PRECAUTION
Note. Perform the RESET MEMORY (AT initialization) when replacing the automatic transaxle assembly, engine assembly or ECM (See INITIALIZATION ). Perform the REGISTRATION (VIN registration) when replacing the ECM (See REGISTRATION )
HINT
RESET MEMORY can not be completed by only disconnecting the battery cable.
- EXPRESSIONS OF IGNITION SWITCH The type of ignition switch used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this section. EXPRESSIONS OF IGNITION SWITCH REFERENCE CHART Switch Type Ignition Switch (Position) Engine Switch (Condition) Expression Ignition switch off LOCK Off Ignition switch ON ON On (IG) Ignition switch ACC ACC On (ACC) Engine start START Start
- REMOVAL AND INSTALLATION PROCEDURE PRECAUTIONS The automatic transaxle is composed of highly precision-finished parts which need careful inspection before reassembly. Even a small nick could cause fluid leakage or affect the performance. The instructions here are organized so that you work on only one component group at a time. This will help avoid confusion caused by similar-looking parts of different sub-assemblies being on your workbench at the same time. The component groups are inspected and repaired from the converter housing side. Complete the inspection, repair and reassembly before proceeding to the next component group as much as possible. If a defect is found in a certain component group during reassembly, inspect and repair this group immediately. If a component group cannot be assembled because some parts are being ordered, be sure to keep all parts of the group in a separate container while proceeding with disassembly, inspection, repair and reassembly of other component groups. Recommended: Toyota Genuine ATF WS All disassembled parts should be washed clean and any fluid passages and holes should be blown through with compressed air. Dry all parts with compressed air. Never use a piece of cloth to dry them. When using compressed air, always aim away from yourself to prevent accidentally spraying ATF or kerosene in your face. Only recommended automatic transaxle fluid or kerosene should be used for cleaning. After cleaning, the parts should be arranged in the correct order for efficient inspection, repair, and reassembly. New discs for the brakes and clutches that are to be used for replacement must be soaked in ATF for at least 15 minutes before reassembly. All oil seal rings, clutch discs, clutch plates, rotating parts, and sliding surfaces should be coated with ATF prior to reassembly. All gaskets and rubber O-rings should be replaced with new ones. Do not apply adhesive cements to gaskets and similar parts. Make sure that the ends of a snap ring are not aligned with one of the cutouts and are installed in the groove correctly. When replacing a worn bushing, the sub-assembly containing the bushing must also be replaced. Check thrust bearings and races for wear or damage. Replace them as necessary. When working with FIPG material, you must observe the following: Using a razor blade and a gasket scraper, remove all the old packing (FIPG) material from the gasket surface. Thoroughly clean all components to remove any loose material. Clean both sealing surfaces with a non-residue solvent. Parts must be reassembled within 10 minutes of application. Otherwise, the packing (FIPG) material must be removed and reapplied.
DEFINITION OF TERMS
| Term | Definition |
|---|---|
| Monitor description | Description of what the ECM monitors and how it detects malfunctions (monitoring purpose and its details). |
| Related DTCs | Diagnostic code |
| Typical enabling condition | Preconditions that allow the ECM to detect malfunctions. With all preconditions satisfied, the ECM sets the DTC when the monitored value(s) exceeds the malfunction threshold(s). |
| Sequence of operation | The priority order that is applied to monitoring, if multiple sensors and components are used to detect the malfunction. While another sensor is being monitored, the next sensor or component will not be monitored until the previous monitoring has concluded. |
| Required sensor/components | The sensors and components that are used by the ECM to detect malfunctions. |
| Frequency of operation | The number of times that the ECM checks for malfunctions per driving cycle. "Once per driving cycle" means that the ECM detects malfunction only one time during a single driving cycle. "Continuous" means that the ECM detects malfunction every time when enabling condition is met. |
| Duration | The minimum time that the ECM must sense a continuous deviation in the monitored value(s) before setting a DTC. This timing begins after the "typical enabling conditions" are met. |
| Malfunction thresholds | Beyond this value, the ECM will conclude that there is a malfunction and set a DTC. |
| MIL operation | MIL illumination timing after a defect is detected. "Immediately" means that the ECM illuminates MIL the instant the ECM determines that there is a malfunction. "2 driving cycle" means that the ECM illuminates MIL if the same malfunction is detected again in the 2nd driving cycle. |
| Component operating range | Normal operation range of sensors and solenoids under normal driving conditions. Use these ranges as a reference. They cannot be used to judge if a sensor or solenoid is defective or not. |
DEFINITION OF TERMS CHART
Scheme 368
Scheme 369
SYSTEM DIAGRAM
The configuration of the electronic control system in the U341E automatic transaxle is as shown in the following chart.
