PRECAUTION

1. Check that the battery cables are connected to the correct terminals.
2. Disconnect the battery cables when the battery is given a quick charge.
3. Do not perform tests with a high voltage insulation resistance tester.
4. Never disconnect the battery while the engine is running.

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. Check Battery Electrolyte Level Check the electrolyte quantity of each cell. Maintenance-Free Battery: If under the lower level, replace the battery (or add distilled water if possible) and check the charging system. Except Maintenance-Free Battery: If under the lower level, add distilled water.
2. Except Maintenance-Free Battery: Check Battery Specific Gravity Check the specific gravity of each cell. Standard specific gravity: 1.25 - 1.29 at 20 °C (68 °F) If the specific gravity is less than specification, charge the battery.
3. Check Battery Voltage After having driven the vehicle and in the case that 20 minutes have not passed after having stopped the engine, turn the ignition switch ON and turn on the electrical system (headlight, blower motor, rear defogger etc.) for 60 seconds to remove the surface charge. Turn the ignition switch OFF and turn off the electrical systems. Measure the battery voltage between the negative (-) and positive (+) terminals of the battery. Standard voltage: 12.5 - 12.9 V at 20°C (68 °F) If the voltage is less than specification, charge the battery. NOTE: Check the indicator as shown in illustration.
4. Check Battery Terminals, Fusible Link And Fuses Check that the battery terminals are not loose or corroded. Check the fusible link, H-fuses and fuses for continuity.
5. Inspect Drive Belt Visually check the belt for excessive wear, frayed cords etc. If any defect has been found, replace the drive belt. NOTE: Cracks on the rib side of a belt are considered acceptable. If the belt has chunks missing from the ribs, it should be replaced. Using a belt tension gauge, measure the belt tension. Belt tension gauge: DENSO BTG-20 (95506-00020) Borroughs No. BT-33-73F Drive belt tension: New belt: 540 - 640 N (55 - 65 kgf) Used belt: 250 - 390 N (25 - 40 kgf) If the belt tension is not as specified, adjust it. NOTE: "New belt" refers to a belt which has been used less than 5 minutes on a running engine. "Used belt" refers to a belt which has been used on a running engine for 5 minutes or more. After installing a belt, check that it fits properly in the ribbed grooves. Check with your hand to confirm that the belt has not slipped out of the groove on the bottom of the pulley. After installing a new belt, run the engine for about 5 minutes and recheck the belt tension. Adjust drive belt tension. Loosen the 2 mount bolts. Insert a bar between the entine RH mount bracket and the generator, and pull it forward to make the adjustment. Torque the 2 bolts. Torque: 14 mm head 18 N.m (185 kgf.Cm, 14 ft.lbf) 17 mm head 54 N.m (550 kgf.Cm, 40 ft.lbf)
6. Visually Check Generator Wiring And Listen For Abnormal Noises Check that the wiring is in good condition. Check that there is no abnormal noise from the generator while the engine is running.
7. Inspect Discharge Warning Light Circuit Turn the ignition switch "ON". Check that the discharge warning light comes on. Start the engine. Check that the light goes off. If the light does not operate as specified, troubleshoot the discharge warning light circuit.
8. Inspect Charging Circuit Without Load NOTE: If a battery/generator tester is available, connect the tester to the charging circuit as premanufacturer's instructions. If a tester is not available, connect a voltmeter to the charging circuit as follows: Disconnect to the wire from terminal B of the generator and connect it to the negative (-) lead of the ammeter. Connect the positive (+) lead of the ammeter to terminal B of the generator. Connect the positive (+) lead of the voltmeter to terminal B of the generator. Ground the negative (-) lead of the voltmeter. Check the charging circuit as follows: With the engine running from idle to 2,000 rpm, check the reading on the ammeter and voltmeter. Standard amperage: 10A or less Standard voltage: 13.5 - 15.1 V If the voltmeter reading is more than standard voltage, replace the voltage regulator. If the voltmeter reading is less than the standard voltage, check the voltage regulator and generator as follows
9. Inspect Charging Circuit With Load With the engine running at 2,000 rpm, turn on the high beam headlights and place the heater blower switch at "H". Check the reading on the ammeter. Standard amperage: 30 A or more

If the ammeter reading is less than standard amperage, repair the generator.

