Maintenance Reminder Light Reset Procedures: Maintenance Toyota Corolla XI

ENGINE OIL CHANGE REMINDER LIGHT RESET - PROCEDURE 1

Note. For all models, before starting reset procedure, switch the display to Trip Meter A while the engine is running.

ENGINE OIL CHANGE REMINDER LIGHT RESET - PROCEDURE 2

Note. For all models, before starting reset procedure, switch the display to Trip Meter A while ignition is ON.

To reset MAINT reminder indicator after engine oil change

1. Set the "ENGINE START STOP" switch or ignition switch OFF with odometer showing TRIP A.
2. While pressing the trip meter reset button (stem), set the "ENGINE START STOP" switch or ignition switch ON.
3. Without multi-information display: Continue to press and hold the button (stem) until the trip meter displays "000000". With multi-information display: Continue to press and hold the button (stem) until "COMPLETE" (on some models, "RESETTING MAINTENANCE DATA") appears on the multi-information display.

ENGINE OIL CHANGE REMINDER LIGHT RESET - PROCEDURE 3

To reset MAINT reminder indicator after engine oil change

1. With ignition or POWER switch ON, press the ODO / TRIP switch until odometer displays "ODO".
2. Turn ignition or POWER switch to OFF position with odometer display showing.
3. Turn ignition POWER switch to ON position while holding down trip meter RESET button.
4. Hold trip meter RESET button down for at least 5 seconds. Odometer should indicate "000000", and MAINT reminder light goes out. NOTE: On some models, before the light goes off, light will illuminate for 3 seconds, flash for 2 seconds and illuminate for 1 second.
5. If system fails to reset, light will remain flashing.

ENGINE OIL CHANGE REMINDER LIGHT RESET - PROCEDURE 4

To reset MAINT reminder indicator after engine oil change

1. With the ignition switch (or Power switch) ON, ensure the odometer is showing TRIP A. Turn ignition (or Power) switch OFF.
2. Set the ignition switch (or Power switch) to ON position (DO NOT start engine) while holding down trip meter RESET (DISP on some models) button.
3. Hold trip meter RESET button down for at least 5 seconds until odometer indicates 000000.
4. When 000000 disappears and the indicator light turns off, the reset is complete.

ENGINE OIL CHANGE REMINDER LIGHT RESET - PROCEDURE 5

To reset MAINT reminder indicator after engine oil change

1. Turn ignition key to LOCK position with odometer display showing.
2. Turn ignition key to ON position while holding down on trip meter reset knob. A message MAINT REQD RESET MODE will appear on display.
3. Hold trip meter knob for at least 5 seconds. A message COMPLETE will appear and beep will be heard.
4. If system fails to reset, repeat reset procedure.

ENGINE OIL CHANGE REMINDER LIGHT RESET - PROCEDURE 6

To reset MAINT reminder indicator after engine oil change

1. Turn ignition switch to OFF position with odometer display showing.
2. Turn ignition switch to ON position while holding down ODO/TRIP reset button on instrument cluster.
3. Hold down reset button until MAINT REQD light goes off. Before MAINT REQD light goes off, it will illuminate for 3 seconds, flash for 2 seconds, illuminate again for one second.
4. If system fails to reset, MAINT REQD light will remain flashing.

ENGINE OIL CHANGE REMINDER LIGHT RESET - PROCEDURE 7

After changing oil and filter, reset warning light mileage counter.

Note. Reset mileage counter after oil and filter change even if light has not come on.

1. Remove plug from instrument panel faceplate below speedometer.
2. Insert a small punch or rod through plug hole and depress knob. (Scheme 1)

Scheme 1

ENGINE OIL CHANGE REMINDER LIGHT RESET - PROCEDURE 8

To reset MAINT reminder indicator after engine oil change

1. Turn off the hybrid system with odometer showing TRIP A.
2. While holding down the trip meter reset knob, turn the POWER switch to ON mode. A message "MAINT REQD RESET MODE" will appear on the display.
3. Hold down the knob for at least 5 seconds. When "MAINT REQD RESET MODE COMPLETE" disappears and the master caution indicator light turns off, the reset is complete.