Scheme 370
MECHANICAL SYSTEM TESTS
- PERFORM MECHANICAL SYSTEM TESTS Measure the stall speed. The object of this test is to check the overall performance of the transaxle and engine by measuring the stall speeds in the D position. NOTE: Driving test should be done on a paved road (a nonskid road). Perform the test at the normal operating ATF (Automatic Transmission Fluid) temperature 50 to 80°C (122 to 176°F). Do not continuously run this test for longer than 5 seconds. To ensure safety, do this test in a wide, clear level area which provides good traction. The stall test should always be carried out in pairs. One technician should observe the conditions of wheels or wheel stoppers outside the vehicle while the other is doing the test. Chock the 4 wheels. Connect the Techstream to the DLC3. Fully apply the parking brake. Keep your left foot pressed firmly on the brake pedal. Start the engine. Shift into the D position. Press all the way down on the accelerator pedal with your right foot. Quickly read the stall speed at this time. Stall speed: 2410 +- 300 rpm Evaluation: PROBLEM REFERENCE CHART Problem Possible cause (a) Stall engine speed is low in D position Engine power output may be insufficient Stator one-way clutch not operating properly HINT: If the value is less than the specified value by 600 rpm or more, the torque converter could be faulty. (b) Stall engine speed is high in D position Line pressure is too low Forward clutch slipping No. 2 one-way clutch not operating properly Improper fluid level Measure the time lag. When the shift lever is shifted while the engine is idling, there will be a certain time lapse or lag before the shock can be felt. This is used for checking the condition of the clutch and brake. NOTE: Perform the test at the normal operating ATF (Automatic Transmission Fluid) temperature: 50 to 80°C (122 to 176°F). Be sure to allow 1 minute interval between tests. Perform the test three times, and measure the time lags. Calculate the average value of the three time lags. Connect the Techstream to the DLC3. Fully apply the parking brake. Start and warm up the engine and check idle speed. Idle speed: approx. 700 rpm (In N position and A/C OFF) Shift the lever from N to D position. Using a stop watch, measure the time from when the lever is shifted until the shock is felt. Time lag: N --> D less than 1.2 seconds In the same way, measure the time lag for N --> R. Time lag: N --> R less than 1.5 seconds Evaluation (If N --> D or N --> R time lag is longer than the specified): PROBLEM REFERENCE CHART Problem Possible cause N --> D time lag is longer Line pressure is too low Forward clutch worn No. 2 one-way clutch is not operating properly N --> R time lag is longer Line pressure is too low Reverse clutch worn 1st and reverse brake worn
Scheme 371
- PERFORM HYDRAULIC TEST Measure the line pressure. NOTE: Perform the test at the normal operating ATF (Automatic Transmission Fluid) temperature: 50 to 80°C (122 to 176°F). The line pressure test should always be carried out in pairs. One technician should observe the conditions of wheels or wheel stoppers outside the vehicle while the other is performing the test. Be careful to prevent SST hose from interfering with the exhaust pipe. This Check must be conducted after checking and adjusting engine. Perform under condition that A/C is OFF. When conducting stall test, do not continue more than 5 seconds. Warm up the ATF. Remove the test plug on the front left side of the transaxle case and connect SST. SST 09992-00095 (09992-00231, 09992-00271) Fully apply the parking brake and chock the 4 wheels. Connect the Techstream to the DLC3. Start the engine and check idling speed. Keep your left foot pressing firmly on the brake pedal and shift into D position. Measure the line pressure when the engine is idling. Depress the accelerator pedal all the way down. Quickly read the highest line pressure when engine speed reaches stall speed. In the same way, do the test in R position. Specified line pressure: LINE PRESSURE SPECIFICATION CHART Condition D position kPa (kgf/cm 2 , psi) R position kPa (kgf/cm 2 , psi) Idling 372 to 412 kPa (3.8 to 4.2 kgf/cm 2 , 54 to 60 psi) 553 to 623 kPa (5.6 to 6.4 kgf/cm 2 , 80 to 100 psi) Stall test 1120 to 1230 kPa (11.4 to 12.5 kgf/cm 2 , 162 to 178 psi) 1660 to 1870 kPa (16.9 to 19.1 kgf/cm 2 , 241 to 271 psi) Evaluation: EVALUATION REFERENCE CHART Problem Possible cause If the measured values at all positions are higher Shift solenoid valve SLT defective Regulator valve detective If the measured values at all positions are lower Shift solenoid valve SLT defective Regulator valve detective Oil pump defective If pressure is low in the D position only D position circuit fluid leak Forward clutch defective If pressure is low in the R position only R position circuit fluid leak Reverse clutch defective 1st and reverse brake defective
INITIALIZATION
- RESET MEMORY NOTE: Perform the RESET MEMORY (AT initialization) when replacing the automatic transaxle assembly, engine assembly or ECM. The RESET MEMORY can be performed only with the Techstream. HINT: The ECM memorizes the condition that the ECT controls the automatic transaxle assembly and engine assembly according to those characteristics. Therefore, when the automatic transaxle assembly, engine assembly, or ECM has been replaced, it is necessary to reset the memory so that the ECM can memorize the new information. Reset procedure is as follows. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON and the Techstream main switch on. Enter the following menus: Powertrain / Engine and ECT / Utility / Reset Memory. Then, press "Next". CAUTION: After performing the RESET MEMORY, be sure to perform the ROAD TEST (See «ROAD TEST»(ref-338645-S03749534042009082800000) ) described earlier. HINT: The ECM is learned by performing the ROAD TEST.
Scheme 372
- MONITOR DRIVE PATTERN FOR ECT TEST Perform this drive pattern as one method to simulate the detection conditions of the ECT malfunctions. (The DTCs may not be detected due the actual driving conditions. And some codes may not be detected through this drive pattern.) HINT: Preparation for driving Warm up the engine sufficiently. (Engine coolant temperature is 60°C (140°F) or higher) Drive the vehicle when the atmospheric temperature is -10°C (14°F) or higher. (Malfunction is not detected when the atmospheric temperature is less than -10°C Driving note Drive the vehicle through all gears. Stop --> 1st --> 2nd --> 3rd --> 4th --> 4th (lock-up ON). Repeat the above driving pattern three times or more. NOTE: When using the Techstream, monitor status can be found in the "Powertrain / Engine and ECT / Data List". In the event that the drive pattern must be interrupted (possibly due to traffic conditions or other factors), the drive pattern can be resumed and, in most cases, the monitor can be completed. Perform this drive pattern on a level road as much as possible and strictly observe the posted speed limits and traffic laws while driving. HINT: *1: Drive at such a speed in the uppermost gear, to engage lock-up. The vehicle can be driven at a speed lower than that in the above diagram under the lock-up condition. NOTE: If necessary to drive the vehicle for approximately 30 minutes to detect DTC P0711 (ATF temperature sensor malfunction).
FAIL-SAFE CHART
- FAIL-SAFE This function minimizes the loss of the ECT functions when any malfunction occurs in each sensor or solenoid. Vehicle speed signal (SPD): When there are problems with vehicle speed signals, 4th upshift is prohibited. Input turbine speed sensor NT (Speed sensor NT): When the input turbine speed sensor has a malfunction, 4th upshift is prohibited. ATF (Automatic Transmission Fluid) temperature sensor: When the ATF temperature sensor has a malfunction, 4th upshift is prohibited. Shift solenoid valve SLU: If the ECM detects a malfunction in the solenoid valve SLU, it turns the valve off. Shift solenoid valve SLT: When the solenoid valve SLT has a malfunction, 4th upshift is prohibited. Engine coolant temperature sensor: When the engine coolant temperature sensor has a malfunction, 4th upshift is prohibited. Knock sensor: When the knock sensor has a malfunction, 4th upshift is prohibited. Throttle position sensor: When the throttle position sensor has a malfunction, 4th upshift is prohibited. Shift solenoid valve S1 and S2: Fail safe function: If either of the shift solenoid valve circuits develops an open or short, the ECM turns the other shift solenoid "ON" and "OFF" in order to shift into the gear positions shown in the table below. The ECM also turns the shift solenoid valve ST OFF at the same time. If both solenoids malfunction, hydraulic control cannot be performed electronically and must be done manually. Manual shifting as shown in the following table must be done (In case of a short circuit, the ECM stops sending current to the short circuit solenoid). Even if starting the engine in the fail-safe mode, the gear position remains in the same position. GEAR POSITION REFERENCE CHART Normal Solenoid Valve S1 ON ON OFF OFF S2 ON OFF OFF ON Gear Position 1st 2nd 3rd 4th (O/D) S1 Malfunction Solenoid Valve S1 X S2 ON --> OFF OFF OFF ON Gear Position *1 3rd 3rd 3rd 4th (O/D) S2 Malfunction Solenoid Valve S1 ON ON OFF OFF S2 X Gear Position *1 2nd 2nd 3rd 3rd S1 and S2 Malfunction Solenoid Valve S1 X S2 X Gear Position *1 3rd 3rd 3rd 3rd *1: Actual gear shift (gear position) under failsafe operation. X: OFF (the ECM stops sending current to a malfunctioning solenoid valve) -->: Condition in the electrical malfunction is shown on the left of "-->". Condition in the fail-safe mode is shown on the right of "-->".
