Starting System: Specifications Toyota Echo I

Starter 17 illustrations

STARTER SPECIFICATIONS

ApplicationSpecification
Camry & Camry Solara
Brush Holder Length
Standard.354" (9.00 mm)
Minimum.157" (4.00 mm)
Commutator
Runout
Standard.0008" (.020 mm)
Maximum.0020" (.050 mm)
Length
Standard.1299" (3.300 mm)
Maximum.1575" (4.000 mm)
Snap Ring End Gap.1969" (5.000 mm)
Celica & Corolla
Brush Length
Standard.610" (15.50 mm)
Minimum.394" (10.00 mm)
Brush Spring Load
1.2 kW
Standard3.09-4.41 Lbs. (1.4-2.0 kg)
Minimum1.98 Lbs. (.9 kg)
1.4 kW
Standard3.97-5.29 Lbs. (1.8-2.4 kg)
Minimum2.64 Lbs. (1.2 kg)
Commutator
Diameter
Standard1.181" (30.00 mm)
Minimum1.142" (29.00 mm)
Undercut Depth
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
ECHO
Brush Length
Standard.551" (14.00 mm)
Minimum.354" (9.00 mm)
Brush Spring Load
Standard3.09-3.97 Lbs. (1.4-1.8 kg)
Minimum1.98 Lbs. (.9 kg)
Commutator
Diameter
Standard1.102" (28.00 mm)
Minimum1.063" (27.00 mm)
Undercut Depth
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
Highlander
Brush Length
Standard.610" (15.50 mm)
Minimum.335" (8.50 mm)
Brush Spring Load(1)
Commutator
Diameter
Standard1.181" (30.00 mm)
Minimum1.142" (29.00 mm)
Undercut Depth
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
MR2
Brush Length
Standard.610" (15.50 mm)
Minimum.394" (10.00 mm)
Brush Spring Load
Standard3.97-5.29 Lbs. (1.8-2.4 kg)
Minimum2.64 Lbs. (1.2 kg)
Commutator
Diameter
Standard1.181" (30.00 mm)
Minimum1.142" (29.00 mm)
Undercut Depth
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
RAV4
Brush Length
Standard.610" (15.50 mm)
Minimum.334" (8.50 mm)
Brush Spring Load
1.2 kW
Standard3.09-4.41 Lbs. (1.4-2.0 kg)
Minimum1.98 Lbs. (.9 kg)
1.4 kW
Standard3.97-5.29 Lbs. (1.8-2.4 kg)
Minimum2.64 Lbs. (1.2 kg)
Commutator
Diameter
Standard1.181" (30.00 mm)
Minimum1.142" (29.00 mm)
Undercut Depth
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
Tacoma
Brush Length
1.4 kW
Standard.610" (15.50 mm)
Minimum.394" (10.00 mm)
2.0 kW
Standard.591" (15.00 mm)
Minimum.354" (9.00 mm)
Brush Spring Load
1.4 kW
Standard3.97-5.29 Lbs. (1.8-2.4 kg)
Minimum2.64 Lbs. (1.2 kg)
2.0 kW
Standard4.85-6.17 Lbs. (2.2-2.8 kg)
Minimum2.86 Lbs. (1.3 kg)
Commutator
Diameter
1.4 kW
Standard1.181" (30.00 mm)
Minimum1.142" (29.00 mm)
2.0 kW
Standard1.378" (35.00 mm)
Minimum1.338" (34.00 mm)
Undercut Depth
1.4 kW
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
2.0 kW
Standard.028" (.70 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
(1) Information not available from manufacturer.
(1)Information not available from manufacturer.

STARTER SPECIFICATIONS (4-CYLINDER)