ENGINE OIL CHANGE REMINDER LIGHT RESET - PROCEDURE 9

To reset MAINT reminder indicator after engine oil change

1. Switch the odometer display to TRIP A with the POWER switch ON.
2. Turn the POWER switch OFF.
3. Turn the POWER switch ON with the km/h MPH button (upper left on center console) held down.
4. Keep pressing the km/h MPH button until the odometer indicates 000000 and the multi-information display indicates that the reset is complete.

ENGINE OIL CHANGE REMINDER LIGHT RESET - PROCEDURE 10

To reset MAINT reminder indicator after engine oil change

1. Switch the odometer display to TRIP A while the engine is running.
2. Set the "ENGINE START STOP" (or ignition) switch to OFF.
3. While pressing the trip meter reset button, set the "ENGINE START STOP" (or ignition) switch to ON mode (DO NOT start the engine). Continue to press and hold the button until the odometer displays 000000, or the multi-information display indicates that the reset is complete. NOTE: For Tacoma models, there is a significant difference between the reset procedure in the owner's manual (used above) and the instructions given in the Toyota service information. The owner's manual is considered to be more reliable for this type procedure, but in the event that the service information is correct, it is this: Turn the ignition switch to ON. Set the ODO/TRIP indication to ODO. While pressing the reset switch, turn the ignition switch OFF and ON again. Press the reset switch for more than 5 seconds.

Note. If the system fails to reset, the warning light will continue flashing.

ENGINE OIL CHANGE REMINDER LIGHT RESET - PROCEDURE 11

To reset MAINT reminder indicator after engine oil change

1. With the Engine switch (or Power switch) ON, ensure the odometer is displayed. Turn Engine (or Power) switch OFF.
2. Turn the Engine (or Power) switch to the ON position. The multi-information display's initial screen will be displayed for a few seconds. While the initial screen is being displayed, press the TRIP button on the steering wheel 3 times, holding the button down on the third press.
3. Continue to press and hold the button until the trip meter displays 000000.

OXYGEN SENSOR WARNING LIGHT RESET - PROCEDURE 1

1. At 30,000 mile intervals, a mileage counter activates warning light in dash to indicate oxygen sensor must be replaced. After replacing sensor, reset mileage counter.
2. To reset mileage counter, move switch to opposite position. On 1980 Celica Supra, cancel switch (Black) is located on bracket above brake pedal. On Cressida, switch is behind small trim panel next to steering column. On all other models, cancel switch (White) is on top of left kick panel. (Scheme 2)

Scheme 2

TIMING BELT REMINDER LIGHT RESET - PROCEDURE 1

TIMING BELT light will come on every 100,000 miles to indicate engine timing belt should be replaced. After belt is replaced, remove rubber grommet from speedometer bezel and reset speedometer counter by pressing reset switch. (Scheme 3)

Scheme 3

TPMS RESET - PROCEDURE 1

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. The system will need to be initialized when tires are replaced with tires of different pressures; tire pressure sensor and/or tire pressure monitor ECU are replaced. Set tire pressure within the specified range before initializing. When a tire pressure sensor and/or tire pressure monitor ECU are replaced, the sensor ID must be memorized by the tire pressure monitor ECU prior to system initialization. See Tire Pressure Sensor Registration .

TPMS RESET - PROCEDURE 2

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. This system requires initializing after changing tires or wheels, after rotating the tires, or when tire pressure warning light blinks twice every second. Set tire pressure within the specified range before initializing. If the tire air pressure is not within the specified range, tire pressure warning system will not function.

Note. If the negative battery terminal is disconnected, initialize the following systems after the terminal is reconnected: power window and sliding roof. Refer to owner's manual or appropriate manufacturer service information.

1. Set the tire pressure of all wheels to pressure specified on the tire and loading information label.
2. With vehicle stopped and parking brake applied, turn ignition switch to ON position.
3. Press and hold the tire pressure warning reset switch until the tire pressure warning light blinks 3 times at one-second intervals. NOTE: If the tire pressure warning light does not blink, turn ignition switch to OFF position and perform the initialization procedure again starting at step 2 . If light still does not blink, there is a problem in the TPM system. See appropriate manufacturer service information.
4. Drive the vehicle at 19 mph (30 km/h) or more to complete the initialization of the skid control ECU (it takes 0.5-1 hour). Vehicle should be driven under the following conditions: The vehicle speed is between 31-62 mph (50-100 km/h). The roads are dry, smooth and straight. The number of passengers is 1 or 2 (including driver). NOTE: If the tire pressure warning light blinks at 0.25 second intervals while the vehicle is being driven, the initialization may have failed. If so, turn ignition switch to OFF position and perform the initialization procedure again starting at step 1 .
5. After initialization is completed, the skid control ECU monitors the tire pressure by using the wheel speed sensors.
6. To verify the system has been initialized, check the length of time the tire pressure warning light is on after turning the ignition switch to the ON position. Light will stay on for 3 seconds if system is initialized, or 4 seconds if system is not initialized.