MONITOR STRATEGY
| Related DTCs | P0705: Park/neutral position switch/Verify switch input |
|---|---|
| Required sensors/Components | Park/neutral position switch |
| Frequency of operation | Continuous |
| Duration | Condition (a) and (c): 2 seconds Condition (b): 60 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY REFERENCE CHART
TYPICAL ENABLING CONDITIONS
| The monitor runs whenever the following DTCs are not present. | None |
|---|---|
| Ignition switch | ON |
| Battery voltage | 10.5 V or more |
TYPICAL ENABLING CONDITIONS CHART
TYPICAL MALFUNCTION THRESHOLDS
One of the following conditions is met: Condition (a), (b), (c) or (d)
Condition (a)
| Number of following signals input simultaneously | 2 or more |
|---|---|
| STAR switch | ON |
| R switch | ON |
| D switch | ON |
| 2 switch | ON |
| L switch | ON |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
Condition (b)
| Number of following signals input simultaneously | 2 or more |
|---|---|
| P switch | ON |
| R switch | ON |
| N switch | ON |
| D switch | ON |
| 2 switch | ON |
| L switch | ON |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
Condition (c)
All of the following conditions are met.
| P switch | OFF |
|---|---|
| R switch | OFF |
| N switch | OFF |
| D switch | OFF |
| 2 switch | OFF |
| L switch | OFF |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
Condition (d)
When shift lever is in P, R or N position, either of following conditions is met.
| 3 switch | ON |
|---|---|
| L switch | ON |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
COMPONENT OPERATING RANGE
| Park/neutral position switch | The park/neutral position switch sends only one signal to the ECM. |
COMPONENT OPERATING RANGE CHART
Scheme 373
Scheme 374
Scheme 375
Scheme 376
Scheme 377
Scheme 378
Scheme 379
Scheme 380
Scheme 381
Scheme 382
- CHECK HARNESS AND CONNECTOR (BATTERY - PARK/NEUTRAL POSITION SWITCH) Disconnect the park/neutral position switch connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition B88-2 (RB) - Body ground Ignition switch ON 11 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK HARNESS AND CONNECTOR (OUTPUT SIGNAL) Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition B88-4 (B) - Body ground Ignition switch ON 11 to 14 V Result RESULT CHART Result Proceed to OK A NG B B: Go to step 8 A: Go to next step
- INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Shift Position Specified Condition 4-5 P and N Below 1 ohms Except P and N 10 kohms or higher 2-6 P Below 1 ohms Except P 10 kohms or higher 2-1 R Below 1 ohms Except R 10 kohms or higher 2-9 N Below 1 ohms Except N 10 kohms or higher 2-7 D and 3 Below 1 ohms Except D and 3 10 kohms or higher 2-3 2 Below 1 ohms Except 2 10 kohms or higher 2-8 L Below 1 ohms Except L 10 kohms or higher NG: REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY (See «REMOVAL»(ref-338645-S34810620112009082800000) ) OK: Go to next step
- CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ECM) Connect the park/neutral position switch connector. Disconnect the ECM connectors. Turn the ignition switch to ON, and measure the voltage according to the value(s) in the table below when the shift lever is moved to each position. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Shift Position Specified Condition B31-73 (P) - Body ground P 11 to 14 V Except P Below 1 V B31-54 (N) - Body ground N 11 to 14 V Except N Below 1 V B31-53 (R) - Body ground R 11 to 14 V* Except R Below 1 V B31-56 (D) - Body ground D and 3 11 to 14 V Except D and 3 Below 1 V B31-55 (2) - Body ground 2 11 to 14 V Except 2 Below 1 V B31-74 (L) - Body ground L 11 to 14 V Except L Below 1 V HINT: *: The voltage will drop slightly due to lighting up of the back up light. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - TRANSMISSION CONTROL SWITCH) Disconnect the transmission control switch connector of shift lock control unit assembly. Turn the ignition switch to ON, and measure the voltage according to the value(s) in the table below when the shift lever is moved to each position. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Shift Position Specified Condition 1 - Body ground D and 3 11 to 14 V Except D and 3 Below 1 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT SHIFT LOCK CONTROL UNIT ASSEMBLY (TRANSMISSION CONTROL SWITCH) Measure the resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Shift Position Specified Condition 1-2 3 and 2 Below 1 ohms Except 3 and 2 10 kohms or higher Result RESULT CHART Result Proceed to OK A NG B B: REPLACE SHIFT LOCK CONTROL UNIT ASSEMBLY (See «DISASSEMBLY»(ref-338645-S09291011712009082800000) ) A: Go to next step
- CHECK HARNESS AND CONNECTOR (TRANSMISSION CONTROL SWITCH - ECM) Connect the transmission control switch connector of shift lock control unit assembly. Turn the ignition switch to ON, and measure the voltage according to the value(s) in the table below when the shift lever is moved to each position. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Shift Position Specified Condition A50-26 (3) - Body ground 3 11 to 14 V Except 3 Below 1 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE ECM (for 2ZR-FE) (See «REMOVAL»(ref-338623-S26554443922009082800000) )
- CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ECM) Turn the ignition switch off. Disconnect the ECM connectors. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition B88-4 (B) - B31-52 (STAR) Always Below 1 ohms Standard resistance (Check for short) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition B88-4 (B) or B31-52 (STAR) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE ECM (for 2ZR-FE) (See «REMOVAL»(ref-338623-S26554443922009082800000) )
| Related DTCs | P0710: ATF temperature sensor/Range check (Fluttering) P0712: ATF temperature sensor/Range check (Low resistance) P0713: ATF temperature sensor/Range check (High resistance) |
|---|---|
| Required sensors/Components | ATF temperature sensor (TFT (1) sensor) |
| Frequency of operation | Continuous |
| Duration | 0.45 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
| (1) Transmission Fluid Temperature | |
| (1) | Transmission Fluid Temperature |
MONITOR STRATEGY REFERENCE CHART
P0710: Range check (Fluttering)
| The monitor runs whenever the following DTCs are not present. | None |
|---|---|
| The typical enabling conditions are not available. |
TYPICAL ENABLING CONDITIONS CHART
P0712: Range check (Low resistance)
| The monitor runs whenever the following DTCs are not present. | None |
|---|---|
| The typical enabling conditions are not available. |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
P0713: Range check (High resistance)
| The monitor runs whenever the following DTCs are not present. | None |
|---|---|
| Time after engine start | 15 minutes or more |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
P0710: Range check (Fluttering)
| ATF temperature sensor (TFT sensor) resistance | Less than 79 ohms or More than 156 kohms |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
P0712: Range check (Low resistance)
| ATF temperature sensor (TFT sensor) resistance | Less than 79 ohms |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
P0713: Range check (High resistance)
| ATF temperature sensor (TFT sensor) resistance | More than 156 kohms |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
| ATF temperature sensor (TFT sensor) resistance | Resistance: 79 a to 156 kohms |
COMPONENT OPERATING RANGE CHART
Scheme 383
| Related DTCs | P0711: ATF temperature sensor/Rationality check |
|---|---|
| Required sensors/Components | ATF temperature sensor (TFT (1) sensor) |
| Frequency of operation | Continuous |
| Duration | Condition (A): 3 seconds Condition (B): 10 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| (1) Transmission Fluid Temperature | |
| (1) | Transmission Fluid Temperature |
MONITOR STRATEGY REFERENCE CHART
The following conditions are common to Condition (A) and (B).