ApplicationSpecification
Avalon
Brush Length
Standard.610" (15.50 mm)
Minimum.394" (10.00 mm)
Brush Spring Load
Standard3.97-5.29 Lbs. (1.8-2.4 kg)
Minimum2.6 Lbs. (1.2 kg)
Commutator
Diameter
Standard1.181" (30.00 mm)
Minimum1.142" (29.00 mm)
Undercut Depth
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
Camry
Brush Holder Length
Standard.354" (9.00 mm)
Minimum.157" (4.00 mm)
Commutator
Runout
Standard.0008" (.020 mm)
Maximum.0020" (.050 mm)
Length
Standard.1299" (3.300 mm)
Maximum.1575" (4.000 mm)
Snap Ring End Gap.1969" (5.000 mm)
Camry Solara
Brush Length
Standard.610" (15.50 mm)
Minimum.394" (10.00 mm)
Brush Spring Load
Standard3.97-5.29 Lbs. (1.8-2.4 kg)
Minimum2.64 Lbs. (1.2 kg)
Commutator
Diameter
Standard1.181" (30.00 mm)
Minimum1.142" (29.00 mm)
Undercut Depth
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
Highlander
Brush Length
Standard.610" (15.50 mm)
Minimum.335" (8.50 mm)
Brush Spring Load(1)
Commutator
Diameter
Standard1.181" (30.00 mm)
Minimum1.142" (29.00 mm)
Undercut Depth
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
Sienna
Brush Length
Standard.610" (15.50 mm)
Minimum.394" (10.00 mm)
Brush Spring Load
Standard3.97-5.29 Lbs. (1.8-2.4 kg)
Minimum2.64 Lbs. (1.2 kg)
Commutator
Diameter
Standard1.181" (30.00 mm)
Minimum1.142" (29.00 mm)
Undercut Depth
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
Tacoma & 4Runner
Brush Length
1.4 kW
Standard.610" (15.50 mm)
Minimum.394" (10.00 mm)
1.8 kW
Standard.591" (15.00 mm)
Minimum.354" (9.00 mm)
Brush Spring Load
1.4 kW
Standard3.97-5.29 Lbs. (1.8-2.4 kg)
Minimum2.64 Lbs. (1.2 kg)
1.8 kW
Standard4.85-6.17 Lbs. (2.2-2.8 kg)
Minimum2.86 Lbs. (1.3 kg)
Commutator
Diameter
1.4 kW
Standard1.181" (30.00 mm)
Minimum1.142" (29.00 mm)
1.8 kW
Standard1.378" (35.00 mm)
Minimum1.338" (34.00 mm)
Undercut Depth
1.4 kW
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
1.8 kW
Standard.028" (.70 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
Tundra
Brush Length
1.2 kW & 1.4 kW
Standard.610" (15.50 mm)
Minimum.394" (10.00 mm)
1.8 kW
Standard.591" (15.00 mm)
Minimum.354" (9.00 mm)
Brush Spring Load
1.2 kW
Standard3.09-4.40 Lbs. (1.4-2.0 kg)
Minimum2.20 Lbs. (1.0 kg)
1.4 kW
Standard3.97-5.29 Lbs. (1.8-2.4 kg)
Minimum2.64 Lbs. (1.2 kg)
1.8 kW
Standard4.85-6.17 Lbs. (2.2-2.8 kg)
Minimum2.86 Lbs. (1.3 kg)
Commutator
Diameter
1.2 kW & 1.4 kW
Standard1.181" (30.00 mm)
Minimum1.142" (29.00 mm)
1.8 kW
Standard1.378" (35.00 mm)
Minimum1.338" (34.00 mm)
Undercut Depth
1.2 kW & 1.4 kW
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
1.8 kW
Standard.028" (.70 mm)
Minimum.008" (.20 mm)
(1) Information not available from manufacturer.
(1)Information not available from manufacturer.

STARTER SPECIFICATIONS (V6)

ApplicationSpecification
Land Cruiser
Brush Length
Standard.591" (15.00 mm)
Minimum.354" (9.00 mm)
Brush Spring Load
Standard4.85-6.17 Lbs. (2.2-2.8 kg)
Minimum2.86 Lbs. (1.3 kg)
Commutator
Diameter
Standard1.378" (35.00 mm)
Minimum1.338" (34.00 mm)
Undercut Depth
Standard.028" (.70 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
Sequoia
Brush Length
1.4 kW
Standard.610" (15.50 mm)
Minimum.334" (8.50 mm)
2.0 kW
Standard.591" (15.00 mm)
Minimum.354" (9.00 mm)
Brush Spring Load
1.4 kW
Standard3.97-4.63 Lbs. (1.8-2.1 kg)
Minimum2.64 Lbs. (1.2 kg)
2.0 kW
Standard4.85-6.17 Lbs. (2.2-2.8 kg)
Minimum2.86 Lbs. (1.3 kg)
Commutator
Diameter
Standard1.378" (35.00 mm)
Minimum1.338" (34.00 mm)
Undercut Depth
Standard.028" (.70 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)
Tundra
Brush Length
1.4 kW
Standard.610" (15.50 mm)
Minimum.394" (10.00 mm)
2.0 kW
Standard.591" (15.00 mm)
Minimum.354" (9.00 mm)
Brush Spring Load
1.4 kW
Standard3.97-5.29 Lbs. (1.8-2.4 kg)
Minimum2.64 Lbs. (1.2 kg)
2.0 kW
Standard4.85-6.17 Lbs. (2.2-2.8 kg)
Minimum2.86 Lbs. (1.3 kg)
Commutator
Diameter
1.4 kW
Standard1.181" (30.00 mm)
Minimum1.142" (29.00 mm)
2.0 kW
Standard1.378" (35.00 mm)
Minimum1.338" (34.00 mm)
Undercut Depth
1.4 kW
Standard.024" (.60 mm)
Minimum.008" (.20 mm)
2.0 kW
Standard.028" (.70 mm)
Minimum.008" (.20 mm)
Maximum Runout.002" (.05 mm)