TPMS RESET - PROCEDURE 3

Note. Initialization is required when changing tire size, rotating tire on vehicle with different front and rear tire inflation pressures.

1. Park vehicle in a safe place and turn ignition key to LOCK position.
2. Adjust the pressure of all installed tires to specified cold tire inflation pressure level.
3. Turn ignition to ON position.
4. Push and hold tire pressure warning reset switch (located below left side of dash) until the tire pressure warning light blinks slowly 3 times.
5. Leave system for a few minutes with ignition switch in ON position, and then turn ignition key to LOCK position.

If the tire warning reset switch is pushed while vehicle is moving, initialization will not take place. If reset switch is accidentally pushed, and initialization takes place, adjust tire inflation pressure to the specified level and initialize the system again.

If tire pressure warning light does not blink slowly 3 times when you push and hold the reset switch, initialization has failed and tire pressure warning system may not work properly. In this case, initialize the system again. If initialization cannot be performed, have the system checked at an authorized dealer.

TPMS RESET - PROCEDURE 4

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. This system requires initializing after changing tires or wheels, after rotating the tires, or when tire pressure warning light blinks once every 3 seconds. Set tire pressure within the specified range before initializing. If the tire air pressure is not within the specified range, tire pressure warning system will not function.

1. Set the tire pressure of all wheels to pressure specified on the tire and loading information label.
2. With vehicle stopped and parking brake applied, turn ignition switch to ON position.
3. Press and hold the tire pressure warning reset switch until the tire pressure warning light blinks 3 times at one-second intervals. (Scheme 4) NOTE: If the tire pressure warning light does not blink, turn ignition switch to OFF position and perform the initialization procedure again starting at step 2. If light still does not blink, there is a problem in the TPM system. See appropriate manufacturer service information.
4. Drive the vehicle at 19 mph (30 km/h) or more to complete the initialization of the skid control ECU (it takes more than one hour). (Scheme 5) Vehicle should be driven under the following conditions: The vehicle speed is between 31-62 mph (50-100 km/h). The roads are dry, smooth and straight. The number of passengers is 1 or 2 (including driver). NOTE: If the tire pressure warning light repeats a cycle of ON (0.5 second) and OFF (2.5 seconds) while the vehicle is being driven, initialization may have failed. If so, turn ignition switch to OFF position and perform the initialization procedure again starting at step 1.
5. After initialization is completed, the skid control ECU monitors the tire pressure by using the wheel speed sensors.
6. To verify the system has been initialized, check the length of time the tire pressure warning light is on after turning the ignition switch to the ON position. Light will stay on for 3 seconds if system is initialized, or 4 seconds if system is not initialized.

Scheme 4

Scheme 5

TPMS RESET - PROCEDURE 5

Note. Reset is NOT required if re-inflating tires to the currently specified tire pressure.

Note. It is necessary to register the transmitter ID in the tire pressure warning ECU when replacing the tire pressure warning valve, transmitter and/or tire pressure warning ECU. The transmitter ID is written on the tire pressure warning valve and transmitter. You will not be able to read the ID numbers after installing the tire pressure warning valve and transmitter on the tire and wheel. Take a note of the 7 digit number (transmitter ID) before starting registration.

When the tire pressure warning light does not go off, or when it comes on during driving, check tire pressure (including spare tire) and adjust as necessary. The warning light should go out within a few minutes.

Register Transmitter ID

1. Set the pressure of all tires (including spare tire) to the pressure specified on the tire and loading information label.
2. Turn ignition switch OFF.
3. Connect a Techstream to the DLC3.
4. Turn ignition switch ON.
5. Turn Techstream ON.
6. Enter the following menus: Chassis / Tire Pressure Monitor / Utility / ID Registration.
7. Follow the procedures displayed on the screen.
8. Confirm the ID numbers for all tires (including the spare tire) are displayed on the screen.

