DESCRIPTION
This DTC is output when there is an open, short or ECU communication malfunction between the main body ECU (instrument panel junction block) and certification ECU (smart key ECU assembly).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2287 | There is an open, short or ECU communication malfunction between the main body ECU (instrument panel junction block) and certification ECU (smart key ECU assembly). | Certification ECU (smart key ECU assembly) Main body ECU (instrument panel junction block) Wire harness or connector |
Scheme 173
The certification ECU (smart key ECU assembly) monitors communication between all the ECUs connected to the certification ECU system LIN bus lines. When the certification ECU (smart key ECU assembly) detects an error in communication with all the ECUs connected to the certification ECU system LIN bus lines at a set interval and 3 times in a row, DTC B2785 will be output.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2785 | Error in LIN communication between ECUs and an open or short in communication lines LIN communication from the certification ECU (smart key ECU assembly) stops for a set amount of time or more | Certification ECU (smart key ECU assembly) Main body ECU (instrument panel junction block) Steering lock ECU (steering lock actuator assembly) ID code box (immobilizer code ECU) Wire harness or connector |
Scheme 174
This DTC is output when LIN communication between the certification ECU (smart key ECU assembly) and the steering lock ECU (steering lock actuator assembly) stops for more than 10 seconds.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2786 | No communication between the steering lock ECU (steering lock actuator assembly) and the certification ECU (smart key ECU assembly) for more than 10 seconds | Steering lock ECU (steering lock actuator assembly) Certification ECU (smart key ECU assembly) Wire harness or connector |
Scheme 175
This DTC is output when LIN communication between the certification ECU (smart key ECU assembly) and the ID code box (immobilizer code ECU) stops for more than 10 seconds.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2789 | No communication between the certification ECU (smart key ECU assembly) and the ID code box (immobilizer code ECU) for more than 10 seconds | ID code box (immobilizer code ECU) Certification ECU (smart key ECU assembly) Wire harness or connector |