| The monitor runs whenever the following DTCs are not present. | None |
|---|---|
| ATF temperature sensor (TFT sensor) circuit | No circuit malfunction |
| ECT (Engine Coolant Temperature) sensor circuit | No circuit malfunction |
| IAT (Intake Air Temperature) sensor circuit | No circuit malfunction |
| Electronic Throttle Control System (if applicable) | No circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
Condition (A)
| Time after engine start | 18 minutes and 20 seconds or more |
|---|---|
| Driving distance after engine start | 5.6 mile (9 km) or more |
| Accumulated driving time | 4 minutes and 10 seconds or more |
| ECT | 15°C (5°F) or more |
| IAT (12 seconds after engine start) | 10°C (14°F) or more |
| ECT (12 seconds after engine start) | 10°C (14°F) or more |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
Condition (B)
| ECT (Current temperature) | 60°C (140°F) or more |
|---|---|
| ECT (12 seconds after engine start) | Less than 35°C (95°F) |
| ATF temperature (12 seconds after engine start) | 100°C (212°F) or more |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
Either of the following conditions is met: Condition (A) or (B)
Condition (A)
| ATF temperature | Less than 20°C (68°F) |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
Condition (B)
| ATF temperature | 100°C (212°F) or more |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
ATF temperature
20°C (68°F) or more and less than 100°C (212°F) under specific condition
| Related DTCs | P0717: Turbine speed sensor/Verify pulse input |
|---|---|
| Required sensors/Components | Transmission revolution sensor (Speed sensor (NT)) |
| Frequency of operation | Continuous |
| Duration | 5 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY REFERENCE CHART
| The monitor runs whenever the following DTCs are not present. | P0500 (VSS) P0748 - P0798 (Trans solenoid (range)) |
|---|---|
| Shift change | After shift change is completed and before starting next shift change operation |
| ECM selected gear | 2nd, 3rd or 4th |
| Output shaft rpm | 1000 rpm or more |
| Park/neutral position switch | OFF |
| R switch | OFF |
| L switch | OFF |
| Transmission range switch fail | Not detected |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
| Engine | Running |
TYPICAL ENABLING CONDITIONS CHART
| Sensor signal rpm | Less than 300 rpm |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
| Transmission revolution sensor (speed sensor (NT)) | Input turbine speed is equal to engine speed when lock-up ON |
COMPONENT OPERATING RANGE CHART
Scheme 384
Scheme 385
Scheme 386
Scheme 387
- INSPECT SPEED SENSOR INSTALLATION Check the speed sensor installation. OK: The installation bolt is tightened properly and there is no clearance between the sensor and transaxle case. NG: REPLACE SPEED SENSOR (NT) (See «REMOVAL»(ref-338645-S17046826612009082800000) ) OK: Go to next step
- INSPECT SPEED SENSOR (NT) Disconnect the speed sensor connector from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 1-2 20°C (68°F) 560 to 680 ohms NG: REPLACE SPEED SENSOR (NT) (See «REMOVAL»(ref-338645-S17046826612009082800000) ) OK: Go to next step
- CHECK HARNESS AND CONNECTOR (SPEED SENSOR - ECM) Connect the speed sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition B31-125 (NT+) - B31-124 (NT-) 20°C (68°F) 560 to 680 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition B31-125 (NT+) - Body ground Always 10 kohms or higher B31-124 (NT-) - Body ground Always ↑ NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE ECM (for 2ZR-FE) (See «REMOVAL»(ref-338623-S26554443922009082800000) )
| Related DTCs | P0724: Stop light switch/Verify switch input |
|---|---|
| Required sensors/Components | Stop light switch, Vehicle speed sensor |
| Frequency of operation | Continuous |
| Duration | GO and STOP 5 times |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY REFERENCE CHART
| The monitor will run whenever this DTC is not present. | None |
|---|---|
| Ignition switch | ON |
| Starter | OFF |
| Battery voltage | 8 V or more |
| GO (Vehicle speed is 30 km/h (18.63 mph) or more) | Once |
| STOP (Vehicle speed is less than 3 km/h (1.86 mph)) | Once |
TYPICAL ENABLING CONDITIONS CHART
| Brake switch | Remain ON during GO and STOP 5 times |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
Scheme 388
Scheme 389
Scheme 390
- READ VALUE USING DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn on the Techstream. Select the item "Powertrain / Engine and ECT / Data List". According to the display on the Techstream, read the "Data List". Standard: TESTER DISPLAY CHART Tester Display Measurement Item/Range Normal Condition Diagnostic Note Stop Light Switch Stop light switch Status/ON or OFF Brake Pedal is depressed: ON Brake Pedal is released: OFF - NOTE: In the table above, the value listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Result RESULT CHART Result Proceed to NG A OK B B: Go to step 3 A: Go to next step
- INSPECT STOP LIGHT SWITCH ASSEMBLY Remove the stop light switch assembly. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Position Specified Condition 1-2 Switch pin free Below 1 ohms ↑ Switch pin pushed in 10 kohms or higher 3-4 Switch pin free 10 kohms or higher ↑ Switch pin pushed in Below 1 ohms NG: REPLACE STOP LIGHT SWITCH ASSEMBLY (See «STOP LIGHT SWITCH»(ref-338636-S21749753632009082800000) ) OK: Go to next step
- CHECK HARNESS AND CONNECTOR (STOP LIGHT SWITCH ASSEMBLY - ECM) Install the stop light switch assembly. Disconnect the ECM connector. Measure the voltage according to the value(s) in the table below when the brake pedal is depressed and released. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition A50-36 (STP) - Body ground Brake pedal Is depressed 11 to 14 V Brake pedal is released Below 1 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE ECM (for 2ZR-FE) (See «REMOVAL»(ref-338623-S26554443922009082800000) )
| Related DTCs | P0751: Shift solenoid valve S1/OFF malfunction Shift solenoid valve S1/ON malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve S1, Speed sensor (NT), Speed sensor (SPD), Engine coolant temperature sensor (ECT) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction (a): 0.85 seconds OFF malfunction (b): 0.8 seconds ON malfunction (a): 0.8 seconds ON malfunction (b): 0.8 seconds |
| MIL operation | 2 driving cycle |
| Sequence of operation | None |
MONITOR STRATEGY REFERENCE CHART
The following conditions are common to all OFF malfunctions and ON malfunctions.