STARTER SPECIFICATIONS (V8)

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Starter Mounting Bolt
Avalon29 (39)
Camry
2.4L 4-Cyl.29 (39)
3.0L V631 (42)
Camry Solara & Celica27 (37)
Corolla & ECHO28 (38)
Highlander
2.4L 4-Cyl.29 (39)
3.0L V631 (42)
Land Cruiser29 (39)
MR2 & RAV428 (38)
Sequoia29 (39)
Sienna27 (37)
Tacoma, Tundra & 4Runner29 (39)
INCH Lbs. (N.m)
Starter Through Bolt
Avalon52 (5.9)
Camry53 (6.0)
Camry Solara
2.4L 4-Cyl.53 (6.0)
3.0L V652 (5.9)
Celica, Corolla, ECHO, Highlander, MR2, RAV4 & Sienna52 (5.9)
Land Cruiser & Sequoia82 (9.3)
Tacoma
1.4 kW52 (5.9)
1.8 kW & 2.0 kW82 (9.3)
Tundra
1.2 kW & 1.4 kW52 (5.9)
1.8 kW & 2.0 kW82 (9.3)
4Runner
1.4 kW52 (5.9)
1.8 kW82 (9.3)

TORQUE SPECIFICATIONS

Fig. 19: Starting System Wiring Diagram (Avalon)
Scheme 19: Starting System Wiring Diagram (Avalon)
Fig. 20: Starting System Wiring Diagram (Camry - 2.2L & 3.0L)
Scheme 20: Starting System Wiring Diagram (Camry - 2.2L & 3.0L)
Fig. 21: Starting System Wiring Diagram (Camry - 2.2L CNG)
Scheme 21: Starting System Wiring Diagram (Camry - 2.2L CNG)
Fig. 22: Starting System Wiring Diagram (Camry Solara)
Scheme 22: Starting System Wiring Diagram (Camry Solara)
Fig. 23: Starting System Wiring Diagram (Celica)
Scheme 23: Starting System Wiring Diagram (Celica)
Fig. 24: Starting System Wiring Diagram (Corolla)
Scheme 24: Starting System Wiring Diagram (Corolla)
Fig. 25: Starting System Wiring Diagram (ECHO)
Scheme 25: Starting System Wiring Diagram (ECHO)
Fig. 26: Starting System Wiring Diagram (Highlander)
Scheme 26: Starting System Wiring Diagram (Highlander)
Fig. 27: Starting System Wiring Diagram (Land Cruiser)
Scheme 27: Starting System Wiring Diagram (Land Cruiser)
Fig. 28: Starting System Wiring Diagram (Lexus LX470)
Scheme 28: Starting System Wiring Diagram (Lexus LX470)
Fig. 29: Starting System Wiring Diagram (MR2)
Scheme 29: Starting System Wiring Diagram (MR2)
Fig. 30: Starting System Wiring Diagram (RAV4)
Scheme 30: Starting System Wiring Diagram (RAV4)
Fig. 31: Starting System Wiring Diagram (Sequoia)
Scheme 31: Starting System Wiring Diagram (Sequoia)
Fig. 32: Starting System Wiring Diagram (Sienna)
Scheme 32: Starting System Wiring Diagram (Sienna)
Fig. 33: Starting System Wiring Diagram (Tacoma)
Scheme 33: Starting System Wiring Diagram (Tacoma)
Fig. 34: Starting System Wiring Diagram (Tundra)
Scheme 34: Starting System Wiring Diagram (Tundra)
Fig. 35: Starting System Wiring Diagram (4Runner)
Scheme 35: Starting System Wiring Diagram (4Runner)