Note. It may take up to 2 or 3 minutes to update the tire pressure data. If the values are not displayed after a few minutes, see the appropriate manufacturer service information. If the IDs have not been registered, DTC C2171/71 is set in the tire pressure warning ECU after 3 minutes or more. If normal pressure values are displayed, the IDs have been registered correctly. If the tire pressure values are not displayed after a few minutes, the IDs may be incorrect or the system may have a malfunction. After all IDs are registered, DTC C2126/26 (Transmitter ID not Received in Main Mode) is set in the tire pressure warning ECU and the tire pressure warning light blinks for 1 minute and then stays on. When the tire pressure warning ECU successfully receives radio waves from all the transmitters whose IDs are stored in the ECU, DTC C2126/26 is deleted and the tire pressure warning light goes off.

Confirmation Of Transmitter ID Registration

1. Set the pressure of all tires (including spare tire) to the pressure specified on the tire and loading information label.
2. Connect a Techstream to the DLC3.
3. Turn ignition switch ON.
4. Turn Techstream ON.
5. Enter the following menus: Chassis / Tire Pressure Monitor / Data List.
6. Observe the "ID Tire Inflation Pressure" values.
7. Confirm the ID numbers for all tires (including the spare tire) are displayed on the screen. If all values are displayed correctly, registration was completed successfully.

TPMS RESET - PROCEDURE 6

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. This system requires initializing after changing tires or wheels, after rotating the tires, or when tire pressure warning light blinks twice every second. Set tire pressure within the specified range before initializing. If the tire air pressure is not within the specified range, tire pressure warning system will not function.

Note. If the negative battery terminal is disconnected, initialize the following system after the terminal is reconnected: Moon Roof. Refer to owner's manual or appropriate manufacturer service information.

1. Set the tire pressure of all wheels to pressure specified on the tire and loading information label.
2. With vehicle stopped and parking brake applied, turn ignition switch to ON position.
3. Press and hold the tire pressure warning reset switch until the tire pressure warning light blinks 3 times at one-second intervals. NOTE: If the tire pressure warning light does not blink, turn ignition switch to OFF position and perform the initialization procedure again starting at step 2 . If light still does not blink, there is a problem in the TPM system. See appropriate manufacturer service information.
4. Drive the vehicle at 19 MPH (30 KM/H) or more to complete the initialization of the skid control ECU (it takes more than one hour.) Vehicle should be driven under the following conditions: The vehicle speed is between 31-62 MPH (50-100 KM/H). The roads are dry, smooth and straight. The number of passengers is 1 or 2 (including driver). NOTE: If the tire pressure warning light blinks at 0.25-second intervals while the vehicle is being driven, the initialization may have failed. If so, turn ignition switch to OFF position and perform the initialization procedure again starting at step 1 .
5. After initialization is completed, the skid control ECU monitors the tire pressure by using the wheel speed sensors.
6. To verify the system has been initialized, check the length of time the tire pressure warning light is on after turning the ignition switch to the ON position. Light will stay on for 3 seconds if system is initialized, or 4 seconds if system is not initialized.

TPMS RESET - PROCEDURE 7

Note. For Sequoia, this procedure applies to vehicles from 2005 up to August 2007. For Sequoia models from September 2007, see TPMS RESET - PROCEDURE 17 .

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. The system will need to be initialized when tires are rotated; tires are replaced with tires of different pressures; tire pressure sensor and/or tire pressure monitor ECU are replaced. Set tire pressure within the specified range before initializing. If tire pressure sensor and/or tire pressure monitor ECU were replaced, ensure that tire pressure sensor IDs are registered prior to initialization. Refer to owner's manual or appropriate manufacturer service information.

Note. When initializing the system, the present tire condition is stored as a standard.

During initialization, the tire pressure monitor valve sub-assembly measures the inflation pressure of the tires, and registers the signals that are transmitted into the tire pressure monitor ECU at a frequency of one per minute. The initialization process is completed when the signals from the 5 tires have been received.