Note. If the battery is fully charged, the indication will sometimes be less than standard amperage.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Disconnect the wire clamp from the wire clip on the rectifier end frame.
2. Remove the rubber cap and nut, and disconnect the generator wire.
3. Disconnect the generator connector.
4. Disconnect the harness clamp from the generator.
5. Loosen the 2 bolts and remove the drive belt.
6. Remove the 2 bolts and generator.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Remove Rear End Cover Remove the nut and terminal insulator. Remove the bolt, 3 nuts, plate terminal and end cover.
2. Remove Brush Holder And Voltage Regulator Remove the brush holder cover from the brush holder. Remove the 5 screws, brush holder and voltage regulator. Remove the seal plate from the rectifier end frame.
3. Remove Rectifier Holder Remove the 4 screws and rectifier holder. Remove the 4 rubber insulators.
4. Remove Pulley Hold SST (A) with a torque wrench, and tighten SST (B) clockwise to the specified torque. SST 09820-63011 Torque: 39 N.m (400 kgf.Cm, 29 ft.lbf) Check that SST (A) is secured to the rotor shaft. Mount SST (C) in a vise. Insert SST (B) into SST (C), and attach the pulley nut to SST (C). To loosen the pulley nut, turn SST (A) in the direction shown in the illustration. NOTE: To prevent damage to the rotor shaft, do not loosen the pulley nut more than one-half of a turn. Remove the generator from SST (C). Turn SST (B), and remove SST (A and B). Remove the pulley nut and pulley.
5. Remove Rectifier End Frame Remove the 4 nuts and wire clip. Using SST, remove the rectifier end frame. SST 09286-46011 Remove the generator washer from the rotor
6. Remove Rotor From Drive End Frame

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. Inspect Voltage Regulator Using an ohmmeter, check the continuity between terminals F and B. Standard: When the positive and negative poles between terminals F and B are exchanged, there is continuity in one way but no continuity in another way. If the continuity is not as specified, replace the voltage regulator. Using an ohmmeter, check the continuity between terminals F and E. Standard: When the positive and negative poles between terminals F and E are exchanged, there is continuity in one way but no continuity in another way. If the continuity is not as specified, replace the voltage regulator.
2. Inspect Rotor For Open Circuit Using an ohmmeter, check that there is continuity between the slip rings. Standard resistance: 2.7 - 3.1 Ohms at 20°C (68 °F) If there is no continuity, replace the rotor.
3. Inspect Rotor For Ground Using an ohmmeter, check that there is no continuity between the slip ring and rotor. If there is continuity, replace the rotor.
4. Inspect Slip Rings Check that the slip rings are not rough or scored. If rough or scored, replace the rotor. Using a vernier caliper, measure the slip ring diameter. Standard diameter: 14.2 - 14.4 mm (0.559 - 0.567 in.) Minimum diameter: 12.8 mm (0.504 in.) If the diameter is less than minimum, replace the rotor.
5. Inspect Stator (Drive End Frame) For Open Circuit Using an ohmmeter, check that there is continuity between the coil leads. If there is no continuity, replace the drive end frame assembly
6. Inspect Stator (Drive End Frame) For Ground Using an ohmmeter, check that there is no continuity between the coil lead and drive end frame. If there is continuity, replace the drive end frame assembly
7. Inspect Exposed Brush Length Using vernier calipers, measure the exposed brush length. Standard exposed length:E 9.5 ~ 11.5 mm (0.374 ~ 0.453 in.) Minimum exposed length: 1.5 mm (0.059 in.) If the exposed length is less than minimum, replace the brush holder assembly.
8. Inspect Positive Rectifier Holder Using an ohmmeter, connect one tester probe to the positive (+) terminal and the other to each rectifier terminal. Reverse the polarity of the tester probes and repeat step (a). Check that one shows continuity and the other shows no continuity. If continuity is not as specified, replace the rectifier holder.
9. Inspect Negative Rectifier Holder Using an ohmmeter, connect one tester probe to each negative (-) terminal and the other to each rectifier terminal. Reverse the polarity of the tester probes and repeat step (a). Check that one shows continuity and the other shows no continuity. If continuity is not as specified, replace the rectifier holder.
10. Inspect Front Bearing Check that the bearing is not rough or worn.
11. If Necessary, Replace Front Bearing Remove the 4 screws, bearing retainer and bearing. Using a socket wrench and press, press out the bearing. Using SST and a press, press in a new bearing. SST 09950-60010 (09951-00500) Install the bearing retainer with the 4 screws. Torque: 3.0 N.m (31 kgf.Cm, 27 in..lbf)
12. Inspect Rear Bearing Check that the bearing is not rough or worn.
13. If Necessary, Replace Rear Bearing Using SST, remove the bearing cover (outside) and bearing. SST 09820-00021 NOTE: Be careful not to damage the fan. Remove the bearing cover (inside). Place the bearing cover (inside) on the rotor. Using SST and a press, press in a new bearing. SST 09820-00031 Using SST, push in the bearing cover (outside). SST 09285-76010

