Steering Column - Standard: Overhaul Toyota Corolla VIII рестайлинг

Disassembly (Except 4Runner)

1. Drill out tapered head bolts and use screw extractor to remove upper bracket bolts. Remove upper bracket from column tube. Remove upper snap ring. Remove steering column mainshaft from column tube. (Scheme 1)-10.
2. Remove lower snap ring. Remove collar from mainshaft (if equipped). Use a screwdriver to remove bushing. Place ignition key lock in ACC position. Push down on stop pin and pull out key cylinder.

Reassembly (Except 4Runner)

To reassemble, reverse disassembly procedure. Apply molybdenum disulfide base grease to thrust stopper and upper bushing. Align bushing tabs with holes of column tube. Install upper bracket with tapered head bolts. Tighten bolts until hexagonal heads break off.

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Disassembly (4Runner)

1. Disconnect intermediate shaft from steering column mainshaft. Remove bolts and dust seal. Remove steering column hole cover. Remove steering column protector. Ensure ignition key is NOT in LOCK position. Remove snap rings and pull out steering column mainshaft from column tube. (Scheme 8)
2. Drill out tapered head bolts and use screw extractor to remove column bracket bolts. Remove upper bracket from column tube. Use screwdriver to release upper bushing tab and remove column tube. Use screwdriver to remove bushing. Place ignition key lock in ACC position. Push down on stop pin and pull out key cylinder.

Scheme 8

Reassembly (4Runner)

To reassemble, reverse disassembly procedure. Align bushing tabs with holes of column tube. Install upper bracket with tapered head bolts. Tighten bolts until hexagonal heads break off.