The initialization process is canceled if the ignition switch is turned to OFF position during initialization. To initialize again, the tire pressure warning reset switch must be pressed again. For this reason, once the tire pressure warning reset switch has been pressed, turning ignition switch to OFF position is not recommended for a minimum of 20 minutes.

1. Set the tire pressure of all wheels (including spare tire) to pressure specified on the tire and loading information label.
2. With the vehicle stopped and parking brake applied, turn the ignition switch to the ON position.
3. Press and hold the tire pressure warning reset switch until the tire pressure warning light blinks 3 times at one-second intervals. (Scheme 6) NOTE: Do not turn the ignition switch to OFF position during initialization (the initialization process takes about 20 minutes). Initialization will be complete if signals are received from all the wheels including the spare. Initialization will be canceled if the ignition switch is turned to OFF position during initialization.
4. Confirm that initialization is complete using the intelligent tester. Check that the pressure for each tire is displayed in INIT THRESHOLD 1 to 5.

Scheme 6

TPMS RESET - PROCEDURE 8

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. This system requires initializing after changing tires or wheels, after rotating the tires, or if warning light blinks once every 3 seconds. Set tire pressure within the specified range before initializing. If the tire air pressure is not within the specified range, tire pressure warning system will not function.

1. Set the tire pressure of all wheels to pressure specified on the tire and loading information label.
2. With vehicle stopped and parking brake applied, turn ignition switch to ON position.
3. Press and hold the tire pressure warning reset switch until the tire pressure warning light blinks 3 times at one-second intervals. (Scheme 7) NOTE: If the tire pressure warning light does not blink, turn ignition switch to OFF position and perform the initialization procedure again starting at step 2. If light still does not blink, there is a problem in the TPM system. See appropriate manufacturer service information.
4. Drive the vehicle at 19 mph (30 km/h) or more to complete the initialization of the skid control ECU (it takes more than one hour). Vehicle should be driven under the following conditions: The vehicle speed is between 31-62 mph (50-100 km/h). The roads are dry, smooth and straight. The number of passengers is 1 or 2 (including driver). NOTE: If the tire pressure warning light repeats a cycle of ON (0.5 second) and OFF (2.5 seconds) while the vehicle is being driven, initialization may have failed. If so, turn ignition switch to OFF position and perform the initialization procedure again starting at step 1.
5. After initialization is completed, the skid control ECU monitors the tire pressure by using the wheel speed sensors.
6. To verify the system has been initialized, check the length of time the tire pressure warning light is on after turning the ignition switch to the ON position. Light will stay on for 3 seconds if system is initialized, or 4 seconds if system is not initialized.

Scheme 7

TPMS RESET - PROCEDURE 9

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. The system will need to be initialized when tires are replaced with tires of different pressures; tire pressure sensor and/or tire pressure monitor ECU are replaced; or when a new vehicle is delivered. Set tire pressure within the specified range before initializing. When a tire pressure sensor and/or tire pressure monitor ECU are replaced, the sensor ID must be memorized by the tire pressure monitor ECU prior to system initialization. See Tire Pressure Sensor Registration .

TPMS RESET - PROCEDURE 10

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. This system requires initializing after changing tires or wheels, after rotating the tires, or when tire pressure warning light blinks twice every second. Set tire pressure within the specified range before initializing. If the tire air pressure is not within the specified range, tire pressure warning system will not function.

1. Set the tire pressure of all wheels to pressure specified on the tire and loading information label.
2. With vehicle stopped and parking brake applied, turn ignition switch to ON position.
3. Press and hold the tire pressure warning reset switch until the tire pressure warning light blinks 3 times at one-second intervals. NOTE: If the tire pressure warning light does not blink, turn ignition switch to OFF position. Perform the initialization procedure again starting at step 2 . If light still does not blink, there is a problem in the TPM system. See appropriate manufacturer service information.
4. Drive the vehicle at 19 mph (30 km/h) or more to complete the initialization of the ABS/skid control ECU (it takes more than one hour). Vehicle should be driven under the following conditions: The vehicle speed is between 31-62 mph (50-100 km/h). The roads are dry, smooth and straight. The number of passengers is 1 or 2 (including driver). NOTE: If the tire pressure warning light blinks at 0.25 second intervals while the vehicle is being driven, the initialization may have failed. If so, turn ignition switch to OFF position. Perform the initialization procedure again starting at step 1 .
5. After initialization is completed, the ABS/skid control ECU monitors the tire pressure by using the wheel speed sensors.
6. To verify the system has been initialized, check the length of time the tire pressure warning light is on after turning the ignition switch to the ON position. Light will stay on for 3 seconds if system is initialized, or 4 seconds if system is not initialized.

