove the nut and disconnect the lead wire from the magnetic switch. Remove the 2 screws holding the magnetic switch to the starter drive housing. Remove the magnetic switch. Remove the return spring and plunger from the drive housing.
2. REMOVE STARTER YOKE ASSY Remove the 2 through bolts, and pull out the yoke together with the commutator end frame. Remove the yoke from the commutator end frame.
3. REMOVE STARTER AMATEUR PLATE Remove the armature plate from the field frame.
4. REMOVE STARTER COMMUTATOR END FRAME COVER Using a screwdriver, remove the frame cover.
5. REMOVE STARTER ARMATURE ASSY Using snap ring pliers, remove the snap ring and plate washer. Remove the armature from the commutator end frame.
6. REMOVE PLANETARY GEAR Remove the 3 planetary gears from the drive housing.
7. INSPECT MAGNETIC SWITCH ASSY Check the plunger. Push in the plunger and check that it returns quickly to its original position. If necessary, replace the magnetic switch assy. Check if the pull-in coil has an open circuit. Check the resistance between terminals 50 and C. Standard: Below 1 ohm If the result is not as specified, replace the magnetic switch assy. Check if the hold-in coil has an open circuit. Check the resistance between terminal 50 and the switch body. Standard: Below 2 ohm If the result is not as specified, replace the magnetic switch assy.
8. INSPECT STARTER ARMATURE ASSY Check the commutator for contamination and burns on its surface. If the surface is dirty or burnt, correct it with sandpaper (No. 400) or a lathe. Check if the commutator has an open circuit. Check the resistance between the segments of the commutator. Standard: Below 1 ohm If the result is not as specified, replace the armature assy. Check if the commutator is grounded. Check the resistance between the commutator and armature coil core. Standard: 10 kohm or higher If the result is not as specified, replace the armature assy. Using a vernier caliper, measure the commutator's depth. Specified depth: 3.1 mm (0.122 in.) Maximum depth: 3.8 mm (0.150 in.) If the depth is greater than the maximum, replace the starter armature.
9. INSPECT STARTER COMMUTATOR END FRAME ASSY Using a vernier caliper, measure the brush length. Standard length: 9.0 mm (0.354 In.) Minimum length: 4.0 mm (0.157 in.) If the length is less than the minimum, replace the end frame assy. Check the brush insulation. Check the resistance between the positive (+) and negative (-) brush. Standard: 10 kohm or higher If the result is not as specified, repair or replace the end frame assy.
10. INSPECT STARTER DRIVE HOUSING ASSY Check the starter clutch. Rotate the clutch pinion gear counterclockwise and check that it turns freely. Try to rotate the clutch pinion gear clockwise and check that it locks. If necessary, replace the drive housing assy.
11. INSTALL PLANETARY GEAR Apply grease to the planetary gears and pin parts of the planetary shaft. Install the 3 planetary gears.
12. INSTALL STARTER ARMATURE ASSY Apply grease to the plate washer and the armature shaft. Install the armature to the starter commutator end frame. Using snap ring pliers, install the plate washer and a new snap ring. Using a vernier caliper, measure the length of the snap ring. Maximum length: 5.0 mm (0.197 in.) If the length is greater than the maximum, replace it with a new snap ring.
13. INSTALL STARTER COMMUTATOR END FRAME COVER Install the end frame cover to the commutator end frame.
14. INSTALL STARTER ARMATURE PLATE Align the keyway of the starter plate with the key inside the yoke, and install the plate.
15. INSTALL STARTER COMMUTATOR END FRAME ASSY Align the rubber of the end frame with the cutout of the yoke. Install the end frame to the yoke.
16. INSTALL STARTER YOKE ASSY Align the protrusion of the yoke with the cutout of the drive housing. Install the yoke with the 2 through bolts. Torque: 6.0 N.m (61 kgf.cm, 53 in..lbf)
17. INSTALL MAGNETIC SWITCH ASSY Apply grease to the plunger and the hook. Hang the plunger hook of the magnetic switch to the drive lever. Install the plunger and return spring. Install the magnetic switch with the 2 screws. Torque: 7.5 N.m (76 kgf.cm, 66 in..lbf) Connect the lead wire to the magnetic switch with the nut. Torque: 10 N.m (102 kgf.cm, 7 ft.lbf)