| The monitor runs whenever the following DTCs are not present. | P0115 - P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0500 (VSS) P0748 - P0798 (Trans solenoid (range)) |
|---|---|
| ECT (Engine Coolant Temperature) | 60°C (140°F) or more |
| Time after shifting N to D | 4.5 seconds or more |
| Transmission shift position | D |
| Shift solenoid valve S1 circuit | No circuit malfunction |
| Shift solenoid valve S2 circuit | No circuit malfunction |
| ECT sensor circuit | No circuit malfunction |
| Electronic Throttle Control System (if applicable) | No circuit malfunction |
| Speed sensor (NT) circuit | No circuit malfunction |
| Speed sensor (SPD) circuit | No circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction (a)
| ECM gearshift command | 1st |
|---|---|
| Vehicle speed | 5.6 mph (9 km/h) or more and Less than 24.9 mph (40 km/h) |
| Throttle valve opening angle | 7.0 % or more and 4.0 % or more at engine speed of 1900 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
OFF malfunction (b)
| ECM gearshift command | 4th |
|---|---|
| Last ECM selected gear | 3rd |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
ON malfunction (a)
| ECM gearshift command | 4th |
|---|---|
| Last ECM selected gear | 3rd |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
ON malfunction (b)
| ECM gearshift command | 4th |
|---|---|
| V current - V last V current: Vehicle speed at current ECM selected gear V last: Vehicle speed at last ECM selected gear | Less than 9.3 mph (15 km/h) |
| TH current - TH last TH current: Throttle valve opening angle at current ECM selected gear TH last: Throttle valve opening angle at last ECM selected gear | Less than 20 % |
| Vehicle speed (current) | Less than 52.8 mph (85 km/h) |
| Throttle valve opening angle (current) | Less than 35 % |
| Engine speed (current) | 3200 rpm or more |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
[OFF malfunction]
Both of the following conditions met: OFF malfunctions (a) and (b)
2 detections are necessary per driving cycle.
1st detection: Temporary flag ON
2nd detection: Pending fault code ON
OFF malfunction (a)
| Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed | 0.64 or more and less than 0.78 (Current) (This means actual gear is 4th) |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
OFF malfunction (b)
| Input speed/Output speed (NT/NO) | Changes as follows 0.95 or more and less than 1.09 (Last) (This means actual gear is 3rd) to 0.64 or more and less than 0.78 (Current) (This means actual gear is 4th) |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
[ON malfunction]
Both of the following conditions met: ON malfunctions (a) and (b)
ON malfunction (a)
| Input speed/Output speed (NT/NO) | No change as follows 0.95 or more and less than 1.09 (Last) (This means actual gear is 3rd) to 0.64 or more and less than 0.78 (Current) (This means actual gear is 4th) |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
ON malfunction (b)
| NE change HINT: NE current - NE last NE current: Engine speed at current ECM selected gear NE last: Engine speed at last ECM selected gear | 1100 rpm or more |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
| Related DTCs | P0756: Shift solenoid valve S2/OFF malfunction Shift solenoid valve S2/ON malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve S2, Speed sensor (NT), Speed sensor (SPD), Engine coolant temperature sensor (ECT) |
| Frequency of operation | Continuous |
| Duration | 0.85 seconds |
| MIL operation | 2 driving cycle |
| Sequence of operation | None |
MONITOR STRATEGY REFERENCE CHART
The following conditions are common to all OFF malfunctions and ON malfunctions.
| The monitor runs whenever the following DTCs are not present. | P0115 - P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0500 (VSS) P0748 - P0798 (Trans solenoid (range)) |
|---|---|
| ECT (Engine Coolant Temperature) | 60°C (140°F) or more |
| Transmission shift position | D |
| Time after shifting N to D | 4.5 seconds or more |
| Shift solenoid valve S1 circuit | No circuit malfunction |
| Shift solenoid valve S2 circuit | No circuit malfunction |
| ECT sensor circuit | No circuit malfunction |
| Electronic Throttle Control System (if applicable) | No circuit malfunction |
| Speed sensor (NT) circuit | No circuit malfunction |
| Speed sensor (SPD) circuit | No circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction (a)
| ECM gearshift command | 1st |
|---|---|
| Vehicle speed | 5.6 mph (9 km/h) or more and less than 24.9 mph (40 km/h) |
| Throttle valve opening angle | 4.0 % or more at engine speed of 1900 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
OFF malfunction (b)
| ECM gearshift command | 3rd |
|---|---|
| Vehicle speed | 5.6 mph (9 km/h) or more |
| Throttle valve opening angle | 4.0 % or more at engine speed of 1900 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
OFF malfunction (c)
| ECM gearshift command | 4th |
|---|---|
| Vehicle speed | 5.6 mph (9 km/h) or more |
| Throttle valve opening angle | 4.0 % or more at engine speed of 1900 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
ON malfunction (a)
| ECM gearshift command | 2nd |
|---|---|
| Vehicle speed | 5.6 mph (9 km/h) or more |
| Throttle valve opening angle | 4.0 % or more at engine speed of 1900 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
ON malfunction (b)
| ECM gearshift command | 3rd |
|---|---|
| Vehicle speed | 5.6 mph (9 km/h) or more |
| Throttle valve opening angle | 4.0 % or more at engine speed of 1900 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
ON malfunction (c)
| ECM gearshift command | 4th |
|---|---|
| Vehicle speed | 5.6 mph (9 km/h) or more |
| Throttle valve opening angle | 4.0 % or more at engine speed of 1900 rpm (Conditions vary with engine speed) |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
[OFF malfunction]
All of the following conditions met: OFF malfunctions (a), (b) and (c)
2 detections are necessary per driving cycle.
