REPLACEMENT Toyota Corolla X

M/t - E351: Removal & Installation 26 illustrations ~1403 words

REPLACEMENT

  1. REMOVE ENGINE UNDER COVER LH
  2. DRAIN MANUAL TRANSAXLE OIL Remove the filler plug and the gasket. Remove the drain plug and gasket, and then drain the manual transaxle oil.
  3. ADD MANUAL TRANSAXLE OIL Install a new gasket and the drain plug. Torque: 49 N*m (499 kgf*cm, 36 ft.*lbf) Add manual transaxle oil. Install the transmission filler plug and a new gasket. Torque: 49 N*m (499 kgf*cm, 36 ft.*lbf)
  4. INSPECT MANUAL TRANSAXLE OIL (See «ON-VEHICLE INSPECTION»(ref-338657-S06432507012009082800000) )
  5. INSTALL ENGINE UNDER COVER LH

Scheme 292

Scheme 292: COMPONENTS
Scheme 292: COMPONENTS

Scheme 293

Scheme 293
Scheme 293

Scheme 294

Scheme 294: REPLACEMENT
Scheme 294: REPLACEMENT

Scheme 295

Scheme 295
Scheme 295

Scheme 296

Scheme 296
Scheme 296
  1. REMOVE ENGINE UNDER COVER LH
  2. REMOVE ENGINE UNDER COVER RH
  3. DRAIN MANUAL TRANSAXLE OIL (See «ON-VEHICLE INSPECTION»(ref-338657-S06432507012009082800000) )
  4. REMOVE FRONT DRIVE SHAFT ASSEMBLY See «REMOVAL»(ref-338643-S22198975202009082800000) .
  5. REMOVE TRANSAXLE CASE OIL SEAL Using SST, remove the transaxle case oil seal. SST 09308-00010
  6. REMOVE TRANSMISSION CASE OIL SEAL Using SST, remove the transmission case oil seal. SST 09308-00010
  7. INSTALL TRANSAXLE CASE OIL SEAL Coat the lip of a new oil seal with MP grease. Using SST and a hammer, tap in the oil seal. SST 09608-10010, 09950-70010 (09951-07200) Standard depth: -0.5 to 0.5 mm (-0.0197 to 0.0197 in.) NOTE: Do not damage the oil seal lip.
  8. INSTALL TRANSMISSION CASE OIL SEAL Coat the lip of a new oil seal with MP grease. Using SST and a hammer, tap in the oil seal. SST 09608-32010, 09950-70010 (09951-07200) Standard depth: 3.0 to 4.0 mm (0.118 to 0.158 in.) NOTE: Do not damage the oil seal lip.
  9. INSTALL FRONT DRIVE SHAFT ASSEMBLY See «INSTALLATION»(ref-338643-S36895472672009082800000) .
  10. ADD MANUAL TRANSAXLE OIL (See «ON-VEHICLE INSPECTION»(ref-338657-S06432507012009082800000) )
  11. INSPECT MANUAL TRANSAXLE OIL (See «ON-VEHICLE INSPECTION»(ref-338657-S06432507012009082800000) )
  12. INSTALL ENGINE UNDER COVER LH
  13. INSTALL ENGINE UNDER COVER RH