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

1. Install Rotor To Drive End Frame Place the rectifier end frame on the pulley. install the rotor to the rectifier end frame.
2. Install Rectifier End Frame Place the generator washer on the rotor. Using a 29 mm socket wrench and press, slowly press in the rectifier end frame. Install the wire clip and 4 nuts. Torque: Nut A 4.5 N.m (46 kgf.Cm, 40 in..lbf) Nut B 5.4 N.m (55 kgf.Cm, 48 in..lbf)
3. Install Pulley Install the pulley to the rotor shaft by tightening the pulley nut by hand. Hold SST (A) with a torque wrench, and tighten SST (B) clockwise to the specified torque. SST 09820-63011 Torque: 39 N.m (400 kgf.Cm, 29 ft.lbf) Check that SST (A) is secured to the pulley shaft. Mount SST (C) in a vise. Insert SST (B) into SST (C), and attach the pulley nut to SST (C). To torque the pulley nut, turn SST (A) in the direction shown. Torque: 111 N.m (1,125 kgf.Cm, 81 ft.lbf) Remove the generator from SST (C). Turn SST (B), and remove SST (A and B).
4. Install Rectifier Holder Install the 4 rubber insulators on the lead wires. NOTE: Be careful of the rubber insulators installation direction. Install the rectifier holder while pushing it with the 4 screws Torque: 2.9 N.m (30 kgf.Cm, 26 in..lbf)
5. Install Voltage Regulator And Brush Holder Place the seal plate on the rectifier end frame. Place the voltage regulator and brush holder on the rectifier end frame. NOTE: Be careful of the holder installation direction. Install the 5 screws. Torque: 2.0 N.m (20 kgf.Cm 18 in..lbf) Place the brush holder cover on the brush holder.
6. Install Rear End Cover Install the end cover and plate terminal with the bolt and 3 nuts. Torque: Nut 4.4 N.m (45 kgf.Cm, 39 in..lbf) Bolt 3.9 N.m (39 kgf.Cm, 35 in..lbf) Install the terminal insulator with the nut. Torque: 4.1 N.m (42 kgf.Cm, 36 in..lbf)
7. Check That Rotor Rotates Smoothly

Scheme 58

1. Install the generator and temporally tighten the 2 bolts.
2. Install the drive belt and adjust the belt tension. See 5 under ON-VEHICLE INSPECTION.
3. Tighen the 2 bolts. Torque: 14 mm head 18 N.m (185 kgf.Cm, 14 ft.lbf) 17 mm head 54 N.m (550 kgf.Cm, 40 ft.lbf)
4. Connect the generator connector.
5. Connect the harness clamp.
6. Connect the generator wire, and install the nut and rubber cap.
7. Connect the generator wire, and install the rubber cap and nut.