1st detection: Temporary flag ON
2nd detection: Pending fault code ON
OFF malfunction (a)
| Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed | 1.50 or more and less than 1.80 (This means actual gear is 2nd) |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
OFF malfunction (b)
| Input speed/Output speed (NT/NO) | 0.95 or more and less than 1.09 (This means actual gear is 3rd) |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
OFF malfunction (c)
| Input speed/Output speed (NT/NO) | 0.95 or more and less than 1.09 (This means actual gear is 3rd) |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
[ON malfunction]
All of the following conditions met: ON malfunctions (a), (b) and (c)
ON malfunction (a)
| Input speed/Output speed (NT/NO) | 2.75 or more and less than 3.51 (This means actual gear Is 1st) |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
ON malfunction (b)
| Input speed/Output speed (NT/NO) | 0.64 or more and less than 0.78 (This means actual gear is 4th) |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
ON malfunction (c)
| Input speed/Output speed (NT/NO) | 0.64 or more and less than 0.78 (This means actual gear is 4th) |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
| Related DTCs | P0787: Shift timing solenoid/Range check (Low resistance) P0788: Shift timing solenoid/Range check (High resistance) |
|---|---|
| Required sensors/Components | Shift solenoid valve ST |
| Frequency of operation | Continuous |
| Duration | 0.128 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY REFERENCE CHART
P0787: Range check (Low resistance)
| The monitor runs whenever the following DTCs are not present | None |
|---|---|
| Solenoid | ON |
| Time after solenoid OFF to ON | More than 0.008 seconds |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
P0788: Range check (High resistance)
| The monitor runs whenever the following DTCs are not present | None |
|---|---|
| Solenoid | OFF |
| Time after solenoid ON to OFF | More than 0.008 seconds |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
P0787: Range check (Low resistance)
| Shift solenoid valve ST resistance | 8 ohms or less |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
P0788: Range check (High resistance)
| Shift solenoid valve ST resistance | 100 kohms or more |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
| Shift solenoid valve ST resistance | 11 to 15 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE CHART
Scheme 391
Scheme 392
Scheme 393
Scheme 394
- INSPECT TRANSMISSION WIRE (ST) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 2 - Body ground 20°C (68°F) 11 to 15 ohms NG: Go to step 3 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transaxle. Disconnect the ECM connectors. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition B31-80 (ST) - Body ground 20°C (68°F) 11 to 15 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE ECM (for 2ZR-FE) (See «REMOVAL»(ref-338623-S26554443922009082800000) )
- INSPECT SHIFT SOLENOID VALVE ST Remove the shift solenoid valve ST. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition Solenoid Connector (ST) - Solenoid Body (ST) 20°C (68°F) 11 to 15 ohms Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK: The solenoid makes an operating sound. NG: REPLACE SHIFT SOLENOID VALVE ST (See «DISASSEMBLY»(ref-338645-S24919483762009082800000) ) OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «REMOVAL»(ref-338645-S11842696532009082800000) )
| Related DTCs | P0973: Shift solenoid valve S1/Range check (Low resistance) P0974: Shift solenoid valve S1/Range check (High resistance) |
|---|---|
| Required sensors/Components | Shift solenoid valve S1 |
| Frequency of operation | Continuous |
| Duration | 0.128 seconds or more |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY REFERENCE CHART
P0973: Range check (Low resistance)
| The monitor runs whenever the following DTCs are not present. | None |
|---|---|
| Solenoid | ON |
| Time after solenoid OFF to ON | More than 0.008 seconds |
TYPICAL ENABLING CONDITIONS CHART
P0974: Range check (High resistance)
| The monitor runs whenever the following DTCs are not present. | None |
|---|---|
| Solenoid | OFF |
| Time after solenoid ON to OFF | More than 0.008 seconds |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
P0973: Range check (Low resistance)
| Shift solenoid valve S1 resistance | 8 ohms or less |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
P0974: Range check (High resistance)
| Shift solenoid valve S1 resistance | 100 kohms or more |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
| Shift solenoid valve S1 resistance | 11 to 15 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE CHART
Scheme 395
Scheme 396
Scheme 397
- INSPECT TRANSMISSION WIRE (S1) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 5 - Body ground 20°C (68°F) 11 to 15 ohms NG: Go to step 3 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transaxle. Disconnect the ECM connectors. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition B31-79 (S1) - Body ground 20°C (68°F) 11 to 15 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE ECM (for 2ZR-FE) (See «REMOVAL»(ref-338623-S26554443922009082800000) )
- INSPECT SHIFT SOLENOID VALVE S1 Remove the shift solenoid valve S1. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition Solenoid Connector (S1) - Solenoid Body (S1) 20°C (68°F) 11 to 15 ohms Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK: The solenoid makes an operating sound. NG: REPLACE SHIFT SOLENOID VALVE S1 (See «DISASSEMBLY»(ref-338645-S24919483762009082800000) ) OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «REMOVAL»(ref-338645-S11842696532009082800000) )
| Related DTCs | P0976: Shift solenoid valve S2/Range check (Low resistance) P0977: Shift solenoid valve S2/Range check (High resistance) |
|---|---|
| Required sensors/Components | Shift solenoid valve S2 |
| Frequency of operation | Continuous |
| Duration | 0.128 seconds or more |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY REFERENCE CHART
P0976: Range check (Low resistance)
| The monitor runs whenever the following DTCs are not present. | None |
|---|---|
| Solenoid | ON |
| Time after solenoid OFF to ON | More than 0.008 seconds |
TYPICAL ENABLING CONDITIONS CHART
P0977: Range check (High resistance)
| The monitor runs whenever the following DTCs are not present. | None |
|---|---|
| Solenoid | OFF |
| Time after solenoid ON to OFF | More than 0.008 seconds |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
P0976: Range check (Low resistance)
| Shift solenoid valve S2 resistance | 8 ohms or less |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
P0977: Range check (High resistance)
| Shift solenoid valve S2 resistance | 100 kohms or more |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
| Shift solenoid valve S2 resistance | 11 to 15 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE CHART
Scheme 398
Scheme 399
Scheme 400
- INSPECT TRANSMISSION WIRE (S2) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 10 - Body ground 20°C (68°F) 11 to 15 ohms NG: Go to step 3 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transaxle. Disconnect the ECM connectors. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition B31-78 (S2) - Body ground 20°C (68°F) 11 to 15 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE ECM (for 2ZR-FE) (See «REMOVAL»(ref-338623-S26554443922009082800000) )
- INSPECT SHIFT SOLENOID VALVE S2 Remove the shift solenoid valve S2. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition Solenoid Connector (S2) - Solenoid Body (S2) 20°C (68°F) 11 to 15 ohms Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK: The solenoid makes an operating sound. NG: REPLACE SHIFT SOLENOID VALVE S2 (See «DISASSEMBLY»(ref-338645-S24919483762009082800000) ) OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «REMOVAL»(ref-338645-S11842696532009082800000) )
| Related DTCs | P2714: Shift solenoid valve SLT/ON malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve SLT, Speed sensor (NT), Speed sensor (SPD) |
| Frequency of operation | Continuous |
| Duration | 1.0 second |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY REFERENCE CHART
The following conditions are common to ON malfunctions (a), (b), (c) and (d).