Scheme 297

Scheme 297: COMPONENTS
Scheme 297: COMPONENTS

Scheme 298

Scheme 298
Scheme 298

Scheme 299

Scheme 299
Scheme 299

Scheme 300

Scheme 300
Scheme 300

Scheme 301

Scheme 301: REMOVAL
Scheme 301: REMOVAL

Scheme 302

Scheme 302
Scheme 302

Scheme 303

Scheme 303
Scheme 303

Scheme 304

Scheme 304
Scheme 304

Scheme 305

Scheme 305
Scheme 305

Scheme 306

Scheme 306
Scheme 306
  1. REMOVE NO. 1 ENGINE COVER SUB-ASSEMBLY (See «REMOVAL»(ref-338620-S39098940172009082800000) )
  2. REMOVE AIR CLEANER CAP SUB-ASSEMBLY (See «ON-VEHICLE INSPECTION»(ref-338624-S39393565442009082800000) )
  3. REMOVE AIR CLEANER CASE (See «REMOVAL»(ref-338620-S39098940172009082800000) )
  4. REMOVE CENTER EXHAUST PIPE ASSEMBLY (See «REMOVAL»(ref-338633-S18972650082009082800000) )
  5. REMOVE FRONT NO. 1 FLOOR HEAT INSULATOR Remove the 3 nuts and remove the No. 1 front floor heat insulator.
  6. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL LH (See «REMOVAL»(ref-338655-S34170282182009082800000) )
  7. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL RH (See «REMOVAL»(ref-338655-S34170282182009082800000) )
  8. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (See «REMOVAL»(ref-338655-S17441726102009082800000) )
  9. REMOVE CENTER NO. 1 INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (See «REMOVAL»(ref-338655-S17441726102009082800000) )
  10. REMOVE INSTRUMENT PANEL BOX ASSEMBLY (See «REMOVAL»(ref-338655-S17441726102009082800000) )
  11. REMOVE FRONT NO. 1 CONSOLE BOX INSERT (See «REMOVAL»(ref-338655-S17441726102009082800000) )
  12. REMOVE FRONT NO. 2 CONSOLE BOX INSERT (See «REMOVAL»(ref-338655-S17441726102009082800000) )
  13. REMOVE UPPER CONSOLE PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-338655-S07872330862009082800000) )
  14. REMOVE CONSOLE BOX CARPET (See «REMOVAL»(ref-338655-S07872330862009082800000) )
  15. REMOVE CONSOLE BOX ASSEMBLY (See «REMOVAL»(ref-338655-S07872330862009082800000) )
  16. REMOVE TRANSMISSION CONTROL CABLE ASSEMBLY Disconnect the control shift cable from the shift lever assembly. Remove the clip and disconnect the control select cable from the shift lever assembly. Using a screwdriver, pull out the transmission control cable stopper. NOTE: Do not remove the stopper. If it is removed, reinstall it to its original position. Rotate the nut counterclockwise approximately 180° and, while holding the nut in that position, disconnect the transmission control cable from the shift lever retainer. NOTE: Do not rotate the nut excessively as it may damage the internal spring and the transmission control cable will not be reusable. Remove the 2 clips and disconnect the 2 transmission control cables from the transaxle. Remove the 2 clips and disconnect the 2 transmission control cables from the control cable bracket. Remove the nut and transmission control cable assembly. Remove the 2 nuts and transmission control cable assembly.

Scheme 307

Scheme 307: ADJUSTMENT
Scheme 307: ADJUSTMENT

Scheme 308

Scheme 308
Scheme 308

Scheme 309

Scheme 309
Scheme 309

Scheme 310

Scheme 310
Scheme 310
  1. ADJUST TRANSMISSION CONTROL SELECT CABLE Remove the console box assembly (See «REMOVAL»(ref-338655-S07872330862009082800000) ). Remove the clip and disconnect the control select cable from the shift lever assembly. Push the two claws together at the top of the transmission control cable lock piece. While holding the two claws together, push the two lugs on the bottom of the lock piece toward each other and upward to pull out the lock piece. Install the transmission control shift cable to the shift lever assembly. Install the control select cable to the shift lever assembly. NOTE: Make sure to adjust the length at the neutral shift position. Make sure that the lock piece is protruding from the adjuster case. Install the clip to the shift lever assembly. Press in and lock the lock piece to the adjuster case. NOTE: Securely press in the lock piece until the lock engages.