TPMS RESET - PROCEDURE 11

Note. Reset is NOT required if re-inflating tires to the currently specified tire pressure.

Note. When a tire pressure sensor and/or tire pressure monitor ECU are replaced, the sensor ID must be memorized by the tire pressure monitor ECU. See Tire Pressure Sensor Registration .

TPMS RESET - PROCEDURE 12

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. This system requires initializing after changing tires or wheels, after rotating the tires, or when tire pressure warning light blinks twice every second. Set tire pressure within the specified range before initializing. If the tire air pressure is not within the specified range, tire pressure warning system will not function. See appropriate manufacturer service information.

Note. If the negative battery terminal is disconnected, initialize the following systems after the terminal is reconnected: power window, power sliding door, power back door and moon roof. Refer to owner's manual or appropriate manufacturer service information.

1. Set the tire pressure of all wheels to pressure specified on the tire and loading information label.
2. With the vehicle stopped and parking brake applied, turn the ignition switch to the ON position.
3. Press and hold the tire pressure warning reset switch until the tire pressure warning light blinks 3 times at one-second intervals (continue pressing the switch for about 3-4 seconds). see scheme 16 NOTE: If the tire pressure warning light does not blink, turn ignition switch to OFF position and perform the initialization procedure again starting at step 2. If light still does not blink, there is a problem in the TPM system. See appropriate manufacturer service information.
4. On 2004-06 models, drive the vehicle at 19 MPH (30 KM/H) or more to initialize the skid control ECU. This may take 30-60 minutes.

Scheme 8

TPMS RESET - PROCEDURE 13

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. The system will need to be initialized when tires are replaced with tires of different pressures; tire pressure sensor and/or tire pressure monitor ECU are replaced; or when a new vehicle is delivered. Set tire pressure within the specified range before initializing. When a tire pressure sensor and/or tire pressure monitor ECU are replaced, the sensor ID must be memorized by the tire pressure monitor ECU prior to system initialization. See Tire Pressure Sensor Registration .

TPMS RESET - PROCEDURE 14

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. The system will need to be initialized when tires are replaced with tires of different pressures; tire pressure sensor and/or tire pressure monitor ECU are replaced; or when a new vehicle is delivered. Set tire pressure within the specified range before initializing. If tire pressure sensor and/or tire pressure monitor ECU were replaced, ensure that tire pressure sensor IDs are registered prior to initialization. See Tire Pressure Sensor Registration .

TPMS RESET - PROCEDURE 15

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. The system will need to be initialized when tires are rotated; tires are replaced with tires of different pressures; tire pressure sensor and/or tire pressure monitor ECU are replaced. Set tire pressure within the specified range before initializing. See Initializing Tire Pressure Monitor System . When a tire pressure sensor and/or tire pressure monitor ECU are replaced, the sensor ID must be memorized by the tire pressure monitor ECU prior to system initialization. See Tire Pressure Sensor Registration .

TPMS RESET - PROCEDURE 16

Note. Reset is NOT required if re-inflating tires to the currently specified tire pressure.

Note. When a tire pressure sensor and/or tire pressure monitor ECU are replaced, the sensor ID must be memorized by the tire pressure monitor ECU. See Tire Pressure Sensor Registration .

Note. If the negative battery terminal is disconnected, initialize the following system after the terminal is reconnected: Power Window Control System. Refer to owner's manual or appropriate manufacturer service information.

TPMS RESET - PROCEDURE 17

Note. For Sequoia, this procedure applies to vehicles from September 2007 and later. For Sequoia models from 2005 up to August 2007, see TPMS RESET - PROCEDURE 7 .

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

The system will need to be initialized when tires are rotated; tires are inflated to a specification different from currently logged pressures; tire pressure sensor and/or tire pressure monitor ECU are replaced. See Initialization . When a tire pressure sensor and/or tire pressure monitor ECU are replaced, the sensor IDs must be memorized by the tire pressure monitor ECU prior to system initialization. See Registration .