| The monitor runs whenever the following DTCs are not present. | None |
|---|---|
| Transmission shift position | D |
| Time after shifting N to D | 4.5 seconds or more |
| ATF (Automatic Transmission Fluid) temperature | 10°C (14°F) or more |
| ATF temperature sensor (TFT sensor) circuit | No circuit malfunction |
| Electronic Throttle Control System (if applicable) | No circuit malfunction |
| Shift solenoid valve S1 circuit | No circuit malfunction |
| Shift solenoid valve S2 circuit | No circuit malfunction |
| Shift solenoid valve SLU circuit | No circuit malfunction |
| Shift solenoid valve SLT circuit | No circuit malfunction |
| Speed sensor (NT) circuit | No circuit malfunction |
| Speed sensor (SPD) circuit | No circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
ON malfunction (a)
| ECM gearshift command | 1st |
|---|---|
| Input (turbine) speed | 200 rpm or more |
| Output speed | 300 rpm or more |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
ON malfunction (b)
| ECM gearshift command | 2nd |
|---|---|
| Input (turbine) speed | 200 rpm or more |
| Output speed | 300 rpm or more |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
ON malfunction (c)
| ECM gearshift command | 3rd |
|---|---|
| Input (turbine) speed | 200 rpm or more |
| Output speed | 300 rpm or more |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
ON malfunction (d)
| ECM gearshift command | 4th |
|---|---|
| Input (turbine) speed | 200 rpm or more |
| Output speed | 300 rpm or more |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
[ON malfunction]
Detection condition: Total accumulated time of ON malfunctions (a), (b), (c) and (d) is 1 second or more
ON malfunction (a)
| NT-NOx 1st gear ratio NT: Input (turbine) speed NO: Internal counter shaft speed | More than 300 rpm at output speed of 1000 rpm (Conditions vary with output speed) |
|---|---|
| Duration | 0.85 seconds or more |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
ON malfunction (b)
| NT - NO x 2nd gear ratio | More than 300 rpm at output speed of 1000 rpm (Conditions vary with output speed) |
|---|---|
| Duration | 0.85 seconds or more |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
ON malfunction (c)
| NT - NO x 3rd gear ratio | More than 300 rpm at output speed of 1000 rpm (Conditions vary with output speed) |
|---|---|
| Duration | 0.85 seconds or more |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
ON malfunction (d)
| NT - NO x 4th gear ratio | More than 300 rpm at output speed of 1000 rpm (Conditions vary with output speed) |
|---|---|
| Duration | 0.85 seconds or more |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
Scheme 401
- CHECK OTHER DTCS OUT PUT (IN ADDITION TO DTC P2714) Connect the Techstream to the DLC3. Turn the ignition switch to ON and the Techstream main switch on. When you use Techstream: Select the item "Powertrain / Engine and ECT / Trouble Codes". Read the DTCs using the Techstream. Result RESULT CHART Result Proceed to P2714 A P2714 and other DTCs B HINT: If any other codes besides "P2714" are output, perform the troubleshooting for those DTCs first. B: Go to DTC CHART (See «DIAGNOSTIC TROUBLE CODE CHART»(ref-338645-S41617275752009082800000) ) A: Go to next step
- INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 1-2 20°C (68°F) 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK: The solenoid makes an operating sound. NG: REPLACE SHIFT SOLENOID VALVE SLT (See «DISASSEMBLY»(ref-338645-S24919483762009082800000) ) OK: Go to next step
- INSPECT TRANSMISSION VALVE BODY ASSEMBLY OK: There are no foreign objects on each valve. NG: REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY (See «REMOVAL»(ref-338645-S22512183192009082800000) ) OK: Go to next step
- INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY OK: The torque converter clutch operates normally. NG: REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY (See «REMOVAL»(ref-338645-S22712104222009082800000) ) OK: REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY (See «REMOVAL»(ref-338645-S22712104222009082800000) )
| Related DTCs | P2716: Shift solenoid valve SLT/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SLT |
| Frequency of operation | Continuous |
| Duration | 1.0 second |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY REFERENCE CHART
| The monitor runs whenever the following DTCs are not present | None |
|---|---|
| Solenoid current cut status | Not cut |
| Battery voltage | 11 V or more |
| CPU commanded duty ratio | 19% or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
| Solenoid status (SLT) from MIC | Fail |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
| Shift solenoid valve SLT | Resistance: 5.0 ohms to 5.6 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE CHART
Scheme 402
Scheme 403
Scheme 404
- INSPECT TRANSMISSION WIRE (SLT) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 3 (SLT+) - 8 (SLT-) 20°C (68°F) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 3 (SLT+) - Body ground Always 10 kohms or higher 8 (SLT-) - Body ground Always ↑ NG: Go to step 3 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transaxle. Disconnect the ECM connectors. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition B31-40 (SLT+) - B31-39 (SLT-) 20°C (68°F) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition B31-40 (SLT+) - Body ground Always 10 kohms or higher B31-39 (SLT-) - Body ground Always ↑ NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE ECM (for 2ZR-FE) (See «REMOVAL»(ref-338623-S26554443922009082800000) )
- INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 1-2 20°C (68°F) 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK: The solenoid makes an operating sound. NG: REPLACE SHIFT SOLENOID VALVE SLT (See «DISASSEMBLY»(ref-338645-S24919483762009082800000) ) OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «REMOVAL»(ref-338645-S11842696532009082800000) )
Scheme 405
The ECM uses the signals from the throttle position sensor, turbine (input) speed sensor, vehicle speed sensor and crankshaft position sensor to monitor the engagement condition of the lock-up clutch. Then the ECM compares the engagement condition of the lock-up clutch with the lock-up schedule in the ECM memory to detect mechanical problems of shift solenoid valve SLU, valve body and torque converter clutch.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| P2757 | Lock-up does not occur when driving in lock-up range or lock-up remains ON in lock-up OFF range. (2-trip detection logic) | Shift solenoid valve SLU remains open or closed Valve body is blocked Shift solenoid valve SLU Torque converter clutch Automatic transaxle (clutch, brake or gear etc.) Line pressure is too low |
DTC DETECTION CONDITION CHART
| Related DTCs | P2757: Shift solenoid valve SLU/OFF malfunction Shift solenoid valve SLU/ON malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve SLU, Speed sensor (NT), Crankshaft position sensor (NE), Engine coolant temperature sensor (ECT) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction: 3.5 seconds ON malfunction: 1.8 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY REFERENCE CHART
The following conditions are common to OFF malfunction and ON malfunction.