Scheme 311

Scheme 311
Scheme 311

Scheme 312

Scheme 312
Scheme 312

Scheme 313

Scheme 313
Scheme 313
  1. INSTALL TRANSMISSION CONTROL CABLE ASSEMBLY Install the transmission control cable assembly with the 2 nuts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) Install the transmission control cable assembly with the nut. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) Install the 2 transmission control cables to the control cable bracket with 2 new clips*1. Install the 2 transmission control cables to the transaxle with the 2 clips. Rotate the transmission control cable nut counterclockwise approximately 180° and, while holding the nut in that position, press in the stopper until it makes 2 "click" sounds. Install the outer part of the transmission control cable to the shift lever retainer, check that the position of the spring is the same as A shown in the illustration, and push in the stopper. HINT: If the stopper cannot be pushed in, slightly rotate the nut clockwise and then push in the stopper. Push the two claws together at the top of the transmission control cable lock piece. While holding the two claws together, push the two lugs on the bottom of the lock piece toward each other and upward to pull out the lock piece. Install the transmission control shift cable to the shift lever assembly. Install the control select cable to the shift lever assembly. NOTE: Make sure to adjust the length at the neutral shift position. Make sure that the lock piece is protruding from the adjuster case. Install the clip to the shift lever assembly. Press in and lock the lock piece to the adjuster case. NOTE: Securely press in the lock piece until the lock engages.
  2. ADJUST TRANSMISSION CONTROL SELECT CABLE (See «ADJUSTMENT»(ref-338657-S17279797842009082800000) )
  3. INSTALL CONSOLE BOX ASSEMBLY (See «INSTALLATION»(ref-338655-S35278536252009082800000) )
  4. INSTALL CONSOLE BOX CARPET (See «INSTALLATION»(ref-338655-S35278536252009082800000) )
  5. INSTALL UPPER CONSOLE PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-338655-S35278536252009082800000) )
  6. INSTALL FRONT NO. 1 CONSOLE BOX INSERT (See «INSTALLATION»(ref-338655-S11921080812009082800000) )
  7. INSTALL FRONT NO. 2 CONSOLE BOX INSERT (See «INSTALLATION»(ref-338655-S11921080812009082800000) )
  8. INSTALL INSTRUMENT PANEL BOX ASSEMBLY (See «INSTALLATION»(ref-338655-S11921080812009082800000) )
  9. INSTALL CENTER NO. 1 INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (See «INSTALLATION»(ref-338655-S11921080812009082800000) )
  10. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (See «INSTALLATION»(ref-338655-S11921080812009082800000) )
  11. INSTALL LOWER INSTRUMENT PANEL FINISH PANEL LH (See «INSTALLATION»(ref-338655-S35424885952009082800000) )
  12. INSTALL LOWER INSTRUMENT PANEL FINISH PANEL RH (See «INSTALLATION»(ref-338655-S35424885952009082800000) )
  13. INSTALL FRONT NO. 1 FLOOR HEAT INSULATOR Install the No. 1 front floor heat insulator with the 3 nuts. Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf)
  14. INSTALL CENTER EXHAUST PIPE ASSEMBLY (See «INSTALLATION»(ref-338633-S22952115102009082800000) )
  15. INSTALL AIR CLEANER CASE (See «INSTALLATION»(ref-338620-S18185234022009082800000) )
  16. INSTALL AIR CLEANER CAP SUB-ASSEMBLY (See «INSTALLATION»(ref-338624-S08368470652009082800000) )
  17. INSPECT FOR EXHAUST GAS LEAK
  18. INSTALL NO. 1 ENGINE COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-338620-S18185234022009082800000) )

Scheme 314

Scheme 314
Scheme 314

Scheme 315

Scheme 315: REMOVAL
Scheme 315: REMOVAL

Scheme 316

Scheme 316
Scheme 316

Scheme 317

Scheme 317
Scheme 317
  1. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL LH (See «REMOVAL»(ref-338655-S34170282182009082800000) )
  2. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL RH (See «REMOVAL»(ref-338655-S34170282182009082800000) )
  3. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (See «REMOVAL»(ref-338655-S17441726102009082800000) )
  4. REMOVE CENTER NO. 1 INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (See «REMOVAL»(ref-338655-S17441726102009082800000) )
  5. REMOVE INSTRUMENT PANEL BOX ASSEMBLY (See «REMOVAL»(ref-338655-S17441726102009082800000) )
  6. REMOVE FRONT NO. 1 CONSOLE BOX INSERT (See «REMOVAL»(ref-338655-S17441726102009082800000) )
  7. REMOVE FRONT NO. 2 CONSOLE BOX INSERT (See «REMOVAL»(ref-338655-S17441726102009082800000) )
  8. REMOVE UPPER CONSOLE PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-338655-S07872330862009082800000) )
  9. REMOVE CONSOLE BOX CARPET (See «REMOVAL»(ref-338655-S07872330862009082800000) )
  10. REMOVE CONSOLE BOX ASSEMBLY (See «REMOVAL»(ref-338655-S07872330862009082800000) )
  11. DISCONNECT TRANSMISSION CONTROL CABLE ASSEMBLY Separate the 3 clamps, and disconnect the wire harness from the shift lever assembly. Remove the clip, and disconnect the control select cable from the shift lever assembly. Disconnect the control shift cable from the shift lever assembly. Using a screwdriver, pull out the transmission control cable stopper. NOTE: Do not remove the stopper. If it is removed, reinstall it to its original position. Rotate the nut counterclockwise approximately 180° and, while holding the nut in that position, disconnect the transmission control cable from the shift lever retainer. NOTE: Do not rotate the nut excessively as it may damage the internal spring and the transmission control cable will not be reusable.
  12. REMOVE SHIFT LEVER ASSEMBLY Remove the 4 bolts and the shift lever assembly.
