Power Window Control System Toyota Echo I

Windows 39 illustrations ~1098 words

Note. For circuit isolation tables and troubleshooting procedures, see POWER WINDOW CONTROL SYSTEM. For circuit wiring diagrams, see SYSTEM WIRING DIAGRAMS.

Scheme 1

Scheme 1: LOCATION
Scheme 1: LOCATION

Scheme 2

Scheme 2: INSPECTION
Scheme 2: INSPECTION

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
  1. 2 Door Models: Inspect Power Window Master Switch Continuity : If continuity is not as specified, replace the switch.
  2. 4 Door Models: Inspect Power Window Master Switch Continuity : If continuity is not as specified, replace the master switch.
  3. 2 Door Models: Inspect One Touch Power Window System (Using An Ammeter) : Disconnect the connector from the master switch. Connect the positive (+) lead from the ammeter to terminal 3 on the wire harness side connector and the negative (-) lead to the negative (-) terminal of the battery. Connect the positive (+) lead from the battery to terminal 4 on the wire harness side connector. As the window goes down, check that the current is approximately 7 A. NOTE: The circuit breaker opens for 7 - 13 seconds after the window stops going down, so that check must be made before the circuit breaker operates. Check that the current increases up to approximately 14.5 A or more when the window stops going down. If operation is not as specified, replace the master switch.
  4. 2 Door Models: Inspect One Touch Power Window System , (Using An Ammeter With A Current-Measuring Probe). Remove the master switch with connector connected. Attach a current-measuring probe to terminal 9 of the wire harness. Turn the ignition switch ON, and set the power window switch in the down position. As the window goes down, check that the current is approximately 7 A. NOTE: The circuit breaker opens for 7 - 13 seconds after the window stops going down, so that check must be made before the circuit beaker operates. Check that the current increases up to approximately 14.5 A or more when the window stops going down. If operation is not as specified, replace the master switch.
  5. 4 Door Models: Inspect One Touch Power Window System , (Using An Ammeter) Disconnect the connector from the master switch. Connect the positive (+) lead from the ammeter to terminal 1 on the wire harness side connector and the negative (-) lead to the negative terminal of the battery. Connect the positive (+) lead from tee battery to terminal 5 on the wire harness side connector. As the window goes down, check that the current flow is approximately 7 A. NOTE: The circuit breaker opens some 4-40 seconds after the window stops going down, so that check must be made before the circuit breaker operates. Check that the current increases up to approximately 14.5 A or more when the window stops going down. If the operation is as specified, replace the master switch.
  6. 4 Door Models: Inspect One Touch Power Window System (Using An Ammeter With A Current-Measuring Probe). Remove the master switch with connector connected. Attach a current-measuring probe to terminal 10 of the wire harness. Turn the ignition switch ON and set the power window switch in the down position. As the window goes down, check that the current flow is approximately 7 A. NOTE: The circuit breaker opens for 4-40 seconds after the window stops going down, so that check must be made before the circuit breaker operates. Check that the current increases up to approximately 14.5 A or more when the window stops going down. If operation is as specified, replace the master switch.
  7. Inspect passenger's power window switch continuity : If continuity is not as specified, replace the switch
  8. 4 Door Models: Inspect Rear Door Power Window Switch Continuity . If continuity is not as specified, replace the switch
  9. Inspect Power Main Relay Continuity If continuity is not as specified, replace the switch.
  10. Front Left Side Door: Inspect Power Window Motor Operation . Connect the positive (+) lead from the battery to terminal 4 and the negative (-) lead to terminal 5, and check that the motor turns clockwise. Reverse the polarity, check that the motor turns counterclockwise. If operation is not as specified, replace the motor.
  11. Front Right Side Door: Inspect Power Window Motor Operation . Connect the positive (+) lead from the battery to terminal 5 and the negative (-) lead to terminal 4, and check that the motor turns clockwise: Reverse the polarity, check that the motor turns counterclockwise. If operation is not as specified, replace the motor.
  12. Rear Left Side Door: Inspect Power Window Motor Operation . Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2, and check that the motor turns clockwise. Reverse the polarity, check that the motor turns counterclockwise. If operation is not as specified, replace the motor.
  13. Rear Right Side Door: Inspect Power Window Motor Operation . Connect the positive (+) led from the battery to terminal 1 and the negative (-) lead to terminal 2, and check that the motor turns clockwise. Reverse the polarity, check that the motor turns counterclockwise. If operation is not as specified, replace the motor.
  14. 2 Door Models Driver's Door: Inspect PTC Operation . Disconnect the connector from the master switch. Connect the positive (+) lead from the battery to terminal 3 and the negative (-) lead to terminal 4 on the wire harness side connector and raise the window to full closed position. Continue to apply voltage, check that there is a circuit breaker operation noise within approximately 4 to 40 seconds. Reverse the polarity, check that the window begins to descend within approximately 60 seconds. If operation is not as specified, replace the motor.
  15. 4 Door Models Driver's Door: Inspect PTC Operation . Disconnect the connector from the master switch. Connect the positive (+) led from the battery to terminal 1 and the negative (-) lead to terminal 5 on the wire harness side connector and raise the window to full closed position. Continue to apply voltage, check that there is a circuit breaker operation noise within approximately 4 to 40 seconds. Reverse the polarity, check that the window begins to descend within approximately 60 seconds. If operation is not as specified, replace the motor.