| The monitor runs whenever the following DTCs are not present. | None |
|---|---|
| Time after shifting N to D | 4.5 seconds or more |
| ECT (Engine Coolant Temperature) | 60°C (140°F) or more |
| Transmission shift position | D |
| ECM selected gear | 3rd or 4th |
| Vehicle speed | 15.5 mph (25 km/h) or more |
| Shift solenoid valve S1 circuit | No circuit malfunction |
| Shift solenoid valve S2 circuit | No circuit malfunction |
| Shift solenoid valve SLU circuit | No circuit malfunction |
| ECT sensor circuit | No circuit malfunction |
| Electronic Throttle Control System (if applicable) | No circuit malfunction |
| Speed sensor (NT) circuit | No circuit malfunction |
| Speed sensor (SPD) circuit | No circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction
| ECM lock-up command | ON |
|---|---|
| Duration time from lock-up on command | 3 seconds or more |
| Actual gear | 3rd or 4th |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
ON malfunction
| ECM lock-up command | OFF |
|---|---|
| Throttle valve opening angle | 8 % or more |
| Vehicle speed | Less than 37.3 mph (60 km/h) |
| Actual gear | 3rd |
| Calculated load value | 22 % or more |
TYPICAL ENABLING CONDITIONS REFERENCE CHART
OFF malfunction
| Engine speed - Input (turbine) speed (NE - NT) | 100 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
[ON malfunction]
2 detections are necessary per driving cycle.
1st detection: Temporary flag ON
2nd detection: Pending fault code ON
Vehicle speed must be under 6.2 mph (10 km/h) once before 2nd detection.
ON malfunction
| Difference between engine speed and Input (turbine) speed | Less than 35 rpm |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
| Related DTCs | P2759: Shift solenoid valve SLU/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SLU |
| Frequency of operation | Continuous |
| Duration | 1.0 second |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY REFERENCE CHART
| The monitor runs whenever the following DTCs are not present. | None |
|---|---|
| Solenoid current cut status | Not cut |
| Battery voltage | 11 V or more |
| CPU commanded duty ratio | 19 % or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
| Solenoid status (SLU) from MIC | Fail |
TYPICAL MALFUNCTION THRESHOLDS REFERENCE CHART
| Solenoid status (SLU) | Resistance: 5.0 to 5.6 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE CHART
Scheme 406
Scheme 407
Scheme 408
Scheme 409
- INSPECT TRANSMISSION WIRE (SLU) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 4 (SLU+) - 9 (SLU-) 20°C (68°F) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 4 (SLU+) - Body ground Always 10 kohms or higher 9 (SLU-) - Body ground Always ↑ NG: Go to step 3 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transaxle. Disconnect the ECM connectors. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition B31-57 (SLU+) - B31-77 (SLU-) 20°C (68°F) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition B31-57 (SLU+) - Body ground Always 10 kohms or higher B31-77 (SLU-) - Body ground Always ↑ NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE ECM (for 2ZR-FE) (See «REMOVAL»(ref-338623-S26554443922009082800000) )
- INSPECT SHIFT SOLENOID VALVE SLU Remove the shift solenoid valve SLU. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 1-2 20°C (68°F) 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK: The solenoid makes an operating sound. NG: REPLACE SHIFT SOLENOID VALVE SLU (See «DISASSEMBLY»(ref-338645-S24919483762009082800000) ) OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «REMOVAL»(ref-338645-S11842696532009082800000) )
Scheme 410
- CHECK FLUID LEVEL HINT: Drive the vehicle so that the engine and transaxle are at normal operating temperature. Fluid temperature: 70 to 80°C (158 to 176°F) Park the vehicle on a level surface and set the parking brake. With the engine idling and the brake pedal depressed, move the shift lever to all positions from P to L. Then return it to P. Pull out the dipstick and wipe it clean. Push the dipstick back fully into the pipe. Pull the dipstick out again and check that the fluid level is within the HOT range. If the fluid level is below the HOT range, add new fluid and recheck the fluid level. If the fluid level exceeds the HOT range, drain the fluid once, add a proper amount of new fluid and recheck the fluid level.
Scheme 411
Scheme 412
Scheme 413
- REMOVE NO. 2 CYLINDER HEAD COVER (See «REMOVAL»(ref-338644-S00228041112009082800000) )
- REMOVE AIR CLEANER CAP SUB-ASSEMBLY (See «REMOVAL»(ref-338623-S32436676142009082800000) )
- REMOVE AIR CLEANER CASE (See «REMOVAL»(ref-338644-S00228041112009082800000) )
- REMOVE SPEED SENSOR Disconnect the speed sensor connector. Remove the bolt and speed sensor. Remove the O-ring from the speed sensor.
Scheme 414
- INSPECT SPEED SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition 1-2 20°C (68°F) 560 to 680 ohms If the resistance value is not as specified, replace the speed sensor.
